KeyTec Suzhou (China) presentation Our company Suzhou KeyTec Precision Components Co. Ltd. (China) Established WOFE in 2000 Total investment 18M$ Fully equiped Toolshop Metal & Plastic & Decoration Components & Full

SLIDE 1

KeyTec Suzhou (China) presentation

SLIDE 2

Our company

Suzhou KeyTec PC presentation

Suzhou KeyTec Precision Components Co. Ltd. (China)

➢ Established WOFE in 2000 ➢ Total investment 18M$ ➢ Fully equiped Toolshop ➢ Metal & Plastic & Decoration ➢ Components & Full Assembly ➢ 27000m2 floor space ➢ ISO 14001 certified (2002) ➢ TS 16949 certified (2004) ➢ ISO 13485 certified (2012) ➢ 25 M€ Sales (2013)

SLIDE 3

Bird’s eye view of our facility

Suzhou KeyTec PC presentation

SLIDE 4

Our capacities

Suzhou KeyTec PC presentation

Production Process

Molding Stamping Plating Assembly

Customer delivery

(components or systems)

Manufacturing process Design New Tool build Gages, jigs, aids

Spare parts, maintenanc e

Painting/ decorating

SLIDE 5

Precision Stamping

Suzhou KeyTec PC presentation

➢Floor Space: 1600m2 ➢Presses: 14 (Kaiser, Seyi, Micron) ➢Tonnage: 25T-400T ➢High Speed (800SPM) ➢Deep Drawing ➢Deburring & Cleaning ➢Ultra Sonic Cleaning ➢Auto Bending & Assy

SLIDE 6

Injection Molding

Suzhou KeyTec PC presentation

➢ Machines: 40 (Arburg, Demag, Engel) ➢ Insert Molding (Metal + Plastic) ➢ Clean room Molding ➢ Electric molding ➢ Tonnage: 15-650T ➢ 2K (2shot) molding ➢ Floor space: 2500m2

SLIDE 7

Painting

Suzhou KeyTec PC presentation

➢ Floor Space: 1000m2 ➢ 1 Automatic spindle line ➢ 2 Manual stations ➢ 1 Water-based robot painting line ➢ CO2 Snow, Ionized and Plasma cleaning integrated in robot line

SLIDE 8

Surface treatments for decoration

Suzhou KeyTec PC presentation

➢ Laser Etching ➢ Silk screen Printing ➢ Pad (tampon) Printing ➢ Painting ➢ Plating (outsourced to partner) ➢ Metal PVD on plastic

SLIDE 9

Assembly

Suzhou KeyTec PC presentation

➢Area: 3000m2 ➢Laser Welding ➢Ultra-sonic Welding ➢Adhesive Bonding ➢Solder-Wave Assy ➢Manual assembly ➢High-class Clean Room (class 100K-1K) ➢Additional 1000m2 dedicated to LCD-BL/TP Assembly

SLIDE 10

Tooling

Suzhou KeyTec PC presentation

➢ World-Class Tooling Center established in 2004 ➢ Die/Mold DFM + Development ➢ Spare parts + New Die and Mold manufacturing ➢ Latest investment: Agie Charmilles CUT3000 (2) with 1.5 U and 3D cutting

SLIDE 11

Technology roadmap

Suzhou KeyTec PC presentation

➢Water Based Robot Painting ➢High Precision Wire cutting ( 1.5 micron and 3D cutting) ➢Burr Free Tooling Design ➢Reel to Reel Stamping and Over Molding ➢High Speed Stamping ➢Round Table Over (Insert) molding ➢Ultra clean oil-free stamping ➢Ultra clean molding (plasma, CO2 snow) ➢Vacuum metalization

SLIDE 12

Quality assurance

Suzhou KeyTec PC presentation

➢ISO 9000 (since 2001) ➢ISO 14001 (since 2002) ➢TS 16949 (since 2005) ➢ISO 13485 (TüV, since 2012) ➢APQP/PPAP ➢FMEA & MSA/SPC/G-RR ➢Supplier Quality Assessment (SQA) ➢8D Action, Continuous Improvement, Training ➢Conform to ROHS, REACH Registration

SLIDE 13

Our quality system

Suzhou KeyTec PC presentation

ISO 13485 IATF 16949 ISO 14001

SLIDE 14

Our quality system

Suzhou KeyTec PC presentation

Quality Manual

Procedure Work Instruction Data Forms

APQP PPAP SPC FMEA MSA

Customer’s Requirement

SLIDE 15

“KeyTec-inside”

Suzhou KeyTec PC presentation

SLIDE 16

“KeyTec-inside”

Suzhou KeyTec PC presentation

SLIDE 17

Special metal parts

Suzhou KeyTec PC presentation

Ultra-Thin LCD Frames (0.1mm) Thick bus bars (3.0mm)

SLIDE 18

Special plastic parts

Suzhou KeyTec PC presentation

Over moulding mounting bracket Battery Terminal Cover 2K Moulding Aperture (2mm)

SLIDE 19

Special decorative parts

Suzhou KeyTec PC presentation

Spherical Cover for Vacuum Cleaner Automotive

SLIDE 20

Special automotive parts

Suzhou KeyTec PC presentation

Fuel System Hybrid Electric Vehicle Battery

SLIDE 21

Automotive lighting

Suzhou KeyTec PC presentation

Metal Caps H3 Cable

SLIDE 22

Automotive insert-molding

Suzhou KeyTec PC presentation

Brake Sensor Carrier Coda connector Airbag Ignitor Body SAFETY PARTS

SLIDE 23

Automotive decorative parts

Suzhou KeyTec PC presentation

Main Process: ➢ Molding ➢ Painting ➢ Printing ➢ Laser etching

SLIDE 24

Complete submodule

Suzhou KeyTec PC presentation

Simultaneous 45 Metal & Plastic Components

➢ APQP

➢ DFM ➢ Tool Design ➢ Tool build ➢ Project mgmt ➢ SQA and SQM ➢ PPAP ➢ 39 Mold tools ➢ 6 Dies

SLIDE 25

LCD TV Backlight & Touchpanel

Suzhou KeyTec PC presentation

Components: ➢ Cover Bottom ➢ Cover Driver ➢ Lamprails ➢ Guide Panels ➢ Cleaning Cleanroom assembly ➢ Class 100 ➢ Functional test ➢ End product

SLIDE 26

Professional product: Gas controller

Suzhou KeyTec PC presentation

➢ Valve for USA water heater ➢ Metal parts ➢ Bobbin winding ➢ Welding ➢ Glueing ➢ Testing

SLIDE 27

CADCAM mouse housing

Suzhou KeyTec PC presentation

➢ Metal & Plastic parts ➢ Soft touch painting ➢ Laser Etching and Printing ➢ Heat Staking and Assembly ➢ Complete Module Choice of 3 different processes for the lens: ➢ Mold →Paint → Print → Laser etch → UV paint ➢ Mold →Silk Screen Print ➢ 2K molding

SLIDE 28

Professional end product

Suzhou KeyTec PC presentation

➢ Plastic ➢ Connectors ➢ Printing ➢ PCB surface mounting ➢ Assembly & Testing ➢ End Product

SLIDE 29

Metal evaporation on plastic

Suzhou KeyTec PC presentation

Mold → CO2 cleaning → (base coat paint) → PVD (Physical Vacuum Deposition) →(top coat paint) high gloss molding PVD Plating Print & topcoat

SLIDE 30

Cosmetic dashboard modules

Suzhou KeyTec PC presentation

Painted & printed steering wheel control panel GPS Display Control Panel

SLIDE 31

GPS faceplate in

Suzhou KeyTec PC presentation

Chrysler Sebring and in…… Ferrari California

SLIDE 32
