IoT Security in Action! Julien Vermillard , Sierra Wireless @vrmvrm - jvermillard@sierrawireless.com EclipseCON EU 2016 Introduction Managing connected devices Why it is simple to exploit non-secured systems How simple to have the minimum

SLIDE 1

IoT Security in Action!

Julien Vermillard, Sierra Wireless @vrmvrm - jvermillard@sierrawireless.com EclipseCON EU 2016

SLIDE 2

Introduction

SLIDE 3

Managing connected devices

Why it is simple to exploit non-secured systems How simple to have the minimum security

SLIDE 4

Network security

SLIDE 5

Deep dive: demo setup

IoT Device (MangOH) Attacker Internet Gateway (Linux PC) Local network Internet

SLIDE 6

Man-in-the-Middle?

IoT Device (MangOH) Attacker PC Linux Ettercap Internet Gateway (Linux PC) Local network Internet

SLIDE 7

Before attack

IoT Device (RaspberryPI) Attacker PC Linux Ettercap Internet Gateway (Linux PC) Local network Internet Traffic to Internet

SLIDE 8

ARP poisoning

IoT Device (MangOH) Attacker PC Linux Ettercap Internet Gateway (Linux PC) Local network Internet

I’m the gateway!

Route everything to the gateway Traffic to Internet

SLIDE 9

DNS spoofing

IoT Device (MangOH) Attacker PC Linux Ettercap Internet Gateway (Linux PC) Local network Internet

Fake DNS response DNS query iot.eclipse.org

LWM2M connection

SLIDE 10

With TLS/DTLS?

IoT Device (RaspberryPI) Attacker PC Linux Ettercap Internet Gateway (Linux PC) Local network Internet

Fake DNS response DNS query iot.eclipse.org

DTLS handshake failure

SLIDE 11

Security with gateways

Sensor network (ex: Zigbee) Gateway: collect data and push to cloud cable, 4G, etc..

Secure transport Low or no security

public network

SLIDE 12

Security with gateways

public network Sensor network (ex: Zigbee) cable, 4G, etc.. Attack gateway get access to all the network Local wireless sniffing

SLIDE 13

End-to-end security

public network

Low power nodes: security starts here

Sensor network (ex: Thread) Router cable, 4G, etc.. See only encrypted communication Not your Achilles’ heel

SLIDE 14

Other benefits of IP to the edge device

Simplicity: only IP networks Topology flexibility compared to gateway Scaling IP routing is something well known

SLIDE 15

Can we trust wireless network?

Wifi password? GPRS encryption? 3G/4G femtocell? Zigbee? Bluetooth? Not talking of plain text wireless network :)

SLIDE 16

Example: GPRS

https://discourse.criticalengineering.org/t/howto-gsm-base-station-with-the-bea glebone-black-debian-gnu-linux-and-a-usrp/56

SLIDE 17

Example: 3G/4G femtocell

http://www.ioactive.com/pdfs/IOActive_Remote_Car_Hacking.pdf

SLIDE 18

Key Management

SLIDE 19

Key management

You will have a fleet of device They needs secrets (key, password, etc..) Unique across devices You need to be able to change those secrets You will probably don’t trust your factory

SLIDE 20

Lightweight M2M Bootstrap

Flash bootstrap credentials

SLIDE 21

I only have bootstrap credentials or I can’t reach final server

Lightweight M2M Bootstrap

SLIDE 22

Lightweight M2M Bootstrap

Give me key and my server(s) Bootstrap Server

SLIDE 23

Lightweight M2M Bootstrap

New keys and server(s) URLs and ACL Bootstrap Server

SLIDE 24

Lightweight M2M Bootstrap

Registration Bootstrap Server Registration Home Automation Server Device Manag. Server

SLIDE 25

Secret key rotation using bootstrap?

Renew or upgrade your secret: 1 - Device authenticate with the bootstrap server 2 - Bootstrap server rewrite the bootstrap secret Next bootstrap the device use the new bootstrap secrets

SLIDE 26

Public Key Infrastructure?

Root CA Intermediate CA End entity 1 End entity 2 End entity3

SLIDE 27

How to verify a certificate

Root trust Identity to verify Intermediate Issuer Signature Expiration ~3 y Public Key Issuer Identity Issuer Signature Expiration ~5 y Public Key Issuer Identity Root Signature Root CA Identity Root Public Key Find Verify Find Verify Identity Identity

SLIDE 28

Enrollment with PKI

Generate Private Public

SLIDE 29

Enrollment with PKI

Private Public Certification Authority Certificate Request

SLIDE 30

Enrollment with PKI

Generate Private Public Certification Authority Certificate CA Private Sign using CA private key a X.509 certificate

SLIDE 31

Enrollment with PKI

Generate Private Public Service CA Public Sign using certificate for authentication

SLIDE 32

Still not IoT friendly

A lot of enterprise protocols: IKE: Internet Key Exchange

RFC2409

CMP: Certificate Management Protocol RFC4210 SCEP: Simple Certificate Enrollment Protocol

draft-gutmann-scep-02

EST: Enrollment Over Secure Transport

RFC7030

IEEE 802.1AR: Secure Device Identity 802.1AR But still nothing ready to use for constrained networks & devices

SLIDE 33

Firmware download

SLIDE 34

Firmware download

IoT Device (RaspberryPI) Attacker PC Linux Ettercap Internet Gateway (Linux PC) Local network Internet

Send firmware with backdoor HTTP GET

SLIDE 35

CMS (Cryptograpic Message Syntax)

See RFC5652 (replaces PKCS #7) Used to digitally sign, digest, authenticate, or encrypt arbitrary message content. Supported by OpenSSL (CLI: openssl cms)

SLIDE 36

Secure boot

Hardware (ROM) enforces booting only correctly signed code Often based on ECDSA signature Hardware based ⇒ no algorithm agility

SLIDE 37

Open-source solutions are there

Eclipse IoT: Leshan, Wakaama, TinyDTLS, Scandium, Paho, Mosquitto, Hono OpenSSL, Mbed TLS CFSSL GnuPG U-Boot
