I3 I3 A CLOSED SED P PROCESS SS The whole process is one "Closed box", which dewater, dries and hygienizes the sludge via an efficient vacuum filter with added heat.

CY CYCL CLE The process creates a cycle of nutrients and minerals. The sludge is dewatered, dried and hygienized. The product can then be returned as a nutrition source for example agricultural land The reflux water contains nutrients and carbon dioxide, which can be synthesized by, for example, plankton algae or chlorophyll carriers for organic nutrition and oxygen to watercourses.

Data Mått: 5,0x4,0x4,5 (m) LxWxH Material: The entire system is built in AI SI 316L Installed heat power: 600 kW Installed electrical power : 40 kW Heater - hot oil system: 25 kg/sek The above figures for power requirements are based on an input flow of 1 m3 / minute with a dry matter of 0.03% Drying temperature: 200 0 C

Capacity Flow of ingoing sludge: ≥ 1000 liter/minut Dry matter of sludge - input: 0,03 – 6% Dry matter of sludge - output: 90% Condensation: Based on an example of a flow rate of 1 m 3 / minute with a dry matter of 0.03%, we will receive approximately 300 kg / h of 60-80 0 C of condensate water.

Co Contact: CEO LARS SVENNINGSSON LARS@LSOSWEDEN.COM TEL: 0046 70 378 58 30 BUSINESS DEVELOPER ÖIVIND GOTSJÖ OIVIND@LSOSWEDEN.COM TEL: 0046 70 777 57 49 BUSINESS DEVELOPER PEDER FLOOD PEDER@LSOSWEDEN.COM TEL: 0046 72 333 99 69
