Integrated Crisis Early Warning System (ICEWS) Computational Social - - PowerPoint PPT Presentation

Integrated Crisis Early Warning System (ICEWS) Computational Social Science Experimental Proving Ground (CSS:EPG)

• Dr. Sean O’Brien

December 29, 2008

Distribution authorized to U.S. Government Agencies only

1

Program Summary

Objective

– Create a comprehensive, integrated, automated, validated, analytic system that forecasts shifts toward/away from country/regional instability

Approach

– Monitor and assess, in near-real time, events and trends that may trigger crises – Develop and integrate validated, transparent, scientifically rigorous, robust and replicable models from diverse perspectives across multiple domains/levels of analysis

February 2007 Solicitation for ICEWS September 2007 Contract Awards October 2007 Program start December 2008 Phase 1 Go/No-Go and Phase 2 Option Decisions March 2009 Phase 2 Options Awarded June 2010 Phase 3 Option Decisions September 2010 Phase 3 Options Awarded

Distribution authorized to U.S. Government Agencies only

2

Performers and Locations

Arlington, VA Atlanta, GA Lawrence, KS Vienna, VA Philadelphia, PA Lexington, SC Athens, GA Seattle, WA Vienna, VA Arlington, VA Philadelphia, PA Weston, MA Washington, DC College Park, MD Arlington, VA Cambridge, MA Oahu, HI Albany, NY Syracuse, NY Hilliard, OH Aspen, CO

• Wethersfield. CT

Washington, DC

Distribution authorized to U.S. Government Agencies only

3

Data Ingest Services DIME Action Modeling

Event Coding

(KU, SAE)

Data Collection

Models and Model Services

DIAS Framework (ANL) adapted by LM LM

Agent Based Models

(UP, LC, LM)

Bayesian Models

(IDI, EG, SAE)

Statistical Models

(KU, SAE, UW, EG)

Leaders Economics Groups & Factions

• Govt. &

Institutions

Text Processing & Analytics SME Interview & QC Tools Events of Interest Overall Stability Stability Assessment & Mitigation Planning

Interactive Interfaces to View & Query Forecasts and Mitigation Strategies

News Feeds Blogs & Reports Databases

Model Inputs

LM-ATL Raven System Concept

DIME Action Mining

(LM)

DIME Action Models

(IDI, LM, UP)

Region/Countries (DIME Effects)

(LC, LM)

Regional Players (DIME Strategies)

(UP)

Stability Impacts

(Linkages to Forecasting Models’ Levers) Stability Forecasting

Key Indicators Primary Phase I Focus Extension of Phase I Primary Phase II Focus

DIME Action Exploration

DIME Actions

Futures Exploration

Aggregation, Explanation, & Transparency

Distribution authorized to U.S. Government Agencies only

4

Phase 1 Achievements

Largest data set ever collected/analyzed for instability forecasting project

– 6.5M news stories from 75 national, regional, and international sources (253M lines of text)

• AP, UPI, BBC Monitor
• India Today, Jakarta Post, Pakistan Newswire, Saigon Times

– 100 other sources of data on country social, demographic, economic, leadership and political factors

• The Economist Intelligence Unit, Freedom House, IMF, World Bank, Political Instability Task Force, and the

Correlates of War project

Developed fully automated capability to monitor and forecast political activity around the globe

– Automatically convert news reports into structured indices that reflect the character and intensity of interactions between key leaders, organizations, and countries —who is doing what to whom, when, where and how around the world

• Using actor dictionary (with over 8,000 entries) and a verb-phrase dictionary (with over 15,000 entries), news

stories coded in four major categories—verbal cooperation/conflict, material cooperation/conflict—comprising 130 variables to measure and monitor the character and intensity of a broad range of political activities

– Resulting indices are used in computer models to identify trends, and cue analysts to impending conflicts

By aggregating some of the indices, performers were able to successfully forecast a variety of instability events in the Pacific Command area of responsibility

– Though only one performer passed Phase 1 gates

Some novel new insights

Distribution authorized to U.S. Government Agencies only

5

Phase 1 New Insights on Forces Driving Country Instability

Identified and demonstrated a “repulsion” effect based on social similarity connectedness

– In countries with similar temporal event patterns, the presence of social unrest in one country, reduces its likelihood in connected countries.

Empirically confirmed inverted “U” relationship between government repression and probability of ethnic/religious violence

– However, effects are conditional on the ethnic composition of the society

Weakness in the combined strength of the two dominant rival parties is a leading indicator for higher violence

.004 ELF .16 ELF .36 ELF .6 ELF .86 ELF 0.5 1 1 2 3 4 5

Political Terror Scale

.004 ELF .16 ELF

Distribution authorized to U.S. Government Agencies only

6

Evaluation Methodology

GFI Data: “Authoritative” set of data on the occurrences and intensity of de-stabilizing events in 29 countries of the PACOM AOR for the period 1998-2006

– Intensity levels 0-4* (common yardstick)

• 0 – No crisis
• 2 – Crisis, violence is used sporadically
• 3 – Severe crisis, violence is used repeatedly and in an organized way
• 4 – War, violence used with continuity, in an organized and systematic way

– De-stabilizing events (variable; best 3 scored)

• Domestic Political Crisis – Significant opposition to the government, but not to the level of

rebellion or insurgency (e.g. power struggle between two political factions involving disruptive strikes or violent clashes between supporters)

• Rebellion – Organized opposition whose objective is to seek autonomy or independence
• Insurgency – Organized opposition whose objective is to overthrow the central government
• Ethnic/Religious Violence – Violence between ethnic or religious groups that is not specifically

directed against the government

• International Crisis – Conflict between two or more states or elevated tensions between two or

more states that could lead to conflict

– Data for 1998-2004 provided to performers for training – Data for 2005-2006 withheld for testing

*Index of Instability/Conflict Intensity from the Heidelberg Institute for International Conflict Research

Distribution authorized to U.S. Government Agencies only

7

Evaluation Methodology

Performers calculate probability of 4 intensity levels for each country 6 mos hence

– Bin probabilities using the 2/3 rule to determine “Low”, “Moderate” and “High” intensity – Compare performers matrix with true matrix for accuracy, recall and precision

Country Year Quarter Max Intensity = 0 Max Intensity = 1 Max Intensity = 2 Max Intensity = 3 Max Intensity = 4 1 0.0192 0.4399 0.5343 0.0065 2 0.0489 0.1817 0.5238 0.2456 3 0.1807 0.3831 0.3587 0.0774 4 0.3012 0.4243 0.2456 0.0288 1 0.1478 0.3432 0.4087 0.1003 2 0.1700 0.3826 0.3683 0.0791 3 0.2492 0.4085 0.2939 0.0484 4 0.3143 0.4450 0.2184 0.0224 Burma 2005 2006

Sum of Probabilities >=2/3, Forecast = High Intensity Sum of Probabilities >=2/3, Forecast = Moderate Intensity Sum of Probabilities >= 2/3, Forecast = Low Intensity

Performers calculate probability of discrete de-stabilizing events for each country 6 mos hence

– Use 2/3 rule to determine “0” or “1” – Compare performers matrix with true matrix for accuracy, recall and precision – Best forecasts for 3 de-stabilizing events will we scored and reported

Country Year Quarter Rebellion Insurgency Domestic Political Crisis Ethnic/ Religious Violence International Crisis 1 0.0027 0.0004 1.0000 0.0000 0.4657 2 0.0034 0.2269 0.8918 0.0000 0.4657 3 0.0000 0.0682 0.9999 0.0000 0.0438 4 0.0050 0.1720 0.9910 0.0000 0.0438 1 0.0034 0.9992 0.9996 0.0000 0.4657 2 0.0013 0.4501 0.9979 0.0005 0.4116 3 0.0000 0.1695 0.9974 0.0000 0.8099 4 0.0001 0.9999 0.9943 0.0000 0.8099 Bangladesh 2005 2006

Probability >=2/3, Forecast = Insurgency 1/3 < Probability < 2/3, No forecast Probability <= 1/3, Forecast = No Rebellion

Distribution authorized to U.S. Government Agencies only

8

Forecasting-Performance Metrics

Phase 0 (Benchmark) 80% (Retrospective) 80% 70% Annual Phase 1 > 80% (Retrospective) 80% 70% 1-6 mos. Phase 2 >85% (Real-Time) 80% 70% 1-3 mos. Phase 3 >85% (Real-Time) 80% 70% 1 mo.

GO/ NO GO

Phase Accuracy Forecast Window Recall Precision

Distribution authorized to U.S. Government Agencies only

9

Results: LM-ATL

Exceeds metrics for the maximum intensity index and 3 instability events: Rebellion, Insurgency, and Ethnic/Religious Violence – Passes Phase 1 gates By integrating improved versions of best of breed models from multiple perspectives, team achieves more accurate, precise forecasts than any one model alone 0% 20% 40% 60% 80% 100% HI Reb Insur DPC ERV IC Accuracy Recall Precision

Precision Threshold Accuracy & Recall Threshold Max Intensity Rebellion Insurgency Ethnic/Religious Violence Domestic Political Crisis International Crisis

Distribution authorized to U.S. Government Agencies only

10

LM-ATL: Quarterly Results

(Phase 2 goal)

0% 20% 40% 60% 80% 100% HI Reb Insur DPC ERV IC Accuracy Recall Precision

Precision Threshold Accuracy & Recall Threshold Max Intensity Rebellion Insurgency Ethnic/Religious Violence Domestic Political Crisis International Crisis

Exceeds metrics for the maximum intensity index and 2 instability events: Rebellion, Insurgency Very close on metrics for Ethnic/Religious Violence Almost passes Phase 2 metrics (retrospective vice near real time)

Distribution authorized to U.S. Government Agencies only

11

LM-ATL Hypothesis

Aggregating model scores with a learned Bayesian network

• utperforms any one other

model

– Because different models cover the EOIs and countries with varying levels of performance

0.00 0.50 1.00 1.50 2.00 2.50 3.00 B u r m a R u s s i a C h i n a N e p a l M a l a y s i a A u s t r a l i a N

• r

t h K

• r

e a B h u t a n V i e t n a m S

• l
• m
• n

I s l a n d s L a

• s

P a p u a N e w G u i n e a J a p a n S

• u

t h K

• r

e a S i n g a p

• r

e M

• n

g

• l

i a F i j i N e w Z e a l a n d M a u r i t i u s I n d i a C

• m
• r
• s

T a i w a n M a d a g a s c a r C a m b

• d

i a I n d

• n

e s i a B a n g l a d e s h T h a i l a n d P h i l i p p i n e s S r i L a n k a UW SAE B 0.00 0.20 0.40 0.60 0.80 1.00 1.20 LM ATL UW LC UPenn SAE L UK SAE B

University of Washington, Dr. Michael Ward Geo-spatial statistics applied to trade ties, flow of people, social similarity University of Penn,

• Dr. Ian Lustic and
• Dr. Barry Silverman

Agent-base models (only 6 and 4 “hard” countries resp.) University of Kansas, Dr. Phil Schrodt College of William and Mary, Dr. Steve Shellman Logit-based statistical models College of William and Mary, Dr. Steve Shellman Bayesian statistical model Aggregation model

Average distance, in quarters and over 29 countries, between probability prediction and ground truth vector for Rebellion, 2005-2006 Distance (in quarters) between probability prediction and ground truth vector for Rebellion, for UW and SAE B models, 2005-2006 Lower value = less error

UW model performs better on these countries SAE B model performs better on these countries

Except for Bangladesh, Rebellion is picked up by some other model

Distribution authorized to U.S. Government Agencies only

12

ICEWS Phase 2 CONOPS

Leadership Characteristics Medium-term (intermittent) I nternal/ External I nteractions Short Term (weekly) Macro-Structural Conditions Longer Term (annually)

Stability/ I nstability Forecast

Phase 1: Retrospective 3-6 months forecast of crises, identification of leading indicators Phase 2 Objective 2: Identification, validation and modeling of linkages between DIME actions and leading indicators

D I M E

Tier 0 Tier 1 Tier 2

Phase 2 Objective 1: Real-time 1 month forecast of EOIs, refinement of leading indicators Also, 2-3 year forecast window Phase 2 DIME data: Taxonomy

• f DIME actions and actual data

2005-present; Continue collection during Phase 2

This is the original Phase 3 objective This is a new objective, requested by PACOM

Distribution authorized to U.S. Government Agencies only

13

Timeline And Evaluation

1 15 16 17 18 19 20 21 22 23 24

Monthly forecasts 1 - 9 LE LE Objective 2: Linkage Evaluations Objective 1: Forecasts DIME data collection/analysis

… …

2-3 year 2-3 year PACOM Evaluation Workshop 1 PACOM Evaluation Workshop 2

14

2-3 year

13 12

Graded for Go/No Go Assessment

Distribution authorized to U.S. Government Agencies only

14

Computational Social Science Experimental Proving Ground (CSS:EPG)

Computational Social Science Experimental Proving Ground (CSS:EPG)

Objective: Develop a synthetic lab to formalize, validate, and integrate social science theories, in a disciplined and cumulative manner, to enable efficient spin

• ff of useful operational applications.

The synthetic lab (transition 1) continuously develops the social science knowledge to enable more and better military applications (transition 2)

• New, more efficient way to conduct social science research experiments
• Better, more conceptually integrated, empirically-grounded, social

knowledge

• Informing better, more reliable operational decisions

Synthetic Lab

Military & Intelligence Applications

Possibly Proprietary & Classified Non-Proprietary & Open Source Social Science Research Community Social Computing Performer Community

CSS:EPG will revolutionize the way social science knowledge is developed, formally validated and applied to real-world strategic and operational decisions

CSS:EPG Trajectory

Distribution authorized to U.S. Government Agencies only

16

Today

Do we have the tools to compose, integrate, and evaluate the theories for predictive potency? Yes, simulations have been used to resolve competing theoretical claims and make predictions, in manual, “one-off” cases. Do we have theories that can reliably address operational questions? Yes, but they are “islands” of competing theoretical claims that need to be integrated, formalized, tested and evaluated holistically

Program End

Performance

• One-off, unvalidated, duplicative

CSS projects, quickly forgotten

• Integration of CSS models at the

software level is ad-hoc, error- prone, and un-validatable

• No clear value to the warfighter

Scenario3_V2.wmv

Real time news feeds Real time Simulation

Scenario3_V2.wmv

Theory-driven, data-driven simulations to reliably and flexibly address a broad range of

• perational questions with important human,

social, cultural, and behavioral implications

Time

Dec 2013

Can we automate the process so theory/data- driven simulations can be applied to current, real world operational questions? Yes, massive simulations can be analyzed, automatically compiled, and executed in real time, and real time exploitation of relevant data is mature.

CSS:EPG Three Challenges

Generality

– Number of analytic cases and number of answerable questions that the simulation environment can address reliably

Composability

– Integrating new theories from 3rd parties – Formalize, integrate and evaluate new theories within the overarching theoretical framework and simulation environment – Question refinement – Decompose operational question into theoretical components, match theoretical components to the relevant theories necessary to answer them, select and assemble theories, simulation components, models, and data streams to answer the question

Timeliness

– Meta-control of question refinement, theory selection and integration, data processing, execution, and analysis – Near real-time data ingest to update events and changing circumstances in AOR – Timely provision of answers to commander’s question

Distribution authorized to U.S. Government Agencies only

17

Increasing generality to the scale necessary for usability by domain experts and operators requires composability and timeliness

Analysis Question HPC Experimentation Environment 18 Data Social Science Theories Historical data artifacts modifiers Integrated model instantiation Experimentation protocol Real-time data Simulations Analysis of results

BAA Requirements for CSS:EPG Developer

Commander’s forward looking question or Theoretical question Formal mapping into theoretical framework

Components of Experimentation Lab

Distribution authorized to U.S. Government Agencies only

Top-Level CSS:EPG Program Delivery

Phase 1 (18 mos) Phase 2 (18 mos) Phase 3 (18 mos) Generality

3 training cases for each analytic question: 1 chosen by performer; 2 developed by govt One case withheld by govt for testing, for each analytic question 3 analytic questions for training, 1 analytic question, withheld by govt, for testing 10-12 cases 10 analytic questions for training; 3 questions withheld for testing Entire AOR, contemporaneous Class of questions relevant to JTF commander during Phase 0 and Phase 4

Composability

No composibility Composibility via external competition for the solution of an

• utstanding, operationally

relevant, social science argument Composibility via external competition

Timeliness

Automation of set-up only No real-time Automated explanation and assessment, done in batch Real-time data Meta-control of execution and analysis Real-time data and execution Each CSS:EPG performer delivers a single modeling environment capable of answering a few questions from a single problem class (Counterinsurgency- questions in backup) CSS:EPG performers extend their simulation platform to answer questions from multiple problem classes and demonstrate ability to formalize and integrate theories, proposed by others CSS:EPG performer extends simulation platform to (semi) automate question refinement, theory selection, model integration, real-time execution, integration of static & real-time data, and analysis Two Transitions:

• COCOM for military

applications

• Civilian research
• rganization to maintain

& expand infrastructure Technical Challenge emphasized in each phase

Distribution authorized to U.S. Government Agencies only

20

Top-Level CSS:EPG Program Structure

Phase 1 (18 mos) Phase 2 (18 mos) Phase 3 (18 mos) Generality

3 training cases for each analytic question: 1 chosen by performer; 2 developed by govt; One blind case for testing 4 analytic questions for training, 1 blind analytic question for testing 10-12 training cases, 3 blind cases for testing 10 analytic questions for training; 3 blind questions for testing; Broader questions that focus on outstanding,

• perationally relevant, social

science arguments All major problems currently relevant to a selected AOR Class of questions relevant to JTF commander for Phase 0 through Phase 4

• perations

Composability Manual composability within

simulation environment Manual composability (with help) by external Grand Challenge competitions among participants for the solution of the analytic questions (next slide) Composability (without help) by external competition participants

Timeliness

Automation of set-up only Automated compilation and execution Automated analysis of results, done in batch Near real-time data Automation and meta-control

• f question refinement,

theory selection, model integration, batch and real- time data ingest, execution, and analysis Near real-time data; Execution quick enough for answer to be relevant to JTF commander Technical Challenge emphasized in each phase

Summary

The Department currently has no reliable, validated means to answer human, social, cultural, and behavioral questions of major import to US national security. Current approach of integrating unproven/untested models/theories at the software level won’t get us there—just provide the means to get to wrong answer quicker. Current academic approach of testing theories in inter (and intra) disciplinary isolation won’t get us there—competing theoretical claims depend on theories from other disciplines at different levels of analysis for their resolution. CSS:EPG has the potential to revolutionize the way that social science knowledge is developed, evaluated, and applied to important operational challenges

Distribution authorized to U.S. Government Agencies only

21

Backup

Distribution authorized to U.S. Government Agencies only

22

Metrics

Distribution authorized to U.S. Government Agencies only

23

Test Metrics

Distribution authorized to U.S. Government Agencies only

24

Time t1 t2 t3 t4 t5 tn ….. Value Ground Truth For v1 Want the average simulation

• utput within 30% of ground

truth 30% band around ground truth Also want the average simulation

• utput to follow the dynamics of

ground truth Time t1 t2 t3 t4 t5 tn ….. Value First Derivative For v1 Example Phase 1 Dependent Variables: Number of violent acts; intensity and kind of gov’t counter- insurgent activities; popular support for gov’t/insurgents; political participation; economic development 30% band around ground truth

Test metrics geared to insure simulation environment captures accurately the value and trend

• f the dependent variables necessary to understand the nature of phenomenon of interest

Test Metrics - Mean Distance Between Simulation Runs & Ground Truth

Distribution authorized to U.S. Government Agencies only

25

Time t1 t2 t3 t4 t5 tn ….. Value Ground Truth For v1 Simulation 1 d1 d2 d3 d4 d5 dn Average Relative Error for Simulation 1 = 1/n(d1/|y1|+d2/|y2|+d3/|y3|+d4/|y4|+d5/|y5|+…+dn/|yn|) Simulation 2 Simulation m Average Error = 1/m(sum of average error for each simulation ) Simulation 3 Average Error < 0.3

y1 yn y2 y3 y4 y5

Test Metrics - Mean Distance Between 1st Derivative of Simulation Runs and Ground Truth

Distribution authorized to U.S. Government Agencies only

26

Time t1 t2 t3 t4 t5 tn ….. Value Ground Truth For v1 Simulation 1 d3 d4 d5 dn Average Relative Error for 1st Derivative of Simulation 1 = 1/(n-1)(d2/|z2|+d3/|z3|+d4/|z4|+d5/|z5|+…+dn/|zn|) Simulation 2 Simulation m Average Error = 1/m(sum of average error for each simulation ) Simulation 3 Average Error < 0.3

y1 yn y2 y3 y4 y5

Time t1 t2 t3 t4 t5 tn ….. Value

zn z2 z3 z4 z5

First Derivative For v1 First Derivative for Simulation 1 d2 First Derivative for Simulation 2 First Derivative for Simulation 3 First Derivative for Simulation m

Study Questions by Phase

Distribution authorized to U.S. Government Agencies only

27

CSS:EPG – Phase 1 Analytic Questions

Questions Training Cases Test Case

When will introducing or increasing foreign force presence in a region increase or decrease the insurgency or shift its focus? Iraq Afghanistan Performer Bid Blind Case When will bolstering Host Nation forces help suppress the insurgency? Re-orient violence

• nto ethno-sectarian or factional axis?

Iraq Afghanistan Performer Bid Under what conditions does government repression depress/increase illegal or violent anti-government activity? Iraq Afghanistan Performer Bid What effects does killing or capturing a high profile insurgent leader have on: popular support for insurgency; insurgent cohesion; insurgent strategy; military/political effectiveness? Iraq Afghanistan Performer Bid Blind Question

CSS:EPG – Phase 2 Analytic Questions

Question Cases Under what conditions does discontent with government policy or performance transform into threats to the regime? Eastern European countries (1989-90); China (1989); Philippines (1983-86); Israel in the West Bank and Gaza (1987-1989); Georgia (2003-04); Bolivia (1983-2008); Egypt (1977) Under what conditions can societies deeply divided along communal lines produce stabilizing overarching identities? Canada (1970-1990); Lebanon (1960-1980); Tanzania & Kenya (1960-1990) Under what conditions can antagonistic groups live together peacefully within a single legal political order? Sudan (1960-Present); Yugoslavia (1950-90); Israel (1948- Present); Algeria (1970-2000); Malaysia (1960-2000) When does corruption increase political stability and when does it decrease it? Central Asian Republics post-Soviet Union; Bangladesh, Indonesia, Vietnam, China (1990s, 2000s) Under what conditions do elections foster unity among antagonistic ethnic groups and under what conditions do elections accentuate tendencies toward violent intergroup conflict or secession? India, Bangladesh, Indonesia, Nigeria (last 20 or 30 years) Do political parties based on religion differ in their performance and democratic potential from parties based on class or ethnicity? India, Malaysia, Morocco, Sri Lanka, Israel, Turkey

CSS:EPG – Phase 2 Analytic Questions (cont’d)

Question Cases Under what conditions does strengthening civil society provide the basis for overthrowing the regime and under what conditions does it support the stability of the regime? Pre- vs post-1989 Soviet Bloc countries What kinds of authoritarian regimes can democratize and what kinds cannot? 1980s Philippines (Marcos), Morocco, Russia, China, Iran, Egypt, Malaysia, Algeria, Pakistan What policies toward particular types of authoritarian regimes can produce democratization? South Africa, Zimbabwe, Philippines What transitions to stability are available for polities divided between modern and prosperous urban sectors and populous but poor and traditionalist rural areas? Thailand 2000s Turkey 1960s-1990s China 1970s-2000s How can democratic transitions be managed to reduce the threat of external aggression? Georgia, 1990s, 200s; Lebanon 2000s; Yugoslavia early 1990s What is the political effect of different kinds of violence on the stability of different kinds of political regimes enjoying different levels of political support? Bangladesh 1990s-2000; Afghanistan post 2001; Northern Ireland 1960s-1990s; India 1960s-2000s; Zimbabwe
