Kommunikation i rymden

Mats Holmström Institutet för rymdfysik (IRF) SUNET TREFpunkt Kiruna 30 mars 2004

slide-2
SLIDE 2

Översikt

  • ASPERA-3 på Mars Express

– Vetenskapliga mål och bakgrund – Nuläge

  • Mars Express dataflöden

– Fysiskt – Format

  • Framgångar och problem
slide-3
SLIDE 3

Solar System Physics: Scientific Goals

Comparative research on the evolution and dynamics of the solar system

  • bjects (planets, asteroids, comets, meteoroids) and their interaction

with the solar wind.

  • How does the interplanetary medium affect and shape the bodies in the

inner solar system?

  • What plasma physical processes determine the structure of the interaction

regions?

  • How do the solar system dust population evolve and interact with planetary

bodies?

1

slide-4
SLIDE 4
slide-5
SLIDE 5

Instrument Development and Construction

The detectors measure characteristic properties such as energy, mass and/or distribution of the particles (electrons, ions or energetic neutral atoms (ENAs))

  • Nozomi (PI). ISAS Mars orbiter. IMI: Ion detector.
  • Rosetta (PI). ESA comet orbiter. ICA: Ion detector.
  • Mars Express (PI). ESA Mars orbiter.

ASPERA-3: ENA, electron and ion detectors.

  • Venus Express (PI). ASPERA-4: ENA and ion detectors.
  • SMART-1 (CoI). ESA Moon orbiter. D-CIXS: X-ray imager.

Future: Bepi-Colombo (ESA Mercury orbiter), Planet-C (ISAS Venus orbiter).

3

slide-6
SLIDE 6

2003-01-22

The Solar Wind

[Parker, 1963]

A collisionless plasma

2

slide-7
SLIDE 7

2003-01-22

Magnetized Planets

[Kivelson & Russell, 1995]

Mercury, Earth, Jupiter, Saturn, Uranus, Neptune

4

slide-8
SLIDE 8

2003-01-22

Non-Magnetized Planets

[Luhmann, 1986]

Venus, Mars

5

slide-9
SLIDE 9

O H + H O+

ENA Production by Charge-Exchange

slide-10
SLIDE 10
slide-11
SLIDE 11
slide-12
SLIDE 12

ASPERA-3

On ESA’s Mars Express mission Launch June 2003 on Russian Soyuz/Fregat Arrives in December 2003

9

slide-13
SLIDE 13

ASPERA-3 Delivered June 2002

7

slide-14
SLIDE 14

Neutral Particle Imager (NPI)

slide-15
SLIDE 15

Neutral Particle Detector (NPD)

Three-dimensional view of the NPD principal components Cut-away view of the NPD sensor

slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26

July 3, 3 Million Kilometers July 3, 8 Million Kilometers

slide-27
SLIDE 27
slide-28
SLIDE 28

Rymden - En tuff miljö

  • Uppskjutning
  • Temperatur
  • Strålning (Single Event Effects)
slide-29
SLIDE 29
slide-30
SLIDE 30

Planeternas positioner...

slide-31
SLIDE 31

Geometri

  • Fri sikt. 5-10 grader över horisonten.
  • Avstånd

– Bandbredden avtar som 1/d2

– Latency: Ljustiden (OWLT)

  • Riktning (tre-axel stabiliserad)

– Markstation: Banbestämmning (centimetrar) – Satellit

  • Bestämmning: Gyron. Star trackers. Sun sensors
  • Ändring: Reaktion wheels. Thrusters
slide-32
SLIDE 32

Markstationer

ESA (NNO), NASA (DSN)

slide-33
SLIDE 33

Satellit

1.6 m HGA (0.4 m LGA) X-band (7.1 GHZ) till Jorden S-band (2.1 GHZ) från Jorden

slide-34
SLIDE 34

Avståndet Mars-Jorden

1/d2

slide-35
SLIDE 35

Bandbredd

kbps

slide-36
SLIDE 36

Händelser idag

PERICENTRE_PASSAGE_0254_/_SSP_(155.68,-43.34)_/_SZA_050 L34T 303 P 04-090T09:40:17.000Z 0 CAN_LOS_10 KMAS 1013 P 04-090T09:50:57.000Z 0 800_KM_ASCEND KMAS 1014 P 04-090T09:55:50.000Z 0 1200_KM_ASCEND L34H 303 P 04-090T10:04:11.000Z 0 CAN_LOS_06 KMAS 1015 P 04-090T10:04:19.000Z 0 2000_KM_ASCEND KMAS 1016 P 04-090T10:24:53.000Z 0 4000_KM_ASCEND L74T 303 P 04-090T12:06:01.000Z 0 NNO_LOS_10 L74H 303 P 04-090T12:54:07.000Z 0 NNO_LOS_01 A75H 303 P 04-090T13:15:37.000Z 43164 KOU_AOS_02 MAPO 255 P 04-090T13:25:10.000Z 0 APOCENTRE_PASSAGE_0255 A75T 303 P 04-090T13:48:06.000Z 39005 KOU_AOS_10 MO2S 6 P 04-090T15:16:27.000Z 2032 OCC_MARS_200KM_START_/_RA_063.81_/_DE_022.41_/_OMP_(331.04,01 MOCS 2 P 04-090T15:28:00.000Z 626 OCC_MARS_START_/_RA_063.82_/_DE_022.41_/_OMP_(325.94,-00.10)_ PENS 154 P 04-090T15:28:34.000Z 3852 MAR_PENUMBRA_START UMBS 151 P 04-090T15:29:23.000Z 3772 MAR_UMBRA_START MOCE 2 P 04-090T15:38:26.000Z 0 OCC_MARS_END_/_RA_063.82_/_DE_022.41_/_OMP_(321.21,-14.32)_/_ MO2E 6 P 04-090T15:50:19.000Z 0 OCC_MARS_200KM_END_/_RA_063.83_/_DE_022.41_/_OMP_(315.61,-29. KMDS 1017 P 04-090T16:25:16.000Z 5661 4000_KM_DESCEND UMBE 151 P 04-090T16:32:15.000Z 0 MAR_UMBRA_END PENE 154 P 04-090T16:32:46.000Z 0 MAR_PENUMBRA_END KMDS 1018 P 04-090T16:46:02.000Z 3181 2000_KM_DESCEND A24H 303 P 04-090T16:54:06.000Z 47424 GDS_AOS_06

slide-37
SLIDE 37

Resursbehov

Sensor-Mode Bit rate [bps] IMA Mode 24 2400 IMA Mode 26 600 ELS Low 68 ELS Normal 260 ELS High 1029 ELS Burst 4100 NPI Normal, High, Burst 265 NPD Low 424 NPD Normal, High 1576 NPD Burst 12328 NPD Raw 34000 Power consumption: 16.8 W without scanner 23.4 W with scanner

slide-38
SLIDE 38
slide-39
SLIDE 39

Dataformat

  • Till satelliten:

– Telecommands (TC)

  • Från satelliten:

– Telemetri (Payload data, temperaturer,

strömmar, ...)

  • Datapaket

– CCSDS standard (ESA, NASA,...) – Felkorrigerande kodning. Komprimering

  • 100 Mbit databuss. 12 Gbit massminne
slide-40
SLIDE 40

Dataflödet

Mars Express ESOC Darmstadt Markstation IRF Kiruna

slide-41
SLIDE 41

Commanding

slide-42
SLIDE 42

Kommandofiler

POR_ 00085 04-086T14:57:34.000Z 04-091T00:21:16.000Z 04-091T01:48:12.000Z 0079 H1AASF01A2 S H2I UTC T P 000 H3 H4 H5 S1 MPER 0000000256 -00:25:00 S204-086T14:57:34Z matsh@irf.se H1AASF03A1 S H2I UTC T P 010 H3 H4 H5 S1 MPER 0000000256 -00:23:17 S204-086T14:57:34Z matsh@irf.se PVASD6501 E D ON PVASD6502 E D OFF PVASD6503 E D ON PVASD6504 E D OFF PVAS00026 R A D 0 PVAS01026 R A D 0 PVAS01126 R A D 0 PVAS01226 R A D 0 PVAS01326 R A D 0 PVAS01426 R A D 0 ...

slide-43
SLIDE 43

HRSC

slide-44
SLIDE 44

OMEGA: Water on Mars

slide-45
SLIDE 45

Note: Mars (and Venus) are planets lacking a strong intrinsic magnetic field (umbrella) => dehydration.

Solar wind scavenging of the martian atmosphere

Planetary wind = Outflow of atmosphere and ionosphere (cometary interaction)

ASPERA will do global imaging and in-situ measurements of: Inflow — solar wind Outflow — planetary wind using: Energetic neutral atom cameras and plasma (ion+electron) spectrometers

Solar wind

Planetary wind 100 ton/day

slide-46
SLIDE 46

ASPERA-3 — Preliminary results (IMA)

Planetary wind (O+)

QuickTime och en TIFF (okomprimerat)-dekomprimerare krävs för att kunna se bilden.

Solar wind/sheath (H+, He++) Planetary wind (O+) Solar wind MEX

  • rbit

Solar wind/sheath Tail/planetary wind Closest approach

Confirmation of the planetary wind - O+ and molecular ions
