KREA

Index

1. Highlights 2. Design & User Interface 3. New Technologies 4. Capacity 5. Configurations 6. Electronics 7. Accessories

2

• 1. Highlights

3

Highlights

• Elegant and appealing design
• Compact footprint suitable for locations with limited space
• A user friendly interface
• An optimum quality of the dispensed drinks prepared from fresh

coffee beans & combined with soluble products

• The capability to dispense a wide range of drinks
• Highest level of operational efficiency thanks to the fact that coffee

hopper & waste containers capacity’s are perfectly balanced

• High throughput thanks to the 600 cc boiler

4

Highlights

N&W developed a brand new dispenser that meets all the above mentioned requirements: Krea

Krea is the new Necta table top model that meets the needs of small locations thanks to newly developed technologies and high tech features such as:

• Compact footprint
• Innovative and elegant design
• Advanced user friendly interface
• Optimized autonomy
• Patented Z4000 brewing system and Freemix

instant technology

• Enhanced electronics

5

• 2. Design & User Interface

6

Weight 41 Kg ca Height 750 mm (with coffee hopper) Depth 564 mm Width 410 mm

Depth with door open 822 mm

Krea has compact dimensions and weight:

7

Design

Design

Krea has an elegant and high tech design thanks to:

8

• Matt-brushed aluminium side panels which give a luxurious feel to

the dispenser

• Precious chromium-plated delivery area grid & frame around the

selection area

• Chromium-plated push buttons
• Stainless steel cup support which conveys an image of quality
• Double LED lights with the possibility to change the lights colour
• Visible coffee beans

User interface

KREA is a table top dispenser which has been conceived for hotels, communities and self-service locations. It boasts

• a wide range of selections
• simple and intuitive use
• clear information about the delivery process
• simple cleaning and easy maintenance

9

User interface

• 10 direct selections
• Chromium-plated buttons which are well visible
• Well readable selection labels, in line with the machine aesthetics
• Large graphic display 128 X 64 pixel with the possibility to show

simple animations during the selection process

• Possibility of LED lighting in the cup station
• Cup station can host 12 OZ paper cups (14 cm height)
• Cup sensor for using own cup, mug or jug

10

• 3. New technologies

11

Z4000 coffee brewer

12

KREA A is equipped with Z4000, granting top quality drinks and

• ptimized delivery times:

Z4000 is available in two versions: Small: for a very short espresso coffee Large: for longer espresso coffee drinks (from 7 to 15 grams of ground coffee) Very interesting for the roaster. New coffee brewer cover easy to remove which keeps the machine clean and tidy once the door is open

• Superb quality coffee which remains unchanged cup after cup.
• The compact boiler grants a perfect temperature
• f the first coffee and avoids overheating of the

next drinks.

New Z4000 coffee brewer

13

New Freemix Instant technology

14

• New mixers and adjustable motordosers whose speed can be

customized according to the local needs (quality vs speed): powders flow, mixing speed

• New single powder canisters with 1 LT and 2 LT capacity
• The parts which must be activated (green)

and cleaned (blue) are coloured so that the technician can easily understand which

• peration should be done
• Blue pipes go out from

coffee group and from mixer to nozzles

• 4. Capacity

15

Capacity

16

The top of the machine can be completely opened thus allowing an easy refill of the containers without removing them

155 exhausted coffee pods in the solid waste bucket 1.4 lt in the liquid waste bucket

Krea C4 Coffee beans Milk Chocolate Tea Capacity 1200 gr 680 gr 1500 gr 800 gr

• 5. Configurations

17

Espresso C4 code 962150 Coffee brewer with large chamber Coffee beans canister + 3 single powder containers

Northern Europe version

18

COFFEE BEANS CHOCOLATE 1 LT DECAFFEINATED COFFEE 1 LT MILK 1.9 LT

France Germany

Espresso C4 code 962151 Coffee brewer with small chamber Coffee beans canister + 3 single powder containers

Southern Europe version

19

COFFEE BEANS CHOCOLATE 1.9 LT DECAFFEINATED COFFEE 1 LT MILK 1.9 LT

Italy Spain

Caffe’ Americ icano Caffe’ Americ icano Descafein inado corto

• 6. Electronics

20

Electronics

21

Thanks to the latest N&W electonic platform it is possible to customize the machine parameters and drinks recipes thus granting the maximum quality and service level to the end user.

• 16 bit technology with 4 MB flash memory
• Open system for statistics transmission and collection in

compliance with EVA-DTS protocol

• Data retrieval via infra red (enhanced DDCMP protocol) or

using connector JACK protocol (DEX) with negotiation of the transmission baudrate between machine and terminal

Electronics

22

• Ability to connect coin validator 24V
• Implementation of enhanced MDB with new functionalities:

multiple price lists, user group, single-vend/multi-vend, cash sale

• Executive
• Software update without losing any statistics or data
• Time bands for happy hour and energy saving options
• Possibility to transfer the default set-up from one machine

to another via Up Key

• Change of programming and user menus through GIGA

management software

• 7. Accessories

23

Accessories

24

• Black metal / black plastics equipped base cabinet

962252

• EXE – MDB Payment system kit

962254

• Water self feeding by 20 lt tank

962255

• Cup warmer

961904
