Hydrogen, I ts Transportation and Markets Presentation by Chris Kretz Business Development Manager May 2 0 , 2 0 1 9 1 6 0 + Years of Hydrogen Experience One of worlds largest producers of merchant hydrogen - > 5.0 million kg per

slide-1
SLIDE 1

Hydrogen, I ts Transportation and Markets

Chris Kretz

Business Development Manager

May 2 0 , 2 0 1 9

Presentation by

1

slide-2
SLIDE 2

6 0 + Years of Hydrogen Experience

  • One of world’s largest producers of

merchant hydrogen

  • > 5.0 million kg per day H2 production
  • Bulk, liquid, and pipeline distribution
  • Onsite generation (SMR, electrolysis)
  • Waste gas clean-up technologies
  • 40 worldwide central plants, 50 small on-

site generators

  • H2 energy projects since 1993

> 250 hydrogen station projects globally

  • 1,000,000 fuelings/ yr
  • Built > 29 fueling stations in California
  • Design, build, own, operate hydrogen

fueling stations and hydrogen supply

slide-3
SLIDE 3

Redefining Fuel

3

... to powering vehicles! Moving from fueling vehicles...

  • Fuel Cell Electric

Vehicles

  • Battery Electric

Vehicles

slide-4
SLIDE 4

Redefining Hydrogen

  • Hydrogen all around us
  • From reactant/ process chemical…

to fuel… to renewable fuel

4

Biogas

SMR

slide-5
SLIDE 5

5

Making Hydrogen

 Steam methane reforming

– CH4 + 2 H2O + Heat  4 H2 + CO2 – Natural gas and/ or biogas as feedstock

 Waste gas purification

slide-6
SLIDE 6

Sm aller On-Site Hydrogen

6

PHG1 0 0

  • 1 container w/ equipment inside
  • Up to 216kg/ day

PHG2 5 0

  • 1 container w/ equipment inside
  • Up to 539kg/ day

PHG8 3 0

  • 2 skids w/ utilities on one skid
  • Up to 1790kg/ day

Features:

  • Industry’s BEST efficiency
  • Automatic, unmanned operation
  • Remotely operated & remote monitoring
  • Modular, simple installation
  • 99.999% H2 Purity Standard
slide-7
SLIDE 7

7

Other W ays to Make Hydrogen

 Electrolysis – 2 H2O + Electric  2 H2 + O2

slide-8
SLIDE 8

Hydrogen Energy Markets

  • Transportation
  • Power Generation

8

Air Products has fueled vehicles on these markets in Europe, Asia and US

slide-9
SLIDE 9

Hydrogen Energy Storage

9

http: / / energystorage.org/ energy-storage/ technologies/ hydrogen- energy-storage

  • Check overall efficiencies
  • Need to have a hydrogn end use in mind
slide-10
SLIDE 10

Getting Started – Hydrogen Supply

Temporary Fueling

  • Days, weeks, or months
  • Minimal site preparation
  • Outdoor fueling
  • Ideal for early days, start-up
  • ie. – 1-3 buses, 3-5 cars, 1-10 forklifts,

1 ship?

10

Air Products Confidential

slide-11
SLIDE 11

Scaling Hydrogen Supply

  • Various Options
  • Liquid hydrogen
  • Making gaseous hydrogen
  • Reforming – natural gas, biogas
  • Electrolyzer
  • Tri-generation
  • Pipeline hydrogen

11 Air Products Confidential

slide-12
SLIDE 12

Orange County Transportation Authority Station ( 2 0 1 9 )

12

  • Delivered liquid hydrogen

(AP LHY)

  • Air Products design & key

equipment

  • Air Products proprietary

dual-phase compressors

  • 6-10 min. fills
  • 10 buses initially
  • Can scale to 30 or

more buses

  • Multiplicative scaling
  • Two dispensers
  • Planned on-stream Spring

2019

slide-13
SLIDE 13

Hydrogen Supply Options and Scaling

13

Scalability Footprint

Delivered gas

H2

Delivered LHY

Trigen Electrolyzer On-Site Reformer

slide-14
SLIDE 14

Traditional Hydrogen Supply I ntegration/ Distribution

14

Merchant Market

( CH 4 , Biogas Offgas Fuel)

SMR

Reform ing Cryogenic Liquefaction Liquid Storage

Custom er( s)

Steam / Pow er Purification Gaseous Pipeline Cylinders Cryogenic Tanker Tube Trailer

abc abc

W aste Gas / Feedstock

slide-15
SLIDE 15

Conventional Hydrogen Delivery Methods

15

Gas Pipeline Liquid Tank Trailer Gas Cylinders Gas Tube Trailer

slide-16
SLIDE 16

Air Products’ Global Hydrogen Pipelines

Mab Ta Phut, Thailand

Gulf of Thailand

H2 Pipeline

Mab Ta Phut, Thailand Europoort, The Netherlands

ROTTERDAM PERNIS ROZENBURG ZWIJNDRECHT To Moerdijk Hydrogen CO

Europoort, The Netherlands Los Angeles, California

WILMINGTON

AIR PRODUCTS FACILITY HYDROGEN PIPELINE

Los Angeles, California

CARSON

Gulf Coast, Texas

PORT ARTHUR BEAUMONT BAYPORT BATTLEGROUND CITY OF HOUSTON CLEARLAKE GULF OF MEXICO BAYTOWN ORANGE HYDROGEN CO SYNGAS Air Products Facilities BAYTOWN LAPORTE PASADEN A CHANNELVIEWMONT BELVIEU

Gulf Coast, Texas Mississippi River Corridor, Louisiana

NORCO CARVILLE PLAQUEMINE GEISMAR CONVENT LAPLAC E GARYVILL E BATON ROUGE NOLA NEW ORLEANS LAKE PONTCHARTRA IN CHALMETTE BELLE CHASE Air Products Facilities Hydrogen Pipeline TAFT GEISMAR

Mississippi River Corridor, Louisiana

GEISMAR

Camacari, Brazil

To Camacari H2 Pipeline

Camacari, Brazil Teesside, UK Sarnia, Ontario

40 40 Corunna Suncor Shell Refinery 40 ST. CLAIR RIVER Air Products Canada

City Of Sarnia

Teesside, UK Strathcona County, Alberta

14 630 14 16 21

City of Edmonton

Sherwood Park Petro-Canada Imperial Oil 16

16

Air Products Confidential

slide-17
SLIDE 17

Newer Hydrogen Delivery Methods

CT-2 5 0 ( 7 5 0 0 psi) CT-1 0 0 0 ( 7 5 0 0 psi) HF-1 5 0 ( 6 6 0 0 psi) Microbulk H2 Truck ( 7 5 0 0 psi)

Air Products Confidential

slide-18
SLIDE 18

Hydrogen Supply Options

  • vs. Challenges

18

Scalability Footprint

Delivered gas

H2

Delivered LHY

Trigen Electrolyzer On-Site Reformer

slide-19
SLIDE 19

19

Thank you… tell me more
