In-session workshop on safety standards Vienna, 19 July 2016

Page 1 /13

Page 2 /13

Propane for light commercial segment can be

considered as most sustainable refrigerant because of both, direct and indirect emissions With 150g of propane charge it’s possible to cover

unitary, plug-in applications

most of unitary, plug-in applications An international effort to increase HC charge

limit in -89 standard to cover all plug in range

with single circuit solution is in progress

Page 3 /13

International level

International and European committees and standards International and European committees and standards

European level

Page 4 /13

Relevant standards and resulting amount of low GWP Relevant standards and resulting amount of low GWP refrigerants refrigerants

1 kg or more 150 g OK 150 g ?

Page 5 /13

A Applicable pplicable types of types of equipment related to the IEC 60335 equipment related to the IEC 60335-

• 2

2-

• 89

89

Page 6 /13

Title of committee/working Title of committee/working group and group and task task

Title of committee/working group: TC61/SC61C/WG 4 Task of TC61/SC61C/WG4: IEC 60335-2-89-A2/Ed2: Household and similar electrical appliances - Safety - Part 2-89: Particular requirements for commercial refrigerating appliances with an incorporated or remote refrigerant unit or compressor To define the maximum flammable refrigerant amount for appliances according to IEC 60335-2-89 and measures to maintain the equivalent safety level as for the present limit.

Page 7 /13

Details about TC61/SC61C/WG4 Details about TC61/SC61C/WG4

Initiation of WG4: According to decision 20 of the Tokyo plenary meeting of IEC SC61C on 13 November 2014, (IEC 60335-2-89-A2/Ed2: Household and similar electrical appliances - Safety - Part 2-89: Particular requirements for commercial refrigerating appliances with an incorporated or remote refrigerant

Page 8 /13

an incorporated or remote refrigerant unit or compressor) WG4 was established to discuss the increase

• f the limit for the filling amount of

flammable refrigerants. Members of the WG4: 23 Members out of 13 countries (AT, BE, BR, CZ, DE, FI, GB, IT, JO, JP, NZ, SK and US)

What issues are under discussion within TC61/SC61C/WG4 What issues are under discussion within TC61/SC61C/WG4

GB proposal:

• Maximum charge of flammable refrigerant – 0,500 kg
• 2 levels for increasing the current limit of 150 g flammable refrigerant –
• ne level up to 300 g and second level up to 500 g flammable refrigerant
• For these 2 levels different tests and measurements would be necessary

like – mechanical impact test, vibration (transport) test, Drop test, minimum air flow, leak simulation test, …. DE proposal:

Page 9 /13

DE proposal:

• Maximum charge of flammable refrigerant – 26 m³ x LFL

e.g. with the LFL 0,038 kg/m³ of R290 = 0,988 kg

• The DE proposal was based on the relevant parts of the IEC 60335-2-40.

In detail this standard has normative requirements to service operations, ventilation requirements, secondary circuits, … Current issues under discussion: Requirements for tubing, hermetically sealed system, symbol for minimum room size, leakage tests and CFD simulation, sources of ignition, adjacent appliances, …

What direction is TC61/SC61C/WG4 going What direction is TC61/SC61C/WG4 going The risk with more than 150 g flammable refrigerant must be the same as we have with the current limit of 150 g

In detail and in our proposal of the WG4:

• The maximum charge limit for flammable refrigerant – 26 [m³] x LFL [kg/m³]
• Refrigerants which are lighter than air (e.g. R50) should be excluded

For appliances with more than 150 g flammable refrigerant…

• Determination of gas concentration might be necessary

Page 10/13

• Determination of gas concentration might be necessary
• Minimum air flow for appliances between 8 x LFL and 26 x LFL should be

required

• The airflow should be guaranteed in any operating conditions
• No refrigerant-containing parts should be exposed to the outside of the

appliance

• Low temperature solder alloys will be not accepted for pipe connections
• All electrical components should be non-sparking electrical apparatus
• Application should have a tested tightness control level of less than 3 grams

per year

Proposal to start a new project or Review Report for maintenance Preparatory Proposal Preliminary Preparation of Working Draft within the working group (WD) Potential work item recorded or maintenance survey

1 2 3

Action Stages Time limits

12 Months

• nths

Circulation of RVN or RR

Time limits for working documents of IEC Time limits for working documents of IEC

When mature, the CD is circulated as a Committee Draft for Vote (CDV) Final Draft International Standard prepared from approved CDV and NCs comments (FDIS) IEC publishes International Standard (IS) Enquiry Approval Publication Committee Working draft circulated as Committee Draft (CD) within the working group (WD)

3 4 5 6 7

12 24 Month 33 Months 36 Months

Page 11/13

Possible time scale of TC61/SC61C/WG4 Possible time scale of TC61/SC61C/WG4

The current proposal of WG4 – 61C/671/DC – is circulating in the IEC National Committees and the closing date is 2016-08-12

Time scale for including the WG4 proposal into the IEC 60335-2-89:

• August 2016 :Closing date of WG4 proposal with feedbacks from the NC
• October 2016: WG4 meeting and SC61C meeting in week 40 (4th to 8th of

October 2016) with work on the compilation of comments on the WG4

Page 12/13

October 2016) with work on the compilation of comments on the WG4 proposal – 61C/671/DC

• Q4_2016:

Creation of a CDV out of the compilated comments

• Q3_2017:

Discussion of CDV and creation of a FDIS

• Q2_2018:

Publishing of the 3rd edition from the IEC 60335-2-89 standard

Thank you

Page 13/13
