Kennedy Station Online Consultation 1 Surface Light Rail Transit 2 - - PowerPoint PPT Presentation

1

Kennedy Station Online Consultation

2

Surface Light Rail Transit

3

Metrolinx LRV

• 4 doors per car (2 single, 2 double)
• Up to 3 cars per consist

4

Light Rail Vehicles (LRVs)

• New LRVs will feature:
• 100% low floors, with level

boarding at stops

• Multiple-entries & Proof of

Payment Fares for fast boarding

• Air conditioning
• Audio and visual passenger information
• Manufactured in Thunder Bay
• High passenger capacity, 1 LRV = 2.5 Buses

5

LRT Operations

• Dedicated transit line for reliable

service

• Predictable travel times
• Traffic signal coordination
• Smooth & comfortable
• Wider stop spacing for

fast service

• Automated fare vending

machines

• Next vehicle arrival

screens

6

Multiple Door Entry

7

Accessible Rail

8

Overview: Design Excellence at Metrolinx

• Design excellence at Metrolinx

refers to the successful interplay between:

• Functionality
• Durability
• Beauty
• Value

9

• 1. A strong conceptual narrative vision across the system
• 2. Design that elevates the quality of the public transit experience
• 3. Civic scale, materiality and quality
• 4. Clarity and simplicity of architectural expression through

integrated design of building systems and elements

• 5. Responsiveness to contextual, local and future conditions

Crosstown Principles of Design Excellence

10

A coherent and unified architectural strategy for the entire Crosstown line

• 1. A Strong Conceptual Narrative Vision across the System

Clear strategy for consistent and variable elements

11

Openness through optimal spatial penetration

• 2. Design that Elevates the Quality of the Public Transit Experience

Optimized daylight penetration

12

Unified ground plan inside and

• utside stations and at stops
• 3. Civic Scale, Materiality and Quality

Civic materials and character of

• pen spaces

13

Integrated structural, mechanical, and electrical systems

• 4. Clarity and Simplicity of Architectural Expression through

Integrated Building Systems and Elements

A clear hierarchy and plan for user-centred integrated information

14

Integration with historic elements

• 5. Responsiveness to Contextual, Local and future Conditions

Sustainability measures

15

• Accessible path from street to platform
• Accessible routes identified
• Station attendant
• Platform edge tactile strip
• Wayfinding tiles on platforms
• Near-level boarding of trains
• Platform edge illumination
• Audible messages throughout stations
• Signage with accessible features
• Designated Waiting Area
• Colour contrast between station walls and floors
• Equipment mounted at accessible heights
• Benches

Crosstown Accessible Features: Stations

16

• Platform edge tactile strip
• Platform edge illumination
• Colour contrast between walls and platform
• Equipment mounted at accessible heights
• Sheltered benches
• Sheltered wheelchair area
• Passenger assistance intercom
• Ramp access to platforms
• Signage with accessible features

Crosstown Accessibility Features: Stops

17

Typical Centre Platform: Example - Bermondsey

18

Bermondsey - Context

Residential Esso Gas Industrial / Commercial Industrial / Commercial

19

Bermondsey

20

Storage Track at Bermondsey

• At key sections along the Crosstown route additional tracks are needed to

ensure vehicle storage and the ability to turn back

• Storage tracks are required in case of unplanned equipment failure
• Required approximately every 4km
• Exact location under review

21

Typical Parallel Side Platforms: Example - Victoria Park, Pharmacy, Birchmount and Ionview

22

Victoria Park - Context

Commercial (Big Box) Eglinton Square Mall Residential Residential Hydro

23

Victoria Park

24

Pharmacy - Context

Commercial Commercial Commercial Commercial Petro Canada

25

Pharmacy

26

Birchmount - Context

Employment Employment Residential Residential Police Station

27

Birchmount

28

Ionview - Context

Residential - Midrise Residential Residential - Midrise Residential - Midrise Commercial Open Space

29

Ionview

30

Typical Far Side Platform Example - Lebovic and Warden

31

Lebovic - Context

Institutional (Ontario Court) Big Box Retail Big Box Retail Big Box Retail Heritage Building

32

Lebovic

33

Warden - Context

Heritage Building Commercial / Big box Retail Commercial / Big box Retail Commercial / Big box Retail Car Dealership

34

Warden

35

Platforms – Day and Night Renderings

36

Kennedy Station Local Context - Demand

Ionview Road Kennedy Road Midland Avenue Eglinton Avenue

+ +

NORTH

37

Kennedy Station Plan View-Phase 1

NORTH

Existing PPUDO New West Entrance Possible Location

• f new TTC TPSS

New GO PPUDO New GO Ticketing Building Existing Bus Terminal to Remain New GO South Tunnel New GO West Platform Existing GO East Platform

38

Kennedy Station Plan View –Phase 2

NORTH

Existing PPUDO New West Entrance New GO PPUDO New GO Ticketing Building Existing Bus Terminal to Remain New GO West Platform Existing GO East Platform Full Extent of future GO West Platform Phase 2:Elevator and Stair to Concourse Future Extension

• f GO West

Platform: Phase 2- after SRT removal

39

Kennedy Station Aerial Perspective

Kennedy Road

New West Entrance Existing PPUDO Existing Bus Terminal to Remain

NORTH

40

Kennedy Station Aerial Perspective Zoom

Existing PPUDO New West Entrance Existing Bus Terminal to Remain

41

Kennedy Station Concourse Level

NORTH

Main Entrance GO Facilities Phase 2: Stair to GO West Platform Phase 2: Stair to GO East Platform Existing South Entrance Existing Stair to GO East Platform Retail Space Phase 2: Elevators GO Platform Future Phase 2: Public Unpaid Link Access to Existing PPUDO Existing Elevator to GO East Platform

42

Kennedy Station Platform Level

NORTH

Existing Bloor-Danforth Subway Platform ECLRT Platform Lower Level Existing Tail-tracks

New Firefighter Access New Firefighter Access

43

Kennedy Station Profile View

Parking West Service Road North Service Road Landscape Band

Multiuse Pathway

Eglinton Avenue

SRT structure to be removed after subway extension

Existing:

• Scarborough RT
• Bus Terminal
• Kennedy subway

station

44

Kennedy Station East-West Section through LRT station

GO East Ticketing Building Underground Connection to ECLRT Phase 2 SRT structure to be removed after subway extension New ECLRT West Entrance

45

New Approach: Alternative Financing and Procurement (AFP)

Public Private Partnership models have been underway in Canada for 20 years

• 165 projects
• 21 transportation projects
• $51 billion total project value

Canada-wide examples

• Canada Line rapid transit project (Vancouver)
• Autoroute 25 (Montréal)
• Trans-Canada Highway (Atlantic Canada)

Ontario examples

• Pan Am games athletes village
• Ottawa Light Rail Transit
• Highway 407 East Phase 1
• The Rt. Hon. Herb Gray Parkway (Formerly the Windsor Essex Parkway)

46

Owner’s Role Changes with AFP

47

New Approach: Advantages of (AFP)

• Increased capacity to bring projects to market
• Transfer of risk
• Appropriate risks transferred to private sector to ensure “on time, on budget”

delivery and offer value for money

• Design, construction, cost escalation, schedule delays, operations, maintenance,

lifecycle, financial risk

• Cost certainty
• Optimal cost combination: combines capital, maintenance and life cycle costs
• Integration of design and construction

48

New Approach: Roles and Responsibilities in the Design Build Finance Maintain model

Design

• Overall scope (inclusion of maintenance,
• perations, etc.)
• Project-Specific Output Specifications

(with Consultant team)

• Real Estate Acquisition (with City of

Toronto)

Build

• Oversee Construction Phase
• Quality Assurance

Finance

• Project Budget
• With Infrastructure Ontario run a competitive

procurement process; select the winning contractor

Maintain

• Testing & Commissioning (with Toronto

Transit Commission)

• Safety Certification and Project Acceptance

TTC to operate

• Integrated with existing TTC system

Metrolinx Role:
