WATERPROOFING YOUR HEALTHCARE FACILITIES Joseph B. Callaghan, Inc. THE 1/90% PRINCIPLE As much as 90% of all water intrusion problems occur within 1% of the total building exterior surface area. CONSEQUENCES OF LEAKAGE Damage to
SLIDE 2
SLIDE 3
CONSEQUENCES OF LEAKAGE
Damage to Interior Finishes Corrosion of Metal Studs & Anchors Wood Rot Freeze/Thaw Deterioration Loss of Insulating Value Electrical Danger
SLIDE 4
CREATIVE LEAK MANAGEMENT
SLIDE 5
SLIDE 6
BASIC WALL TYPES
BARRIER CAVITY
SLIDE 7
BARRIER WALLS
TRADITIONAL Absorbs and evaporates moisture slowly
Mass Masonry
- Pyramids
- Churches
- Philadelphia City Hall
SLIDE 8
BARRIER WALLS
CONTEMPORARY Impermeable cladding materials and permanently sealed joints
Precast Panel – Seashore House EIFS – Moss Rehab Curtainwall – 1 & 2 Liberty Stone Panel – 4 Penn
SLIDE 9
BARRIER WALL LIMITATIONS
Cladding materials are
not impermeable and rarely uncracked
– Includes: masonry, concrete, EIFS
External joint sealants
alone are not very reliable or durable
– Urethane (7-10 yrs) – Silicone (15-20 yrs)
SLIDE 10
DAMAGE & DETERIORATION
SLIDE 11
CAVITY WALLS
Two wythes of masonry
separated by an air cavity and tied together
Cavity may or may not
contain insulation
Moisture may penetrate
the outer masonry, but cannot travel across a void
Flashing allows water in the
cavity to exit
SLIDE 12
CAVITY WALL DESIGN CONSIDERATIONS
Material selection Mortar quality & joint type Flashing design & detailing
– Specify flashing service life equal to building life
- Additional cost during construction = $3-10/LF
- If repaired after construction, cost = $125/LF
– Install end dams when needed
SLIDE 13
TYPICAL FLASHING DETAILS
SLIDE 14
TYPICAL FLASHING DETAILS
SLIDE 15
HEALTHCARE FACILITY CONDITIONS
1922 1962 1978
SLIDE 16
EXAMPLE – PHASE I
CAVITY WALL BASEMENT
SLIDE 17
ABOVE GRADE SUB-GRADE
Warranty Expectations?
SLIDE 18
ABOVE GRADE SUB-GRADE
SLIDE 19
EXAMPLE – PHASE II
CAVITY WALL BASEMENT CAVITY WALL
SLIDE 20
CAVITY WALL BARRIER WALL
ADDITION ROOF ORIGINAL BLDG.
SLIDE 21
CAVITY WALL BARRIER WALL
INCORRECT
SLIDE 22
CAVITY WALL BARRIER WALL
CORRECT
SLIDE 23
EXAMPLE – PHASE III
CAVITY WALL BASEMENT CAVITY WALL CURTAINWALL
SLIDE 24
CAVITY WALL CURTAINWALL
SLIDE 25
CAVITY WALL CURTAINWALL
SLIDE 26
SLIDE 27
SUMMARY
WHEN DESIGNING ADDITIONS:
– Understand exterior wall types and how they interact – Make sure design professional understands them – Specify waterproofing material to match expected building life – Warranty expectations Know them!
