LBNF Absorber Design

Vladimir Sidorov Accelerator and Beam Interface Group meeting 2 June 2016

LBNF Absorber Design

• The current version of the LBNF Absorber includes all

modifications that occurred since the Absorber review a year ago.

• 1. Core blocks modified design.
• 2. Air Cooled Shielding Design.
• 3. Thermocouples assemblies design.
• 4. Waterlines modified design.
• 5. Drain system design.
• 6. Additional concrete shielding.

6/2/2016 Vladimir Sidorov/ LBNF Absorber Design 2

Absorber overall view.

6/2/2016 Vladimir Sidorov/ LBNF Absorber Design 3

The LBNE Absorber is built from water cooled Aluminum and Steel Core Blocks surrounded by steel and concrete

• shielding. Overall dimensions of the absorber are: Length-460in.; Width-408in.; Height-554in with RH facility.

RH Facility Manifold Air in Air out Drain system Thermo- couples Morgue Additional concrete shielding

6/2/2016 Vladimir Sidorov/ LBNF Absorber Design 4

The absorber core includes: Aluminum Spoiler, five Aluminum Mask blocks with different hole diameters, nine sculpted Aluminum blocks, four solid Aluminum blocks and four Steel blocks. Spoiler dimensions: 40”W ;40”H;12” thickness. Mask core blocks dimensions: 77”/79W; 77”H; 12” thickness . Sculpted Al, Solid Al, Steel blocks dimensions: 60”/62W; 60”H; 12” thickness.

Spoiler Mask (5) Sculpted (9) Al Solid (4) Steel(4) Beam Concrete Steel Core blocks Hadron monitor

6/2/2016 Vladimir Sidorov/ LBNF Absorber Design 5

Core Module design

Sculpted Core block Solid core block Tubes cover Thermocouples inserts Water lines Air channels Module Core block

6/2/2016 Vladimir Sidorov/ LBNF Absorber Design 6

Absorber components and air flow

Air delivery holes 9”x48” Water manifold Water tubes Steel shielding Concrete shielding Modules support structure Core block modules Concrete T-blocks

The air cooled absorber is designed to remove 225 kW of the energy from the surrounded absorber core blocks steel shielding. The absorber shielding is made from CCSS 9.11” steel plates. The support core blocks housing is made from 12” construction low carbon steel. The gap between neighboring steel plates is 0.20”.

6/2/2016 Vladimir Sidorov/ LBNF Absorber Design 7

Drain system design

Water collection hole Water level switch port Valve Duct 18”x36”
