SLIDE 1
Vulnerability and risk of impacts of flatfishes to climate change
William W. L. Cheung Nippon Foundation-UBC Nereus Program, Institute for the Oceans and Fisheries, UBC
Vulnerability and risk of impacts of flatfishes to climate change - - PowerPoint PPT Presentation
Vulnerability and risk of impacts of flatfishes to climate change - - PowerPoint PPT Presentation
Vulnerability and risk of impacts of flatfishes to climate change William W. L. Cheung Nippon Foundation-UBC Nereus Program, Institute for the Oceans and Fisheries, UBC 2015-2017 the warmest years on record The future ocean What does CO 2
SLIDE 2
SLIDE 3
The future ocean
SLIDE 4
Gattuso, Magnan, Billé, Cheung, Howes, Joos, et al. 2015 Science.
What does CO2 emission do to the oceans?
Temperature
SLIDE 5
Flatfishes and their fisheries under climate change
Physical Biological Social/Economics
From: Sumaila, Cheung, Lam, Pauly, Herrick (2011) Nature Climate Change
SLIDE 6
Temperature and oxygen constraining fish production
- Theory predicts that aquatic ectotherms distribute
themselves to maximize their growth performance.
From: Pörtner & Farrell (2008) Science
SLIDE 7
Predicted temperature preference of exploited flatfishes (Pleuronectiformes) based on their biogeography
Polar Tropical
SLIDE 8
Predicted temperature preference of exploited flatfishes (Pleuronectiformes) based on their biogeography
Polar Tropical
SLIDE 9
Protected Area Latitude Country A Country B Original distribution Depth Climate-shifted distribution
Local extinction
Invasion
Warming Hypoxia Decrease in primary production
SLIDE 10
Global catches of flatfishes (Pleuronectiformes)
Data source: Sea Around Us
Future catches? Which species will be more at risk?
Subsistence
SLIDE 11
This talk
1. Vulnerabilities and risk of impacts to climate change; 2. Projections of changing flatfish distribution and potential fisheries production; 3. Adapting to climate effects on flatfishes.
SLIDE 12
This talk
1. Vulnerabilities and risk of impacts to climate change; 2. Projections of changing flatfish distribution and potential fisheries production; 3. Adapting to climate effects on flatfishes.
SLIDE 13
Framework of assessing vulnerability and risk of impacts
Adapted from Jones and Cheung 2017. Glob. Chang. Biol.
Risk of climate impacts Hazards: T, O2, pH Exposure: Species’ biogeography Sensitivity: Linf , TP, TG Vulnerability Adaptive capacity: Fec, LB, DR, HA
SLIDE 14
Exposure to hazard (ExV)
!"# = &'()(#
+,-./+,0,) – &'()(# .34./+,,,)
56 (#
.34./+,,,)
- Exposure = grid cells that the species is predicted to occur;
- Hazard = changes in ocean conditions relative to their past
variability: temperature, oxygen, pH;
- Pelagic – surface variables; Demersal – bottom variables;
- Use multiple ESM outputs to include uncertainties;
- Index is based on the mean change relative to variability.
SLIDE 15
Fuzzy logic expert system
High (0.75) Moderate (0.25)
- For each 0.5o x 0.5o spatial grid cell of the world oceans:
Heuristic rules
Knowledge accumulation
SLIDE 16
Exposure to hazard Index
- Example: Greenland Halibut– RCP 8.5
Exposure
SLIDE 17
Sensitivity
- Breath of temperature tolerance (TT) – overlaying species
distribution of temperature data (Cheung et al. 2013);
- Maximum body length (ML) – FishBase and Sealifebase;
- Taxonomic group (TG) – sensitivity to ocean acidification.
Example: Greenland halibut TG = 12 oC: moderate (0.5) and high (0.5) ML = 80 cm: large (1.0) TG = fishes Sensitivity = low (0.5), moderate (0.5), very high (1)
SLIDE 18
Adaptive capacity
- Latitudinal range (LR) – occurrence records;
- Depth range (DR) – FishBase and SeaLifeBase;
- Fecundity (FE)– FishBase and SeaLifeBase;
- Habitat restriction – Association to specific habitats (Cheung
et al. 2008) Example: Greenland halibut LR = 46 o: medium (0.13) and large (0.87) DR = 2000 m: very large (1.0) FE = ~45000 eggs: large (0.61), very large (0.39) Adaptive capacity = high (0.87), very high (1.00)
SLIDE 19
Vulnerability index = 39
Low (0.58), moderate (0.25), high (0.72)
Risk of impact = 55
- Example: Greenland halibut
Risk of impact
SLIDE 20
VVUl
Exploited flatfishes (Species number = 47) Moderate to high vulnerability and risk of impacts
Vulnerability Exposure to hazards Risk of impacts RCP 2.6 RCP 8.5 RCP 2.6 RCP 8.5
Species with highest estimated risk: Spottail spiny turbot (Psettodes belcheri) West coast sole (Austroglossus microlepis) Spiny turbot (Pettodes bennettii)
SLIDE 21
Vulnerability and risk of impact of 1,074 exploited fishes and invertebrates globally
Risk of impact
Vulnerability Risk of impact
Jones and Cheung 2017. Glob. Chang. Biol.
SLIDE 22
Risk of impacts under RCP 8.5 by Exclusive Economic Zones
- Exploited flatfishes (N = 47)
Exposure
SLIDE 23
This talk
1. Vulnerabilities and risk of impacts to climate change; 2. Projections of changing flatfish distribution and potential fisheries production; 3. Adapting to climate effects on flatfishes.
SLIDE 24
Dynamic Bioclimate Envelope Model
Source: Cheung et al. (2008, 2011); Fernandes et al. (2013)
SLIDE 25
Projected range shifts (centroid shifts)
Case study: Northwest Atlantic
Witch flounder
SLIDE 26
Projected range shifts (centroid shifts)
Case study: Northwest Atlantic
Witch flounder Greenland halibut
SLIDE 27
Projected range shifts (centroid shifts)
Case study: Northwest Atlantic
Witch flounder Greenland halibut Yellowtail flounder
SLIDE 28
Projected range shifts (centroid shifts)
Case study: Northwest Atlantic
SLIDE 29
Projected range shifts in North Pacific and Atlantic Oceans RCP 8.5
Case study: Northeast Atlantic
Median shift = 16 km decade-1
Based on: Jones and Cheung (2015) ICES J M Sci
- Local temperature velocity
- Density-dependent effects
SLIDE 30
Scaling between global atmospheric warming and loss of maximum catch potential of flatfishes (N = 47 spp)
Paris Agreement Business as usual Based on: Cheung, Reygondeau, Frölicher (2016) Science
SLIDE 31
Regional differences in projected in changes in maximum potential catches RCP 8.5
Change in catch potential (%)
Based on: Lam, Cheung et al. (2016) Scientific Report
SLIDE 32
Implications for coastal communities
Weatherdon, Ota, Close, Cheung (2016) PLoS One
SLIDE 33
ADAPTING TO CLIMATE CHANGE
SLIDE 34
Protect and restore coastal vegetation Eliminate overfishing Mitigate pollution
Potential solutions
LOCAL
SLIDE 35
Climate impacts on effectiveness of MPA
SLIDE 36
”Climate-proofing” MPA
Species MPA Species MPA Centroid shift (CS) MPA size (s)
Now Future
SLIDE 37
”Climate-proofing” MPA
Species MPA Species MPA Centroid shift (CS) MPA size (s)
For MPA to be climate-proof: s > CS
Now Future
SLIDE 38
Climate-proofing global MPAs
SLIDE 39
Climate-proofing global MPAs
Percentile of range shifts by 2050: 25th 50th 75th
SLIDE 40
Climate-proofing global MPAs
Percentile of range shifts by 2050: 25th 50th 75th
North Sea Plaice Box
SLIDE 41
Mariculture of flatfishes
Mariculuture
Data source: Sea Around Us
SLIDE 42
Mariculture suitable environment
Data source: Oyinlola, Cheung, et al. (in review) Hippoglossus hippoglossus Paralichthys olivaceus Solea solea Solea sengalensis
Unsuitable Suitable
SLIDE 43
Potential mariculture area and countries currently producing flatfishes
Data source: Oyinlola, Cheung, et al. (in review)
SLIDE 44
Potential mariculture area and countries currently producing flatfishes
Data source: Oyinlola, Cheung, et al. (in review)
- Other constraints on sustainability: ecological, social, economic,
technological?
SLIDE 45
Summary
- Exploited flatfishes have moderate to high risk of
impacts under climate change;
- Distribution shifts across their ranges under
climate change;
- Reduction in maximum catch potential by up to
20% under business-as-usual global warming;
- A portfolio of solutions (mitigation and
adaptation) are needed to manage risk of climate change on flatfishes and their fisheries.
SLIDE 46
Acknowledgement
SLIDE 47
Challenges to transboundary fisheries management
Abrantes, Cheung (in prep)
E.g. Pacific halibut (RCP 8.5)
+
- +
+
- +
- -
