HVDC Transmission for Rural Alaska STAKEHOLDERS ADVISORY GROUP SECOND MEETING January 14, 2010 A NCHORAGE , A LASKA Joel D. Groves , P.E. polarconsult alaska, inc. ENGINEERS - PLANNERS - ENERGY CONSULTANTS 1503 W. 33rd Avenue, Suite 310

SLIDE 1

polarconsult alaska, inc. engineers planners energy consultants

HVDC Transmission for Rural Alaska

STAKEHOLDERS’ ADVISORY GROUP SECOND MEETING

January 14, 2010 ANCHORAGE, ALASKA Joel D. Groves, P.E.

polarconsult alaska, inc.

ENGINEERS - PLANNERS - ENERGY CONSULTANTS

1503 W. 33rd Avenue, Suite 310 Anchorage, Alaska (907) 258-2420 www.polarconsult.net joel@polarconsult.net

SLIDE 2

polarconsult alaska, inc. engineers planners energy consultants

MEETING GOALS

1. PROJECT STATUS UPDATE
2. DISCUSS PHASE III GOALS, SITES
3. FORM SAG WORK GROUPS
4. PROJECT Q & A
5. NEXT MEETING

polarconsult alaska, inc. engineers planners energy consultants

Project Status – Highlights

Manitoba International, LTD under contract as

specialist HVDC consultant

Operates Nelson River Bipoles, 2 HVDC circuits (3,400

MW) in arctic climate.

Operates HVDC Research Centre, Expertise in HVDC
perations, hardware, R&D and testing capabilities
Tasked with technical review, MTDC network

assessment, special hardware, cold climate experience, communications, fault detection, and regulatory assistance.

SLIDE 3

polarconsult alaska, inc. engineers planners energy consultants

Project Status – Converter

polarconsult alaska, inc. engineers planners energy consultants

1 MW Enclosure (20’x13’)

SLIDE 4

polarconsult alaska, inc. engineers planners energy consultants

Low Voltage Cabinet

Weight & Dims: 63”H x 42”D x 74”L 2,300 lbs Emergency Transport: CASA-212-200 Cooling Forced Air

polarconsult alaska, inc. engineers planners energy consultants

High Voltage Assembly

Weight & Dims 62”H x 36”D x 127”L 4,900 lbs (wet) 2,100 lbs (dry) Emergency Transport CASA 212-200 Cooling Coolant is Luminol TR/TRi Pour Point -60C Flash Point 170C Natural Oil Convection

SLIDE 5

polarconsult alaska, inc. engineers planners energy consultants

Project Status – Intertie Control

Phase III Demo Controls
Phase III demo will be point-to-point
HVDC power regulation by DC line voltage
Communications desirable for control and fault

detection

Communications necessary for load shed
HVDC Vision for Alaska = MTDC Networks
More work is needed to define control schema
Manitoba tasked with developing a roadmap

polarconsult alaska, inc. engineers planners energy consultants

Project Status – Overhead System

Validated conceptual design
Foundation design in progress
Waiting for pricing and product development options

from vendors

SLIDE 6

polarconsult alaska, inc. engineers planners energy consultants

Project Status – OH Example GVEA Northern Intertie

Commissioned 1968
Guyed lattice, 138 kV
1,000’ – 1,200’ spans
Permafrost soils
Some frost jacking issues

polarconsult alaska, inc. engineers planners energy consultants

Project Status – Submarine Cable Work Plan

Conceptual materials and design of cable done
Soliciting budgetary pricing from manufacturers to

design and manufacture cable in commercial quantities

No testing needed in Phase II

SLIDE 7

polarconsult alaska, inc. engineers planners energy consultants

Project Status – Buried Cable Work Plan

Unarmored submarine cable is suitable
Existing 1/0 35kV AC cable is suitable
Frost cracking is key issue in arctic soils
No proven solution from utility/oil industry
experience. GCI doing some interesting work with

telecom cables – same problem

Evaluating test options and developing test plan

polarconsult alaska, inc. engineers planners energy consultants

Project Status – Construction and O&M Methods

Identified existing rigs/equip that can be adapted to

construct overhead system

Working on O&M methods

SLIDE 8

polarconsult alaska, inc. engineers planners energy consultants

Project Status – Economics

Collecting cost data
Economic analysis will start in Q2 2011

polarconsult alaska, inc. engineers planners energy consultants

Phase III Demonstration Project - PROJECT OBJECTIVES

Prove up HVDC Hardware
Prove up innovative technologies
Overhead, overland cable, etc.
Prove functionality of SWER

SLIDE 9

polarconsult alaska, inc. engineers planners energy consultants

Phase III Demonstration Project- PROJECT CRITERIA

Transmission only
Lengths >10 miles
Load < 1 MW
Benefit
Readiness
Constructability

polarconsult alaska, inc. engineers planners energy consultants

Phase III Demonstration Project CANDIDATE PROJECTS

SLIDE 10

polarconsult alaska, inc. engineers planners energy consultants

FROM DISTRIBUTING ALASKA’S POWER NANA PACIFIC/WH PACIFIC/NANA COLT DECEMBER 2008

polarconsult alaska, inc. engineers planners energy consultants

SLIDE 11

polarconsult alaska, inc. engineers planners energy consultants polarconsult alaska, inc. engineers planners energy consultants

SLIDE 12

polarconsult alaska, inc. engineers planners energy consultants polarconsult alaska, inc. engineers planners energy consultants

SLIDE 13

polarconsult alaska, inc. engineers planners energy consultants polarconsult alaska, inc. engineers planners energy consultants

SLIDE 14

polarconsult alaska, inc. engineers planners energy consultants polarconsult alaska, inc. engineers planners energy consultants

SLIDE 15

polarconsult alaska, inc. engineers planners energy consultants polarconsult alaska, inc. engineers planners energy consultants

SLIDE 16

polarconsult alaska, inc. engineers planners energy consultants

QUESTIONS AND COMMENTS
