MATRIX SATATYA

IP CAMERAS

❖

Key Features

❖

Camera Details

❖

Technical Specifications

❖

Contact Us

AGENDA

• Very Expensive Products
• Smaller Market and Difficult to Sell
• Slow Sales Cycle
• Brand over Product Performance
• High Profits and Less Competition
• Gain Customer Loyalty
• Value for Money
• Quick Support
• Faster Sales Cycle
• Low Profits and Very High Competition
• Loss of Your Credibility
• Lose Customer in the Long Run
• Inferior Quality and Lack of Support

Overpriced Brands Matrix SATATYA Cheap Products

THE VIDEO SURVEILLANCE MARKET

3-Dimensional Benefits of Matrix Video Surveillance

Reduction in Solution Cost Improved Productivity Simplicity of Management Better Reliability Greater Visibility & Control Enhanced Security Improved Safety Proactive Solution

MATRIX SATATYA

KEY FEATURES

BETTER IMAGE QUALITY

LOW LIG IGHT PERFORMANCE

• Exceptional low light performance with color

images at 0.08Lux SONY STARVIS series sensors

• Matrix IP Cameras are powered with Sony STARVIS series sensors with EXMOR

technology.

• It is a back-illuminated sensor, where there is no internal reflection and hence

reduced noise.

• Higher photon absorption capacity leads to exceptional low light performance.

TECHNOLOGY

CONSISTENT PERFORMANCE

• The camera smartly varies its exposure time

and rectifies the over-exposed and under- exposed areas in the scene thus giving more informative and clear image. TRUE WDR

WDR: OFF WDR: ON (120dB)

• Wide dynamic range takes two

samples of the image, one at slow shutter speed for the dark area, and one at fast shutter speed for the bright area, and combines them into one image.

• Both the extreme lighting

conditions can be captured well by this feature.

TECHNOLOGY

GREATER COVERAGE

• IP Camera 3.6mm Lens: FOV 90°
• IP Camera 6mm Lens: FOV 56°

HIGHER FIELD OF VIEW

• Field of view (FOV) is a measure of

how large an area a camera is capable of viewing.

• The FOV is based on the camera and

lens.

• Increasing the lens’ focal length

decreases the perceived distance to the viewing area, but also decreases the area that the camera is able to view.

TECHNOLOGY

BANDWIDTH AND STORAGE OPTIMIZATION

LATEST COMPRESSION TECHNIQUE

• Save 50% on bandwidth and storage

H.264 H.265 BANDWIDTH

Matrix Matrix Bit Bit-rate:130 rate:1300kbp 0kbps

Other Other Bit Bit-rate:2500kbps rate:2500kbps

TECHNOLOGY

• In traditional H.264, each micro

block is fixed irrespective of the regional information.

• However, in H.265, the size of the

block is determined by the regional

• information. The blocks are smaller

when minute information is to be displayed.

OPTIMIZED STORAGE

• Automatic frame rate reduction during no

activity period ADAPTIVE STREAMING

Matrix Matrix Bit Bit-rate: 800kbps Fps:15fps Fps:15fps

Other Other Bit Bit-rate: 2500kbps rate: 2500kbps Fps:25fps Fps:25fps

TECHNOLOGY

• Automatically reduces frames per second based on the activity in the region.
• Saves cost on storage, up to 40%

OPTIMIZED STORAGE

• Divides a single stream into multiple bitrates

based on its importance

Matrix Matrix Only the important parts of the image are in high resolution, saving bandwidth.

Other Other All parts of All parts of the image are in high the image are in high resolution resolution

SMART STREAMING

TECHNOLOGY

OPTIMIZED BANDWIDTH

• REGION OF INTEREST: Allows streaming and recording of only critical areas from the

entire image REGION OF INTEREST

• FOUR STREAM SUPPORT: Different streams for viewing, storing and recording

FOUR STREAM SUPPORT

ONBOARD STORAGE

• Edge recording support up to 128GB

SD CARD SUPPORT

CONECTIVITY

• Communication with the server is initiated

from camera’s end

• No Public

IP required for centralized monitoring PUSH TECHNOLOGY

INTELLIGENT VIDEO ANALYTICS

MOTION DETECTION

• Helps you mark critical areas where motion should not occur. If motion occurs, it

sends instant notifications.

IN INTRUSION

• Provides notification on entry or exit from a high security or dangerous area.

TRIP IPWIRE

• It identifies any motion over a defined virtual line. This can be extremely useful in

perimeter security by virtual fencing.

ALERTS

EMAIL WITH SNAPSHOT SNAPSHOT SCHEDULE PRE/POST ALARM RECORDING SMS UPLOAD IMAGE/CLIP

OTHER EVENTS

NETWORK DISCONNECT IP CONFLICT STORAGE ALERT

RELIABLITY

• Bigger Metal Enclosure with Better Heat

Dissipation and Sturdiness RUGGED CONSTRUCTION

CERTIFICATIONS

*IK10 for Dome Variants Only

MADE IN INDIA

All of this, Indigenously designed and manufactured in India!

40% of Matrix employees are engaged in R&D

24x7 SUPPORT

• Excellent Pre-sales Support: Solution designing and implementation

support.

• Excellent Post Sales Support: Ensuring that none of our partners are

stranded at any time.

• Case Locking: Matrix authorization and support restricted to one

partner per case.

MATRIX SATATYA

CAMERA DETAILS

CAMERA NOMENCLATURE

PRODUCT RANGE

2.8-12mm MVL 2.8-12mm MVL 3.6mm 6mm 2.8-12mm

2MP 3MP 2MP 3MP PTZ

MATRIX SATATYA

TECHNICAL SPECIFICATION

PTZ CAMERAS

• In built Analytics: Intrusion Detection and

Tripwire

• 30x Optical Zoom, 4.3-129mm Varifocal lens
• 6 Pieces IR Array LEDs with IR Distance of

120m

• 1 Audio Input and 1 Audio Output
• 1 Alarm Input and 1 Alarm Output
• H.264/M-JPEG, Quad Stream
• 128GB SD Card
• IP66, TVS 4,000V Lightning Protection
• CE, RoHS and UL Certified

MATRIX CAMERAS SATATYA CIBR20FL36CWS Fixed lens SATATYA CIBR20FL60CWS Fixed lens SATATYA CIBR20VL12CWS Varifocal lens Sensor type and size

SONY - CMOS 2MP Active Pixel Progressive Scan, Back Illuminated Image sensor(Exmor Technology - STARVIS Series) Size: 1/2.8"

Spectral response

300nm - 1000nm

Minimum illumination(b/w)

0 Lux with IR LED On

Minimum object distance

0.3m

IR led type

4 - Array LEDs

IR range

Up to 30m

Focal length

3.6mm 6mm 2.8-12mm

HFOV( degrees)

90° 56° 98° to 33°

Aperture

F 1.2 F 1.2 F 1.4 – F 2.8

Iris control

No Yes

Zoom

No Yes(Manual)

Focus

No Yes(Manual)

2MP BULLET CAMERAS

MATRIX CAMERAS SATATYA CIBR20FL36CWS Fixed lens SATATYA CIBR20FL60CWS Fixed lens SATATYA CIBR20VL12CWS Varifocal lens Maximum Resolution

1920*1080(2MP) @ 30fps

Available Resolutions

1080p(2MP)/720p/D1/2CIF/CIF

Stream Profiles

Four streams are supported Profile 1: 2MP up to 30fps (H.265/H.264) Profile 2: D1 up to 5fps (MJPEG) Profile 3: D1 up to 30fps (H.265/H.264) Profile 4: 720p up to 30fps (H.265/H.264/MJPEG)

• Max. Number of

Simultaneous Streams

4

Bitrate Type

CBR/VBR

Bitrate

512Kbps - 4Mbps

Video Compression

H.265/H.264/MJPEG

Frame Rate

1 - 30fps

GOP

1 - 100

Shutter Speed

1/12500s to 1/25s

Adaptive Stream

Yes

Smart Stream

Yes (Max. 3 Windows)

ONVIF Profile

S

2MP BULLET CAMERAS

MATRIX CAMERAS SATATYA CIBR20FL36CWS Fixed lens SATATYA CIBR20FL60CWS Fixed lens SATATYA CIBR20VL12CWS Varifocal lens ROI

Yes

BLC

Yes

White Balance

Auto/Fluorescent/Incandescent/Sunny

Digital Zoom

Yes

E-PTZ

Yes

Digital WDR

Yes

True WDR

Yes

Noise Filter(2DNR)

Yes (Auto/Manual)

3DNR

Yes (Auto/Manual)

Image Enhancement

Saturation/ Contrast/Brightness/Hue/Sharpness/Rotate

Edge Recording

Yes

Network Recording

Yes

Image-Snapshots

Yes

Standard POE

802.3af

SD card

Yes (Up to 128 GB)

Power Supply

12V/2A

Power Consumption

Less than 7W

LAN Port Speed

10/100 Mbps

2MP BULLET CAMERAS

MATRIX CAMERAS SATATYA CIBR20FL36CWS Fixed lens SATATYA CIBR20FL60CWS Fixed lens SATATYA CIBR20VL12CWS Varifocal lens Motion Detection

Yes

View Tamper

Yes

Line intrusion/ Directional motion/ Trip Wire

Yes

Zone Intrusion

Yes

IP-Conflict

Yes

Network-Disconnect

Yes

Storage Alert

Yes

Actions

Email/TCP/ SMS Notifications , Alarm Recording & Image/Clip Upload

Operating Temperature/Humidity

0 to 50 Degree Celsius

FCC Part-15 Class-B

Yes

Ingress Protection

IP66

Weight

920gm

2MP BULLET CAMERAS

MATRIX CAMERAS SATATYA CIDR20FL36CWS Fixed lens SATATYA CIDR20FL60CWS Fixed lens SATATYA CIDR20VL12CWS Varifocal lens Sensor type and size

SONY - CMOS 2MP Active Pixel Progressive Scan, Back Illuminated Image sensor(Exmor Technology - STARVIS Series) Size: 1/2.8"

Spectral response

300nm - 1000nm

Minimum illumination(b/w)

0 Lux with IR LED On

Minimum object distance

0.3m

IR led type

30-Through-hole LEDs

IR range

Up to 30m

Focal length

3.6mm 6mm 2.8-12mm

HFOV( degrees)

90° 56° 98° to 33°

Aperture

F 1.2 F 1.2 F 1.2

Iris control

No Yes

Zoom

No Yes(Manual)

Focus

No Yes(Manual)

2MP DOME CAMERAS

MATRIX CAMERAS SATATYA CIDR20FL36CWS Fixed lens SATATYA CIDR20FL60CWS Fixed lens SATATYA CIDR20VL12CWS Varifocal lens Maximum Resolution

1920*1080(2MP) @ 30fps

Available Resolutions

1080p(2MP)/720p/D1/2CIF/CIF

Stream Profiles

Four streams are supported Profile 1: 2MP up to 30fps (H.265/H.264) Profile 2: D1 up to 5fps (MJPEG) Profile 3: D1 up to 30fps (H.265/H.264) Profile 4: 720p up to 30fps (H.265/H.264/MJPEG)

• Max. Number of

Simultaneous Streams

4

Bitrate Type

CBR/VBR

Bitrate

512Kbps - 4Mbps

Video Compression

H.265/H.264/MJPEG

Frame Rate

1 - 30fps

GOP

1 - 100

Shutter Speed

1/12500s to 1/25s

Adaptive Stream

Yes

Smart Stream

Yes (Max. 3 Windows)

ONVIF Profile

S

2MP DOME CAMERAS

MATRIX CAMERAS SATATYA CIDR20FL36CWS Fixed lens SATATYA CIDR20FL60CWS Fixed lens SATATYA CIDR20VL12CWS Varifocal lens ROI

Yes

BLC

Yes

White Balance

Auto/Fluorescent/Incandescent/Sunny

Digital Zoom

Yes

E-PTZ

Yes

Digital WDR

Yes

True WDR

Yes

Noise Filter(2DNR)

Yes (Auto/Manual)

3DNR

Yes (Auto/Manual)

Image Enhancement

Saturation/ Contrast/Brightness/Hue/Sharpness/Rotate

Edge Recording

Yes

Network Recording

Yes

Image-Snapshots

Yes

Standard POE

802.3af

SD card

Yes (Up to 128 GB)

Power Supply

12V/2A

Power Consumption

Less than 7W

LAN Port Speed

10/100 Mbps

2MP DOME CAMERAS

MATRIX CAMERAS SATATYA CIDR20FL36CWS Fixed lens SATATYA CIDR20FL60CWS Fixed lens SATATYA CIDR20VL12CWS Varifocal lens Motion Detection

Yes

View Tamper

Yes

Line intrusion/ Directional motion/ Trip Wire

Yes

Zone Intrusion

Yes

IP-Conflict

Yes

Network-Disconnect

Yes

Storage Alert

Yes

Actions

Email/TCP/ SMS Notifications , Alarm Recording & Image/Clip Upload

Operating Temperature/Humidity

0 to 50 Degree Celsius

FCC Part-15 Class-B

Yes

Ingress Protection

IP66

Weight

1400gm

2MP DOME CAMERAS

MATRIX CAMERAS SATATYA CIBR30FL36CWS Fixed lens SATATYA CIBR30FL60CWS Fixed lens SATATYA CIBR30VL12CWS Varifocal lens Sensor type and size

SONY - CMOS 2MP Active Pixel Progressive Scan, Back Illuminated Image sensor(Exmor Technology - STARVIS Series) Size: 1/2.8"

Spectral response

300nm - 1000nm

Minimum illumination(b/w)

0 Lux with IR LED On

Minimum object distance

0.3m

IR led type

4 - Array LEDs

IR range

Up to 30m

Focal length

3.6mm 6mm 2.8-12mm

HFOV( degrees)

82° 52° 88° to 30°

Aperture

F 1.2 F 1.2 F 1.4 – F 2.8

Iris control

No Yes

Zoom

No Yes(Manual)

Focus

No Yes(Manual)

3MP BULLET CAMERAS

MATRIX CAMERAS SATATYA CIBR30FL36CWS Fixed lens SATATYA CIBR30FL60CWS Fixed lens SATATYA CIBR30VL12CWS Varifocal lens Maximum Resolution

2048*1536(3MP)@ 30fps

Available Resolutions

2048*1536(3MP)/1080p(2MP)/720p/D1/2CIF/CIF/QCIF

Stream Profiles

Four streams are supported Profile 1: 3MP up to 30fps (H.265/H.264) Profile 2: D1 up to 30fps (H.265/H.264) Profile 3: D1 up to 5fps (MJPEG) Profile 4: 720p up to 30fps (H.265/H.264/MJPEG)

• Max. Number of

Simultaneous Streams

4

Bitrate Type

CBR/VBR

Bitrate

512Kbps - 8Mbps

Video Compression

H.265/H.264/MJPEG

Frame Rate

1 - 30fps

GOP

1 - 100

Shutter Speed

1/12500s to 1/25s

Adaptive Stream

Yes

Smart Stream

Yes (Max. 3 Windows)

ONVIF Profile

S

3MP BULLET CAMERAS

MATRIX CAMERAS SATATYA CIBR30FL36CWS Fixed lens SATATYA CIBR30FL60CWS Fixed lens SATATYA CIBR30VL12CWS Varifocal lens ROI

Yes

BLC

Yes

White Balance

Auto/Fluorescent/Incandescent/Sunny

Digital Zoom

Yes

E-PTZ

Yes

Digital WDR

Yes

True WDR

Yes (120dB)

Noise Filter(2DNR)

Yes (Auto/Manual)

3DNR

Yes (Auto/Manual)

Image Enhancement

Saturation/ Contrast/Brightness/Hue/Sharpness/Rotate

Edge Recording

Yes

Network Recording

Yes

Image-Snapshots

Yes

Standard POE

802.3af

SD card

Yes (Up to 128 GB)

Power Supply

12V/2A

Power Consumption

Less than 7W

LAN Port Speed

10/100 Mbps

3MP BULLET CAMERAS

MATRIX CAMERAS SATATYA CIBR30FL36CWS Fixed lens SATATYA CIBR30FL60CWS Fixed lens SATATYA CIBR30VL12CWS Varifocal lens Motion Detection

Yes

View Tamper

Yes

Line intrusion/ Directional motion/ Trip Wire

Yes

Zone Intrusion

Yes

IP-Conflict

Yes

Network-Disconnect

Yes

Storage Alert

Yes

Actions

Email/TCP/ SMS Notifications , Alarm Recording & Image/Clip Upload

Operating Temperature/Humidity

0 to 50 Degree Celsius

FCC Part-15 Class-B

Yes

Ingress Protection

IP66

Weight

920gm

3MP BULLET CAMERAS

MATRIX CAMERAS SATATYA CIDR30FL36CWS Fixed lens SATATYA CIDR30FL60CWS Fixed lens SATATYA CIDR30VL12CWS Varifocal lens Sensor type and size

SONY - CMOS 2MP Active Pixel Progressive Scan, Back Illuminated Image sensor(Exmor Technology - STARVIS Series) Size: 1/2.8"

Spectral response

300nm - 1000nm

Minimum illumination(b/w)

0 Lux with IR LED On

Minimum object distance

0.3m

IR led type

4 - Array LEDs

IR range

Up to 30m

Focal length

3.6mm 6mm 2.8-12mm

HFOV( degrees)

82° 52° 88° to 30°

Aperture

F 1.2 F 1.2 F 1.4

Iris control

No Yes

Zoom

No Yes(Manual)

Focus

No Yes(Manual)

3MP DOME CAMERAS

MATRIX CAMERAS SATATYA CIDR30FL36CWS Fixed lens SATATYA CIDR30FL60CWS Fixed lens SATATYA CIDR30VL12CWS Varifocal lens Maximum Resolution

2048*1536(3MP)@ 30fps

Available Resolutions

2048*1536(3MP)/1080p(2MP)/720p/D1/2CIF/CIF/QCIF

Stream Profiles

Four streams are supported Profile 1: 3MP up to 30fps (H.265/H.264) Profile 2: D1 up to 30fps (H.265/H.264) Profile 3: D1 up to 5fps (MJPEG) Profile 4: 720p up to 30fps (H.265/H.264/MJPEG)

• Max. Number of

Simultaneous Streams

4

Bitrate Type

CBR/VBR

Bitrate

512Kbps - 8Mbps

Video Compression

H.265/H.264/MJPEG

Frame Rate

1 - 30fps

GOP

1 - 100

Shutter Speed

1/12500s to 1/25s

Adaptive Stream

Yes

Smart Stream

Yes (Max. 3 Windows)

ONVIF Profile

S

3MP DOME CAMERAS

MATRIX CAMERAS SATATYA CIDR30FL36CWS Fixed lens SATATYA CIDR30FL60CWS Fixed lens SATATYA CIDR30VL12CWS Varifocal lens ROI

Yes

BLC

Yes

White Balance

Auto/Fluorescent/Incandescent/Sunny

Digital Zoom

Yes

E-PTZ

Yes

Digital WDR

Yes

True WDR

Yes (120dB)

Noise Filter(2DNR)

Yes (Auto/Manual)

3DNR

Yes (Auto/Manual)

Image Enhancement

Saturation/ Contrast/Brightness/Hue/Sharpness/Rotate

Edge Recording

Yes

Network Recording

Yes

Image-Snapshots

Yes

Standard POE

802.3af

SD card

Yes (Up to 128 GB)

Power Supply

12V/2A

Power Consumption

Less than 7W

LAN Port Speed

10/100 Mbps

3MP DOME CAMERAS

MATRIX CAMERAS SATATYA CIDR30FL36CWS Fixed lens SATATYA CIDR30FL60CWS Fixed lens SATATYA CIDR30VL12CWS Varifocal lens Motion Detection

Yes

View Tamper

Yes

Line intrusion/ Directional motion/ Trip Wire

Yes

Zone Intrusion

Yes

IP-Conflict

Yes

Network-Disconnect

Yes

Storage Alert

Yes

Actions

Email/TCP/ SMS Notifications , Alarm Recording & Image/Clip Upload

Operating Temperature/Humidity

0 to 50 Degree Celsius

FCC Part-15 Class-B

Yes

Ingress Protection

IP66

Weight

1400gm

3MP DOME CAMERAS

MATRIX CAMERAS SATATYA CIBR20MVL12CWP SATATYA CIDR20MVL12CWP SATATYA CIBR30MVL12CWP SATATYA CIDR30MVL12CWP Sensor type and size

SONY - CMOS 2MP Active Pixel Progressive Scan, Back Illuminated Image sensor(Exmor Technology - STARVIS Series) Size: 1/2.8"

Spectral response

300nm - 1000nm

Minimum illumination(b/w)

0 Lux with IR LED On

Minimum object distance

0.3m

IR led type

4 - Array LEDs

IR range

Up to 30m

Focal length

2.8-12mm 2.8-12mm 2.8-12mm 2.8-12mm

HFOV( degrees)

98° to 33° 98° to 33° 88° to 30° 88° to 30°

Aperture

F 1.4 – F 2.8 F 1.4 F 1.4 F 1.4

Iris control

Yes (Auto/Manual)

Zoom

Yes (Motorized)

Focus

Yes (Motorized)

MOTORIZED VARIFOCAL CAMERAS

MATRIX CAMERAS SATATYA CIBR20MVL12CWP SATATYA CIDR20MVL12CWP SATATYA CIBR30MVL12CWP SATATYA CIDR30MVL12CWP

• Max. Resolution

1920*1080(2MP) @ 30fps 2048*1536(3MP)@ 30fps

Resolutions

1080p(2MP)/720p/D1/2CIF/CIF 2048*1536(3MP)/1080p(2MP)/720p/D1/2CIF/CIF/ QCIF

Stream Profiles

Profile 1: 2MP up to 30fps (H.265/H.264) Profile 1: 3MP up to 30fps (H.265/H.264) Profile 2: D1 up to 5fps (MJPEG) Profile 2: D1 up to 30fps (H.265/H.264) Profile 3: D1 up to 30fps (H.265/H.264) Profile 3: D1 up to 5fps (MJPEG) Profile 4: 720p up to 30fps (H.265/H.264/MJPEG) Profile 4: 720p up to 30fps (H.265/H.264/MJPEG)

Simultaneous Streams

4 4

Bitrate Type

CBR/VBR CBR/VBR

Bitrate

512Kbps - 4Mbps 512Kbps - 8Mbps

Video Compression

H.265/H.264/MJPEG H.265/H.264/MJPEG

Frame Rate

1 - 30fps 1 - 30fps

GOP

1 - 100 1 - 100

Shutter Speed

1/12500s to 1/25s 1/12500s to 1/25s

Adaptive Stream

Yes Yes

Smart Stream

Yes (Max. 3 Windows) Yes (Max. 3 Windows)

ONVIF Profile

S S

MOTORIZED VARIFOCAL CAMERAS

MOTORIZED VARIFOCAL CAMERAS

MATRIX CAMERAS MATRIX CAMERAS SATATYA CIBR20MVL12CWP SATATYA CIDR20MVL12CWP SATATYA CIBR30MVL12CWP SATATYA CIDR30MVL12CWP ROI

Yes

BLC

Yes

White Balance

Auto/Fluorescent/Incandescent/Sunny

Digital Zoom

Yes

E-PTZ

Yes

Digital WDR

Yes

True WDR

Yes

Noise Filter(2DNR)

Yes (Auto/Manual)

3DNR

Yes (Auto/Manual)

Image Enhancement

Saturation/ Contrast/Brightness/Hue/Sharpness/Rotate

Edge Recording

Yes

Network Recording

Yes

Image-Snapshots

Yes

Standard POE

802.3af

SD card

Yes (Up to 128 GB)

Power Supply

12V/2A

Power Consumption

Less than 7W

LAN Port Speed

10/100 Mbps

MATRIX CAMERAS SATATYA CIBR20MVL12CWP SATATYA CIDR20MVL12CWP SATATYA CIBR30MVL12CWP SATATYA CIDR30MVL12CWP Motion Detection

Yes

View Tamper

Yes

Line intrusion/ Directional motion/ Trip Wire

Yes

Zone Intrusion

Yes

IP-Conflict

Yes

Network-Disconnect

Yes

Storage Alert

Yes

Actions

Email/TCP/ SMS Notifications , Alarm Recording & Image/Clip Upload

Operating Temperature/Humidity

0 to 50 Degree Celsius

FCC Part-15 Class-B

Yes

Ingress Protection

IP66

Weight

920gm 1400gm 920gm 1400gm

MOTORIZED VARIFOCAL CAMERAS

For further information: Call: +91 99987 55555 E-mail: Customer.Care@MatrixComSec.com Visit: www.MatrixVideoSurveillance.com For Updates: Follow us, Watch us, Like us

CONTACT US

THANK YOU
