IPv4 Run-Out And the consequences Alex Semenyaka | UADOM, Kyiv | 6 December 2019 Timeline 2011 IANA ran-out of /8s 15 Sept 2012 RIPE NCC: exhaustion - final /22 per member 17 April 2018 RIPE NCC: final 185/8 block depleted 25

slide-1
SLIDE 1

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

And the consequences

IPv4 Run-Out

slide-2
SLIDE 2

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

2

Timeline

  • 2011 IANA ran-out of /8s
  • 15 Sept 2012 RIPE NCC: exhaustion - final /22 per member
  • 17 April 2018 RIPE NCC: final 185/8 block depleted
  • 25 November 2019, 14:35 UTC: last /22 run-out
slide-3
SLIDE 3

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

Remaining IPv4 Pool in Millions

3

slide-4
SLIDE 4

Alex Semenyaka | Yandex Next Hop, Moscow | 7 October 2019

4

slide-5
SLIDE 5

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

5

Reserved IPv4

  • /13: temporary assignments
  • Approx. /16: Internet Exchange Points (IXPs)
  • Of /15 reserved for this purposes
  • With the current rate, enough for 10 years more
  • /13: quarantine
  • Will be allocated later
  • IPv4 dust
slide-6
SLIDE 6

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

6

  • Supported by the IPv4 policy
  • First, you have to become LIR.
  • Only if you did not already get an

allocation from the RIPE NCC

  • /24

The Waiting List

slide-7
SLIDE 7

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

7

Addresses being returned

  • Continues after run-out
  • Closures
  • Recovered space: approx. 2000 /24s in 2019
slide-8
SLIDE 8

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

8

What about other RIRs?

APNIC AfriNIC LACNIC ARIN

slide-9
SLIDE 9

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

  • Trading in IPv4 is inevitable
  • Priority accurate registry
  • Current policy:
  • IPv4 transfers are allowed
  • 24 month holding period

Transfers: RIPE community 2012 response

9

slide-10
SLIDE 10

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

  • You have to have a LIR status to get a PA block
  • PI cannot be used to make further assignments to other

parties.

  • Both IPv4 and IPv6
  • Even 1 address
  • Thus, PI is suitable for Internet resources, but for ISPs
  • There was no strict control over this rule, but it can be invented

PI vs PA

10

slide-11
SLIDE 11

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

11

IPv4 Lifespan Extension


Rearranging Deck Chairs on the Titanic

slide-12
SLIDE 12

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

12

IPv6 in Ukraine

  • The grows just

started

  • Current level is

sufficiently lower than the world average: 27%, according to Google

  • IPv6 operators:
  • Netassist
  • ITL.ua
  • Triolan
  • ?
slide-13
SLIDE 13

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

13

IPv6 in Ukraine

  • There are powerful reasons for such a low IPv6 penetration
  • However, nursing these causes instead of trying to fight them

will now lead to operational problems for operators

  • It is easies for content providers, and they can help telecom
  • perators
  • Content over IPv6 saves money on NAT/CGNAT expanding
slide-14
SLIDE 14

Alex Semenyaka | UADOM, Kyiv | 6 December 2019

Popularity of IPv6-capable websites

14

Source of data BigMir Liveinternet InAU Similar Web TNS Number of resources 300 300 3000 25 50 25 IPv6-enabled, % 30,0% 30,7% 25,9% 36,0% 32,0% 24,0% Protected by Cloudflare, % 27,3% 24,7% 11,9% 4,0% 10,0% 0,0% Native IPv6 support, % 2,7% 6,0% 14,0% 32,0% 22,0% 24,0%

} }

Count only local resources Include global resources (Google, Facebook etc)

  • It makes perfect

sense for operators to implement IPv6

  • The most popular

resources are IPv6- enabled (Google, Youtube, Facebook)

  • Cloudflare helps
  • Most of local

resources do not see the reason to turn IPv6 on

slide-15
SLIDE 15

?

Questions
