Hydrogeology in the Carpathian Basin Peter Szucs 1,2 , Tams Madarsz 1 , Lszl Perger 3 1 University of Miskolc, Department of Hydrogeology and Engineering Geology, Miskolc-Egyetemvaros, Hungary,hgszucs@uni-miskolc.hu 2 EFG Panel of Experts

slide-1
SLIDE 1

Hydrogeology in the Carpathian Basin

Peter Szucs1,2, Tamás Madarász1, László Perger3

1University of Miskolc, Department of Hydrogeology and Engineering Geology,

Miskolc-Egyetemvaros, Hungary,hgszucs@uni-miskolc.hu

2EFG Panel of Experts on Hydrogeology 3National Institute of Environment (NeKI), Department of River Basin Management,

Budapest, Hungary

EFG Hydrogeology Workshop European water policy: challenges for Hydrogeologists Brussels, 22-23 November 2013

slide-2
SLIDE 2

Outline

  • Facts and specialties concerning hydrogeology in the

Carpathian Basin

  • Implementation of the Water Framework and Groundwater

Protection Directives. Challenges and experience

  • Conclusions
slide-3
SLIDE 3

Special hydrogeological conditions inside the Carpathian Basin belonging to the Danube watershed

(source: NeKI 2011)

One of the closest basin of the Earth concerning the surface and subsurface water accounts

slide-4
SLIDE 4

Haas (2001) Complex geology Pre-Neogene basement relief

Special hydrogeological conditions of Hungary

slide-5
SLIDE 5

Special hydrogeological conditions of Hungary

(Bada et al. 1999) The Carpathian Basin is under tectonic compression Over-pressured aquifers

20 40 60 80

P [MPa]

  • 4500
  • 3500
  • 2500
  • 1500
  • 500

500

z [mBf] P(z), Rétegnyomás - mélység összefüggés EOV Y: 749000 m - 777000 m EOV X: 136000 m - 157000 m Terület: Fábiánsebestény és környéke

st 9.8067MPa/km

Hidrosztatikus nyomásállapot

Fáb-4 Fáb-4 Oros-3 Nsz-3 Oros-1 Szentes-ÉK-1

slide-6
SLIDE 6

Special hydrogeological conditions of the Great Plain

H'

1

H1

Duna T isza

  • 5500
  • 5000
  • 4500
  • 4000
  • 3500
  • 3000
  • 2500
  • 2000
  • 1500
  • 1000
  • 500

500 1000

  • 5500
  • 5000
  • 4500
  • 4000
  • 3500
  • 3000
  • 2500
  • 2000
  • 1500
  • 1000
  • 500

500 1000 Elevation a.s.l. (m) 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180

Szeged

H''

1

H2

9 90 90 90 80 8 85 8 5 8 5 95 95 95 9 5 100 1 100 110 1 1 120 120 130 120 1 5 1 5 150 200 1000 5 1000 1 500 200 150 120 100 100 1 1 1 2 1 5 2 ? 100 120 1 5 2 5 110

W E

Distance from western end of cross section (km) 50x exagerated elevation (m a.s.l.) land surface

(vertical exageration: Mh Mv = 10 ) hydraulic head contour (m a.s.l.) with direction of fluid driving force top of Pre-Neogene basement with fault 120

Tóth and Almási 2001

  • Deep over-pressured flow systems
  • riginated from the Pre-Neogene basement
  • Superimposed, shallower, gravity-driven

flow system „Unique natural groundwater laboratory” József Tóth

slide-7
SLIDE 7

Floods, excess inland water and draught can occur at the same place and same time!!! (Source: NeKI)

Special hydrogeological conditions of Hungary

Aridity map Risk map of potentially excess inland water

slide-8
SLIDE 8

IMPLEMENTATION OF THE EU WFD

  • Wide range of water

bodies

  • Fulfilment of

environmental goals

  • River basin planning

for good status of waters Danube basin 800.000 km2 100 millions inhabitants 14 (+5) countries

slide-9
SLIDE 9

Trans-boundary aquifers in Europe

Legend : responded to inventory transboundary aquifers transboundary aquifers

IE GB FR PT ES CH IT AT RO BG YU BA HR NO SE FI RU EE LV LT RU BY PL DE NL BE LU DK CZ SK HU SI AL TR UA GE AM AZ KZ IS MD MK GR

Hungary

Source: UNECE Hungary (Source: NeKI) Groundwater bodies: 185 Transboundary: 40 Special hydrogeological conditions of Hungary Hungary downstream Ukraine upstream Szucs and Virag (2010)

The largest specific number concerning internationally shared aquifers in Europe

slide-10
SLIDE 10

Shared waters shared responsibility (not only for GW)

  • exchange of information (promoted by
  • joint problem diagnosis
  • joint decisions on transboundary measures
  • working together in coordination of common

interested measures

slide-11
SLIDE 11

Groundwater bodies in Hungary by WFD

slide-12
SLIDE 12

Status assessment of HU groundwater bodies

Good Weak by quantity Weak by quality Weak by both

slide-13
SLIDE 13

Groundwater for ecosystems by WFD

slide-14
SLIDE 14

The role of groundwater resources in drinking water supply

Percentage of drinking water supply covered by groundwater resources: World more than 50 %, Europe more than 75 %, Hungary more than 95%. (around 700 million m3/year)

WHYMAP, 2008

slide-15
SLIDE 15

Aquifers for drinking water supply in Hungary

slide-16
SLIDE 16

Program for vulnerable drinking water resources

slide-17
SLIDE 17

Waterworks operated from vulnerable groundwater resources

8% 11% 57% 22% 2% Aquifer types

partiszűrésű talajvizes rétegvizes karsztvizes egyéb

Bank filtered Porous aquifer Shallow groundwater Karstic aquifer

5% 5% 27% 15% 30% 10% 8% Water abstraction (m3/d)

50 alatt 50 - 100 100 - 500 500 - 1.000 1.000 - 5.000 5.000 - 15.000 15.000 fölött

Others

slide-18
SLIDE 18

71% 17% 11% 1%

Aquifer types

partiszűrésű talajvizes talajvizes és rétegvizes rétegvizes

Bank filtered

Shallow goundwater Porous aquifer Bank filtered Combined (shallow & porous)

10% 42% 37% 10% 1%

Water abstraction to be protected (m3/d)

10.000 alatt 10.000 - 30.000 30.000 - 50.000 50.000 - 100.000 100.000 fölött

Vulnerable aquifers for prospective drinking water reserve

Capacity: around 1 000 000 m3/day

slide-19
SLIDE 19

The importance of mineral, medicinal and thermal water resources

Favorable natural conditions in the whole Carpathian Basin. Complex geology flow systems and tectonics, post volcanic effects Large diversity in groundwater chemistry

slide-20
SLIDE 20

OGYFI – 195 different registered mineral waters, and 220 acknowledged medicinal water sources .

The importance of mineral, medicinal and thermal water resources

Increasing national trend in mineral water consumption

slide-21
SLIDE 21

Budapest – 2nd place, Best Spa Vacation in Europe, TripAdvisor, 2009

The importance of mineral, medicinal and thermal water resources Around 100 million m3 /year thermal water production (baneological and heat utilization)

slide-22
SLIDE 22

80% of the total area of Hungary is suitable for thermal water production (Mádlné Szőnyi Judit 2006) - increasing geothermal energy

utilization – geothermal atlases

VITUKI

Around 3000 petroleum industry deep wells are available

The importance of mineral, medicinal and thermal water resources

slide-23
SLIDE 23

Available groundwater resources (Somlyódy 2011)

Recharge ??? Available GW resources.: 2.5 km3/year Drinking, mineral, medicinal and thermal water resources can not be handled independently. Sustainability ??? Utilization ???

The importance of groundwater resources

Extreme weather conditions ???

slide-24
SLIDE 24

Conclusions

  • Groundwater resources play significant role in Hungary as well as in the whole

Carpathian Bain. Many specialties. Main source of drinking water supply

  • The increasing utilization of mineral, medicinal and thermal water resources is

important national interest. National Development Plan

  • Realization of integrated groundwater management. The importance of

transboundary collaboration concerning surface and groundwater resources

  • Many tasks and challenges for hydrogeologists inside the Carpathian basin. 1/3
  • f groundwater bodies in Hungary are not in good condition
slide-25
SLIDE 25

Thank you for your attention

Faculty of Earth Science and Engineering founded in 1735
