Kobalto Highlights Patented Z3000 Necta espresso brewer producing - - PowerPoint PPT Presentation

▶

Feb 18, 2023 108 likes •208 views

Kobalto Highlights Patented Z3000 Necta espresso brewer producing 15 bar pressure for the perfect espresso Easy to brand Simple to use no need for an expensive skilled barista Up to 12oz drinks thanks to the large chamber,

SLIDE 1

Kobalto

SLIDE 2

Highlights

Patented Z3000 Necta espresso brewer producing

15 bar pressure for the perfect espresso

Easy to brand
Simple to use no need for an expensive skilled

barista

Up to 12oz drinks thanks to the large chamber,

variable brewer

High performance, suitable for large high volume

sites thanks to two boilers (7.5L instant and 600cc espresso)

Colour coded internal parts for easy maintenance

and operation

Wide drinks menu with a variety of layouts

available

SLIDE 3

Design and User Interface

Elegant and stylish design in stainless steel
Between 8 – 16 direct selection push buttons with

blue LED lights

Large, clear product labels
Coffee waste container easily accessed through the

door behind the dispensing area, without the need for opening the machine

SLIDE 4

Dimensions

Width: 470mm Depth: 570mm Weight 78 Kg Height: 750mm (920mm including bean hopper)

SLIDE 5

UK Specification and layouts

4 canister machine – Coffee Beans, milk, instant coffee and chocolate
7,9 or 12 oz drinks options
Available in espresso version

SLIDE 6

Capacity

Coffee Beans: 1.2Kg Milk: 700g 2 Mixing Bowls Solid Waste Capacity: 150 cakes Drip Tray Capacity: 1.5L Chocolate: 1.7Kg Instant Coffee: 500g

SLIDE 7

Capacity

1 x Coffee Beans 1.2 kg approx 133 cups 1 x Chocolate 1.7 kg approx 83 cups 1 x Instant coffee 0.5 kg approx 350 cups 1 x Milk 0.7 kg approx 90 cups

SLIDE 8

The Range

Kobalto is a welcome addition to N&W’s already established Ho.Re.ca range. This is how the machine fits in with our other machines:

SLIDE 9

Available accessories

Base cabinet Side payment module for coin mech Cup warmer Pump and tank kit
