Interface

Objectives

• Discuss interfaces

– concept – definition – implementation – support for generic code

2

Interface

• An interface defines a specification

– also called contract

• A class can agree to abide by the contract

– by implementing the interface – enforced by compiler

3

Interface definition

• An interface is created using the keyword interface

– body contained in { and } – names follow class naming convention with initial upper case I

4

interface IMyInterface { ... }

interface definition

Interface contents

• Interface can contain method, indexer, property, and event

– no implementations allowed – no other types of members allowed

interface IMyInterface { void Process(int arg1, double arg2); float this [int index] { get; set; } string Name { get; set; } event MouseEventHandler Mouse; }

method indexer property event

5

Access level

• Interface contents implicitly public

– error to use modifier explicitly

interface IMyInterface { public void Process(int arg1, double arg2); ... }

error, can not explicitly label as public

6

Framework interfaces

• .NET Framework defines many interfaces

public interface ICloneable {

• bject Clone();

} 7 public interface IDisposable { void Dispose(); } public interface IList ... { int Add (object value); void Remove (object value); bool Contains(object value); ... }

Custom interface

• Programmer can define interface

interface IFighter { void Punch(int side); void Kick (int side); void Block(); } interface IWrestler { void Takedown(int legs); void Escape(); }

8

Implementing interface

• Class can support interface

– declare using class : interface syntax – implement contents

class Soldier : IFighter { public void Punch(int side) { Move(arms[side], Forward); } public void Kick (int side) { Move(legs[side], Forward); } public void Block() { Move(arms[Left ], Up); Move(arms[Right], Up); } ... }

implement methods declare

9

Interface reference

• Interface reference can refer to implementing object

– access limited – can only access interface members

IFighter f = new Soldier(); f.Punch(Left); f.Kick(Right); f.Block(); ...

can only call IFighter methods when using IFighter reference

10

Implementation by multiple classes

• Many classes can support the same interface

– implement methods in their own way

11

class Soldier : IFighter { public void Punch(int side) { ... } public void Kick (int side) { ... } public void Block() { ... } ... } Soldier implements IFighter class Robot : IFighter { public void Punch(int side) { ... } public void Kick (int side) { ... } public void Block() { ... } ... } Robot implement IFighter

Generic code

• Methods coded against interface

– work with any implementing object

12 void WarmUp(IFighter f) { f.Punch(Left ); f.Punch(Right); f.Kick (Left ); f.Kick (Right); } void Fight(IFighter a, IFighter b) { a.Punch(Left); b.Block(); b.Punch(Right); a.Block(); b.Kick(Left); } void Match() { Soldier s = new Soldier(); Robot r = new Robot (); WarmUp(s); WarmUp(r); Fight(s, r); }

generic

• k, both

implement IFighter

Type testing

• Can test if object implements particular interface

– using operator is

void March(Soldier s) { if (s is IFighter) ... }

test if Soldier implements IFighter

13

Implementing multiple interfaces

• Class can support several interfaces

– comma separated list in class definition – must define methods of all interfaces

14

class Soldier : IFighter, IWrestler { public void Punch(int side) { ... } public void Kick (int side) { ... } public void Block() { ... } public void Takedown(int legs) { ... } public void Escape() { ... } ... } IFighter methods IWrestler methods

Compatibility

• Object compatible with reference of any supported interface

void WarmUp(IFighter f) { ... } void Stretch(IWrestler w) { ... } void Prepare(Soldier s) { WarmUp (s); Stretch(s); }

• k since Soldier

implements both interfaces

15

Inheritance and interface

• Class may inherit from base class and implement interfaces

– same syntax in declaration – base class must be listed first or compile time error

class Soldier : Person, IFighter, IWrestler { ... }

base class interface interface

16

Interfaces should not grow

• Adding methods to interface will break client code

– classes no longer implement all methods

interface IFighter { void Punch(int side); void Kick (int side); void Block(); void Bite(); } class Soldier : IFighter { ... public void Punch(int side) { ... } public void Kick (int side) { ... } public void Block() { ... } } new method code breaks

17

Interface inheritance

• Interface can inherit from other interface

– syntax analogous to class inheritance – creates new interface that is a specialization of base interface

18

interface IFighter { void Punch(int side); void Kick (int side); void Block(); }

base

interface IStreetFighter : IFighter { void Bite(); }

derived

Multiple interface inheritance

• Interface can inherit from multiple interfaces

– new interface includes members of all base interfaces – can also add its own

interface IFighter { void Punch(int side); void Kick (int side); void Block(); } interface IStreetFighter : IFighter, IWrestler { void Bite(); } interface IWrestler { void Takedown(int legs); void Escape (); } multiple inheritance allowed

19

Implementing derived interface

• Class implementing derived interface must code all methods

– of all interfaces in hierarchy

class Soldier : IStreetFighter { public void Punch(int side) { ... } public void Kick (int side) { ... } public void Block() { ... } public void Takedown(int legs) { ... } public void Escape() { ... } public void Bite() { ... } ... } from IFighter from IWrestler from IStreetFighter

20

Ambiguity

• Different interfaces may define method with same signature

– ambiguous when class tries to implement both interfaces

interface IFighter { void Block(); ... } interface IWrestler { void Block(); ... }

same signature different interfaces 21

Resolving ambiguity

• Class may need to implement interfaces having ambiguity
• Two options to handle the situation

– can implement one method that fills both roles – can implement both methods explicitly

22

Implement one method

• When implementing two interfaces with same method

– can implement one method – the method must logically work in both roles – simplest solution when applicable

class Soldier : IFighter, IWrestler { public void Block() { ... } ... }

interfaces contain method with same signature class codes one method only

23

Explicit method implementation

• When implementing two interfaces with same method

– can explicitly implement both methods – must qualify each implementation with interface name – no access modifier allowed

class Soldier : IFighter, IWrestler { void IFighter.Block() { ... } void IWrestler.Block() { ... } ... }

interfaces contain 2 methods with same signature IFighter version IWrestler version

24

Limitation on explicit method call

• Call to explicit method implementation limited
• Cannot call through reference of class type

– call would be ambiguous since more than one exists – methods are not public

25

Soldier s = new Soldier(); s.Block(); ...

Soldier reference error, cannot call Block

Calling explicit method implementation

• Call explicit method implementation with interface reference

– type of reference determines method called

Soldier s = new Soldier(); IFighter f = s; f.Block(); IWrestler w = s; w.Block(); ...

IFighter reference calls IFighter.Block IWrestler reference calls IWrestler.Block

26

Summary

27

• Interface

– named collection of declarations – useful to write generic code

• Classes implement interfaces

– must implement all methods – gain type compatibility with interface
