Infill Code Revisions

May 3, 2018 Community Assembly

SpokaneCity.org/projects > Infill Housing/Infill Development

• Housing affordability and choice

– Expand opportunities for homeownership – Build on available vacant land near centers

• Streamline the process for infill

development

• Make infill more compatible with

surrounding neighborhoods

Adopted Guidance

SpokaneCity.org/projects > Infill Housing/Infill Development

Attached Housing

City Limits RHD RMF RTF ¼ mi CC CC3 Overlay CC1-4, DT

City Limits RHD RMF RTF ¼ mi CC CC3 Overlay CC1-4, DT

Wall Height

• p. 6 - SMC 17C.110.200

Table 17C.110-3

Wall Height 30 ft.

• RMF zone increase

from 30 to 35 ft.

– Match roof height – Meet planned density – Increase number of full stories – Increase design and development options – Match 35 ft. wall height for accessory structures Existing Code

Roof Height 35 ft.

Proposal

Roof Forms

• p. 6 - SMC 17C.110.200

Table 17C.110-3

Existing Code

30 ft. 35 ft.

Proposed Code

For multi-dwelling structures, these roof forms are limited to >60 ft. from a single-family use. Attached housing must incorporate elements and forms from nearby buildings in historic neighborhoods. 30 ft. 35 ft.

Scale: Approx. 60 ft.

Example RMF Scenarios

(for illustration only) Redevelopment Emerson-Garfield Redevelopment Cliff-Cannon Infill – East Central Infill – Logan KEY Vacant lot Single-family use 2-to-4-unit use 5-plus unit use

Minimum Lot Width/Front Lot Line RTF, RMF, RHD zones

Street access only Alley parking access

Existing Code

1 2

• Min. width 36 ft.

1 2

• Min. width 16 ft.

Street access only Alley parking access 1 2

• Min. width 25 ft.

1 2

• Min. width 16 ft.

Proposed Code

Attached Housing – Curb Cuts Proposed RTF, RMF, RHD zones

Existing Code

1 2 3 4

Proposed Code

Park Park Park Park

• Approach width (at curb) min. 12 ft.
• Driveway width min. 9 ft.
• Max. 20% of lot

Park Park Park Park Park Park Park Park Park

1 2 3 4 Limit one curb cut per two dwellings Lots less than 40 feet wide

Curb Cuts

Street

Side Lot Line Setback - Attached Houses RA, RSF, RTF, RMF, RHD zones

Existing Code Proposed Code

1 2 Alley Street

• Min. setback

3 ft. Duplex Attached Houses

• Min. setback

3 ft. 6 ft. 1 2 Alley Street Alley 2 1 Attached Houses

Parking Area Setback Commercial and Industrial zones

Existing/Proposed Front Parking Area Setback 60 ft. 20 ft. 60 ft. 5 ft. 20 ft. Proposed Side Parking Area Setback Side lot line Residential zone Non-residential zone Residential zone Front lot line Street Street

• Reduce the setback

from 20 ft. to 5 ft. adjacent to residential side street lot lines

– Allow more flexible site design – Provide more available space for parking

Parking Area Setback

Proposal Existing Code

• 20-ft. setback within

the first 60 ft. abutting a residential zoning district

• Open houses

– Facebook Q&A Session Monday, May 7, 10-11 am – Wednesday, May 9, 12-2 pm, City Hall

• Plan Commission Workshop

– May 9

• Plan Commission hearing

– Early Summer 2018

• City Council hearing

– Summer 2018

Infill Code Revisions

SpokaneCity.org/projects > Infill Housing/Infill Development

• Questions?

• Following slides for information if needed.

Existing Transition Standards

• Landscape buffer
• Minimum setbacks

– adjacent to RSF, RTF residential zones

• Parking

Existing Transition Standards

• Lot size

transition

– Only sites 2+ acres in RSF zone – If subdivision proposed

Transitional Standards

Platted, but not zoned RSF Never platted Lots avg. 4,500 ft2 Lots avg. 6,500 ft2 Lots avg. 10,000 ft2 Lots 11,000+ ft2 New lot

• min. =

4,500 ft2 New lot

• min. =

6,500 ft2 New lot

• min. =

7,200 ft2

• Intent

– Facilitate compatible development – Consistent development pattern

• Issues caused

Lot Size Transition

WALL HEIGHT IN THE RMF ZONE

Attached Housing – Design Standards

Wall Height

• p. 6 - SMC 17C.110.200

Table 17C.110-3

Existing Transition Standards

• Upper level

step backs adjacent to RSF & RTF residential zones

Upper Level Step Back Example

| 26

LOT WIDTH AND FRONT LOT LINE

Attached Houses

• RTF, RMF, RHD zones,

sites without alley parking: Reduce from 36

• ft. to 25 ft.

– Match minimum for duplexes – Meet planned density – Increase design and development options

Lot Width/Front Line

• p. 5 - SMC 17C.110.200

Table 17C.110-3

Front Lot Line 36 ft. Example Lots Existing Code Proposal Lot Width 36 ft.

1 2

Building Envelope

• Reduce the side setback
• pposite the common wall to

the standard from the double requirement to the standard for other development

– Remove impediment to attached housing – Match minimum for duplexes – Increase design and development options

Side Setback

Proposal

• p. 8

SMC 17C.110.310

Proposed Minimum Lot Width

Single-Family Attached Houses Multi-Dwelling Structures Zone: RTF, RMF, RHD RTF RMF, RHD 25-ft. lot width

• 16 ft. with alley parking

and no curb cut not permitted 25-ft. lot width

Lot Dimensions

• p. 5 - SMC 17C.110.200

Table 17C.110-3

• Lot dimension and other development

standards

– RTF, RMF, RHD zones

• Transition standards

– Adjacent to RSF, RTF zone

• Landscape buffers, setbacks
• Upper level step backs

– Conditional uses – Lot size transition – Multifamily design standards

Existing Development Code
