IPv6 and Internet2 Update IPv6 and Internet2 Update

Heather BOYLES <heather@internet2.edu> and Matt ZEKAUSKAS <matt@internet2.edu> From slides developed by Bill CERVENY <cerveny@internet2.edu> 2005 IPv6 Summit in Taiwan August 23, 2005 Heather BOYLES <heather@internet2.edu> and Matt ZEKAUSKAS <matt@internet2.edu> From slides developed by Bill CERVENY <cerveny@internet2.edu> 2005 IPv6 Summit in Taiwan August 23, 2005

slide-2
SLIDE 2

2

Contents Contents

  • Internet2 and Abilene Overview
  • History
  • Participants and Connectors
  • Deployment
  • Addressing
  • Multicast
  • Measurement
  • Member Activities
  • Commitment
slide-3
SLIDE 3

3

Internet2 Goals Internet2 Goals

  • Create a leading edge network capability

for the national research community

  • Enable revolutionary Internet applications
  • Ensure the rapid transfer of new network

services and applications to the broader Internet community.

slide-4
SLIDE 4

4

Abilene Network Abilene Network

  • OC-192c over unprotected DWDM

waves with SONET framing

  • Original design of current upgrade

was as a dual stack IPv4/IPv6 network

slide-5
SLIDE 5

5

Abilene Partners Abilene Partners

  • Indiana University
  • Juniper Networks
  • Nortel Networks
  • Qwest Communications
  • North Carolina, Ohio, San Diego and

Texas ITECs

slide-6
SLIDE 6

6

Abilene Backbone Abilene Backbone

slide-7
SLIDE 7

7

Abilene Participation

May 2005

Abilene Participation

May 2005

  • 44 direct connections (OC-3c → 10 GigE)
  • 5 10-GigE connections (10 Gbps)
  • 6 OC-48c connections (2.5 Gbps)
  • 3 Gigabit Ethernet connections (1 Gbps)
  • 30 connections at OC-12c (622 Mbps) or smaller
  • 235 participants – research universities &

laboratories

  • All 50 states, District of Columbia & Puerto Rico
  • Expanded access
  • 125 sponsored participants
  • 34 state education networks
  • Active IPv6 participation at all levels
slide-8
SLIDE 8

8

Abilene Peering Abilene Peering

  • Peering Methods
  • Exchange point
  • Direct peering to backbone router
  • Peering through GigaPoPs, through tunnels or BGP

multihop

  • IPv6 and IP Multicast Peering Policy – open peering

policy, with transit if desired – different from IPv4

slide-9
SLIDE 9

9

Abilene Peering - Connectivity Abilene Peering - Connectivity

  • Connectivity to Exchange Points
  • MANLAN (Internet2/NYSERnet partnership) – 10

GigE

  • PacWave-Seattle – 10 GigE
  • PacWave-LA – 10 GigE
  • Starlight – 2 x 10 GigE
  • NGIX East – 10 GigE
  • NGIX West – 1 GigE in very near future
  • Palo Alto PAIX – 333Mbps
  • MCI MAE – OC-3
slide-10
SLIDE 10

10

Last updated: May 2005

Abilene Federal/Research Peering Abilene Federal/Research Peering

slide-11
SLIDE 11

11

Last updated: May 2005

Abilene International Peering Abilene International Peering

slide-12
SLIDE 12

12

Abilene IPv6 History Abilene IPv6 History

  • Substantial input from the Internet2

IPv6 working group

  • Tunnel network deployed 2001
  • Migration to native, dual stack

implementation at end of 2001 (Cisco 12008)

  • Native dual stack was default for the

upgrade (OC 192 + Juniper T640)

  • Early testing
slide-13
SLIDE 13

13

IPv6 Participants and Connectors IPv6 Participants and Connectors

  • Participants: 56
  • Connectors: 26
  • Peers: 34
  • 1 Corporate
  • 3 Federal
  • 26 International
slide-14
SLIDE 14

14

Abilene IPv6 Growth Abilene IPv6 Growth

IPv6 Participant/Connector/Peer Growth 10 20 30 40 50 60 Sep-00 Dec-00 Mar-01 Jun-01 Sep-01 Dec-01 Mar-02 Jun-02 Sep-02 Dec-02 Mar-03 Jun-03 Sep-03 Dec-03 Mar-04 Jun-04 Sep-04 Dec-04 Mar-05 Date Participants Connectors Peer Netw orks

slide-15
SLIDE 15

15

Additional IPv6 Deployment Additional IPv6 Deployment

  • Backbone unicast enabled
  • Routing – BGP and IS-IS
  • 6 to 4 tunnel relays:
  • Indiana University
  • Pittsburgh Supercomputer Center
slide-16
SLIDE 16

16

Deployment Issues Deployment Issues

While Abilene and Gigapops are IPv6- enabled, a “last mile” problem persists as it relates to IPv6. Theories:

  • Hardware doesn’t support IPv6
  • Application server time-outs
  • Difficulty convincing administrators of value
  • Ensuring security isn’t being compromised
  • Application protocols don’t support IPv6

Source: Joe Breen, University of Utah

slide-17
SLIDE 17

17

IPv6 Security IPv6 Security

  • Abilene NOC activities:
  • Limiting the v6 prefixes connectors send us as

we do for IPv4

  • Limited filtering for peer networks
  • New v6-security e-mail list
slide-18
SLIDE 18

18

Deployment Issues Deployment Issues

  • [This is an old slide, but unfortunately,

its still true]

  • Many monitoring tools are missing,

impacting security

  • Schools are reluctant to deploy fully

because of potential for attacks

  • For example, difficulty in supporting access

lists that monitor address/port number – extended header implementation problem

slide-19
SLIDE 19

19

IPv6 Multicast IPv6 Multicast

  • Abilene is IPv6 Multicast enabled, but is

not currently part of the global m6bone infrastructure

  • NYSERnet, New York’s research and

education network, is configuring IPv6 Multicast across their backbone

slide-20
SLIDE 20

20

IPv6 Traffic Map IPv6 Traffic Map

slide-21
SLIDE 21

21

Abilene IPv4/IPv6 Measurement Abilene IPv4/IPv6 Measurement

  • Backbone measurements via IPv4 and IPv6:
  • BWCTL – Bandwidth Control
  • OWAMP – One Way Active Measurement

Protocol

  • Measurements to and from Abilene backbone
  • http://e2epi.internet2.edu/pipes/ami/pmp-info.html
  • Difference between IPv6 and IPv4

performance on Abilene is indistinguishable

slide-22
SLIDE 22

22

IPv4/IPv6 Comparative Performance Graphics IPv4/IPv6 Comparative Performance Graphics

slide-23
SLIDE 23

23

IPv4/IPv6 Comparative Performance Review IPv4/IPv6 Comparative Performance Review

  • Reviewed Abilene backbone 180 TCP

throughput (iperf) measurements for a specific period – May 12 around 13:00 UTC.

  • Measurement systems have 1GigE interfaces
  • Measurements averaged 980Mbps with IPv4

tests and 977Mbps with IPv6 tests

  • IPv6 lags IPv4 TCP throughput by about .1 -

.3 percent for most measurements across same links.

  • Other than saying that IPv6 performance

differences are insignificant, do these measurements say anything else?

slide-24
SLIDE 24

24

Internet2 Member IPv6 Activities Internet2 Member IPv6 Activities

  • North Carolina State University and Centaur Labs
  • - IPv6 streaming audio feeds from radio stations

WCPE and WZYC

  • IPv6 H.323 at Georgia Tech
  • NYSERnet experimenting with IPv6 Multicast via

the international M6bone effort

  • IPv6 Multicast Demo at Fall Member Meeting in planning

stages

  • Abilene IPv6-enabled hosts
  • http://ipv6.internet2.edu/ipv6hosts.shtml
slide-25
SLIDE 25

25

Applications Applications

  • Currently monitoring applications like
  • VRVS (CalREN)– IPv6 support in

development

  • Internet2 detective – detecting IPv6
  • DVTS (Wide)
  • Preliminary interest in finding synergies

with amateur radio community and IPv6

slide-26
SLIDE 26

26

IPv6 Routing IPv6 Routing

  • Revising policies for IPv6 routing with

international peers and commercial networks (via experimental, non-production peerings)

  • Some of revised policies may apply to IPv4

unicast and multicast

  • Feedback from Abilene connectors and

international peer networks is being solicited

  • IPv6 Transit options from commercial IPv6

network provider under investigation

slide-27
SLIDE 27

27

IPv6 Routing (continued) IPv6 Routing (continued)

  • Question: Should Abilene Network advertise

routes received from Asian-Pacific peer networks to other Asian-Pacific Networks?

  • Policies being considered:
  • If peer network wishes to send Abilene both non-

commercial and commercial routes, commercial routes should/must be tagged with a commercial community string

  • Routing policy should be symmetric between

Abilene and peer network

slide-28
SLIDE 28

28

Support for IPv6 Support for IPv6

  • Tutorials
  • Two day workshops, hands-on experience
  • Descriptions and planning guides
  • http://ipv6.internet2.edu/workshops/index.shtml
  • http://ipv6.internet2.edu/workshops/setup/
  • Alternate discussion/lecture with hands-on

lab exercises

  • Slides are available
  • http://ipv6.internet2.edu/presentations/
slide-29
SLIDE 29

29

Internet2 Commitment Internet2 Commitment

  • Internet2 is committed to deploying an IPv6

native dual stack network for the research community.

  • Internet2 is committed to encouraging

connectors, peers, and members to fully deploy IPv6 on their networks.

  • Internet2 will monitor IPv6 penetration in

the future to provide guidance to the community.

  • Network penetration.
  • Availability of software and tools
  • Security Issues
slide-30
SLIDE 30

30

For Further Information … For Further Information …

  • References
  • http://www.internet2.edu
  • http://abilene.internet2.edu
  • http://www.abilene.iu.edu
  • http://ipv6.internet2.edu
slide-31
SLIDE 31
