D AY 38 C ONSTRUCTING PARALLEL LINES I NTRODUCTION Parallel lines refer to lines in a plane that do not meet or have a constant distance between them along their length. We encounter parallel lines in most cases such as opposite edges of
SLIDE 2
SLIDE 3
VOCABULARY
Parallel Line
Lines in a plane that are separated by the path of constant width along their lengths.
SLIDE 4
Construction
To construct parallel lines, there are 3 main methods that are used. These are; i). The use of a set square ii). The use of angle transfer method iii). The use of parallelogram method The second one is the most common used method of construction. Use of set square One shorter side of the set square aligned to the line while the other shorter side on a straight edge
- r a ruler. The set square is then slid along the
SLIDE 5
The straight edge till the other shorter side reaches the point, T, where the line has to pass. A line is then drawn guided by the shorter side of the set square. The result is a pair of parallel lines.
T U V
SLIDE 6
Use of angle transfer method
We would like to draw a line passing through B and parallel to AC. We draw a line from A to B. Using a smaller but suitable radius on the compasses, we place the tip of the compass at A then make an arc to intersect both AC and AB.
A C B
SLIDE 7
Without adjusting the compass, place the tip of the compass at B and make an arc in the similar direction as the first one.
A C B
SLIDE 8
We then place the tip of the compass at the intersection of the first arc on line AB then make it intersect the intersection of arch and line AC.
A C B A C B
SLIDE 9
Using the same radius, we make a similar arc above B with the intersection of line AB and the second arch as the center (location of the tip)
A C B
SLIDE 10
We then connect B to the intersection of the two
arcs and we have a line parallel to AC.
A C B
SLIDE 11
The use of parallelogram method We would like to draw a line at C parallel to line PC To do so, we put the tip of the compass at P then draw an arc to pass through V.
P C V
SLIDE 12
Without adjusting the radius of the arc, we make the same arc at C as shown above
P C V
SLIDE 13
We the put the tip of the compass at P and make an arc to go through C as shown above.
P C V
SLIDE 14
We the put the tip of the compass at V and make an arc to go through the arc above C as shown above.
P C V
SLIDE 15
We then connect the intersection point to C to have the parallel line. Connecting the same point to V makes a line parallel to PC.
P C V
SLIDE 16
HOMEWORK
Draw a line parallel to VW at C
V W C
SLIDE 17
ANSWERS TO HOMEWORK
We use a set square method
V W C
