Safety Design in Buildings @Intersec 2014 Leading the standards of - - PowerPoint PPT Presentation

Leading the standards of Life-safety and Property-protection...

1

Safety Design in Buildings @Intersec 2014

Leading the standards of Life-safety and Property-protection...

2

Fire Protection Balance in New Codes for Life Safety

Leading the standards of Life-safety and Property-protection...

 Fire is the most tangible of all visible mysteries.  We can’t rely on a single action to ensure Life Safety.  The Balanced Approach to Fire Protection is an absolute necessity.

Important Facts…

Leading the standards of Life-safety and Property-protection...

Fire Protection Philosophy

• Passive Fire Protection
• Active Fire Protection

DIIMM Balanced approach in New Codes

• UAE Fire Code
• International Codes

Questions & Close

Topic Summary

Leading the standards of Life-safety and Property-protection...

• Fire Statistics
• UAE Fires – Cause, Prevention, Containment, Role of Authorities
• Importance of Life Safety
• Fire Protection – Engineering & Philosophy
• DIIMM Philosophy
• Balanced Fire Protection



Passive



Active

• What do codes say?

What am I going to talk about?

Leading the standards of Life-safety and Property-protection...

117 million fires worldwide each year 84% deaths are in the residential fires 75% of all fire deaths are caused by SMOKE 60% of people killed in fires are not in the room of it’s origin 50% of survivors could not see more than 3½ m

Fire Statistics at a Glance

1,375 million fires in America alone At least 5,350 major fires  15 every day 2,855 fire deaths  1 every 184 minutes (all fires) 2,470 fire deaths  1 every 213 minutes (structural fires) 16,500 civilian injuries  1 every 32 minutes $12.4 billion direct property damages

Global Data:

Leading the standards of Life-safety and Property-protection...

UAE Data:

Fire in the UAE;

• 2011:

3,274

• 2010:

4,980

• 2009:

2,602

• 2008:

3,173

34% reduction in fires in 2011

• No. of casualties fell to 33 in 2011 (from 174 in 2010)
• No. of injuries fell to 237 in 2011 (from 2525 in 2010)

Fire Statistics at a Glance

Leading the standards of Life-safety and Property-protection...

8

Leading the standards of Life-safety and Property-protection...

9

Leading the standards of Life-safety and Property-protection...

Key to reduced fires –

 Public Awareness  Code Implementation  Code Compliance  Education & Training  Bold Initiatives by AHJ

How did it happen?

Leading the standards of Life-safety and Property-protection...

11

UAE fire incidents 500 times less than in Paris alone

Major General Rashid Thani Al Matroushi (DG OF D-CD AND responds to few burning questions - Published Thursday, January 10, 2013 Comparative analysis of fire incidents in 2010 (per 100,000 people) “For the year 2013 we are keen to realize the lowest levels, in terms of the number and size of fire incidents per 100 people and in comparison to the levels in other nations, Mr. Al Matroushi said”.

UAE 34 Paris 17,966 Toronto 5,673 Frankfurt 2,570 London 189 Singapore 105

Leading the standards of Life-safety and Property-protection...

 Life Safety  Property Protection  Continuity of Operation

Fire Protection Philosophy

Leading the standards of Life-safety and Property-protection...

13

Keeping the significance of Safety Design in Buildings for human lives in mind, I encourage the audience and all stake-holders – Building Owners, Architects, Consultants, Contractors, AHJ i.e. Civil Defence Authority, Fire Departments – to take up the life safety issues with utmost priority and responsibility…

A message with great sense of responsibility towards human lives is reflected in one of the verses from the Holy Qur’an…

Safety Design for Life Safety

Leading the standards of Life-safety and Property-protection...

ِ ِِمِْهَْرل ِِنٰـَمْهَْرل ِهللَْ ِِمْبش.

اًعمَِـج ـساهنرل اـممْـأ اـَهنـأـكـف اـهاـممْـأ مِـَـو

And whoever saved one life, it is as though he saved entire mankind (5:32 – Al Qur’an)

Leading the standards of Life-safety and Property-protection...

Suppression Focus on Education Detection Containment

Passive & Active Fire Protection – A Balance

Leading the standards of Life-safety and Property-protection...

16

The Fire Protection Safety Arch

Leading the standards of Life-safety and Property-protection...

Passive Fire Protection It’s invisible but working all the time!

The Sleeping Policeman !!!

Leading the standards of Life-safety and Property-protection...

Smoke is the killer?

Leading the standards of Life-safety and Property-protection...

Consider

A square room 20 ft x 20 ft x 20 ft has a pencil hole between compartments. How long will it take for the smoke to fill the room to a thickness such that you cannot see your hands 18 inches in front of you?

How Fast Does Smoke Travel?

Leading the standards of Life-safety and Property-protection...

Pencil Hole 3 minutes 40 seconds

20 ft x 20 ft x 20 ft room

Leading the standards of Life-safety and Property-protection...

Passive Fire Protection

“Passive” fire protection is an integral part of fire protection engineering. Fire Stopping Fire Proofing Fire Doors Fire Dampers Firestop is a general term for a passive fire protection system.

Leading the standards of Life-safety and Property-protection...

Where is fire-stop used?

Leading the standards of Life-safety and Property-protection...

This category addresses

• penings

in fire rated assemblies where penetrants are passing through a fire-rated construction and where the integrity of the wall and/or floor needs to be maintained.

Through Penetrations Fire Stop System

Leading the standards of Life-safety and Property-protection...

Penetrations

Leading the standards of Life-safety and Property-protection...

Membrane Penetration Fire Stop System

Openings in fire rated assemblies where only one side of the fire rated barrier is penetrated. Such as electrical outlet boxes and other electrical devices.

Leading the standards of Life-safety and Property-protection...

Fire Resistive Joint Systems

This category addresses any gap, joint, or opening (whether static or dynamic) between two fire-rated barriers including where the top of a wall meets a floor; wall edge to wall edge configurations; floor edge to floor edge configurations; floor edge to wall configurations.

Leading the standards of Life-safety and Property-protection...

Fire-resistant Joints

Head of Wall Vertical Joints Horizontal Joints Edge of Slab

Leading the standards of Life-safety and Property-protection...

Perimeter Fire Barriers

This category addresses any gap, joint,

• r
• pening, whether static
• r dynamic, between a

fire-rated floor assembly and a non-rated exterior wall assembly.

Leading the standards of Life-safety and Property-protection...

29

Building Envelop

Most talked about issue worldwide! What are the dynamics

• f vertical spread in a

high-rise building?

Leading the standards of Life-safety and Property-protection...

30

Rated Floor Assembly and non-rated Curtain Wall System Elevated temp. and pressure breaks lower vision glass Flames may erupt through the

• windows. Oxygen fuels the fire.

Fire attacks the curtain wall structure from both sides causing a premature failure of the wall structure and potentially the vision glass above!

Vision Glass (upper floor)

Leading the standards of Life-safety and Property-protection...

31

Firestop Coating or Sealant over mineral wool safing

Rated Floor Assembly and non- rated Curtain Wall System

A properly designed & tested Perimeter Fire Barrier System not only protects the perimeter joint but critical wall framing and support elements as well! Properly installed & supported mineral wool spandrel insulation

Leading the standards of Life-safety and Property-protection...

32 32

Extending the Rated Floor to the Wall...

In rated construction, all floors are rated The perimeter joint must be sealed with an approved material or system that extends this rating to the exterior wall surface

MANDATORY!

Leading the standards of Life-safety and Property-protection...

Active Fire Protection

24 x 7

!

• Detection & Notification
• Suppression & Extinguishing

Leading the standards of Life-safety and Property-protection...

Fire Protection Systems

• Occupancy, Fire area, Height, Occupant Load
• Chapter 9, NFPA 13

Sprinkler Systems

• Height, Occupancy, Occupant Load
• Chapter9, NFPA 14

Standpipe Systems

• Occupancy, Occupant Load
• Chapter 8, NFPA 72

Fire Alarm and Detection Systems

• Chapter 10, NFPA 92

Smoke Control Systems

Leading the standards of Life-safety and Property-protection...

Sprinkler Protection

Leading the standards of Life-safety and Property-protection...

DIIMM Philosophy of Fire Protection

The individual elements of DIIMM philosophy put together result in the much needed ‘Safe System Installation’. The elements being;

• Design
• Install
• Inspect
• Maintain/Manage

36

Leading the standards of Life-safety and Property-protection...

 Design:

Most appropriate listed /designed system(s)

37

DIIMM Philosophy of Fire Protection

Code Requirement?

Design & Selection in accordance with

• UAE Fire Code (Main)

:Section 21.6

• Annexure A.1.21

: Section 6

Leading the standards of Life-safety and Property-protection...

38

Design & Selection of systems

 Products & Systems  Submittal  Quality Assurance  Storage, Handling  Etc.

 Design…

DIIMM Philosophy of Fire Protection

Leading the standards of Life-safety and Property-protection...

39

Submittal

6.3.1 Formal submittal by manufacturer consisting of;

• a. Product Data –Specifications, Technical Data and MSDS for each material

including the composition and limitations, if any.

• b. Design Listings and certifications – System design listing including illustrations as

per applicable referenced standard

• c. Engineering Judgment (EJ) – In case of deviation and shall be site specific
• d. Method Statement with manufacturer’s installation instructions
• e. 10 years standard warranty

Leading the standards of Life-safety and Property-protection...

 Install:

6.8 For installation of all the systems, installer shall strictly follow design listed and certified systems including illustrations therein and manufacturer’s installation instruction.

40

DIIMM Philosophy of Fire Protection

Code Requirement?

Design & Selection in accordance with

• UAE Fire Code (Main)

:Section 21.10

• Annexure A.1.21

: Section 6.8, 6.9

Leading the standards of Life-safety and Property-protection...

 Install…

6.9 Installer qualification



Installer shall be certified.



No installer without Civil Defence license shall work on the site.



To be certified, the installer shall be licensed by Civil Defence.

41

DIIMM Philosophy of Fire Protection

Leading the standards of Life-safety and Property-protection...

 Inspect:

Fire protection systems shall be inspected in accordance with applicable local and international codes.

 NFPA 25

: Standard for the Inspection, Testing & Maintenance

• f Water-Based-Fire Protection Systems

 ASTM E2174

: Standard Practice for On-Site Inspection of Installed Fire Stops

 ASTM E2393

: Standard Practice for On-Site Inspection of Installed Fire Resistive Joint Systems and Perimeter Fire Barriers.

42

DIIMM Philosophy of Fire Protection

Leading the standards of Life-safety and Property-protection...

43

Code Requirement?

Inspection & Field Quality Control

• UAE Fire Code (Main)

:Section 21.14

• Annexure A.1.21

: Section 6.12

Leading the standards of Life-safety and Property-protection...

44

Code Requirement?

UAE Fire & Life Safety Code of Practice 2011 (Annexure A.1.21) 6.12. Inspection

6.12.1. Inspection of through penetration firestop systems shall be in accordance with ASTM E 2174, Standard Practice for On-Site Inspection of Installed Fire Stops. 6.12.2. Inspection of fire resistive joints and perimeter barriers shall be in accordance with ASTM E 2393, Standard Practice for On-Site Inspection of Installed Fire Resistive Joint Systems and Perimeter Fire Barriers.

Leading the standards of Life-safety and Property-protection...

45

Code Requirement?

UAE Fire & Life Safety Code of Practice 2011 (Annexure A.1.21) 6.12. Inspection

6.12.3. Inspection of the cladding, roofing and glazing systems shall be carried out in each phase of the installation progress, ensuring the appropriate implementation of the Manufacturer’s recommendations. 6.12.4. Work shall not be certified as completed unless approved by the inspecting agency. 6.12.5. Inspector Qualification Inspection Agency shall be accredited to IAS AC 291 criteria of International Accreditation Service acceptable to Civil Defence Authority.

Leading the standards of Life-safety and Property-protection...

 Maintain/Manage:



Over a period of time, installed fire & life safety systems deteriorate.



Building owners shall undertake annual inspections to comply with local regulations.



Damaged or deteriorated systems or system components shall be regularly maintained and/or replaced.

46

DIIMM Philosophy of Fire Protection

Leading the standards of Life-safety and Property-protection...

47

UAE Fire & Life Safety Code of Practice 2011 (Annexure A.1.21) 6.14. Maintenance & Management

6.14.1. Provide protection and maintain conditions during and after installation that ensure installed fire stopping, curtain-wall, cladding, roofing and glazing systems are without damage or deterioration at the time of Substantial

• Completion. If, despite such protection, damage or deterioration occurs, cut
• ut and remove damaged or deteriorated systems immediately and install

new materials.

Code Requirement?

Leading the standards of Life-safety and Property-protection...

48

2011 UAE Fire & Life Safety Code of Practice & Annexure A.1.21 6.14. Maintenance & Management

6.14.2. The condition of installed firestop systems shall be visually inspected by the owner or owner’s inspection agency annually. Damaged, altered or breached firestop systems shall be properly repaired, restored or replaced to comply with applicable codes as per the guidelines of Civil Defense. 6.14.3. Any new openings made therein for passage of through penetrants shall be protected with approved firestop system to comply with applicable codes as per the guidelines of Civil Defense.

Code Requirement?

Leading the standards of Life-safety and Property-protection...

Understanding of the code



UAE Fire & Life Safety Code of Practice 2011



International Codes

Leading the standards of Life-safety and Property-protection...

Features of Int’l codes

UAE Fire Code 2011

Chapter 1: Fire-rated construction & compartmentation

4: Fire-resistance Rating Requirements 5: Exterior Walls 6: Horizontal Separations 9: Openings 13: Height & Area Requirements 20: Fire-resistive Materials & Construction 21: Fire Stopping 22: Ducts & Air Transfer Openings

IBC 2012

Chapter 7: Fire & Smoke Protection

703 & 704: Fire-resistance Ratings 705: Exterior Walls 706: Fire Walls 707: Fire Barriers 708: Shaft Enclosures 709: Fire Partitions 710: Smoke Barriers 711: Smoke Partitions

Leading the standards of Life-safety and Property-protection...

UAE Fire Code 2011

Chapter 1: Fire-rated construction & compartmentation

23: Smoke Barriers 24: Smoke Barrier Penetrations 25: Smoke Dampers 26: Vertical Openings 29: Convenience Openings 30: Service Openings 33: Concealed Spaces 34-38: Interior Finishes

IBC 2012

Chapter 7: Fire & Smoke Protection

712: Horizontal Assemblies 713: Penetrations 714: Fire-resistant Joints 715: Opening Protectives 716: Duct & Air Transfer Openings 717: Concealed Spaces 718-721: Others Chapter 8: Interior Finishes

Features of Int’l codes

Leading the standards of Life-safety and Property-protection...

UAE Fire Code 2011

Chapter 9: Fire Protection Systems

5, 9-35: Automatic Sprinkler System 42-47: Automatic Fire Extinguishing Systems 6-7: Fire Pumps

Chapter 4: Portable Fire Extinguishers Chapter 8: Fire Detection & Alarm Systems

IBC 2012

Chapter 9: Fire Protection Systems

903: Automatic Sprinkler Systems 904: Automatic Fire-extinguishing Systems 905: Standpipe Systems 906: Portable Fire Extinguishers 907: Fire Alarm & Detection Systems 908: Emergency Alarm System

Features of Int’l codes

Leading the standards of Life-safety and Property-protection...

UAE Fire Code 2011

Chapter 10: Mechanical Ventilation & Smoke Control Systems

2-45: Smoke Ventilation System

IBC 2012

Chapter 9: Fire Protection Systems

909: Smoke Control System 910: Smoke & Heat Vents 911: Fire Command Center 912: Fire Department Connections 913: Fire Pumps 914-915: Emergency Response Systems

Features of Int’l codes

Leading the standards of Life-safety and Property-protection...

Questions?

Sajid Raza

M - +971 50 801 6050 E – sraza@butlerme.com
