Atmospheric Non-thermal Plasma Jet and its Applications Dr. Eng./ Kamal M. A. Ahmed Assistant Professor Egyptian Atomic Energy Authority Introduction 1 Outline Plasma, sources & configurations 2 Plasma Jet Design, components &

slide-1
SLIDE 1

Atmospheric Non-thermal Plasma Jet and its Applications

  • Dr. Eng./ Kamal M. A. Ahmed

Assistant Professor

Egyptian Atomic Energy Authority

slide-2
SLIDE 2

2

1

Introduction

Plasma, sources & configurations

2

Plasma Jet

Design, components & diagnostics

3

Measurements

Electrical & temperature& wettability

4

Plasma Applications

Outline

slide-3
SLIDE 3

3

1

Introduction

2

Plasma Jet

3

Measurements

4

Plasma Applications

Outline

slide-4
SLIDE 4

4

D C B A

Introduction

➢

Plasma in our life

➢

Plasma classifications

➢

Electrical safety & Plasma sources

➢

Plasma configurations

slide-5
SLIDE 5

Plasma definition

5

  • plasmas are mostly generated by electrical

discharges

slide-6
SLIDE 6

Plasma in our life

6

Plasmas occur naturally comprise the majority of the universe (95 or 99).

Natural Plasma

➢ Well-known examples : ▪ the Sun ▪ stars ▪ the ionosphere ▪ Lightning Aurora (U. of Alaska)

Plasmas in Solar physics Lightning

Plasmas in astrophysics

يبطقلا قفشلا

slide-7
SLIDE 7

Plasma in our life

7

but also can be manmade.

Artificial Plasma

  • Lighting
  • Spray

Coatings

Plasma display Melting Cutting Biomedical

slide-8
SLIDE 8

Plasma classifications

8

2.54 GHz

  • kHz
  • 13.56 MHz
slide-9
SLIDE 9

How to produce plasma

9

Power supply HV (1) (2) (3)

What voltage and current are dangerous for humans?

slide-10
SLIDE 10

Electrical safety

10

Current < 30 mA Voltage < 50 V AC, 50 Hz

Electricity in touch

✓ Earthing

slide-11
SLIDE 11

Earthing

11

Device Charged device Earthing rod

slide-12
SLIDE 12

For the measurements devices

12

Should be isolated from the plasma source and the power supply Power supply 220 V 50 Hz Plasma chamber

Measure devices

Isolation transformer ✓ The coaxial cables should be 50 ohm

slide-13
SLIDE 13

Plasma Configurations

13

✓ Glow discharge ✓ DBD ✓ Corona discharge

slide-14
SLIDE 14

Plasma Configurations

14

✓ MHCD ✓ Gliding arc discharge ✓ Plasma focus ✓ Plasma torch

slide-15
SLIDE 15

Plasma Jet Configurations

15

Floating electrode MHCD Coaxial discharge Pin-to-ring discharge

slide-16
SLIDE 16

16

1

Introduction

2

Plasma Jet

3

Measurements

4

Plasma Applications

Outline

slide-17
SLIDE 17

17

01 03 02

Design Goals 1 2

Device Components Dia iagno nosti stics cs

3

Plasma Jet

slide-18
SLIDE 18

Design goals

18

Advantages of Atmospheric plasma NON-thermal (Cold) Plasma Ch/cs Gas selection ection Power source’s choice; Neon Power supply Factors affect the plasma operation Electrode & insulators

1 6 5 4 3 2

slide-19
SLIDE 19

Advantages of Atmospheric plasma

19

➢ No Vacuum equipment's Required ➢ Lower Purchase and Maintenance Costs ➢ Can be operated in open air with large treatment areas. ➢ Minimum cooling is required ➢ Different configurations and geometries are available

Atmospheric plasma

slide-20
SLIDE 20

NON-thermal (Cold) Plasma ch/cs

20

✓ The majority of the electrical energy deposited in the Non-thermal (cold) plasma heats the electrons instead of heating the background gas.

➢ Because the ions and the neutrals remain relatively cold, cold plasmas is used for the treatment

  • f heat sensitive materials including polymers and biological tissues.

➢ Its characteristics include a strong thermodynamic non- equilibrium nature, low gas temperature, presence of reactive chemical species and high selectivity offer a tremendous potential to utilize these cold plasma sources in a wide range of applications.

slide-21
SLIDE 21

Factors affecting the plasma operation

21

(Supply frequency, working voltage, gas type, flow rate, working pressure, electrode spacing and electrode material) HV

Power supply ❑ V? ❑ I? ❑ f(Hz)?

Gas

❑ Type? ❑ P? ❑ Flow rate

Electrodes

❑ Material ❑ Dimensions : spacing & hole ❑ Configuration

Insulator

slide-22
SLIDE 22

Using Air is an advantageous

22

  • Low cost
  • Portability
  • Ozone generation

➢ Higher flow rates helps in Cooling of the system

Endless Air 50% cost reduction

Gas selection ➢ Gas can be Air, H2, He, O2, N2, Ar, CH4,..etc.

slide-23
SLIDE 23

I-V Ch/s

23

V = Vdc - RI

slide-24
SLIDE 24

Power source’s choice

24

The breakdown voltage must exceed

❑ depends on the pressure, p and electrode spacing, d. ❑ Vb will exceed hundred kV for atmospheric pressure ❑ Solution is : MHCD (d in micrometer range)

)] 1 1 ln[ln( )] . ( ln[ ) . (

se b

d p A d p B V  + − =

d=1cm

Atmospheric

d=500 m MHCD

slide-25
SLIDE 25

25

➢

To reduce breakdown voltage, the power supply frequency is increased.

➢

So RF is favored over DC

➢

Low frequency RF is favored due to :

  • Higher Ion Density.
  • Increased Efficiency.
  • Better Uniformity.

What about higher cost of RF Supply

slide-26
SLIDE 26

Neon Power supply

26

Output

10 kV, 30 mA and 20 kHz

✓

A neon power supply is chosen as a low- cost power supply.

slide-27
SLIDE 27

27

Electrode selection Electrode’s material can be

⚫ Stainless steel, ⚫ Aluminum, ⚫ Graphite deposition, ⚫ Copper ⚫ Tungsten ⚫ ….etc

slide-28
SLIDE 28

Insulator selection

28

Material

Melting point(C)

Alumina 2072 Porcelain 1400 Glass 1500 Mica 1250

Teflon 335 Mylar 254

Silicon rubber 200 PVC 160 Acrylic 160

❑ Sustain HV ❑ Stand for high T (melting point)

slide-29
SLIDE 29

ANPJ Atmospheric Nonthermal Plasma Jet

29

slide-30
SLIDE 30

Plasma jet

30

Electrodes Gas inlet Envelope Power supply

slide-31
SLIDE 31

Plasma jet in our lab.

31

Electrodes Gas inlet Envelope PS Mylar Teflon

slide-32
SLIDE 32

ANPJ-II

32

slide-33
SLIDE 33

33

ANPJ-II

Power supply

slide-34
SLIDE 34

Comparison

Previous

ANPJ Device

New

ANPJ-II Device

Only 6 cm3

4%

100% 156 cm3

slide-35
SLIDE 35

Flow system

35

❑ The flow rate in the range from 3 to 25 L/min.

N2 Air

slide-36
SLIDE 36

Plasma jet length

36

slide-37
SLIDE 37

Diagnostics tools

37

slide-38
SLIDE 38

Diagnostic devices

38

Plasma jet device Optical fiber cables To oscilloscope PMT DC power supply Thermometer Neon Power supply N2 gas Variac Spectrometer Voltage probe

slide-39
SLIDE 39

Diagnostics devices

39

✓ Voltage divider ✓ Rogowski coil ✓ Photomultiplier Tube ✓ Optical Emission Spectroscopy ✓ Gas and components’ temperature

slide-40
SLIDE 40

Voltage divider

40

Scale the voltage to be suitable for the measurement device

slide-41
SLIDE 41

Rogowski coil

41

slide-42
SLIDE 42

Temperature measurements

42

✓ thermocouple or IR

Thermometer

 used to measure the gas temperature  Thermocouples act as a transducer converting thermal energies into electrical  Thermocouples are flexible, inexpensive, and provide fairly accurate temperature measurements.

slide-43
SLIDE 43

43

1

Introduction

2

Plasma Jet

3

Measurements

4

Plasma Applications

Outline

slide-44
SLIDE 44

Electrical measurements

Current, voltage and power measurements

44

slide-45
SLIDE 45

Electric circuit

45

Neon power supply 10kV, 30 mA, 20kHz 5 nF Vd (t) i(t) Plasma jet device Gas inlet 21:1 voltage probe 1000:1 voltage probe 0-220 V Vc (t) 25 Ω Variac

slide-46
SLIDE 46

Electrical Ch/s

46

dt ) t ( V ) t ( i T 1 P

d 

=

slide-47
SLIDE 47

Electric Ch/cs Lissajous figure Method

47

dQ ) t ( V T 1 P

d

=

Charge Discharge voltage

slide-48
SLIDE 48

Plume electrical measurements

48

Plasma jet Cathode Anode R2= 9 MΩ R1= 20 kΩ Z=0 mm R3= 1 kΩ Voltage divider Dielectric Probe Oscilloscope (b) (a)

slide-49
SLIDE 49

Plume electrical measurements

49

A safely plasma dose is generated from the plasma jet device even when the exposure time is relatively long (220h).

Plasma power density equals 0.17 mW/cm2 << 135 J/cm2

slide-50
SLIDE 50

Temperature measurements

Gas and electron temperature measurements

50

slide-51
SLIDE 51

Gas temperature

51

<50 oC

Gas T Axial distance

✓ Cold plasma

For heat- sensitive treatments Polymer & biomedical

slide-52
SLIDE 52

Spectroscopy- photomultiplier

52

eV in ) I A g I A g ( ln ) E E ( T k

2 2 1 1 1 1 2 2 2 1 exc

  − =

slide-53
SLIDE 53

Plume intensity

53

N2 Intensity Axial distance

slide-54
SLIDE 54

Species emission from plasma jet

54

Stephan Reuter, J. Phys. D: Appl. Phys. 51 (2018) 233001

✓ Ozone ✓ NO ✓ OH

slide-55
SLIDE 55

Spectroscopy- Spectrometer

55

Glass slide for protection

USB cable

5 mm

Spectrometer

OceanView software

Cable support Slider 5m Optical fiber cable Gas flow Envelope Electrodes Plasma jet

450

slide-56
SLIDE 56

Excitation Electron Temperature (Alg lgorit

  • rithm

hm for

  • r spectrometer)

56 Output Data from Spectrometer Temperature Estimation Peak Identification Peak Modeling Peak Detection Data Acquistion System Equalization Background Subtraction

         − 

k ki k exc

g A I ln E kT

400 500 600 700 800 900 1000 00 500 1000 1500 2000 2500 3000 3500
slide-57
SLIDE 57

Spectrum

57

https://www.nist.gov/

slide-58
SLIDE 58

Electron vs gas temperature

58

11680 <400 K

Tgas Te

~ 1 eV

✓ Cold plasma

slide-59
SLIDE 59

Sine vs pulsed wave comparison

59

Xiong et al., PHYSICS OF PLASMAS 17, 043506 (2010)

Advantages of pulsed

✓ Less temperature ✓ Higher velocity ✓ Less energy consumption

slide-60
SLIDE 60

Wettability

Contact angle measurements

60

slide-61
SLIDE 61

Contact angle & wettability

61

Smaller Contact angle Larger Better Wettability Worse Better adhesiveness Worse

 

slide-62
SLIDE 62

Contact angle Measurements spherical cap approach

62

h Substrate

a α

θ

 =  = 

−

2 ; ) a h ( tan 1

) 3 ( 6

2 2

a h h V + = 

➢

V is known , a is computed, h is calculated

➢

Contact angle is measured

slide-63
SLIDE 63

Contact angle Measurements LBADS approach

63

slide-64
SLIDE 64

Contact angle

64

Contact angle Treatment time

59

14

N2

➢ Wettability improvement of Mylar substrate ▪

by measuring contact angle (spherical cap, LBADS)

slide-65
SLIDE 65

Ink removal

65

slide-66
SLIDE 66

Ink removal

66

slide-67
SLIDE 67

Etching area

67

Etching Area Treatment time

slide-68
SLIDE 68

Plasma applications

68

slide-69
SLIDE 69

69

Water treatment Plasma chemical removal of corrosion Surface/Polymer treatment

Bacterial inactivation/ Wound healing In In dentistry istry

Antimicrobial treatment of foods In Agriculture

slide-70
SLIDE 70

Water treatment

70

https://ieeexplore.ieee.org/document/6184321/figures#figures

slide-71
SLIDE 71

Plasma chemical removal of corrosion

71

Before treatment After treatment

slide-72
SLIDE 72

Surface treatment

72

slide-73
SLIDE 73

Polymer treatment

73

https://www.sciencedirect.com/science/article/abs/pii/S0008622316307977

Etching of CNT patterns on PET Increasing the adhesive process Cleaning

slide-74
SLIDE 74

Bacterial inactivation

74

slide-75
SLIDE 75

Wound healing

75

slide-76
SLIDE 76

In dentistry

76

▰ https://physicsworld.com/a/plasmas-are-cool-for-dental-disinfectio

slide-77
SLIDE 77

Antimicrobial treatment of foods

77

Control

slide-78
SLIDE 78

In Agriculture

78

➢ Increase rooting speed ➢ Reduce water consumption ➢ Enhance seed germination ➢ Stimulate plant growth ➢ Prevent pests

slide-79
SLIDE 79

Useful Software/Article resources

79

❑ http://gen.lib.rus.ec/ ❑ EKB يرصملا ةفرعملا كنب ❑ Researchgate ❑ Sci-hub.tw ❑ Facebook groups ❑ https://www.facebook.com/groups/ResearchPaperThesisArticlesandBooks/ ❑ https://www.facebook.com/groups/paperreqest/ ❑ https://www.facebook.com/groups/ScientificPapers/ ❑ https://www.facebook.com/groups/literaturefree/

✓ MATLAB ✓ ORIGIN ✓ ENGAUGE DIGITIZER ✓ IMAGEJ

Useful Software

For Latex beginner's

https://www.overleaf.com

slide-80
SLIDE 80

THANKS!

An Any qu quest estions? You can find me at Kamal_hagag@yahoo.com https://www.facebook.com/kamal.abdelaziz 01 0109 094146 46069
