Lecture 2: Architectural Performance Laws and Rules of Thumb

• Prof. V. Catania
• Lab. Calcolatori

Measurement Tools

• Benchmarks, Traces, Mixes
• Cost, delay, area, power estimation
• Simulation (many levels)

– ISA, RT, Gate, Circuit

• Queuing Theory
• Rules of Thumb
• Fundamental Laws

The Bottom Line: Performance (and Cost)

"X is n times faster than Y" means ExTime(Y) Performance(X)

• -------- =
• ExTime(X) Performance(Y)
• Speed of Concorde vs. Boeing 747
• Throughput of Boeing 747 vs. Concorde

Performance Terminology

“X is n% faster than Y” means:

ExTime(Y) Performance(X) n

• -------- =
• = 1 +
• ExTime(X) Performance(Y)

100

n = 100(Performance(X) - Performance(Y))

Performance(Y) Example: Y takes 15 seconds to complete a task, X takes 10 seconds. What % faster is X?

Example

15 10 = 1.5 1.0 = Performance (X) Performance (Y) ExTime(Y) ExTime(X) = n = 100 (1.5 - 1.0) 1.0 n = 50%

Legge di Amdahl

MAKE THE COMMON CASE FAST!

Il performance improvement che può essere guadagnato rendendo una qualche attività più veloce è limitato dalla frazione di tempo in cui tale attività ha luogo. SPEEDUP: misura di quanto più veloce un task gira sulla macchina ENHANCED

Amdahl's Law

Speedup due to enhancement E:

ExTime w/o E Performance w/ E Speedup(E) = ------------- = ------------------- ExTime w/ E Performance w/o E

Suppose that enhancement E accelerates a fraction F

• f the task by a factor S, and the remainder of the

task is unaffected, then: ExTime(E) = Speedup(E) =

Amdahl’s Law

ExTimenew = ExTimeold x (1 - Fractionenhanced) + Fractionenhanced Speedupoverall = ExTimeold ExTimenew Speedupenhanced = 1 (1 - Fractionenhanced) + Fractionenhanced Speedupenhanced

Amdahl’s Law

• Floating point instructions improved to run 2X;

but only 10% of actual instructions are FP Speedupoverall = ExTimenew =

Amdahl’s Law

• Floating point instructions improved to run 2X;

but only 10% of actual instructions are FP Speedupoverall = 1 0.95 = 1.053 ExTimenew = ExTimeold x (0.9 + .1/2) = 0.95 x ExTimeold

Legge di Amdahl Improve x5 in CPU speed Increase x5 cost CPU use w/e: 50% of time (50% I/O) CPU cost = 1/3 Total Computer Cost

Evaluate the investment from cost/performance viewpoint

Speedup = 1 0,5 0,5 5 = 1,67

New cost = 2 3×11 3 ×5 = 2,33 times the original cost

Cost increase > performance improvement!

FPSQR ops. responsible of 20% of Execution time FP ops. responsible of 50% of Execution time Alternative enhancements:

• 1. To make a HW implementation of FPSQR ops.

with a speed up of 10

• 2. To increase ALL FP ops. to RUN 2x FASTER

with the same cost of 1 Comparison:

SpeedupFPSQR= 1 1-0,20,2 10 = 1,22 SpeedupFP= 1 1-0,5 0,5 2 = 1,33

Legge di Amdahl

Corollary: Make The Common Case Fast

• All instructions require an instruction fetch,
• nly a fraction require a data fetch/store.

– Optimize instruction access over data access

• Programs exhibit locality

Spatial Locality Temporal Locality

• Access to small memories is faster

– Provide a storage hierarchy such that the most frequent accesses are to the smallest (closest) memories. Reg's Cache Memory Disk / Tape

Legge di Amdahl

• Cache memory 5x FASTER of Main memory
• 90% CPU time is spent in a fraction of code which

could be put in cache What is the Speedup overall using cache?

Speedup = 1 1-% time cache can be used % time cache can be used Speedup using cache

Speedup = 1 1−0,9 0,9 5 =3,6

Occam's Toothbrush

• The simple case is usually the most frequent and

the easiest to optimize!

• Do simple, fast things in hardware and be sure

the rest can be handled correctly in software

Metrics of Performance

Compiler Programming Language Application Datapath Control Transistors Wires Pins

ISA

Function Units (millions) of Instructions per second: MIPS (millions) of (FP) operations per second: MFLOP/s Cycles per second (clock rate) Megabytes per second Answers per month Operations per second

Cycles Per Instruction

CPU time = CK cycles for a program × TCK

Average Cycles per Instruction Instruction Frequency CPI=CK cycles for a program Instruction Count = CPU time × CK rate Instruction Count

CPI = ∑

i=1 n

CPIi×F i

where

F i= I i Instruction Count

NB: CPIi should be measured and not just derived from CPU Ref. Manual (it must include cache misses, etc.) CPUtime= ICxCPIxTck =IC× Tck×∑

i=1 n

CPIi×F i

Aspects of CPU Performance

CPU time = Seconds = Instructions x Cycles x Seconds Program Program Instruction Cycle CPU time = Seconds = Instructions x Cycles x Seconds Program Program Instruction Cycle

• Instr. Cnt CPI Clock Rate

Program Compiler

• Instr. Set

Organization Technology

Aspects of CPU Performance

CPU time = Seconds = Instructions x Cycles x Seconds Program Program Instruction Cycle CPU time = Seconds = Instructions x Cycles x Seconds Program Program Instruction Cycle

Inst Count CPI Clock Rate Program X Compiler X (X)

• Inst. Set.

X X Organization X X Technology X

CPI Example

Base Machine (A): COMPARE + BRANCH  2 separate instructions New Machine (B): COMPARE + BRANCH  1 integrated instruction (TCKB = 1,25 TCKA) Which machine is faster?

OP Freq. Cycles CPI(i) BRANCH 20% 2 0,4 COMP 20% 1 0,2 Others 60% 1 0,6 100% 1,2 OP Freq. Cycles BRANCH ? 2

• thers

? 1 100%

CPI Example

CPU time A=I C A×1,2×T CK A Machine B: I CB=I C A−20%I C A=0,8I CA

Branch freq .=20% IC A 80% I C A =25

OP Freq. Cycles CPI(i) BRANCH 25% 2 0,5

• thers

75% 1 0,75 100% 1,25

CPU time B =1,25×I CA×T CK A =I C B×CPIB×1,25×T CK A=0,8 I C A×1,25×1,25T CK A=

CPUA is FASTER than CPUB

Marketing Metrics

MIPS = Instruction Count / Time * 10^6 = Clock Rate / CPI * 10^6

• Machines with different instruction sets ?
• Programs with different instruction mixes ?

– Dynamic frequency of instructions

• Uncorrelated with performance

MFLOP/s = FP Operations / Time * 10^6

• Machine dependent
• Often not where time is spent

Normalized: add,sub,compare,mult 1 divide, sqrt 4 exp, sin, . . . 8 Normalized: add,sub,compare,mult 1 divide, sqrt 4 exp, sin, . . . 8

Cycles Per Instruction

CPU time = CycleTime *



CPI * I i = 1 n i i CPI =



CPI * F where F = I i = 1 n i i i i Instruction Count

“Instruction Frequency” Invest Resources where time is Spent!

CPI = Instruction Count / (CPU Time * Clock Rate) = Instruction Count / Cycles

“Average Cycles per Instruction”

Organizational Trade-offs

Instruction Mix Cycle Time CPI

Compiler Programming Language Application Datapath Control Transistors Wires Pins

ISA

Function Units

Example: Calculating CPI

Typical Mix

Base Machine (Reg / Reg) Op Freq Cycles CPI(i) (% Time) ALU 50% 1 .5 (33%) Load 20% 2 .4 (27%) Store 10% 2 .2 (13%) Branch20% 2 .4 (27%) 1.5

Base Machine (Reg / Reg) Op Freq Cycles ALU 50% 1 Load 20% 2 Store 10% 2 Branch 20% 2

Typical Mix

Example

Add register / memory operations:

– One source operand in memory – One source operand in register – Cycle count of 2

Branch cycle count to increase to 3. What fraction of the loads (in the base machine) must be eliminated for this to pay off?

Example Solution

Exec Time = Instr Cnt x CPI x Clock Op Freq Cycles ALU .50 1 .5 Load .20 2 .4 Store .10 2 .2 Branch .20 2 .3 Reg/Mem 1.00 1.5

Example Solution

Exec Time = Instr Cnt x CPI x Clock Op Freq Cycles Freq Cycles ALU .50 1 .5 .5 – X 1 .5 – X Load .20 2 .4 .2 – X 2 .4 – 2X Store .10 2 .2 .1 2 .2 Branch .20 2 .3 .2 3 .6 Reg/Mem X 2 2X 1.00 1.5 1 – X (1.7 – X)/(1 – X)

CPINew must be normalized to new instruction frequency

CyclesNew InstructionsNew

Example Solution

Exec Time = Instr Cnt x CPI x Clock Op Freq Cycles Freq Cycles ALU .50 1 .5 .5 – X 1 .5 – X Load .20 2 .4 .2 – X 2 .4 – 2X Store .10 2 .2 .1 2 .2 Branch .20 2 .3 .2 3 .6 Reg/Mem X 2 2X 1.00 1.5 1 – X (1.7 – X)/(1 – X) Instr CntOld x CPIOld x ClockOld = Instr CntNew x CPINew x ClockNew 1.00 x 1.5 = (1 – X) x (1.7 – X)/(1 – X)

Example Solution

Exec Time = Instr Cnt x CPI x Clock Op Freq Cycles Freq Cycles ALU .50 1 .5 .5 – X 1 .5 – X Load .20 2 .4 .2 – X 2 .4 – 2X Store .10 2 .2 .1 2 .2 Branch .20 2 .3 .2 3 .6 Reg/Mem X 2 2X 1.00 1.5 1 – X (1.7 – X)/(1 – X) Instr CntOld x CPIOld x ClockOld = Instr CntNew x CPINew x ClockNew 1.00 x 1.5 = (1 – X) x (1.7 – X)/(1 – X) 1.5 = 1.7 – X 0.2 = X ALL loads must be eliminated for this to be a win!

CPU time including Cache

CPUTIME=CPUCK cyclesMemory Stall Cycles × TCK Memory Stall Cycles =N ° misses×miss penalty = =I C×miss per instruction ×miss penalty =

=I C× mem. ref . per instr .× miss rate × miss penalty

Example

Base Machine (A): Base Machine (B): CPI = 2 for cache hits Compare with a new machine B: 40% of Load/Store ops. 2% miss rate miss penalty: 25 cycles CPU TIME A

=CPU CK cyclesMemory Stall Cycles ×T CK=

= I C×CPI0×T CK

Memory Stall Cycles

=I C× mem. ref . per instr .× miss rate × miss penalty =I C×10,4× 0,02 × 25 =IC×0,7

CPU TIME B= I C×2I C×0,7×T CK=2,7×I C×T CK

CPU TIME B/CPU TIME A=1,35
