LAUNCHING RCS – THINGS TO CONSIDER KOBUS SMIT, STRATEGIC ENGAGEMENT DIRECTOR – GSMA

RCS Deployment Options Operators face a number of choices in deploying RCS:

• RCS Infrastructure: on premises
• r hosted?
• Which vendor?
• Which RBM server?

The following slides outline the alternatives

CONFIDENTIAL

ADVANTAGES

• More flexibility
• More options for differentiation from other
• perators
• E.g. integration with legacy messaging
• Infrastructure can be partly shared with VoLTE
• Allows to use joint registration
• More efficient on client-side (e.g. battery

consumption)

• Provides more visibility of the traffic and user

behaviour

• Makes it easier to provide customer support
• No need to provide authentication options to 3rd

parties

DISADVANTAGES

• Requires more expertise to set up and operate
• Deployment timeline will normally be longer
• Requires the establishment of specific connections

with other networks

• Most networks can be covered with connections

through hubs

• Some may need dedicated connections (e.g. other

major operators in country)

• Need for joint project with other network

3

Operator Owned Solution

CONFIDENTIAL

ADVANTAGES

• Easy to deploy
• Only requires providing access from cellular network

and enabling authentication

• Access may even be straightforward if using the

internet APN as HOS APN

• Almost no in-house experience is required
• Easy interconnect
• Almost instant connectivity to other networks hosted

by same party and all networks that party connected to already

• No technical expertise required for further

connections

• Quicker to deploy

DISADVANTAGES

• Separate infrastructure
• Requires dual registration
• Somewhat less efficient on client side
• Little control over feature roadmap of network
• More difficult to connect to legacy messaging infrastructure
• Fall-back to SMS on the client is probably most viable

approach

• Requires providing 3rd parties with options to authenticate user
• Limits authentication options
• Somewhat mitigated from UP 2.0 onwards with OpenID

connect authentication that can be performed against endpoint provided by operator

• Less visibility of traffic
• Customer support and general monitoring (e.g. fraud

prevention) will be harder

4

Hosted Solution

CONFIDENTIAL

• Hosted RCS solutions are a low-Capex, faster way to introduce RCS A2P services
• Service provider may seek to monetise provision of the RCS service through

revenue-sharing on A2P revenue

• Operators considering hosted services should:
• Be aware of the WA.09 ecosystem principles
• Be aware of the short, medium and long term financial pros and cons
• Ensure they maintain control of the directory of chatbots reachable from the device
• Ensure that they contractually maintain the right and technical ability to connect to

aggregators and chatbots, regardless of whether the chatbots are enabled by the hosted solution provider or another party

5

Business Model for Hosted RCS

LEGAL INTERCEPT Operator services are obliged to support legal intercept Approaches differ by country and by vendor

• Operators should request

details of how Legal Intercept is satisfied from all potential vendors One of 3 Models for Legal Intercept usually applies

• 1) Regulator says RCS is

not a regulated service

• 2) Regulator Legal

Intercept performed by 3rd pary service provider

• 3) Regulator requires

Operator to provide Legal Intercept in their network Both 2) and 3) above can be subject to a temporary derogation by the Regulator

RCS Interconnect Interconnect is necessary to achieve reach and market coverage Operators can choose point to point interconnect

• r interconnecting

via hubs

RCS INTERCONNECTION DIFFERS FROM SMS IN SEVERAL REGARDS

• Specification enables different

approaches for person-to- person interconnect traffic and Business interconnect traffic

• Traffic type tag in traffic

header

• Different SIP address

format for originator

• Emphasis on hubs (join once /

connect to multiple networks) approach to deliver scale

• Ability for MNOs to

interconnect for A2P traffic in a commercially viable – currently no MNO is exploiting this capacity but it is achievable

RCS INTERCONNECTION ARCHITECTURE MNO 1 MNO 2..n

MAAP PLATFORM

MAAP API Gateway MAAP Platform RCS Core Session Border Controller MAAP API Gateway MAAP Platform RCS Core Session Border Controller

AGGREGATOR

RCS HUB

P2P INTERCONNECTION HUBS

• Currently 2 hubs supporting

active networks

• Vodafone Group hub
• Google hub(s) Europe,

Americas and Asia

• Multiple additional providers
• f hubs entering the market

(see below)

• MNO hub initiative

announced at MWC 2018

• P2P hubs will be governed by
• GSMA document on

definition of hub-as-a- service

• Hub interconnect MoU

encouraging hubs to interconnect

Live Hubs

• N. America

Live Hubs Europe

• N. America

Live Hubs Europe

Live Hubs China S.E Asia

Forecast to go from one to multiple launches in 2018 P2P INTERCONNECTION HUBS TODAY

AMX Brazil AMX Mex Rogers Bell Mobility Sprint Tracphone Reliance Jio China Mobile Singtel

ZTE (China) ZTE (Singapore) Google (San Fran)

VF Albania VF Romania VF UK VF Portugal VF Spain VF Turkey

Vodafone 12

VF Ireland VF Italy VF Greece VF Hungary VF Germany VF Czech Republic

Vodafone

DT Albania DT Hungary DT Cosmote DT Slovakia DT Romania Orange Romania Orange Slovakia Telenor Norway Telenor Denmark Telia Norway Globe

Google Hosted Vodafone Hosted ZTE Hosted WIT Platform MNO Platform Launched and interconnected Launched Launching this FY

Google (Belgium)
