JET GROUP DAYLIGHT AND SHEV SOLUTIONS DRIVEN BY DAYLIGHT

page 2

www.jet-group.com.hr

JET Group is the market leader for flat roof solutions with continuous rooflights, light domes and smoke and heat exhaust solutions

• I. Introduction of the JET Group

AGENDA

• II. Products of the JET Group
• III. Project Example
• IV. JET Group References

page 3

www.jet-group.com.hr

Product Category Product Examples

• JET Group manufactures and sells products and

systems that provide: ‒ Daylight entrance through the roof ‒ Ventilation solutions ‒ Smoke and heat exhaust solutions

• Thereby creating:

‒ An optimal energy balance ‒ A comfortable, healthy and safe environment for users of buildings

• For both, residential and non-residential

applications

• Active in whole Europe
• 685 employees in the JET Group
• Annual turnover of 157 mio. EUR

JET Group is the market leader for flat roof solutions with continuous rooflights, light domes and smoke and heat exhaust solutions

• I. Introduction of the JET Group

page 4

www.jet-group.com.hr

The JET Group offers a full range of products and services focusing on the roof light and ventilation market.

1 2

Light domes Continuous rooflights SHEV systems / Ventilation products Service & Maintenance

1 2 3

Overview of Product Portfolio for Export Markets

4 3

Full Range of Superior Branded Solutions

• II. Products of the JET Group

page 5

www.jet-group.com.hr

Light domes are a versatile flat roof solution for daylight management and natural ventilation

• Standard light domes are a

cost-effective solution for natural daylight

• Multi-layered domes provide

high energy efficiency

• Numerous opening

possibilities as well as SHEV solutions

• Numerous additional

solutions against hail, burglary, fall and fall through Description

1

• II. Products of the JET Group

page 6

www.jet-group.com.hr

• JET continuous rooflights are

large sources of daylight up to a width of 12 m

• Flaps in combination with SHEV

technology provide safety and daily ventilation solutions

• Heat insulation profiles provide

a high isothermal performance

• JET continuous rooflights have

certified fall through protection systems and patented profiles Description

JET continuous rooflight systems provide light, air and safety for industrial buildings of all dimensions

2

• II. Products of the JET Group

page 7

www.jet-group.com.hr

• 2. Continuous rooflights
• II. Products of the JET Group

SHEV opening angles: Full flap  165° Side/ Beam / Crown flap  130° Double flap  95°

rooflight with double flap (for ventilation and SHEV)

page 8

www.jet-group.com.hr

VARIO-NORM

• 2. Continuous rooflights
• II. Products of the JET Group

page 9

www.jet-group.com.hr

VARIO-NORM

• 2. Continuous rooflights

JET VARIO-NORM rooflight

• II. Products of the JET Group

page 10

www.jet-group.com.hr

VARIO-THERM

• 2. Continuous rooflights
• II. Products of the JET Group

page 11

www.jet-group.com.hr

Isothermal detail

with basement-connection-profile VARIO-THERM

• 2. Continuous rooflights
• II. Products of the JET Group

page 12

www.jet-group.com.hr

JET has achieved the European Technical Assessments (ETA) for VARIO-NORM and VARIO-THERM rooflights

European Technical Assessments (ETA)

• 2. Continuous rooflights
• II. Products of the JET Group

page 13

www.jet-group.com.hr

• JET SHEV systems are tested

and certified according to DIN EN 12101-2

• Systems can be opened

pneumatically and electrically

• All SHEV units can optionally

be used for daily ventilation

• Our 24V / 48V SHEV devices

guarantee maximum safety in case of fire Description

SHEV systems and ventilation products combine daylight solutions with fire prevention systems

3

• II. Products of the JET Group

page 14

www.jet-group.com.hr

Full flap (ventilation) Full flap (pneumatical / 24V SHEV-function)

• JET-SHEV-systems fulfill the requirements of DIN EN 12101-2
• II. Products of the JET Group
• 3. SHEV systems / Ventilation products

page 15

www.jet-group.com.hr

Light Domes (ventilation function) Light Domes (pneumatical / 24V SHEV-function)

• II. Products of the JET Group
• 3. SHEV systems / Ventilation products
• JET-SHEV-systems fulfill the requirements of DIN EN 12101-2

page 16

www.jet-group.com.hr

Certificate of constancy of performance EN12101-2

• II. Products of the JET Group
• 3. SHEV systems / Ventilation products

page 17

www.jet-group.com.hr

Certificate of constancy of performance EN12101-2

• II. Products of the JET Group
• 3. SHEV systems / Ventilation products

page 18

www.jet-group.com.hr

• II. Products of the JET Group
• 3. SHEV systems / Ventilation products

Aa – values light domes Aa – values rooflight flaps

page 19

www.jet-group.com.hr

• II. Products of the JET Group
• 3. SHEV systems / Ventilation products

Reasons for SHEV – systems

page 20

www.jet-group.com.hr

• II. Products of the JET Group
• 3. SHEV systems / Ventilation products

Building after a fire without SHEV systems

Reasons for SHEV – systems

page 21

www.jet-group.com.hr

• Regionally based installation

teams install our products under consideration of the local requirements

• JET provides service and

maintenance for SHEV and glazing systems

• In addition, a large range of

safety products for all product ranges is provided

• All safety products are tested

and certified Description

Regionally based service teams with skilled SHEV system technicians provide service & maintenance

4

• II. Products of the JET Group

page 22

www.jet-group.com.hr

• III. Project Example

Requirements from planner :

• 1% aerodynamical smoke exhaust area*
• 2.600 mm roof opening width
• Fixed quantities and sizes of continuous rooflights
• Co² SHEV system

Section 1 4.758 m² 1% = 47,58 m² Section 3 1.698 m² 1%=16,98 m² Section 2 1.756 m² 1%=17,56 m² Section 4 10.570 m² 1% = 105,07 m² Section 5 2.410 m² 1%=24,10 m²

*this value is variable and depending on requirements

page 23

www.jet-group.com.hr

• III. Project Example

page 24

www.jet-group.com.hr

JET-Group – References

Example of rooflight flap text in offers and order confirmations:

• III. Project Example

page 25

www.jet-group.com.hr

JET-Group – References

Calculation

Section 1  4.758 m²  1% = 47,58 m² needed smoke exhaust area Solution: 20 flaps Aa – value: 2,387 m²  47,74 m² Section 2  1.756 m²  1% = 17,56 m² needed smoke exhaust area Solution: 7 flaps Aa – value: 2,387 m² + 1 flap Aa – value: 1,17 m² = 17,879 m² Section 3  1.698 m²  1% = 16,98 m² needed smoke exhaust area Solution: 7 flaps Aa – value: 2,387 m² + 1 flap Aa – value: 1,17 m² = 17,879 m² Section 4  10.570 m²  1% = 105,7 m² needed smoke exhaust area Solution: 18 flaps Aa – value: 3,71 m² + 16 flap Aa – value: 2,387 m² 2 flaps Aa – value: 1,17 m² = 107,31 m² Section 5  2.410 m²  1% = 24,1 m² needed smoke exhaust area Solution: 10 flaps Aa – value: 2,387 m² + 2 flap Aa – value: 1,17 m² = 26,21 m²

• III. Project Example

page 26

www.jet-group.com.hr Project Facts:  14 JET VARIO NORM continuous roof lights with 20 mm IR control green glazing 2,80 x 12,20 m  16 JET VARIO NORM continuous roof lights with 20 mm IR control green glazing 2,80 x 6,20 m  84 JET smoke-heat exhaust and ventilation flaps

• III. Project Example

page 27

www.jet-group.com.hr Rijeka / Croatia Project Facts:  192 JET VARIO NORM continuous rooflights fix / 2,65 x 5,52 m

• IV. JET Group References

page 28

www.jet-group.com.hr Cerna / Croatia Project Facts:  6 JET VARIO NORM continuous rooflights 2,20 x 5,60 m incl. SHEV flaps

JET-Group – References

• IV. JET Group References

page 29

www.jet-group.com.hr Varaždin / Croatia Project Facts:  81 JET VARIO NORM continuous rooflights up to 2,15 x 21,20 m incl. ventilation flaps

• IV. JET Group References

Thank you for your attention!

Contact details: Viktor Schneider Tamara Svjetlicic Export Area Manager Sales Representative Phone: +49 5744 503 132 Phone: +385 1 8895 581 Email: vschneider@jet-gruppe.de Email: tsvjetlicic@jet-gruppe.de
