Is the growth rate of N 2 O increasing? Brad Hall 1 , Geoff Dutton 2 , Ed Dlugokencky 1 , David Nance 2 , Debbie Mondeel 2 , Patricia Lang 1 , Andrew Crotwell 2 , James Elkins 2 1 NOAA/ESRL 2 University of Colorado/CIRES 2015 Global Monitoring

slide-1
SLIDE 1

Is the growth rate of N2O increasing?

Brad Hall1, Geoff Dutton2, Ed Dlugokencky1, David Nance2, Debbie Mondeel2, Patricia Lang1, Andrew Crotwell2, James Elkins2

1NOAA/ESRL 2University of Colorado/CIRES

2015 Global Monitoring Annual Conference, Boulder, CO

slide-2
SLIDE 2

agricultural soils natural soils

  • cean

industry biomass burning

  • ther

25% 25% 40%

N2O Source Distribution

Total source ~17 Tg-N yr-1 Total sink ~13 Tg-N yr-1

slide-3
SLIDE 3

Interannual Variability

– Thompson et al, 2013 – Ishijima, et al, 2009

  • ENSO, QBO
  • soil moisture
  • temperature

Seasonal Cycle

– Nevison et al, 2011 – Hamilton and Fan, 2000

  • STE
  • ocean exchange (thermal)

Global Emissions (inverse model, ecosystem model)

  • Thompson et al, 2014
  • Saikawa et al, 2014
  • Huang et al, 2008
  • Tian et al, 2015
slide-4
SLIDE 4

Global mean N2O

AGAGE data: https://agage.mit.edu/data/agage-data

slide-5
SLIDE 5

Instrumentation/Methods/Programs

slide-6
SLIDE 6

CATS CCG Otto

N2O growth rate

slide-7
SLIDE 7

Focus on 2002-2013: Expanded global coverage, improved instrumentation

slide-8
SLIDE 8

ppb yr-2

2ND Order Term, least squares fit: ppb yr-2 (2002-2013)

Individual programs at select measurement sites

0.005 0.01 0.015 0.02 0.025 alt brw mhd mlo kum smo cgo psa spo CATS in situ Otto flask CCG flask

slide-9
SLIDE 9

2ND Order Term, least squares fit: ppb yr-2 (2002-2013)

Zonal Means from CCG flask data ppb yr-2

0.000 0.005 0.010 0.015 0.020 0.025

Arctic NH Temp. NH Tropics SH Tropics SH Temp. global

slide-10
SLIDE 10

Ammonia (kilo tonnes) International Fertilizer Industry Association

10 000 20 000 30 000 40 000 50 000 60 000 70 000 80 000 2000 2005 2010 2015 North America East Asia EU 10 000 20 000 30 000 40 000 50 000 60 000 70 000 80 000 2000 2005 2010 2015 North America West Asia South Asia

Urea (kilo tonnes)

slide-11
SLIDE 11

Recent Emission Trends from Modeling Studies

South Asia, Asia

  • N. America, Europe

Tropical S. America, Africa

  • Fig. 6 from Tian et al, 2015 {doi/10.1890/EHS14-0015.1}

Inversion Ecosystem

slide-12
SLIDE 12

Zonal means: well-resolved gradients

slide-13
SLIDE 13

Compare N2O zonal averages

slide-14
SLIDE 14

Compare to SF6

Growth Rate

slide-15
SLIDE 15

Summary

  • N2O growth rate increasing since ~2003

>> acceleration: 0.014-0.016 ppb/yr2

  • observed globally
  • higher growth rates in S.H.
  • mean growth rate in 2013: ~1 ppb/yr
  • inter-hemispheric difference is decreasing

>> ~0.15 ppb over 10 years

  • influence of climate drivers on tropical S.H.

emissions?

slide-16
SLIDE 16

end

slide-17
SLIDE 17
slide-18
SLIDE 18

N2O Growth Rate: 2002-2013 period

slide-19
SLIDE 19

Calibration: Reproducibility ~0.1 ppb (1-sigma)

slide-20
SLIDE 20
slide-21
SLIDE 21

CPC Soil Moisture data provided by the NOAA/OAR/ESRL PSD, Boulder, Colorado

Monthly mean soil moisture

slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24

N2O at Barrow, Alaska
