slide-1
SLIDE 1

Layout Components

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-2
SLIDE 2
  • Here is the general naming scheme for ICEfaces component tags:

– Layout Components: panel* – Input Components: input* – Output Components: output* – Selection Components: select*

Component Naming Schemes

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-3
SLIDE 3

ice:panelGroup

  • Work horse of the panel components
  • Renders child components surrounded by a HTML

<div></div>

  • Base container for the following dynamic behaviours

– Drag and drop source and target configuration – Draggable container option

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

– Context menu linking – Panel tool tip linking – Effects container

  • Default CSS class name is icePnlGrp
slide-4
SLIDE 4

ice:panelGrid

  • Convenient wrapper for displaying non-iterative data in

an HTML <table/> tag

  • Child components are each place in a table cell.
  • New rows are defined by the integer attribute

“columns”. Once x number or child component are rendered a new row is started

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Default CSS class name applied to the <table /> tag is
  • icePnlGrd. CSS class can be applied to rows and

columns

  • Warning! No functionality for column or row spanning
slide-5
SLIDE 5

ice:panelSeries

  • The panelSeries component provides a mechanism for

dynamically generating a series of repeating child- components within a panel

  • Child components define the rendered layout
  • Default CSS name applied to the parent <div/> is

icePnlSrs

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Flexible component iterator -- essentially a dataTable

with out the <table />

  • Ability to use with an ice:dataPaginator in order to

provide pagination of results

slide-6
SLIDE 6

ice:panelTabSet

  • Renders a table driven tabbed user interface.
  • Comes in two flavours, declarative and iterative
  • The parent tag <ice:panelTabSet /> contain child tags

<ice:panelTab /> in either flavour

  • Selected tab change event can be optionally

configured

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Selected tab can also be dynamically changed via a

backing bean value

  • CSS styling for this component is complex but also

very flexible

slide-7
SLIDE 7
  • This component allows the user to hide content and

have it expand when the header is clicked

ice:panelCollabsible

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-8
SLIDE 8

Other Layout Components

  • panelPopup

– Modal and popup modes, will be covered in Facelet composite components

  • panelStack

– Similar to Swing component of the same name. – Not a good component to use when trying to minimize the weight of the component tree on the server

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

weight of the component tree on the server

  • Newer Components:

– panelDivider, split pain with dynamic divider – panelTooltip, popup container – menuContext, right-click popup context menu

slide-9
SLIDE 9

Auto Complete Component

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-10
SLIDE 10

Auto-Complete Component

  • ice:selectInputText component provides an inputText

component enhanced with auto-complete functionality

  • The component requires developers to implement the

matching list search algorithm in their backing bean

  • The ice:selectInputText component can generate one
  • f two types of lists:

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

– A list of String data – A list of arbitrarily complex child components

slide-11
SLIDE 11

Exercise: Overview

  • The goal of this exercise is to add auto-complete

functionality to the city field of the form

  • When done, the user will be able to select a city from an

auto-complete drop-down list, and the city, provinceId, and postalCode fields will be updated automatically

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-12
SLIDE 12

Step 1: Auto-Complete Component

  • The city field is currently using an ice:inputText component

for user entry

  • Rename ice:inputText with ice:selectInputText for the city

field

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-13
SLIDE 13

Step 2: Add valueChangeListener for city

  • In order to detect that the user has typed in some characters into the city field,

we need to add a valueChangeListener

  • Add the following attribute to the ice:selectInputText component:

valueChangeListener="#{applicantForm.cityListener}"

  • Open ApplicantForm.java in the IDE and paste the following method:

public void cityListener(ValueChangeEvent valueChangeEvent) { FacesContext facesContext = FacesContext.getCurrentInstance(); UIViewRoot uiViewRoot = facesContext.getViewRoot(); String cityNameStartsWith = (String)valueChangeEvent.getNewValue(); getCitySupport().filterSelectItems(cityNameStartsWith);

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

City city = getCitySupport().getCityByName(cityNameStartsWith); if (city != null) { UIInput cityInputText = (UIInput) uiViewRoot.findComponent("applicantForm:city"); cityInputText.setSubmittedValue(city.getCityName()); cityInputText.setValue(city.getCityName()); UIInput provinceInputText = (UIInput) uiViewRoot.findComponent("applicantForm:provinceId"); provinceInputText.setSubmittedValue(Long.toString(city.getProvinceId())); provinceInputText.setValue(city.getProvinceId()); UIInput postalCodeInputText = (UIInput) uiViewRoot.findComponent("applicantForm:postalCode"); postalCodeInputText.setSubmittedValue(city.getPostalCode()); postalCodeInputText.setValue(city.getPostalCode()); FacesContextHelper.clearImmediateFacesMessages(facesContext); } }

  • Note the call to getCityByName() which will eliminate the hard coded value of “Orlando” in the

backing bean

slide-14
SLIDE 14

Step 3: Add immediate attribute

  • Normally valueChangeListeners fire during the

PROCESS_VALIDATIONS phase of the JSF lifecycle

  • But in order to avoid seeing extraneous validation failures,

we need to add immediate=“true” to the auto-complete component

  • Open the applicantForm.xhtml file in the IDE

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Open the applicantForm.xhtml file in the IDE
  • Add the following to the ice:selectInputText tag:

immediate="true"

slide-15
SLIDE 15

Step 4: Replace valueChangeListener for postalCode

  • Replace the entire postalCodeListener() method with the following code:

public void postalCodeListener(ValueChangeEvent valueChangeEvent) { FacesContext facesContext = FacesContext.getCurrentInstance(); UIViewRoot uiViewRoot = facesContext.getViewRoot(); String newPostalCode = (String) valueChangeEvent.getNewValue(); City city = getCitySupport().getCityByPostalCode(newPostalCode); if (city != null) { UIInput cityInputText = (UIInput) uiViewRoot.findComponent("applicantForm:city"); cityInputText.setSubmittedValue(city.getCityName()); cityInputText.setValue(city.getCityName());

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

UIInput provinceInputText = (UIInput) uiViewRoot.findComponent("applicantForm:provinceId"); provinceInputText.setSubmittedValue(Long.toString(city.getProvinceId())); provinceInputText.setValue(city.getProvinceId()); UIInput postalCodeInputText = (UIInput) uiViewRoot.findComponent("applicantForm:postalCode"); postalCodeInputText.setSubmittedValue(city.getPostalCode()); postalCodeInputText.setValue(city.getPostalCode());

FacesContextHelper.clearImmediateFacesMessages(facesContext);

} }

  • Note the call to getCityByPostalCode() which will eliminate the hard coded value of “32801” for Orlando in the backing bean – now the code

will work with any known postal code

slide-16
SLIDE 16

Step 5: Add Select Items

  • In order to populate the auto-complete list with items:

– Add the following “iterator” attributes to the ice:selectInputText component:

listVar="city" listValue="#{citySupport.selectItems}"

– Add the following f:facet component as a child of the ice:selectInputText component:

<f:facet name="selectInputText">

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

<f:facet name="selectInputText"> <ice:panelGrid columns="2"> <ice:outputText id="autoCompleteCity" value="#{city.cityName}" /> <ice:outputText id="autoCompletePostalCode" value="#{city.postalCode}" /> </ice:panelGrid> </f:facet>

slide-17
SLIDE 17

Step 6: Add City Transfer Object

  • Create a new Java class:

– training.jobapplication.transfer.City

  • Add the following properties:

private long cityId; private long provinceId; private String cityName; private String postalCode;

  • Generate getters/setters for each property
  • Add the following constructor:

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Add the following constructor:

public City(long cityId, long provinceId, String cityName, String postalCode) { this.cityId = cityId; this.provinceId = provinceId; this.cityName = cityName; this.postalCode = postalCode; }

slide-18
SLIDE 18

Step 7: Remove Obsolete Injection

  • Open the ApplicantForm.java file in the IDE
  • Remove the following line, because we don’t need it anymore:

private ProvinceSupport provinceSupport;

  • Remove the corresponding getProvinceSupport() and

setProvinceSupport() method, because we don’t need it anymore either

  • Open the faces-config.xml file in the IDE
  • Remove the managed-property that injects the provinceSupport into

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Remove the managed-property that injects the provinceSupport into

the applicantForm backing bean: <managed-property> <property-name>provinceSupport</property-name> <value>#{provinceSupport}</value> </managed-property>

slide-19
SLIDE 19

Step 8: Add CitySupport Bean

  • Create a new Java class:

– training.jobapplication.bean.support.CitySupport

  • The code we need to paste is too large, so find the

CitySupport.java file in the solutions folder and copy the contents

  • Note the foreign-key relationship with provinceId, and that

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Note the foreign-key relationship with provinceId, and that

the provinceSupport bean will be injected into the citySupport bean in order to lookup provinceId keys

  • Walk through the filterSelectItems() method and look at

how the filter is applied

slide-20
SLIDE 20

Step 9: Define CitySupport Bean

  • Open the following file in the IDE:

– jobApplication/WEB-INF/faces-config.xml

  • Add the following managed-bean and managed-property:

<managed-bean> <managed-bean-name>citySupport</managed-bean-name> <managed-bean- class>training.jobapplication.bean.support.CitySupport</managed- bean-class> <managed-bean-scope>request</managed-bean-scope>

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

<!-- Inject the provinceSupport bean into the --> <!-- citySupport bean in order to promote loose coupling --> <managed-property> <property-name>provinceSupport</property-name> <value>#{provinceSupport}</value> </managed-property> </managed-bean>

slide-21
SLIDE 21

Step 10: Specify Injection into Backing Bean

  • Open the faces-config.xml file in the IDE
  • Add the following managed-property to the applicantForm

backing bean:

<!-- Inject the citySupport bean into the --> <!-- backing bean in order to promote loose coupling --> <managed-property> <property-name>citySupport</property-name>

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

<property-name>citySupport</property-name> <value>#{citySupport}</value> </managed-property>

  • Open the ApplicantForm.java file in the IDE
  • Add the following property:

private CitySupport citySupport;

  • Generate a getters and setters for citySupport
slide-22
SLIDE 22

Step 11: Run Application

  • Re-publish/deploy the jobApplication

project

  • Run the application in the browser
  • Enter a value for First Name, Last Name,

Travel Percentage, and Date of Birth

  • Click in the City field and type the letter “A”

– Notice that “Atlanta” and “Albany” appear

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

– Notice that “Atlanta” and “Albany” appear

  • Select Atlanta from the list
  • Note that the Province is GA and the Postal

Code is 30329

  • Enter a postal code: 32801
  • Note that the Province is FL and the City is

Orlando

slide-23
SLIDE 23

Rich Text Editor Component

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-24
SLIDE 24

Rich Text Editor

  • The h:inputTextarea and ice:inputTextarea render

themselves as an HTML <textarea /> tag which provides the user with the ability to enter only plain text

  • The ice:inputRichText component enables the user to enter

rich text like bold, italic, hyperlinks, and bullets:

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-25
SLIDE 25

Implementation

  • The ice:inputRichText component is currently implemented

as a wrapper around the FCKEditor open source project

– The name comes from the initials of Frederico Caldeira Knabben, the project founder

  • The FCKEditor represents rich text as HTML, and allows the

user to click on a “Source” button to work directly with the

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

user to click on a “Source” button to work directly with the underlying HTML if desired

slide-26
SLIDE 26
  • Setting the Toolbar

– <ice:inputRichText toolbar="#{inputRichTextBean.toolbarMode}“ …/>

  • Toolbar types

– Default – Basic

Toolbar

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

– Basic

slide-27
SLIDE 27
  • Setting the Language

– <ice:inputRichText language="en" …/>

  • Available Languages

English (United Kingdom) (en-uk) Esperanto (eo) Estonian (et) Faroese (fo) Finnish (fi) Mongolian (mn) Norwegian (no) Norwegian Bokmal (nb) Persian (fa) Polish (pl) Afrikaans (af) Arabic (ar) Basque (eu) Bengali/Bangla (bn) Bosnian (bs)

Language

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

Finnish (fi) French (fr) Galician (gl) German (de) Greek (el) Hebrew (he) Hindi (hi) Hungarian (hu) Italian (it) Japanese (ja) Khmer (km) Korean (ko) Latvian (lv) Lithuanian (lt) Malay (ms) Polish (pl) Portuguese (Brazil) (pt-br) Portuguese (Portugal) (pt) Romanian (ro) Russian (ru) Serbian (Cyrillic) (sr) Serbian (Latin) (sr-latn) Slovak (sk) Slovenian (sl) Spanish (es) Swedish (sv) Thai (th) Turkish (tr) Ukrainian (uk) Vietnamese (vi) Bosnian (bs) Bulgarian (bg) Catalan (ca) Chinese Simplified (zh-cn) Chinese Traditional (zh) Croatian (hr) Czech (cs) Danish (da) Dutch (nl) English (en) English (Australia) (en-au) English (Canadian) (en-ca)

slide-28
SLIDE 28
  • Skins

– <ice:inputRichText skin=“office2003” …/>

  • Available Skins

– default – office2003

Skins

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

– office2003 – silver

slide-29
SLIDE 29
  • The default behavior of the ice:inputRichText is to only save its data

when the save icon is clicked

  • In order to make the ice:inputRichText participate in normal ICEfaces

Save Button / Submit Behavior

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • In order to make the ice:inputRichText participate in normal ICEfaces

form submission, the saveOnSubmit attribute must be set to true

<ice:inputRichText saveOnSubmit=“true”…/>

slide-30
SLIDE 30

Exercise: Overview

  • The goal of this exercise is to replace the

ice:inputTextarea component with an ice:inputRichText component

  • This will allow the user to enter text like bold, italic, bullets

in the resume, rather than simply plain text

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-31
SLIDE 31

Step 1: Replace Component

  • Open the applicantForm.xhtml file in the IDE
  • Replace the ice:inputTextarea component with the

following markup: <ice:inputRichText id="resume" saveOnSubmit="true" toolbar="Basic" width="500" height="200"

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

width="500" height="200" value="#{applicant.resume}" />

slide-32
SLIDE 32

Step 2: Output Submitted Rich Text

  • Open the ApplicantForm.java file in the IDE
  • Add the following line to the submit() method:

System.out.println("submit() resume=" + this.applicant.getResume());

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-33
SLIDE 33

Step 3: Run Application

  • Re-publish/deploy the jobApplication project
  • Run the application in the browser
  • Enter First Name: John
  • Enter Last Name: Doe
  • Enter Travel Percentage: 50
  • Enter Date of Birth: 1/1/1970
  • Enter Postal Code: 32801
  • Click Show Resume

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Click Show Resume
  • Enter Rich Text:

– This is some bold text

  • Click Submit Application
  • Note that the Tomcat console has this HTML

fragment as the value for resume: submit() resume=<p>This is some <strong>bold</strong> text</p>

slide-34
SLIDE 34

File Upload Component

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-35
SLIDE 35

File Upload

  • Normal HTML forms look like this:

<form enctype=“application/x-www-form-urlencoded”> … </form>

  • But when doing file upload, forms look like this:

<form enctype=“multipart/form-data”> … </form>

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

</form>

  • The JSF 1.x specification completely ignored the

multipart/form-data case – additionally, there is no file- upload component provided by the JSF RI

  • Prior to ICEfaces, the only way to intercept these types of

postback requests was to implement a PhaseListener

slide-36
SLIDE 36

The ice:inputFile Component

  • ICEfaces overcomes the JSF file upload shortcoming by

providing an ice:inputFile component

  • The component renders itself as an <iframe> which points

to a small HTML fragment that is generated by the ICEfaces servlet

  • The HTML fragment contains markup like this:

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • The HTML fragment contains markup like this:

<input type=“file” … />

  • This markup will manifest itself in the browser as a text

field with a “Browse…” button and an “Upload” button

  • When the user selects a file and clicks the “Upload” button,

the ICEfaces uploadServlet receives the file data

slide-37
SLIDE 37

Progress Indicator

  • The file upload component can be tied to an

ice:outputProgress component

  • The progress indicator is updated during the file upload via

ICEfaces Ajax Push

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-38
SLIDE 38

Uploaded File

  • After the file upload is complete, the file will exist in the

folder specified in the com.icesoft.faces.uploadDirectory init-param in web.xml

– This can be an absolute or relative folder path – If relative, it is relative to the Tomcat working directory for the web application

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Alternatively, the folder can be specified by the

uploadDirectory attribute of the ice:inputFile component

– See also: uploadDirectoryAbsolute and uniqueFolder attributes

slide-39
SLIDE 39

Exercise: Overview

  • The goal of this exercise is to replace the

ice:inputRichText component with an ice:inputFile component

  • This will allow the user to upload a resume document,

rather than typing in a resume in the text area

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-40
SLIDE 40

Step 1: Replace Component

  • Replace the ice:inputRichText component with the

following markup:

<ice:inputFile id="resume" actionListener="#{resumeUploader.actionListener}" label="#{msgs.uploadResume}" progressListener="#{resumeUploader.progressListener}" />

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-41
SLIDE 41

Step 2: Add Progress Indicator and Message

  • Add the following table row markup just above the table row for the

ice:inputFile component: <tr> <td> <ice:outputProgress value="#{resumeUploader.fileProgress}" labelComplete="#{resumeUploader.currentFile.fileName}" /> </td> </tr>

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

</tr>

slide-42
SLIDE 42

Step 3: Modify Model Bean

  • Open the Applicant.java file in the IDE
  • Delete the following line:

private String resume;

  • Delete the getResume() and setResume() methods

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-43
SLIDE 43

Step 7: Add FileUpload Utility Bean

  • Create the following utility bean Java class:

– training.jobapplication.bean.util.FileUploader

  • The size of the source code is too large to copy/paste from

slides, so instead, find the file in the solution folder and paste the contents into the IDE

  • This is a general purpose utility bean that can be reused by

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • This is a general purpose utility bean that can be reused by
  • ther ICEfaces web applications
slide-44
SLIDE 44

Step 8: Remove Console Output

  • Open the ApplicantForm.java file in the IDE
  • Delete this line:

System.out.println("submit() resume=" + this.applicant.getResume());

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-45
SLIDE 45

Step 9: Message Bundle

  • Add the following key+value pair to Msgs_en.properties:

uploadResume=Upload Resume

  • This will be the label of the upload button

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

slide-46
SLIDE 46

Step 10: Define Managed Beans

  • Paste the following markup into faces-config.xml:

<managed-bean> <managed-bean-name>resumeUploader</managed- bean-name> <managed-bean-

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

class>training.jobapplication.bean.util.File Uploader</managed-bean-class> <managed-bean-scope>request</managed-bean- scope> </managed-bean>

slide-47
SLIDE 47

Step 11: Run Application

  • Re-publish/deploy the jobApplication

project

  • Run the application in the browser
  • Enter First Name: John
  • Enter Last Name: Doe
  • Enter Travel Percentage: 50
  • Enter Date of Birth: 1/1/1970

ICESOFT TECHNOLOGIES INC.

www.icefaces.org

  • Enter Postal Code: 32801
  • Click Show Resume
  • Select a file from your local drive
