Improvements to MongoRocks in 2017 Mark Callaghan Member of Technical Sta ff , Facebook MongoDB Engines mmapv1 - update-in-place B-Tree WiredTiger - copy-on-write B-Tree MongoRocks - log structured merge tree (LSM) Why MongoRocks?

slide-1
SLIDE 1

Improvements to MongoRocks in 2017

Mark Callaghan

Member of Technical Staff, Facebook

slide-2
SLIDE 2
  • mmapv1 - update-in-place B-Tree
  • WiredTiger - copy-on-write B-Tree
  • MongoRocks - log structured merge tree (LSM)

MongoDB Engines

slide-3
SLIDE 3
  • Best space efficiency
  • Better write efficiency
  • Good read efficiency
  • Effective with SSD & disk

Why MongoRocks?

RUM = Read, Update, Memory

  • An algorithm can’t be optimal for all 3
  • See Designing Access Methods: The RUM Conjecture
slide-4
SLIDE 4

We make MongoRocks better by making RocksDB better

  • Smarter compaction
  • Support for database >> RAM
  • Less response time variance
  • Much more done and in progress

Making MongoRocks better

slide-5
SLIDE 5
  • RocksDB has too many options
  • CPU bound on IO-heavy tests
  • Percona Server isn’t using recent RocksDB releases

Things to make better in MongoRocks

slide-6
SLIDE 6

Percona Server for MongoDB

  • 3.0.15 with RocksDB 4.1.0 (October 2015)
  • 3.2.15 with RocksDB 4.4.1 (February 2016)
  • 3.4.6 with RocksDB 4.13.5 (December 2016)

Compiled from source

  • MongoDB 3.4.7 with RocksDB 5.7.3 (August 2017)

MongoDB versions tested

slide-7
SLIDE 7
  • N collections (N is 1 or 16)
  • 1 PK, 3 secondary indexes per collection
  • Inserts are in PK order, random for secondary indexes
  • Queries are short range scans
  • Supports MongoDB and MySQL
  • In Python, need to rewrite with something faster

Insert benchmark

Runs in 4 phases 1. Insert-only - load X million rows 2. Scan PK, secondary indexes in sequence 3. N clients do queries, N clients each insert 1000/s 4. N clients do queries, N clients each insert 100/s Configuration options

  • Database in memory vs IO-bound
  • Client per collection

Finding database stalls for 10 years

slide-8
SLIDE 8

Load throughput

IO-bound

mmapv1 WiredTiger MongoRocks 3.0 3.2 3.4 3.0 3.2 3.4 3.0 3.2 3.4 Inserts/second 15000 30000 45000 60000

51,943 14,234 14,446 47,990 14,179 13,983 7,827 17,286 13,157

Large server, 16 clients

In-memory

mmapv1 WiredTiger MongoRocks 3.0 3.2 3.4 3.0 3.2 3.4 3.0 3.2 3.4 Inserts/second 30000 60000 90000 120000

54,933 93,284 24,286 50,241 94,841 21,122 7,931 113,533 17,778

slide-9
SLIDE 9

IO-bound load efficiency

Large server, 16 clients, database >> RAM, v3.4.6

Avg IPS IO read/ insert IO KB read/ insert IO KB write/insert CPU/insert Size (GB) mmapv1 14446 3.95 22.72 25.53 595 11xx WiredTiger 14234 1.81 26.26 39.31 2082 577 MongoRocks 51493 0.05 2.83 10.32 461 487

slide-10
SLIDE 10

Scan secondary indexes

Large server, 16 clients

IO-bound

mmapv1 WiredTiger MongoRocks 3.0 3.2 3.4 3.0 3.2 3.4 3.0 3.2 3.4 Seconds 1250 2500 3750 5000

3,538 2,182 1,474 3,022 2,149 1,461 13,904 2,078 1,334 In-memory

mmapv1 WiredTiger MongoRocks 3.0 3.2 3.4 3.0 3.2 3.4 3.0 3.2 3.4 Seconds 250 500 750 1000

363 230 121 340 231 116 1,932 159 103

slide-11
SLIDE 11

IO-bound: read-write

mmapv1 WiredTiger MongoRocks 3.0 3.2 3.4 3.0 3.2 3.4 3.0 3.2 3.4 Queries/second 1500 3000 4500 6000

5,390 630 175 5,596 484 120 432 4,025 103

Large server, 16 clients, database >> RAM

mmapv1 WiredTiger MongoRocks 3.0 3.2 3.4 3.0 3.2 3.4 3.0 3.2 3.4 Inserts/second 4000 8000 12000 16000

15,845 13,221 12,253 15,845 13,930 12,277 7,119 12,812 11,944

slide-12
SLIDE 12

IO-bound: read-write

Large server, 16 clients, database >> RAM, v3.4.6

Avg IPS Avg QPS IO MB read/
 second IO MB write/ second CPU mmapv1 12253 175 416 324 8.3 WiredTiger 13221 630 631 567 42.4 MongoRocks 15845 5390 914 504 21.2

slide-13
SLIDE 13

In-memory: read-write

mmapv1 WiredTiger MongoRocks 3.0 3.2 3.4 3.0 3.2 3.4 3.0 3.2 3.4 Queries/second 10000 20000 30000 40000

21,272 29,214 9,822 23,349 29,379 7,218 12,820 32,256 1,010

Large server, 16 clients, database >> RAM

mmapv1 WiredTiger MongoRocks 3.0 3.2 3.4 3.0 3.2 3.4 3.0 3.2 3.4 Inserts/second 4000 8000 12000 16000

15,845 15,845 15,754 15,845 15,845 15,352 7,029 15,364 15,276

slide-14
SLIDE 14

load: oplog impact

IO-bound

mmap WT Rocks

  • plog

no oplog

  • plog

no oplog

  • plog

no oplog Inserts/second 20000 40000 60000 80000

71,395 14,976 14,720 51,493 14,234 14,446

Large server, 16 clients, v3.4.6

In-memory

mmap WT Rocks

  • plog

no oplog

  • plog

no oplog

  • plog

no oplog Inserts/second 40000 80000 120000 160000

77,906 145,180 25,649 54,933 93,284 24,286

slide-15
SLIDE 15

Load: benefit from new features

Small server, 1 clients, database >> RAM, v3.4.7

Load Avg IPS IO read/ insert IO KB read/ insert IO KB write/insert CPU/insert

  • ld features

9319 0.04 4.42 18.68 6124 new features 10806 0.02 1.91 14.17 5283

slide-16
SLIDE 16

rocksdb.org mongorocks.org smalldatum.blogspot.com twitter.com/markcallaghan

Thank you

slide-17
SLIDE 17

An LSM in one slide

1000.sst
 0:999 999.sst
 0:999 998.sst
 0:999 997.sst 0:999 993.sst 0:249 994.sst
 250:499 995.sst 500:749 996.sst
 750:999 802.sst
 0:24 610.sst
 25:50

…

471.sst 950:974 480.sst
 975:999 49.sst
 0:1 1001.sst
 2:4

…

2.sst 995:996 1.sst
 997:999

Level-0 Level-1 Level-2 Level-3 memtable write ahead log

slide-18
SLIDE 18

Space efficiency

  • Fragmentation
  • Fixed page size
  • Per-row metadata
  • Key prefix encoding

Efficiency: RocksDB vs a B-Tree

Write efficiency

  • Uses more space = more data to write
  • sizeof(page) / sizeof(row)
  • large writes
  • write delta

Read efficiency

  • More data in cache & less data to cache
  • Bloom filter
  • Spend less on writes, use more for reads
  • Read-free index maintenance
