Introduction to Metasploit Stefano Cristalli November 29, 2018 Laboratorio di Sicurezza e Reti Universit` a degli Studi di Milano Table of contents 1. Basic commands in the Metasploit console 2. DEMO: exploiting Heartbleed 3. Exercises

slide-1
SLIDE 1

Introduction to Metasploit

Stefano Cristalli November 29, 2018

Laboratorio di Sicurezza e Reti — Universit` a degli Studi di Milano

slide-2
SLIDE 2

Table of contents

  • 1. Basic commands in the Metasploit console
  • 2. DEMO: exploiting Heartbleed
  • 3. Exercises
  • 4. DEMO: creating a simple trojan
  • 5. Exercises

1

slide-3
SLIDE 3

Basic commands in the Metasploit console

slide-4
SLIDE 4

Discovery

Command db nmap. Like standard nmap, but interfaced with Metasploit’s db db nmap -v -sV 192.168.19.128

  • v verbose output
  • sV tries to determine service/version info

2

slide-5
SLIDE 5

Exploit search

Commands search and use. msf > search gitlab msf > use exploit/multi/http/gitlab shell exec Once we know which service to attack, it is time to search for exploits.

3

slide-6
SLIDE 6

Exploit configuration

Before executing the exploit, we must configure options. Examples: set RHOST 192.168.19.128 set RPORT 8080 Commands info and show options will give us information on the exploit and on its options. It’s also a good idea sometimes to see what the exploit does by looking at its code, with command edit.

4

slide-7
SLIDE 7

Exploit test and execution

We can perform a check of the vulnerability. Not always present, and remember to always check the implementation! msf > check If we want to actually run the exploit, the command is run: msf > run

5

slide-8
SLIDE 8

DEMO: exploiting Heartbleed

slide-9
SLIDE 9

Exercises

slide-10
SLIDE 10

Exercises

  • 1. Scan vulnbox for services. Which ones can you identify?
  • 2. Try to exploit the running services. Can you find a working exploit?
  • 3. The Apache server we have already analyzed runs a CGI script at

/cgi-bin/hello.sh It’s just an hello world, so the code is not vulnerable. Maybe the underlying program is a bit... old?

6

slide-11
SLIDE 11

DEMO: creating a simple trojan

slide-12
SLIDE 12

Exercises

slide-13
SLIDE 13

Exercises

  • 1. Analyze /home/user/vuln/vuln.c on vulnbox. What does the

program do?

  • 2. Exploit the program. Spawn a shell by generating a payload with

msfvenom.

  • 3. A local shell isn’t enough. Produce and test shellcodes for bind and

reverse remote shells.

7
