KamLAND Koji Ishidoshiro (Tohoku University) for KamLAND collaboration The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors KamLAND collaboration University of Hida, Japan 46 scientists 11 institutes,

slide-1
SLIDE 1

KamLAND

Koji Ishidoshiro (Tohoku University) for KamLAND collaboration

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

slide-2
SLIDE 2

KamLAND collaboration

Tohoku university University of Tokyo Osaka university University of Alabama Berkeley Colorado State University Hawaii University University of Tennessee University of Washington North Carolina Central University NIKEF

11 institutes, 46 scientists

Hida, Japan March 2013

slide-3
SLIDE 3

Contents

  • KamLAND detector
  • Latest results
  • Next challenges
  • Summary

Note: KamLAND-Zen will be presented in after noon session and poser session.

slide-4
SLIDE 4

KamLAND detector

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

slide-5
SLIDE 5

KamLAND

Kamioka Liquied scintillator Anti-Neutrino Detector (since 2002)

  • 1,000 t liquid scintillator

Dodecan (80%), Psedocumene (20%), PPO (1.36g/l)

  • 1,325 17inch + 554 20inch PMTs

Outer detector (for muon veto)

  • 3.2kton water cherenkov detector
  • ~100 20inch PMTs
  • 1,000 m depth (Kamioka mine)

Φ13m balloon

(125 um thickness)

Φ18 stainless tank

slide-6
SLIDE 6

KamLAND

Anti-neutrino detection: delayed coincidence measurement

¯ νe

p

n n p

d

γ (2.2 MeV)

e+

e−

γ (511 keV) γ (511 keV)

prompt delayed

  • time-spatial correlated events
  • Reduction of background events
slide-7
SLIDE 7

KamLAND

The world cleanest detector

238U 3.5x10-18g/g 232Th 5.2x10-17g/g

Ions are billion time more solvable to water. Wash scintillator with pure water. It is trillion times cleaner than ordinary material

  • r 100 times cleaner than Super-Kamiokande.
slide-8
SLIDE 8

Targets of KamLAND

Largest anti-neutrino detector with ultimate low background. Different neutrino physics in a wide energy range

slide-9
SLIDE 9

History of KamLAND

slide-10
SLIDE 10

Latest results

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

Reactor neutrino Geo-neutrino

slide-11
SLIDE 11

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

Anti-neutrino flux in Kamioka

slide-12
SLIDE 12

Expected spectrum

Normal-reactor phase Low-reactor phase

2 4 6 8 2 4 6 8

Neutrino energy[Mev]

“Reactor on-off” study for neutrino

  • scillation and geo-neutrino analysis
slide-13
SLIDE 13

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

Observed spectrum

slide-14
SLIDE 14

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

L/E plot

slide-15
SLIDE 15

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

Oscillation analysis

slide-16
SLIDE 16

Geo-neutrino

slide-17
SLIDE 17

Motivation of geo-neutrino

componential analysis of chondrite meteorite (Indirect measurement)

Why ?

Geo-neutrino can directly test radiogenic heat production and the BSE model(s).

slide-18
SLIDE 18

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

Results of geo-neutrino

slide-19
SLIDE 19

Comparison with Models

slide-20
SLIDE 20

Next challenges

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

PreSN neutrino Proton decay Future projects

slide-21
SLIDE 21

PreSN neutrino

slide-22
SLIDE 22

Emitted neutrinos in Si burning phase before core-collapse supernova

PreSN neutrino

ACTA PHYSICA POLONOCA B 40, 3063 (2009)

slide-23
SLIDE 23

PreSN neutrino

ACTA PHYSICA POLONOCA B 40, 3063 (2009)

Emitted neutrinos in Si burning phase before core-collapse supernova

slide-24
SLIDE 24

Flux of PreSN neutrino

AIP Conference Proceedings 944, 109 (2007)

3h 6h 12h 24h 48h

Energy is low !!

Only high energy tail (>1.8MeV) is detectable

Nearby events

inverse-beta threshold (1.8MeV)

slide-25
SLIDE 25

Candidates

Nearby supergiants

Red supergiants

  • Antares (170pc)
  • Betelgeuse (200pc)

Wolf-Rayer star

  • Gamma Velorum (340pc)
slide-26
SLIDE 26

No oscillation Normal Inverted

Evis [MeV] Arbitary unit [/0.2MeV]

Expected spectrum

slide-27
SLIDE 27

Expected values

48-24h 24-3h 3-0h Time 1.6 6.1 9.2 Normal 0.7 2.9 4.4 Inverted

Number of events

Model: Betelgeuse like star with d=200pc

slide-28
SLIDE 28

Expected values

48-24h 24-3h 3-0h Time 1.6 6.1 9.2 Normal 0.7 2.9 4.4 Inverted

Number of events

48-24h 24-3h 3-0h Efficiency 50% 98% 99.6% Normal Efficiency 19% 80% 93% Inverted

False rate/yr

1.7 1.3 0.032

Detection efficiency (with present background level)

Model: Betelgeuse like star with d=200pc

slide-29
SLIDE 29

Expected values

48-24h 24-3h 3-0h Time 1.6 6.1 9.2 Normal 0.7 2.9 4.4 Inverted

Number of events

48-24h 24-3h 3-0h Efficiency 31% 95% 99.9% Normal Efficiency 9.4% 62% 94% Inverted

False rate/yr

2.4 1.6 0.38

Detection efficiency (reactor on)

Model: Betelgeuse like star with d=200pc

slide-30
SLIDE 30

Very early alarm

Large uncertainty of detection efficiency:

  • reactor status
  • neutrino mass hierarchy
  • uncertainty of distance
  • models of the stellar evolution

B e t e l g e u s e : 2 ± 5 p c

KamLAND will detect PreSN neutrinos.

Targets: Antares, Betelgeuse, and Gamma Velorum

Very early alarm (before SN neutrino)

Useful for astro committee and neutrino/GW detectors Excellent chance:

  • Measurement of optical shock wave
  • Study on the final stage of the stellar evolution

We are developing the alarm system.

Not miss neutrino/GW from SN

slide-31
SLIDE 31

Proton decay

slide-32
SLIDE 32

Proton decay

KamLAND (and scintillator experiment):

SUSY SO(10): p → K+¯

ν

τ ∼ 1032 − 1034

with

  • Water Cherenkov detector

: below the Cherenkov threshold (253MeV)

K+

sensitive to

K+

Indirect measurement (efficiency ~5%): 5.9x1033yr

yr

decay channel

K+ K+ → µ+νµ K+ → π0π+

(63.54%) (20.68%)

  • KamLAND is searching for with higher efficiency.

p → K+¯ ν

slide-33
SLIDE 33

Features of signal

slide-34
SLIDE 34

Features of signal

Prompt (double pulse) event Delayed event Asymmetry of 1st and 2nd peak

slide-35
SLIDE 35

Simulation of double pulse fitting

1st pulse + 2nd pulse 1st pulse 2nd pulse

slide-36
SLIDE 36

MC simulation (efficiency)

V e r y P r e l i m i n a r y

slide-37
SLIDE 37

Life time

C

  • m

i n g s

  • n

! !

slide-38
SLIDE 38

Future projects

slide-39
SLIDE 39

Future projects

75kCi 144Ce

CeLAND

4th neutrino search Ce source in KamLAND

KamLAND-Pico

Dark matter search NaI in KamLAND Check DAMA result

slide-40
SLIDE 40

Summary

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

slide-41
SLIDE 41

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

KamLAND: the largest anti-neutrino detector Latest results Including reactor-off period

  • Improvements of oscillation parameter
  • Geo-neutrino measurement with low background

Next challenges

  • PreSN monitor system
  • Proton decay (K+v)
  • CeLAND (4th neutrino)
  • KamLAND-Pico (dark matter)
slide-42
SLIDE 42
slide-43
SLIDE 43
slide-44
SLIDE 44
slide-45
SLIDE 45

Geo-neutrino detection

Beta-decay of radioactivities (U, Th, K) in the Earth

slide-46
SLIDE 46

Energy spectrum

reactor (α, n)

slide-47
SLIDE 47

The 14th International Workshop on Next generation Nucleon Decay and Neutrino Detectors

Results of geo-neutrino

slide-48
SLIDE 48

Rate + shape + time analysis

slide-49
SLIDE 49
slide-50
SLIDE 50

Expected events

AIP Conference Proceedings, 944, 109 (2009)

slide-51
SLIDE 51
slide-52
SLIDE 52

Model

Betelgeuse like star Stellar evolution

Astroparticle Physics Volume 21, Issue 3, June 2004, Pages 303–313

  • Mass: 20M
  • Distance: 200pc

Oscillation

F = pF¯

νe + (1 − p)F¯ νx

p : survival probability

slide-53
SLIDE 53

Stellar evolution

ACTA PHYSICA POLONIGA B, 41, 1611 (2010)

slide-54
SLIDE 54

Statistics

200pc and low-reactor status (0.1 event/day)

48-24h 24-3h 3-0h Normal Inverted

slide-55
SLIDE 55

Detection efficiency

48-24h 24-3h 3-0h Efficiency 78%/55% >99% >99% Normal Efficiency 41%/17% 96%/89% >99% Inverted

False rate/yr

1.7/0.06 1.3/0.034 0.032

150pc and low-reactor status 150pc and normal status

48-24h 24-3h 3-0h Efficiency 42% >99% >99% Normal Efficiency 10% 81% >99% Inverted

False rate/yr

0.6 0.4 0.68

  • Final stage is OK !!
  • Early alarm is possible (efficiency > 80%)
slide-56
