SLIDE 1

Kernel Implementations III

8 February 2019 OSU CSE 1

SLIDE 2

Implementing a Kernel Class

From the examples so far, you should see

there are two major questions to address:

– Q1: What data representation (a.k.a. data structure) should be used to represent a value of the new type being implemented? – Q2: What algorithms should be used to manipulate that data representation to implement the contracts of the kernel methods?

8 February 2019 OSU CSE 2

SLIDE 3

How To Think About Q1

Two-level thinking: Restrict your attention

to exactly two adjacent levels in the tower

– One is the level for which you are implementing a new kernel class

See the kernel interface for the new type you are

creating

– The other is the level directly below the level for the new kernel class you are creating

See the interfaces for the types of the variables

you are using to represent a value of the new type

8 February 2019 OSU CSE 3

SLIDE 4

8 February 2019 OSU CSE 4

Queue Queue3 implements QueueKernel extends QueueSecondary extends Object extends Standard extends Iterable extends

Example revisited: Queue represented using a Sequence.

SLIDE 5

8 February 2019 OSU CSE 5

Queue Queue3 implements QueueKernel extends QueueSecondary extends Object extends Standard extends Iterable extends

The class Queue3 uses the interface Sequence.

Sequence uses

SLIDE 6

8 February 2019 OSU CSE 6

Queue Queue3 implements QueueKernel extends QueueSecondary extends Object extends Standard extends Iterable extends Sequence uses

The two levels

f the tower of

abstractions for Queue3 are this level with Queue ...

SLIDE 7

8 February 2019 OSU CSE 7

Queue Queue3 implements QueueKernel extends QueueSecondary extends Object extends Standard extends Iterable extends Sequence uses

... and this level with Sequence.

SLIDE 8

Example: Queue3 on Sequence

public class Queue3<T> extends QueueSecondary<T> { private Sequence<T> entries; ... }

8 February 2019 OSU CSE 8

SLIDE 9

public class Queue3<T> extends QueueSecondary<T> { private Sequence<T> entries; ... }

8 February 2019 OSU CSE 9

There is one instance variable (a.k.a. data member) in this representation of a Queue: a Sequence called entries.

Example: Queue3 on Sequence

SLIDE 10

Picture: Queue3 on Sequence

8 February 2019 OSU CSE 10

< 4, 7, 3 > What the client sees: a Queue whose value is < 4, 7, 3 >.

SLIDE 11

Picture: Queue3 on Sequence

8 February 2019 OSU CSE 11

< 4, 7, 3 > < 4, 7, 3 > What the implementer can manipulate: a Sequence whose value is < 4, 7, 3 >.

SLIDE 12

8 February 2019 OSU CSE 12

NaturalNumber NaturalNumber2 implements NaturalNumber- Kernel extends NaturalNumberSecondary extends Object extends Standard extends Comparable extends

Example revisited: NaturalNumber represented using a Stack.

SLIDE 13

8 February 2019 OSU CSE 13

NaturalNumber NaturalNumber2 implements NaturalNumber- Kernel extends NaturalNumberSecondary extends Object extends Standard extends Comparable extends Stack uses

The class NaturalNumber2 uses the interface Stack.

SLIDE 14

8 February 2019 OSU CSE 14

NaturalNumber NaturalNumber2 implements NaturalNumber- Kernel extends NaturalNumberSecondary extends Object extends Standard extends Comparable extends Stack uses

The two levels

f the tower of

abstractions for NN2 are this level with NN ...

SLIDE 15

8 February 2019 OSU CSE 15

NaturalNumber NaturalNumber2 implements NaturalNumber- Kernel extends NaturalNumberSecondary extends Object extends Standard extends Comparable extends Stack uses

... and this level with Stack.

SLIDE 16

Example: NaturalNumber2 on Stack

public class NaturalNumber2 extends NaturalNumberSecondary { private Stack<Integer> digits; ... }

8 February 2019 OSU CSE 16

SLIDE 17

public class NaturalNumber2 extends NaturalNumberSecondary { private Stack<Integer> digits; ... }

8 February 2019 OSU CSE 17

There is one instance variable (a.k.a. data member) in this representation of a NaturalNumber: a Stack<Integer> called digits.

Example: NaturalNumber2 on Stack

SLIDE 18

Picture: NaturalNumber2 on Stack

8 February 2019 OSU CSE 18

724 What the client sees: a NaturalNumber whose value is 724.

SLIDE 19

8 February 2019 OSU CSE 19

724 < 4, 2, 7 > What the implementer can manipulate: a Stack whose value is < 4, 2, 7 >.

Picture: NaturalNumber2 on Stack

SLIDE 20

Two-Level Thinking

8 February 2019 OSU CSE 20

client view: mathematical model, method contracts implementer view: data representation, algorithms

SLIDE 21

Two-Level Thinking

8 February 2019 OSU CSE 21

client view: mathematical model, method contracts implementer view: data representation, algorithms See the kernel interface for a description of what the software behaves like, what the client sees.

SLIDE 22

Two-Level Thinking

8 February 2019 OSU CSE 22

client view: mathematical model, method contracts implementer view: data representation, algorithms See the kernel class for a description of how the software achieves its behavior.

SLIDE 23

Two-Level Thinking

8 February 2019 OSU CSE 23

client view: mathematical model, method contracts implementer view: data structure, algorithms The ovals denote sets

f mathematical

model values, this

ne for the client’s

view of the new type ...

SLIDE 24

Two-Level Thinking

8 February 2019 OSU CSE 24

client view: mathematical model, method contracts implementer view: data structure, algorithms ... and this one for the kernel-class implementer’s view of the chosen data representation.

SLIDE 25

Two-Level Thinking

8 February 2019 OSU CSE 25

This is the abstract state space: the set of all possible math model values as seen by a client.

SLIDE 26

Two-Level Thinking

8 February 2019 OSU CSE 26

This is the concrete state space: the set of all possible math model values of the data representation.

SLIDE 27

Two-Level Thinking

8 February 2019 OSU CSE 27

This is the interpretation of each concrete value (below) as an abstract value (above).

SLIDE 28

Two-Level Thinking

8 February 2019 OSU CSE 28

Example: For interface NaturalNumber this is the set of all integer values that are non- negative. 7 165 29

SLIDE 29

Two-Level Thinking

8 February 2019 OSU CSE 29

Example: For class NaturalNumber2 this is the set of all string of integer values that satisfy the properties we want in the data representation. 7 165 29 <> <7> <9,2> <5,6,1>

SLIDE 30

Two-Level Thinking

8 February 2019 OSU CSE 30

Example: For class NaturalNumber2 the interpretation maps a string of integer to the integer whose decimal digits are those in the string, in reverse order. 7 165 29 <> <7> <9,2> <5,6,1>

SLIDE 31

Implementing a Kernel Class

Recall, there are two major questions to

address:

– Q1: What data representation (a.k.a. data structure) should be used to represent a value of the new type being implemented? – Q2: What algorithms should be used to manipulate that data representation to implement the contracts of the kernel methods?

8 February 2019 OSU CSE 31

SLIDE 32

How To Think About Q2

One-step thinking: Restrict your attention

to the states just before and just after a method call

Combined with two-level thinking about

the data representation, this leads to a device called a commutative diagram

8 February 2019 OSU CSE 32

SLIDE 33

Commutative Diagram

8 February 2019 OSU CSE 33

7 165 29 <> <7> <9,2> <5,6,1> 7 165 29 <> <7> <9,2> <5,6,1> before the method call after the method call

SLIDE 34

Commutative Diagram

8 February 2019 OSU CSE 34

7 165 29 <> <7> <9,2> <5,6,1> 7 165 29 <> <7> <9,2> <5,6,1> This is the abstract transition: for each state before the call, where it might end up according to the method’s contract.

SLIDE 35

Commutative Diagram

8 February 2019 OSU CSE 35

7 165 29 <> <7> <9,2> <5,6,1> 7 165 29 <> <7> <9,2> <5,6,1> This is the concrete transition: for each state before the call, where it might end up according to the method’s body.

SLIDE 36

8 February 2019 OSU CSE 36

7 165 29 <> <7> <9,2> <5,6,1> 7 165 29 <> <7> <9,2> <5,6,1> The contract says that, if n = 0, then the call n.multiplyBy10(7); will result in n = 7.

Example: n.multiplyBy10(7)

SLIDE 37

Example: n.multiplyBy10(7)

8 February 2019 OSU CSE 37

7 165 29 <> <7> <9,2> <5,6,1> 7 165 29 <> <7> <9,2> <5,6,1> So, given any data representation of n = 0, the method body must change it so that after the call it has some data representation of n = 7.

SLIDE 38

Over-Up and Up-Over “Commute”

8 February 2019 OSU CSE 38

7 165 29 <> <7> <9,2> <5,6,1> 7 165 29 <> <7> <9,2> <5,6,1>

SLIDE 39

Over-Up and Up-Over “Commute”

8 February 2019 OSU CSE 39

7 165 29 <> <7> <9,2> <5,6,1> 7 165 29 <> <7> <9,2> <5,6,1> Starting here, going over then up ...

SLIDE 40

Over-Up and Up-Over “Commute”

8 February 2019 OSU CSE 40

7 165 29 <> <7> <9,2> <5,6,1> 7 165 29 <> <7> <9,2> <5,6,1> ... is the same as going up then over.

SLIDE 41

Correctness

The kernel class correctly implements

the kernel interface if and only if, for every method and for every legal input state for that method, the method body (over-then- up) always results in a state that satisfies the method contract (up-then-over)

The commutative diagram lets you think

clearly about how to make your code correct

8 February 2019 OSU CSE 41

SLIDE 42

Some Questions To Think About

Given a kernel class, can there ever be

more than one data representation for a given abstract value? In other words, can there be more than one concrete value that can be interpreted as the same abstract value?

– If so, what would it look like in the diagram?

8 February 2019 OSU CSE 42

SLIDE 43

Some Questions To Think About

Given a kernel interface, can there ever be

more than one possible correct (abstract) result of a call, according to a method’s contract?

– If so, what would it look like in the diagram?

8 February 2019 OSU CSE 43

SLIDE 44

Some Questions To Think About

Given a kernel class, can there ever be

more than one possible correct (concrete) result of a call, according to a method’s body?

– If so, what would it look like in the diagram?

8 February 2019 OSU CSE 44
