SLIDE 1
iMFLUX
a process innovation company enabled by
CHANGING THE WAY THE WORLD MOLDS PLASTIC PARTS.
OUR VISION OUR PURPOSE
MOVE THE INJECTION MOLDING INDUSTRY TO THE GREEN CURVE
iMFLUX a process innovation company enabled by DESIGN CONTROLS - - PowerPoint PPT Presentation
iMFLUX a process innovation company enabled by DESIGN CONTROLS - - PowerPoint PPT Presentation
iMFLUX a process innovation company enabled by DESIGN CONTROLS SERVICE COMPANY VISION OUR VISION OUR PURPOSE CHANGING THE WAY MOVE THE INJECTION THE WORLD MOLDS MOLDING INDUSTRY PLASTIC PARTS. TO THE GREEN CURVE WHO IS iMFLUX 4 3
SLIDE 2
SLIDE 3
WHO IS iMFLUX
1 2 3 4
PARENT ESTABLISHED LOCATION PURPOSE
WHOLLY OWNED SUBSIDIARY OF THE PROCTER AND GAMBLE COMPANY HEADQUARTERED IN HAMILTON, OH DELIVER SAVINGS, SPEED, INNOVATION TO P&G, P&G SUPPLIERS, AND EXTERNAL PARTNERS FORMED IN 2013 AFTER SEVERAL YEARS OF DEVELOPMENT AND ROLLOUT WITHIN P&G
SLIDE 4
PROPRIETARY PROCESS TECHNOLOGY WORLD CLASS TOOL DESIGN AND MANUFACTURING PAID FOR INNOVATION SERVICES
PRODUCTS & SERVICES
SLIDE 5
Low Constant Pressure
+ Lower clamp tonnage + Less retained stress + Uniform stress (less warp) + Lower melt temps + Less gate blush + Less flash + Less core shift + Improved multi-cavity molds + Enable family molds + Less material degradation + Less mold wear + Less press wear
No Hesitation
+ Reduced flow lines + Reduced tiger striping + Improved thin walling + Higher L/T + Improved optical clarity + Smaller cold runners
Pack-as-it-Fills
+ Less sink marks + Stronger weld lines + Faster cycle times + Improved surface finish
Cavity Pressure Response
+ Reduced flash + Automatic adjust for viscosity + Real time adjust for down cavities + Actuate sequential gates + Lighter parts (1-3%) + Not effected by leaky check ring + Not effected by worn barrel
Considerations
+ Windage designed in tool + Undercuts may hang on + Velocity limited press/tool combination + Recovery limited press/tool combination
iMFLUX PROCESS SUMMARY
Plastic Pressure
T fill-pack-hold-cool (1)
SLIDE 6
Throughput Increase 20-30% Part weight Reduction 1-3% Improved Quality Reduced Scrap Reduced inventory Lower press investment Instant capacity Lower energy Costs >10% Renewable materials Post consumer recycle New Materials And fillers Expanded design window Family tools & multi cavity
iMFLUX BENEFIT WHEEL
SLIDE 7
FILLING COOL OPEN/ CLOSE FILLING COOL OPEN/ CLOSE
High Velocity High Pressure High Shear Rates Hesitation Cosmetics High Pressure Variation High Shrink Differentials Residual Stress Forms Sink Cosmetics Low Velocity 25-50% Reduction in Pressure Low Shear Rates Pressure Controlled Filling Constantly Adjusts Flow Velocities No Hesitation Eliminate Splay, Tiger Stripes, Etc Low Pressure Differentials Low Shrink Variation Lower Molded Stresses Reduced Sink Improved Cosmetics Reduce Warp
Conventional Injection Molding iMFLUX Low Constant Pressure Molding
PACKING/HOLD CAVITY PRESSURE REACTION
DISRUPTIVE PROCESS TECHNOLOGY
SLIDE 8
Plastic Pressure
Conventional
T fill-pack-hold-cool (1)
T fill T pack-hold T cool
T cool (2)
Low Pressure Process Faster Cycle
iMFIUX
+ 25% - 50% Lower Pressures + Up to 40% Reduction in clamp force + Combine Fill/Pack phases + Reinvest pressure savings for other benefits + Integrate to existing assets (IM machines and tooling) iMFLUX vs. CONVENTIONAL
iMFLUX PROCESS
SLIDE 9
LOW CONSTANT PRESSURE + Lower Clamp Tonnage + Lower Melt Temperatures + Up-Cavitation Molds + Less Retained Stress + Uniform Stress [Less Warp] + Less Gate Blush + Less Flash + Less Cavity-to-Cavity Variation + Less Material Degradation
Plastic Pressure
Conventional
T fill-pack-hold-cool (1)
T fill T pack-hold T cool
T cool (2)
Faster Cycle
iMFIUX
Low Constant Pressure
iMFLUX PROCESS
SLIDE 10
+ Reduced Flow Lines + Improved Thin-Walling + Higher L/T Capability + Smaller Cold Runners
Pa Part is fu fully y packed 3 3 Inch long cold runner 0. 0.030 030 inch diameter
NO FLOW HESITATION
iMFLUX PROCESS
Plastic Pressure
Conventional
T fill-pack-hold-cool (1)
T fill T pack-hold T cool
T cool (2)
Faster Cycle
iMFIUX
No Flow Hesitation
SLIDE 11
+ Faster Cycle Time + Reduced Sink Marks + Stronger Weld Lines + Improved Surface Finish PACK AS IT FILLS
iMFLUX Conventional Plastic Pressure
Conventional
T fill-pack-hold-cool (1)
T fill T pack-hold T cool
T cool (2)
Faster Cycle
iMFIUX
Pack as it Fills
iMFLUX PROCESS
SLIDE 12
Cavity Pressure Response
+ Lighter Parts [1-3%] + Reduced Flash + Automatic Adjustments For Viscosity Shifts + Real-time Adjustment for Blocked Cavities + Actuate Sequential Valve Gates + Not Affected by Leaky Check Rings + Not Affected by Worn Barrel
Plastic Pressure
Conventional
T fill-pack-hold-cool (1)
T fill T pack-hold T cool
T cool (2)
Faster Cycle
iMFIUX
Cavity Pressure Response Cavity Pressure
iMFLUX PROCESS
SLIDE 13
+ Recovery Limited Press/Tool Combination + Velocity limited Press/Tool Combination + Poor Mold Design / Conditions + Molds “Tuned” to Poor Processing Conditions CONSIDERATIONS
Plastic Pressure
Conventional
T fill-pack-hold-cool (1)
T fill T pack-hold T cool
T cool (2)
Faster Cycle
iMFIUX
iMFLUX PROCESS
SLIDE 14
USER INTERFACE CAVITY PRESSURE FEEDBACK SOFTWARE & CONTROLS NOZZLE PRESSURE SENSOR
iMFLUX INTEGRATION
SLIDE 15
“Any sufficiently advanced technology is indistinguishable from magic” Arthur C. Clark
For additional information:
Steve Willis Vice President Sales 3550 Symmes Road Hamilton, OH 45015 Mobile: +1 (513) 454-4642 Email: willis.sl@imflux.com
iMFLUX, Inc.
