Inferring Human Interaction from Motion Trajectories

University of California, Los Angeles, USA

1 Department of Statistics 2 Department of Psychology

Tianmin Shu1 Yujia Peng2 Hongjing Lu2 Song-Chun Zhu1 Lifeng Fan1

People are adept at inferring social interactions from highly simplified stimuli.

Heider and Simmel (1944)

• Later studies showed that the perception of human-like interactions relies on some critical

low-level motion cues, e.g., speed and motion direction. (Dittrich & Lea, 1994; Scholl &

Tremoulet, 2000; Tremoulet & Feldman, 2000, 2006; Gao, Newman, & Scholl, 2009; Gao, McCarthy, & Scholl, 2010…)

[Gao & Scholl, 2011] Chasing vs. Stalking

Real-life Stimuli

[Shu et al., 2015] [Choi et al., 2009]

(Shu, et al., 2015)

Tracking human trajectories and labeling group human interactions.

[Shu et al., CVPR 2015]

Experiment 1

• Participants
• 33 participants from the UCLA subject pool
• Stimuli
• 24 interactive actions
• 24 non-interactive actions
• Duration: 15-33 s
• 4 out of 48 actions were used as practice
• Task
• Judging whether the two agents are

interacting at each moment.

1 2 1 2 1 2 1 2

Interactive instances Non-interactive instances

Interactive Example

Non-interactive Example

Human Experiment Results

Video frame

Interactive action 4 Non-interactive action 40

Human Experiment Results

N = 33

Video frame

Interactive action 4 Non-interactive action 40

• Previous studies have developed Bayesian models to reason about the

intentions of agents when moving in maze-like environments

(Baker, Goodman, & Tenenbaum, 2008; Baker, Saxe, and Tenenbaum, 2009; Ullman et al., 2009; Baker, 2012...)

Computational Model

[Ullman et al., 2009] [Baker, 2012]

• Previous studies have developed Bayesian models to reason about the

intentions of agents when moving in maze-like environments

(Baker, Goodman, & Tenenbaum, 2008; Baker, Saxe, and Tenenbaum, 2009; Ullman et al., 2009; Baker, 2012...)

• In the current study, we are not trying to explicitly infer intention.

Instead, we want to see if the model can capture statistical regularities (e.g. motion patterns) that can signal human interaction.

Computational Model

Computational Model

S: latent sub-interactions Y: interaction labels Г : input layer, motion trajectories of two agents

(0: interactive, 1: non-interactive)

• 1. Conditional interactive fields (CIFs)

Interactivity can be represented by latent motion fields, each capturing the relative motion between the two agents.

Linear Dynamic System:

An example CIF: Orbiting

• Arrows: represent the mean relative motion at different locations
• Intensities of the arrows: the relative spatial density which increases from light to dark

• 2. Temporal parsing by latent sub-interactions

Latent motion fields can vary over time, which enables the model to characterize the behavioral change of the agents.

A Simple View of Our Model

Interaction ≈ Fields + Procedure

Formulation

• Г: input of motion trajectories
• S: latent variable, sub-interaction
• Y: interaction labels

Given the input of motion trajectories Г, the model infers the posterior distribution of the latent variables S and Y:

(0: interactive, 1: non-interactive)

Formulation

• Г: input of motion trajectories
• S: latent variable, sub-interaction
• Y: interaction labels

(0: interactive, 1: non-interactive)

Formulation

• Г: input of motion trajectories
• S: latent variable, sub-interaction
• Y: interaction labels

(0: interactive, 1: non-interactive)

Formulation

• Г: input of motion trajectories
• S: latent variable, sub-interaction
• Y: interaction labels

(0: interactive, 1: non-interactive)

Learning

• Gibbs sampling

The model infers the current status of latent variables

Inference

Infer st under the assumption of interaction (i.e., yt = 1) The model infers the current status of latent variables

Inference

Infer st under the assumption of interaction (i.e., yt = 1) The posterior probability of yt = 1 given st ∈ S The model infers the current status of latent variables

Inference

Prediction

Predict/synthesize xt+1 given yt and st Predict/synthesize st+1 given yt+1 and all previous s yt+1 = 1: interactive trajectories yt+1 = 0: non-interactive trajectories

Training Data

• 1. UCLA aerial event dataset (Shu et al. 2015)

http://www.stat.ucla.edu/˜tianmin.shu/AerialVideo/AerialVideo.html

• 131 training instances (excluding trajectories used in

the stimuli)

• 22 validation instances from 44 stimuli
• 22 testing instances from the remaining stimuli

Training Data

• 1. UCLA aerial event dataset (Shu et al. 2015)

http://www.stat.ucla.edu/˜tianmin.shu/AerialVideo/AerialVideo.html

• 131 training instances (excluding trajectories used in

the stimuli)

• 22 validation instances from 44 stimuli
• 22 testing instances from the remaining stimuli
• 2. The second dataset was created from the
• riginal Heider-Simmel animation (i.e., two

triangles and one circle).

• 27 training instances

A few predominant CIFs:

• 1. approaching
• Arrows: represent the mean relative motion at different locations
• Intensities of the arrows: the relative spatial density which increases from light to dark

A few predominant CIFs:

• 2. Passing by (upper part)

A few predominant CIFs:

• 2. Passing by (upper part) and following (lower part)

A few predominant CIFs:

• 3. Leaving/avoiding

The frequencies of CIFs. Illustration of the top five frequent CIFs learned from the training data.

Temporal Parsing of Fields in Heider-Simmel Animations

Interactiveness Inference in Aerial Videos

Experiment 1 Results

Comparison of online predictions by our full model (|S| = 15) (orange) and humans (blue) over time (in seconds) on testing videos.

Time (s) Time (s) Time (s) Interactive ratings

Experiment 1 Results

Comparison of online predictions by our full model (|S| = 15) (orange) and humans (blue) over time (in seconds) on testing videos.

Time (s) Time (s) Time (s) Interactive ratings

Trained on Heider-simmel stimuli, tested on aerial video stimuli: r = 0.640 and RMSE of 0.227

Test the Model Trained from Aerial Videos on Heider-Simmel Stimuli

Experiment 2

• We used the model trained on aerial videos to synthesize new interactive videos:

Experiment 2

• We used the model trained on aerial videos to synthesize new interactive videos
• The model generated 10 interactive animations

Synthesized interactive video (y=1)

Model predicted interactiveness

5x

Experiment 2

• We used the model trained on aerial videos to synthesize new interactive videos
• The model generated 10 interactive animations

Synthesized interactive video (y=1)

Model predicted interactiveness

5x

Model predicted interactiveness

Experiment 2

• We used the model (trained on aerial videos) to synthesize new interactive videos:
• The model generated 10 interactive animations and 10 non-interactive animations

Synthesized non-interactive video (y=0) 5x

Experiment 2 Results

N = 17

• The interactiveness between the two agents in the synthesized videos was judged

accurately by human observers.

• The model effectively captured the visual features that signal potential interactivity

between agents.

Conclusion

• Decontextualized animations based on real-life videos enable human

perception of social interactions.

Conclusion

• Decontextualized animations based on real-life videos enable human

perception of social interactions.

• The hierarchical model can learn the statistic regularity of common

sub-interactions, and accounts for human judgments of interactiveness.

Conclusion

• Decontextualized animations based on real-life videos enable human

perception of social interactions.

• The hierarchical model can learn the statistic regularity of common

sub-interactions, and accounts for human judgments of interactiveness.

• Results suggest that human interactions can be decomposed into

sub-interactions such as approaching, walking in parallel, or orbiting.

For more details, please visit our website

http://www.stat.ucla.edu/~tianmin.shu/HeiderSimmel/CogSci17/
