IMPLEMENTING COLLOCATION GROUPS #1

IMPLEMENTING COLLOCATION GROUPS #2

About Draper Lab

• An independent, not-for-profit corporation

dedicated to applied research, engineering development, education, and technology transfer

– Spun off from the Massachusetts Institute of Technology in 1973 – Expertise in guidance, navigation and control systems – Early applications: U.S. Navy's Fleet Ballistic Missile Program and NASA's Apollo Program

IMPLEMENTING COLLOCATION GROUPS #3

Agenda

• Why collocation groups?
• ITSM code components
• Additional tools
• A process to move 40TB
• Conclusions

IMPLEMENTING COLLOCATION GROUPS #4

Why do I want Collocation groups?

• Number of nodes vs. number of slots
• 1. Nodes < slots; collocate by node or

filespace

• 2. Nodes > slots; can't collocate
• If collocate is on, no control of node mixing,

still 1 mount per node during migration

• Node size vs. tape capacity
• 1. Size > tape cap.; collocation fills tape
• 2. Size < tape cap.; collocation wastes tape
• Collocation by group makes "supernodes"

which work for both case 1's

IMPLEMENTING COLLOCATION GROUPS #5

Server Configuration

2 33,000,000 4,300,000 For desktops SD2 40 230,000,000 45,400,000 For desktops SD 18 47,500,000 8,500,000 For servers SS 6 5,000 5,500 Library manager LM Physical TB Number of files DB size (pages) Function Acronym

• Sun v480 4 processors, Solaris 9
• Raw disk for db, log, backuppool, no raid
• TSM server code at 5.3.1.3

IMPLEMENTING COLLOCATION GROUPS #6

The starting SD server mess

• Volumes

– 417 to process – Average nodes / volume is 188 – Max is 713 – 25 are over 500

• Nodes

– 1635 nodes – Average 48 volumes / node – Max is 132 – 25 are over 100

IMPLEMENTING COLLOCATION GROUPS #7

New server commands

• Def, del, upd, query collocgroup

– names and describes the group

• Def, del collocmember

– adds a node to a group

• Query nodedata

– Very fast!! – Lists tapes which have files for a node or group, no separation by filespace

• Upd stgpool colloc=group

IMPLEMENTING COLLOCATION GROUPS #8

The secret perl scripts

• 4 scripts in the bin directory, not documented
• Used only defgroups.pl

– Analyzes ‘q occ’ data, creates define statements to build the groups – Execution

• ./defgroups.pl id pwd domain size [execute]

IMPLEMENTING COLLOCATION GROUPS #9

Fix the defgroups.pl SQL

• Eliminate stgpool subselect

– Change stgpool subselect to in list, name your tape stgpool

• Eliminate join between nodes & occupancy

– check domain_name with a subselect

• Eliminate check for a collocgroup

– It is always null while implementing

• Runtime drops from “beyond the limits of my

patience” to 5 minutes

IMPLEMENTING COLLOCATION GROUPS #10

Using Query Nodedata

• SQL generates a command for each node

– Also 'q nodedata * stg=pool_name'

• Run file from step1, direct output to 2nd file

– ‘q nodedata’ doesn’t have a corresponding SQL table (the very expensive volumeusage table is close)

• Edit output to get only node name and

volume name

• Load into MySql
• Analyze

IMPLEMENTING COLLOCATION GROUPS #11

Tools

• MySQL desktop development server

– Very handy to have! – No select for nodedata – Do complex joins without killing the server – http://www.mysql.com/

• UltraEdit editor

– Sorting, column editing, hex editing – http://www.ultraedit.com/

IMPLEMENTING COLLOCATION GROUPS #12

Preliminaries

• Decide target number of tapes in each group

– Convert it to 'size in megs' for defgroups.pl – Goal is 4 tapes – We compress at the client, so lto2 capacity is 200G, 'size' is 800,000

• Run defgroups.pl on domain(s)
• Execute the commands from defgroups.pl
• 'Update stgpool <name> colloc=group'
• Mark all current tapes readonly

– Stops migrating to uncollocated filling tapes – Makes SQL easier

• Have as many scratch tapes as groups

IMPLEMENTING COLLOCATION GROUPS #13

A process to minimize tape mounts

• By turning on collocation by group, a move or

reclaim within the tapepool will need an

• utput tape mount for each collocgroup on

the input tape. – Potentially very slow, stressful for the tape drives

• Solution is to move data from tape to devt=file

pools on disk where files are put into groups, then migrate back to tape.

IMPLEMENTING COLLOCATION GROUPS #14

Storage pools

• 3 sequential pools on disk

– seqdisk3, seqdisk4, seqdisk5

• 2 pools receive data from tapes

– Seqdisk3 & 4 each have 2 69G volumes – Not collocated, moves don’t reconstruct

• Seqdisk5 receives data from seqdisk3 & 4

– 170 8GB volumes on 10 146GB drives, each with its own file system. – Collocated by group, moves reconstruct

IMPLEMENTING COLLOCATION GROUPS #15

The schedules and scripts

• Each script is executed every 10 minutes by a

schedule – 6 similar schedules for each script

• For script a, run at 00:00, 00:10, 00:20, etc.
• T4_VOLUMES_ODD, move odd numbered volumes

to seqdisk3

• T4_VOLUMES_EVEN, move even numbered

volumes to seqdisk4

• T4_MOVES, moves seqdisk3 & 4 volumes to

seqdisk5

• T4_MIGRATES, starts migration of seqdisk5 to tape
• T4_VOLUMES_DIRECT move some tapes direct to

tape

IMPLEMENTING COLLOCATION GROUPS #16

SQL to make the scripts

• Use a file as a macro to create the script
• The T4_VOLUMES* script has a prolog with logic

– checks if backuppool migration is running, exit if yes – checks if SEQDISK3 is being used, exit if yes – checks for space in SEQDISK3, if yes then run

• Run SQL to select odd/even volumes ordered by

pct_utilized and append it to the file

• For each volume, need 4 lines in the script

– test if the volumes is still full or filling – goto script lines to issue a move command – issue the move command – exit

IMPLEMENTING COLLOCATION GROUPS #17

Other methods to move all that data

• Direct tape to tape within the pool

– Not as bad as I had feared! – Analyzed which tapes had the fewest groups

• n them and moved them tape to tape.
• Of 278 tapes, 219 have 30 or more (42 max)
• Move nodedata direct tapes to tapes

– Move nodedata list-of-all-the-nodes-in-group – Need extra scratch tapes because source tapes aren't emptied quickly

IMPLEMENTING COLLOCATION GROUPS #18

The results so far

• Started on Aug-5, results as of Sep-8
• Volumes

– 160 to process – Average nodes / volume is 188 – Max is 485 – 10 are over 400

• Nodes

– 1629 nodes – Average 22 volumes / node – Max is 63 – 4 are over 50

IMPLEMENTING COLLOCATION GROUPS #19

Summary

• Match your process to your resources

– Does your disk write speed match your tape read speed?

• The more groups you have, the longer a tape

to tape move or reclaim will take.

• Do 2 processes?

– Few cg's on a tape, do tape to tape. – Lots of cg's on a tape, do tape to file.
