What Convnets Make for Image Captioning?

Leiden Institute of Advanced Computer Science, Leiden University Presenter: Yanming Guo Yu Liu*, Yanming Guo*, and Michael S. Lew

23rd International Conference on MultiMedia Modeling (MMM 2017)

Discover the world at Leiden University

Image Captioning

Describe an image with meaningful and sensible sentence-level captions.  Objects  Actions  Descriptive words  Relations

…

A large bus sitting next to a very tall building

Discover the world at Leiden University

Image Captioning

 Retrieval approaches  Generative approaches

• --- Map images to pre-defined sentences
• --- Estimate novel sentences

A white dog and a brown dog run along side each other at the beach; A dog running on a wet suit on the beach

Discover the world at Leiden University

Image Captioning

 Caption does not have to be previous seen  A good language model  More intelligent  Better performance Advantages:

 Retrieval approaches  Generative approaches

• --- Map images to pre-defined sentences
• --- Estimate novel sentences

Discover the world at Leiden University CNN

…

START “White” “Cup” “White” “Cup” END

RNN

General Structure

High-level image features Generate a sentence of words

?

Discover the world at Leiden University CNN

…

START “White” “Cup” “White” “Cup” END

RNN

General Structure

?

What Convnets make for image captioning?

Discover the world at Leiden University

 Single-label Convnet

Three types of Convnets

• --- Convnet pre-trained on ImageNet dataset, e.g. AlexNet, VGG …

 Multi-label Convnet

• --- Fine-tune Convnet on 80 object categories of MS COCO

 Multi-attribute Convnet

• --- Fine-tune Convnet on attributes of MS COCO (e.g. 300 attributes)

Single-label Multi-label Multi-attribute

finetune

Generic representation Salient objects Salient objects, actions, relations…

Discover the world at Leiden University

Three types of Convnets

Input image Single-label Convnet Multi-label Convnet Multi-attribute Convnet

The visualization of the most activated feature map in conv5_3

Discover the world at Leiden University

Single-label feature Multi-label feature Multi-attribute feature LSTM LSTM LSTM LSTM

…

Aggregation feature 𝑦0 𝑞1 𝑦1 𝑞2 𝑦i−2 𝑞i−1 𝑦T−1 𝑞T ag(x) ag(x) ag(x) ag(x)

…

Multi-Convnet Aggregation

Discover the world at Leiden University

Multi-Scale Testing

… … …

224 256 320 CNN FCN FCN

LSTM

xt

average transfer transfer

Caption generation

Discover the world at Leiden University

Experiments

• BLUE: measures the precision of n-grams between the

generated and reference sentences (e.g. B-1, B-2, B-3, B-4).

• METEOR: computed based on the alignment between the

words in a generated and reference sentences.

• ROUGE-L: focus on a set words that are appear in the same
• rder in two sentences.
• CIDEr: use a tf-idf weights for computing each n-grams.

Discover the world at Leiden University

Experiments

• Multi-scale: considerable improvement
• SL-Net: largest dimension & worst performance
• ML-Net: smallest dimension & considerable improvement
• MA-Net : medium dimension & significant improvement

Discover the world at Leiden University

Experiments

• Multi-scale testing using FCN is always better;
• The aggregation of different Convnets can enhance the performance

Discover the world at Leiden University

Experiments

Multi-Convnet aggregation: A man and a dog on a small boat. Single-label Convnet: A man is sitting on the water with a surfboard. Multi-label Convnet: A man sitting on a boat in front of a boat. Multi-attribute Convnet: A man and a dog on a boat. Ground truth: A man and a dog on a small yellow boat.

Discover the world at Leiden University

Experiments

Discover the world at Leiden University

Experiments

Ours: A man riding a wave in the ocean. GT: A man riding a wave on a surfboard in the ocean. Ours: A living room with a lot of furniture. GT: Living room with furniture with garage door at one end. Ours: A man riding a horse at a horse. GT: A horse that threw a man off a horse. Ours: A close up

• f an elephant

with an elephant GT: A man getting a kiss on the neck from an elephant's trunk

Discover the world at Leiden University

Conclusion

 Multi-attribute Convnet performs better for image captioning  The aggregation of different Convnets can deliver slightly better performance than each individual Convnet  Efficient multi-scale augmentation test using FCNs  Comparable results with the state-of-the-art

Thanks for your attention! Questions please?
