How to treat SFA In-Stent Restenosis: Case Examples SCAI CPVI: SFA State-of-the-Art Treatment Strategies Andrew J. P. Klein, MD, FACC, FSCAI Interventional Cardiology Vascular and Endovascular Medicine Piedmont Heart Institute Atlanta, GA

SLIDE 1

Andrew J. P. Klein, MD, FACC, FSCAI Interventional Cardiology Vascular and Endovascular Medicine Piedmont Heart Institute Atlanta, GA

How to treat SFA In-Stent Restenosis: Case Examples

SCAI CPVI: SFA State-of-the-Art Treatment Strategies

SLIDE 2

Disclosures:

▪ I have nothing to disclose.

SLIDE 3

Advisory Board for Medtronic Peripheral Vascular

Section (March 2018-Oct 2018)

Conflict of Interest

SLIDE 4

The Data

SLIDE 5

“We are going to talk about LASERS”

SLIDE 6

Photochemical

– Breaks carbon–carbon bonds (photochemical)

Photothermal

– Increases temp intra-cellular H2O→ cell rupture→ vapour bubble at the catheter tip

Photomechanical

– Expansion and implosion of these bubbles disrupts the obstructive intra- vascular material

Fragments released are <10 μm in

diameter

Laser:Mechanism

SLIDE 7

Data

J Am Coll Cardiol Intv 2015;8:92–101

SLIDE 8

Take Home from EXCITE ISR

SLIDE 9

Laser + DCB vs. Laser+ PTA

Figure 1. One-year freedom from (A) target lesion revascularization, (B) target lesion occlusion, and (C) target lesion reocclusion among lesions treated for in-stent occlusion (Tosaka III). BA, balloon angioplasty; CI, confidence interval; DCB, drug-coated balloon; HR, hazard ratio; KM, Kaplan-Meier; LA, laser. Kokkinidis, D. G., Hossain, P., Jawaid, O., Alvandi, B., Foley, T. R., Singh, G. D., … Armstrong, E. J. (2018). Journal of Endovascular Therapy, 25(1), 81–88. https://doi.org/10.1177/1526602817745668

SLIDE 10

4 diameters (0.9, 1.4, 1.7, 2.0 mm)
Larger diameter lasers (1.7, 2.0 mm)

– Straight vessel >3 mm – 7F and 8F guides

Laser Choice

Interventional Cardiology Review, 2016;11(1):27–32

SLIDE 11

Laser Atherectomy

SLIDE 12

Turbo-Elite Laser

– CVX-300 Excimer Laser – Can be used independently or prior to TT when a pilot hole is not evident

Turbo Tandem Laser

– Constrained within a guide catheter – Ablate concentric and eccentric lesions in FP vessels>5mm – Requires >2 mm Pilot channel – 7Fr

Lasers

SLIDE 13

A 74-year-old severe

claudication (Rutherford class III; TASC A; ABI 0.81) in the right leg.

Stent placement by

PTA of the right femoral artery extending from the proximal to distal segments was performed less than 1 year prior.

Laser Case

Miller et al. VASCULAR DISEASE MANAGEMENT 2016;13(1):E17-E30

SLIDE 14

78 yr old

female with rest pain of LLE

Laser Case 2

Miller et al. VASCULAR DISEASE MANAGEMENT 2016;13(1):E17-E30

SLIDE 15

60 yr old male with a

history of PAD s/p SFA stenting presents with recurrent lifestyle limiting claudication

No rest pain, no ulcers

Case 2: Off the reservation

ABI Monophasic signals are seen bilaterally. ABI in the right is .49 with a toe pressure 20. ABI in the left is .31 with a toe pressure 20. Impression: moderate to severe arterial insufficiency on the right and severe on the left.

SLIDE 16

Preprocedural CTA

SLIDE 17

Angio

SLIDE 18

Procedure

SLIDE 19

OFF LABEL USE OF DA

SLIDE 20

FINAL (before DCB was an option)

SLIDE 21

FINAL

SLIDE 22

Rinse Repeat

SLIDE 23

Usual

SLIDE 24

Off label DA use

SLIDE 25

Usual with a Twist

SLIDE 26

Follow Up

ABI Monophasic signals are seen on the right and biphasic on the left. The ABI's are >1.0

bilaterally. toe pressure on the right is 124

and on the left is 116 Impression: No hemodynamically significant arterial insufficiency to either lower extremity at rest.

SLIDE 27

ISR:Jetstream Atherectomy

Korean Circ J. 2018 Mar; 48(3): 191–197.

SLIDE 28

Covering ISR with

Viabahn stent grafts

Cannot get ISR

inside these

Edge restenosis
Go down hard!
Might be considered

for long lesions

ISR: RELIGN

Adams G et al. Endovascular Today June 2015

SLIDE 29

ISR @6months

Minor and Cook, Endovascular Today June 2015

SLIDE 30

ISR Case->RELIGN
