LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 1

Let‘s talk about …

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 2

What is LITECOM?

LITECOM is designed to serve the lower market segment sold and commissioned also by the electrician LITECOM is a “cut-off” of LITECOM infinity with same hardware but slightly modified software. Successor of the current systems EMOTION, LITENET, PROFESSIONAL, ZBOX The new approach to Lighting management…

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 3

What is LITECOM?

LITECOM is a Lighting Management System for one or multiple rooms or an entire floor. With LITECOM you can control luminaires and blinds in terms of

• switching & dimming
• adjust color (RGB), color-temperature (TW) and balance of

luminaires

• operate motors to operate e.g. blinds (position & angle),

screens, windows, …

• call and define scenes
• via time-schedule
• via presence-management
• self-contained emergency luminaires
• … etc.

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 4

And beyond!

LITECOM will provide open interfaces in order to:

• to enable third party developers to perform applications running on the controller
• support third party application to interact with the system
• enables new opportunities of system-to-system & system-to-field communication

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 5

How does LITECOM?

The Touch-Panel(s)! The Portal to LITECOM Build-ins or mobiles are supported The User Interface! The Face of LITECOM For intuitive & reliable operation proven The Controller! The Heart of LITECOM Contains all functionallity

LITECOM CCD

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 6

What is really new?

The APP-concept! The Core of LITECOM Provides flexibility & scalability

• User Centered
• Application Focused
• Open
• Complete Lighting Solution
• Generate Higher Value

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 7

What is really new?

The Wizard-Guided-Tour! The Helper of LITECOM Supports where needed Step by Step from the scratch to a running System!

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 8

Topology

Data:

• 3 DALI Lines (supplied – 120 loads)
• 1 LM Line (not supplied)
• Nearly all LM-Modules compatible
• All mobile devices compatibel
• Up to 250 actuators

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 9

LITECOM USPs

APPs as sellable assets (e.g. Daylight control or a luminaire specific WOW App) Price flexibility for offers and new sales

• pportunities

Opens us the possibility of sales over the electrician due a HMI designed and tested easy and fast setup also without particular knowledge of the system Differentiate in lighting solutions with all Zumtobel lighting philosophies and Know-How integrated to offer a holistic approach Easily possible as LITECOM is just a “cut off” of infinity

Functional flexibility with APP concept Guided commissioning for non-experts Colour/Tunable White/Shows – All in one Seamlessly expandable to LITECOM infinity

Expanding LITECOM to a building-wide system Electrician can commission by themselves and tender our product without the need of special training

USPs + Functions

Other Functions Integrated Emergency control (single battery) Integrated blind control Usage of mobile devices (Smartphone/Tablet) for operation and commissioning Open interfaces for third party developers

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 10

Comparison to EMOTION

• Touchpanel=Controller

up to 128 Luminaires controllable TFT – Touchscreen No interface to other systems not upgradeable

LUXMATE EMOTION

• Tochpanel and Controller separated

Up to 250 actuators controllable (incl. Blinds) APP concept – Variable Functions Part of LITECOM infinity Control with every mobile devices

• Variable tierings possible

LITECOM

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 11

Touch panel Further Apps (Shows) Services Release finalizing LPP integration 1

LITECOM (LW1) LITECOM

Controller Basic Software App concept SEQUENCE App Apps (Presence, Time, Daylight, Wizard) Further Apps (Sky Scanner, mobile interface, Daylight Wizard, Help function, Interface design) Finish object model for building wide systems… eBox Integration Emergency Cloud (Scalability) BacNet & OPC Interface KNX Interface Open Development Interface for Apps First Editor version LPP integration 2

LITECOM (LW2) LITECOM INF. (LW1)

LITECOM Development Roadmap

Final Editor version LITECOM Graphics Interface to Lighting design programs Radio Interface Camera Sensor Integration Consider thermal impact Further Apps (Interface design, luminaire & application spec. Apps, ) CPS integration

LITECOM INF. (LW2)

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 12

LITECOM 4 things to take Away!

LITECOM – expandable in size and functionality ranging from 250 actuators (LITECOM) up to 100.000 actuators (LITECOM infinity) The APP-concept – provides flexibility and power for the customer in a new dimension regarding lighting management (SEQUENCE, Emergency, Daylight…) The Wizard – even with little knowledge, this will lead you to your target setting up the system Mobile interaction – ALL mobile devices are control panels for LITECOM without extra costs

Powered by

LITECOM L&B-Fair Training, Rene Joppi & Dieter Meyer, March 2014 13

THANK YOU.
