ITALIAN INNOVATION AND TECHNOLOGY

www.topsystemdrive.com - info@topsystemdrive.com

HYSTORY

Top System was born in Latina (Italy) in 1999. Driven by their passion for boats and mechanical engineering , Vincenzo with his brother Alessio Tuccio, founded their company in their family’s mechanic workshop. In 2001 after the succesful results obtained from the first trials, Vincenzo and Alessio decided to expand their business further by producing a full range of surface drive systems. In 2004 Top System company started a commercial partnership with SAIM MARINE company. It was at this point that the product begun to be appreciated and endorsed by several famous boat builders. In 2006 Top System worked for Pershing yacht on Pershing 50’ (to solve problems encountered with concurrent systems) In 2008 Top System started a new production in Tunisia, that is where our main workshop is located. In 2009 Top System produced TS 120: the biggest surface drive In 2010 Top System started supplying military naval departments In 2014 Pershing started his production with TS Drive on P70 In 2015 Pershing put TS Drives on all range of Pershing boats. In 2016 TOP SYSTEM AMERICA INC. was born In 2017 Easy Set revolutionary system with joystick without tie bar

COMPANIES

TS DRIVE SRL

LATINA ITALIA

TS SERVICE SARL

ENFIDHA TUNISIA

TOP SYSTEM AMERICA INC

FORT LAUDERDALE FLORIDA

SURFACE DRIVES

MAIN IMPORTANT TS FEATURES

• REVOLUTIONARY JOINT SYSTEM , DIVERSE FROM THE ORDINARY ONES IN THE MARKET
• INTERACTIVE “EASY SET SYSTEM” WHICH PROVIDES AUTO CONTROL OF TRIM AND FLAPS
• COMPLETE PACKAGE INCLUDING PROPELLERS
• INNOVAVITE DOCKING SYSTEM, THE FIRST IN HISTORY OF SURFACE DRIVES
• STAINLESS STEEL MADE : Robust – resistant to staining -corrosion- heat damage and chemical change. Has lifelong

durability and is even eco-friendly as it’s 100 % recyclable.

• LARGE RANGE OF OPTIONS - 12 MODELS FROM 100 to 3000 KW power: we are the exclusive producers of bigger

models with torsional load up to 25.000 Nm, such as TS 120 and TS 150.

• COMPETITIVENESS: we pride ourselvels on providing our clients with short delivery time - reliable assistance – large

inventory and competitive pricing

• CUSTOMIZATION: conducted studies in the design for special applications- providing made-to-order systems.
• RESEARCH: Continuous development of the product range, paying attention to the evolution of the engines

Top System surface drive on Pershing

Top system’s started collaborating with Pershing in 2006 because of several problems encountered with the pre-existing system

• n P50.

To address and solve those problems Top System developed a new custom drive named Ts75P. Another important addition project pertains Pershing 70 with model Ts85P. This model was designed according to specific Pershing yacht’s requirements. Top system differs from previously systems adopted by Pershing boats for the shape of the drive, material of construction ( stainless steel) and above all for the joint’s system which is engineered to allow the four movements to the drive. The shape of the drive is designed to optimize the flow of water on the propeller. Specifically, the directional fin, inserted in a flush mounted manner, provides a flawless, smooth surface around the propeller hub, thus insuring an unobstructed water flow before the propeller. EASY SET the control becomes totally automatic. Shipyards and owners often judged the transmission surface with skepticism as, in spite of providing performances superior to any

• ther type of installation, they lacked in maneuverability of the hull.

To dispel this prejudice, in recent years the company TS DRIVE Srl, owner of the Topsystem Surface Drive brand, has established partnerships with leader realities of the electronic and naval automation sector with the objective to sharpen new technologies, which could guarantee the installation of high performance surface transmissions without sacrificing comfort and maneuverability. Thus was born the system “EASY SET” which is studied in synergy with, the leading companies in the electronic and naval automation sector XENTA and ONYX.

2017

Top System surface drive on Pershing

The system is composed by a series of components which interact with each other for an automated control of the vessel, and to allow to maneuver the transmissions by employing only the maneuvering joystick developed by XENTA, without the coupling rod. The experience was refined after a long collaboration with Pershing Yacht through the installation of high performance propulsion systems on shipyard’s models . Such models are integrated with devices able to electronically and independently adjust the transmissions with trim and variable direction. The electronic system, developed for Pershing , employs a software which automatically adapts to the propulsions’ position depending on the boat loading conditions and on the revolutions of the engine. In this way, by intervening on both , trim and flap, the vessel achieves its highest performance. To improve the driving experience, XENTA has developed a type of helm-by-wire steering system capable of enhancing the response’s qualities and reliability of the hydraulic actuation system, with the exceptional characteristics tactile-feeling of a steering wheel mechatronics. The mechatronics applied to steering systems is the state of the art also in the automotive world of sports cars. In the semi-active version of the wheel , according to the sail conditions, is possible to control the hardness and the wheel race to adapt the steering system’s response to the vessel gait, and therefore to make the steering safe and precise. The active version is capable, thanks to the technologically advanced mechatronics system, to arouse all those rider’s sensations typical of driving a sports car. The system varies the resistance, viscosity and the inertia of the wheel running on the basis of the boat gait, so as to transfer to the pilot the maximum feeling and full control. In the active version the wheel is self-centering. The wheel goes back to the center independently whenever the driver releases it, exactly as it happens with the steering wheel of a car. The wheel goes back to the center in a controlled manner to guarantee the perfect return to the boat’s route. Once in the route, the system continues to actuate the rudders as to guarantee the maintenance of the route even in windy conditions or current which normally require the intervention of the pilot.

Top System surface drive on Pershing

The maneuvering joystick XENTA, developed for the surface transmissions is a further integrated component of the system EasySet which represents a historic transition since the joystick handles the total control of both transmissions. The two rudder-drive move independently because are not joined together by any coupling rod. The Joystick allows two different modes of operation: Docking and Cruise. In the “Docking” mode maneuver, the propulsion devices are managed independently allowing the captain to concentrate on the more suitable maneuver and leaving to the system the task of defining the action of the engine and thrusters. In this manner, 360 degree rotations and translations constitute simple actions to perform. During Navigation is possible to activate the mode “Cruise” which allows to accelerate and steer the boat by using only the joystick. The software manages the drives independently in order to vary the distance between the two propellers so as to find the optimum performance point. A crucial optional of this module is the DPS ( Dinamic Position System) which commands independently the vessel keeping it in a static position in the desired point. The all System is controlled by a monitor touch-screen which is positioned in the dashboard and which can be personalized electronically with different functionalities. For instance, to ensure the safety of the guest on board of high performance vessels, this device can manage the control of the angle rudder according to the boat’s speed. On the touch- screen monitor is even possible to personalize the driving style according to the condition of the ocean. Obviously the manual commands are always available to ensure the maximum driving pleasure in the constant pursuit of maximum performance. Lastly, the software can also be upgraded with extra features to allow the visualization of the tanks levels or, to manage auxiliary controls such as handling platform, safety blocks, tender-lift, etc.

EASY SET TRADE MARK

EXCLUSIVE PRODUCTS

• EASY SET

Trim – flap - pitch –roll automatic control system

• EASY DOCKING

joistick control for docking and cruise

• HELM by WIRE

Eletronic Helm

TYPE OF TRASMISSION TT TS TE

MODELS RANGE 2018

Model

Hp max @propeller RPM Max torque Input NM Pleasure Max torque Input NM Duty

TS 40

420@2500

1.400 1.100 TS 45

380@1400

2.000 1.600 TS 55

500@1400

2.600 2.000 TS 65

770@1300

4.300 3.500 TS 75

1150@1100

7.300 5.500

New TS 80

1550@1100

11.000 7.000 TS 85

1650@920

13.000 9.600 TS 95

1950@980

17.000 11.000

New TS 100

2400@980

20.500 14.000

New

TS 110

2650@890

23.000 19.000 TS 120

2900@815

30.000 24.000 TS 150

4300@760

41.500 33.000

GREAT RESULT ON PERSHING YACHT

In collaboration with Ferretti group, our company developed many optional Easy trim control, Easy DOCK and several custom models.

Model Weight FOR COMPLETE KIT Pershing boat application Max torque Input NM Pleasure Boats carried for FG TS/TT /TE 40 120 1.400 TS/TT/TE 45 150 2.500 TS/TT /TE 55 220 2.800 TS /TT/TE 65 360 4.300 TS/TT 75X 420 PERSHING 50.01 & 5 X 7.300 30 TS/TT 75S 700 PERSHING 62 11.000 10 TS/TT 85 P 1000 PERSHING 70 / FSD 195 (CUSTOM MADE) 13.000 25

New TS 80

705 11.000

• TS/TT 95 P

1650 PERSHING 82 2400HP(CUSTOM MADE) 17.000 03 TS 95S 2200 PERSHING 82 2600HP 20.000 10

New TS 100

2215

20.500

• New

TS 110

2400

23.000

• TS 105 DOUBLE

TS 105 TRIPLE 2400 3600 PERSHING 9X 2600HP PERSHING 108 2600HP 22.000 22.000 04 03 TS 120 2400 30.000 TS 150 2800 41.500

TOP SYSTEM DRIVES models

COMPONENTS

TRANSOM ASSEMBLY RUBBER PROTECTIVE BELLOWS

DRIVE

PROPELLER SHAFT TRIM CYLINDER

COVER

REMOVABLE DIRECTIONAL FIN

Top System is manufactured entirely in stainless steel. The system is composed

• f three main components:

TRANSOM ASSEMBLY — JOINT RNG - COUPLING DRIVE (stern tube)

PRODUCTION & COMPONENTS

The drive coupling system is achieved by means of a special universal joint system designed by our company. The coupling system provides absolute strength and simplicity of use. Above all, it guarantees high performance, thanks to the “trimming” transmission. Another important function of the coupling system is that it supports the torsion loads of the whole equipment. (In other propulsion systems with spherical couplings, this function is carried out by the trim cylinder).

TOP SYSTEM JOINT

TOP SYSTEM JOINT

In practical applications the coupling system employs two fixing supports. These supports are connected, one to the stern of the vessel and the other to the stern tube which holds the propeller; these supports provide the required angular adjustment for the coupling ( =30°) which in turn allows the propellers’ desired degree of immersion. The supports are composed of two threaded bores, positioned at 180° into which is screwed the bush, responsible for the tightening of the sphere.

OTHER SYSTEM

TOP SYSTEM TECHNOLOGY

The movement of the ring joint absorbs the totality of the momentum generated by the rotation of the propeller and of the shaft inside the stern tube. In this manner, the whole force is transmitted, to the transom assembly,through the stern transom of the boat

TOP SYSTEM TECHNOLOGY

Neutral condition: Centre of rotation perfectly balanced and homokinetic. Condition with rotation of one cross-member along the Y-axis: The centre of rotation continues to retain its position even if the cross-members are at an angle: homokinetic condition. Rotation condition for one cross-member along the Y and Z-axes: The centre of rotation continues to retain its position even if the cross-members are at an angle: homokinetic conditions.

The bellows in the system have two functions: To protect the coupling from sea water by making it watertight; to contain the lubricating oil for the joints. In order to manufacture this type of bellows, research and tests were carried out so as to obtain a mixture of Nitrile rubber, which is resistant to oil, abrasion and flame.

BELLOWS AND COMPONENTS

Two new developments pertain the coupling arrangement of the trim’s tabs, and the steering control cylinders. Both, in view of their dimensions, benefit from TS spherical coupling system used on the drives for the smaller models. This solution, apart from giving greater strength to the supports, also creates a watertight passage in the hydraulic tubes. Finally, studies have been carried out to design a new protection system of the shaft seals, which has already became the “war horse” of all the Top System models. This system, is significantly effective in preventing foreign bodies from damaging the hydraulic seals.

TECHNICAL DEVELOPMENTS

Prop safety cover Special Nut locking system for props

TECHNICAL DEVELOPMENTS

FIN RUDDER

TECHNICAL

The lubrication circuit is composed of 2 separate rooms: One room for shaft One room for socket and rubber On TS 100/105/110/and120 the lubrification system is

• nly one chamber.

It is possible to change the oil without haul out the vessel

LUBRIFICATION

Top System Easy-Set is an revolutionary system for the automatic control of the boat’s attitude, by means of trim tabs and shaft trimming. Thanks to a powerful processor capable of processing navigation parameters in real time, Easy-Set constantly adjusts the angle of the trim tabs and propeller shafts to obtain:

• the perfect attitude at any time,
• ptimum performance,
• maximum fuel efficiency,
• comfort during navigation.

EASY SET

Functions:

• control of trim tabs and shaft

trimming

• steering assistance
• roll stabilization
• steering limitation at high speed
• maneuvering assistance
• shaft parking
• engine data monitoring

EASY SET

HARDWARE OVERVIEW

ENGINE ENGINE

EASY SET

Functions:

• control of trim tabs and shaft trimming
• steering assistance
• roll stabilization
• steering limitation at high speed
• maneuvering assistance
• shaft parking
• engine data monitoring
• aft platform control

EASY SET

Functions:

• control of trim tabs and shaft trimming
• steering assistance
• roll stabilization
• steering limitation at high speed
• maneuvering assistance
• shaft parking
• engine data monitoring
• aft platform control
• water and fuel tank monitoring

EASY SET

SERVICE LEVELS

• 1. Free-access service page
• Check single units status
• Check communication with peripherals
• Read firmware version
• Take pictures of SYSTEM STATUS page,

ALARMS page and HISTORY page and send them to TopSystem service office!

• 2. Password-protected service page
• Check input signals status
• Manual comands (be careful)
• Calibrate the system after hardware replacement

EASY SET

SERVICE LEVELS

• 3. Remote assistance
• Advanced diagnostic
• Firmware upgrade
• Windows 7, 8, 8.1, 10
• Onyx Marine Software Pack
• Teamviewer 11

Internet

Ethernet patch

EASY SET

Top System EASY DOCK is the new joistick innovative control system for surface drive The two drives are not connected by tie bar

EASY DOCK

Over the years Top System ‘s fundamental activity has been in the service and care of its customers. It’s by making customer care our top priority , that we established a superior image in the market. In fact, we are especially known for offering our customers innovative solutions under very special terms and

• prices. Also, the versatility of our product, together with our ability to customize it to satisfy the market’s

demands, has endowed us with an even greater competitive advantage. To conclude, thanks to the ease of construction, our system also became particularly appreciated by the end users, who endorsed it for all the Pershing models.

SERVICE

WARRANTY

All the systems’ spare parts are generally in stock in our warehouse. As far as concerns wear parts like bellows , pipes, filters etc. every service point must have a back-up supply to meet the demands of the area in question. On all the parts we offer one-year warranty.

PARTS

SERVICE NETWORK ITALY

REGIONE COMPANY LOCATION LIGURIA TASSARA MOTORI RAPALLO LIGURIA BASE NAUTICA GENOVA TOSCANA CECCHI FULVIO SARDEGNA NAUSIKA BOAT SERVICE OLBIA SARDEGNA SNO OLBIA CAMPANIA SUPER VEE NAPOLI CAMPANIA MORRACASSO CASTELLAMMARE DI STABIA LAZIO RIZZARDI SERVICE LAZIO NAUTICA AZZURRA GAETA PUGLIA MARINE SERVICE MARINA DEL GARGANO VENETO PMI SERVICE SICILIA AMANTEO SNC LIPARI

SERVICE NETWORK WORLD

REGIONE AZIENDA E LOCALITA’ FRANCIA EAMS COSTA AZZURRA SPAGNA SIA MARINE IBIZA E BALEARI SPAGNA DUEMME YACHT SERVICE ALICANTE GRECIA SEA FRONT PIREO ATENE TURCHIA KRAKEN MARINE INDUSTRIES LTD

SERVICE NETWORK WORLD

REGIONE AZIENDA E LOCALITA’ EMIRATI ARABI

L B S DUBAI

AMERICA

USA MARINE ASSISTANCE LLC ATLANTIC MARINE NY P&L MARINE FL

INDIA

MARINE SOLUTION MOMBAY-GOA

IRAN

DATA MARINE TEHERAN

THAILANDIA

EVENGY LTD – POUKHET

NORD AFRICA

TS SERVICE SARL
