HOW TO INTERPRET YOUR BLOODWORK Saturday, April 18, 2020 Cyrus C. Hsia, HBSc, MD, FRCPC Associate Professor of Medicine Program Director of the Hematology Training Program Schulich School of Medicine and Dentistry, Western University Associate

slide-1
SLIDE 1

HOW TO INTERPRET YOUR BLOODWORK

Saturday, April 18, 2020 Cyrus C. Hsia, HBSc, MD, FRCPC Associate Professor of Medicine Program Director of the Hematology Training Program Schulich School of Medicine and Dentistry, Western University Associate Medical Director, Blood Transfusion Laboratory London Health Sciences Centre

slide-2
SLIDE 2
  • Presenting from London, Ontario

2

April 18, 2020 C. Hsia

slide-3
SLIDE 3

OBJECTIVES

  • Outline of presentation: The end of the presentation, the audience will be

able to..

  • Describe and evaluate the parts of a complete blood count (CBC)
  • Describe myelodysplastic syndromes (MDS)
  • *COVID-19 & MDS
  • Discuss questions on blood tests and what their results mean

3

April 18, 2020 C. Hsia

slide-4
SLIDE 4

Our bodies are made of cells and more cells..

4

April 18, 2020 C. Hsia

slide-5
SLIDE 5

The easiest way to collect a sample of your blood cells is to take a blood sample. A laboratory technologist (sometimes referred to as a phlebotomist) will draw a blood sample from your arm. Blood is collected in a test tube and sent to the local laboratory for testing. We are going to talk about the complete blood count (CBC)

April 18, 2020 C. Hsia

5

slide-6
SLIDE 6

The complete blood count

April 18, 2020 C. Hsia

6

slide-7
SLIDE 7

What is blood made of?

April 18, 2020 C. Hsia

7

slide-8
SLIDE 8

This is an example of a complete blood count (CBC) and a white cell differential

April 18, 2020 C. Hsia

8

slide-9
SLIDE 9

This is an example of a complete blood count (CBC) and a white cell differential

April 18, 2020 C. Hsia

9

This is the CBC This is the white cell differential

slide-10
SLIDE 10

The complete blood count doesn’t measure everything. Notice that it does not contain other tests of the blood such as iron levels, kidney function, liver function, thyroid function, sugar levels, cholesterol, calcium, electrolytes.. These other tests are for another discussion and followed by various physicians.

April 18, 2020 C. Hsia

10

This is the CBC This is the white cell differential

slide-11
SLIDE 11

What is a reference range? How do we come up with this?

April 18, 2020 C. Hsia

11

Patient Results Reference Range

slide-12
SLIDE 12

Let’s talk about height as an example You have to decide to cut off the range somewhere..

April 18, 2020 C. Hsia

12

slide-13
SLIDE 13

Reference Ranges for each lab value is determined by each individual lab based on their reagents and “normal” controls.

April 18, 2020 C. Hsia

13

Patient Results Reference Range

slide-14
SLIDE 14

What are white blood cells?

April 18, 2020 C. Hsia

14

slide-15
SLIDE 15

White blood cells (WBC) are also called leukocytes (LKC).

April 18, 2020 C. Hsia

15

slide-16
SLIDE 16

White blood cells are also called leukocytes (LKC) There are many different types of white blood cells that have different functions.

April 18, 2020 C. Hsia

16

slide-17
SLIDE 17

What do white blood cells do? These cells are primarily for fighting infections and has a role in inflammation.

April 18, 2020 C. Hsia

17

slide-18
SLIDE 18

WBC or LKC is part of the complete blood count (CBC) WBC is made up of a number of different white blood cells provided in the white cell differential

April 18, 2020 C. Hsia

18

This is the CBC This is the white cell differential

slide-19
SLIDE 19

What do these white cells do?

April 18, 2020 C. Hsia

19

This is the white cell differential

slide-20
SLIDE 20

What do these white cells do? If these blood cells are too low you can have these problems. Note: Low neutrophils is called (neutropenia). You may have been told this in clinic that if you have neutropenia to watch for fevers.

April 18, 2020 C. Hsia

20

  • Neutrophils
  • fight bacteria, fungi
  • Lymphocytes
  • fight viruses
  • Monocytes
  • help fight infections, can migrate to other tissues to

engulf infections and debris

  • Eosinophils
  • help fight larger parasites, part of allergic response
  • Basophils
  • release histamine, part of inflammatory response
slide-21
SLIDE 21

What are red blood cells?

April 18, 2020 C. Hsia

21

slide-22
SLIDE 22

Red blood cells (RBC) are also called erythrocytes ERC is the erythrocyte count

April 18, 2020 C. Hsia

22

slide-23
SLIDE 23

There are different measures that involve red blood cells such as hemoglobin, hematocrit, MCV and RDW.

April 18, 2020 C. Hsia

23

slide-24
SLIDE 24

Hemoglobin molecules are essential.. They carry

  • xygen in the red blood

cells.

April 18, 2020 C. Hsia

24

slide-25
SLIDE 25

Hemoglobin molecules are essential.. They carry

  • xygen in the red blood

cells.

April 18, 2020 C. Hsia

25

slide-26
SLIDE 26

Anemia means low hemoglobin.

April 18, 2020 C. Hsia

26

slide-27
SLIDE 27

Hematocrit is the volume of blood occupied by red blood cells.

April 18, 2020 C. Hsia

27

slide-28
SLIDE 28

MCV = mean cell volume. This is the average size of red blood cells. RDW = red cell distribution

  • width. This is how variable

the size of red cells are.

April 18, 2020 C. Hsia

28

slide-29
SLIDE 29

What are platelets?

April 18, 2020 C. Hsia

29

slide-30
SLIDE 30

Platelets are also called thrombocytes

April 18, 2020 C. Hsia

30

slide-31
SLIDE 31

Function to form a clot along with clotting factors

April 18, 2020 C. Hsia

31

slide-32
SLIDE 32

Low platelets lead to easy bleeding and bruising

April 18, 2020 C. Hsia

32

slide-33
SLIDE 33

The factory..

April 18, 2020 C. Hsia

33

slide-34
SLIDE 34

Where do all of our blood cells come from?

April 18, 2020 C. Hsia

34

slide-35
SLIDE 35

This is the factory that makes all of our blood cells..

April 18, 2020 C. Hsia

35

slide-36
SLIDE 36

In the bone marrow factory, all of our blood cells come from a stem cell. Stem cells divide and grow and eventually become these different blood cells.

April 18, 2020 C. Hsia

36

slide-37
SLIDE 37

This is how we take a bone marrow sample..

April 18, 2020 C. Hsia

37

slide-38
SLIDE 38

This is how we take a bone marrow sample..

April 18, 2020 C. Hsia

38

slide-39
SLIDE 39

All blood cells come from the bone marrow factory.

39

April 18, 2020 C. Hsia

slide-40
SLIDE 40

What is MDS?

April 18, 2020 C. Hsia

40

slide-41
SLIDE 41

MYELODYSPLASTIC SYNDROMES

  • Definition
  • Myelodysplastic syndromes (MDS) form a group of clonal

hematopoietic stem cell malignancies characterized by ineffective hematopoiesis in one or more cell lineages, associated peripheral cytopenias, and risk of transformation to acute myeloid leukemia

April 18, 2020 C. Hsia

41

Sloand EM. Myelodysplastic syndromes: introduction. Semin Hematolo. 2008;45:1-2. Valent P, Horny HP, Bennett JM, et al. Leuk Res 2007;31:72-36.

slide-42
SLIDE 42
  • Dr. Robert Barr and the Ford Pinto

42

April 18, 2020 C. Hsia

slide-43
SLIDE 43

MYELODYSPLASTIC SYNDROMES

  • In other words..
  • MDS is a group of blood and bone marrow disorders

(cancers) where the blood cells are made with defects and don’t survive as long as it should.

  • This leads to low blood counts in 1 or more of the blood cells.
  • It is NOT leukemia, but can be considered pre-leukemic.
  • It is NOT 1 disease and behaves differently in different

people.

April 18, 2020 C. Hsia

43

slide-44
SLIDE 44

HOW COMMON IS MDS?

  • Actual incidence very difficult to determine
  • Approx 3-4 per 100,000, much more common in elderly, approx

1 in 1000

  • Median age at diagnosis 65 – 70 years

April 18, 2020 C. Hsia

44

World Health Organization Classification of Tumours. Pathology & Genetics: Tumours of Haematopoietic and Lymphoid Tissues. Edited by Elaine S. Jaffe, Nacy Lee Harris, Harald Stein, James W. Vardiman. IARC Press Lyon 2001. Silverman, LR. Modulation of the Clone: Altering the Course of Myelodysplastic Syndrome. Blood & Bone Marrow Transplantation Reviews 2006; 16(3):5-8.

slide-45
SLIDE 45

WHAT CAUSES MDS?

  • Causes?
  • idiopathic (meaning we don’t know)
  • can be secondary to toxic exposures such as chemotherapy,

radiation, environmental toxins

  • may be associated with some hereditary disorders but MDS in

general is NOT hereditary

April 18, 2020 C. Hsia

45

World Health Organization Classification of Tumours. Pathology & Genetics: Tumours of Haematopoietic and Lymphoid Tissues. Edited by Elaine S. Jaffe, Nacy Lee Harris, Harald Stein, James W. Vardiman. IARC Press Lyon 2001. Silverman, LR. Modulation of the Clone: Altering the Course of Myelodysplastic Syndrome. Blood & Bone Marrow Transplantation Reviews 2006; 16(3):5-8.

slide-46
SLIDE 46
  • Patient
  • Poor quality of life - time and commitment to transfusions
  • Complications of Iron Overload
  • Cardiorespiratory symptoms
  • Hospitalizations for cardiac complications, infections, bleeding,

increased risk of leukemic transformation

  • Increased risk of shorter survival
  • Society
  • Transfusion burden
  • Hospitalizations for cardiac complications, infections, complications of

iron overload, bleeding, leukemia

46

April 18, 2020 C. Hsia

slide-47
SLIDE 47

MANAGEMENT FOR MDS PATIENTS

  • The mainstay of management is supportive
  • Transfusions, antibiotics
  • No specific transfusion threshold, rather patient dependent based on level of

hemoglobin associated with symptoms of anemia

Steensma DP and Bennett JM. The Myelodysplastic Syndromes: Diagnosis and Treatment. Mayo Clin Proc. 2006;81(1):104-130.

47

April 18, 2020 C. Hsia

slide-48
SLIDE 48

TREATMENTS IN MDS

  • It depends on the type of MDS you have and how fit you are
  • Lower risk MDS
  • Transfusions and other supportive care
  • Erythropoietin (EPO) – if your body is not producing enough
  • Iron chelation therapy – if you have too much iron from transfusions
  • Revlimid (lenalidomide) – if you have the 5q deletion
  • Higher risk MDS
  • Transfusions and other supportive care
  • Stem Cell Transplant - Reserved for the “younger” patient with severe disease
  • Vidaza (azacytidine) – For patients who can come to the cancer centre 7 days

every 28 days

Steensma DP and Bennett JM. The Myelodysplastic Syndromes: Diagnosis and Treatment. Mayo Clin Proc. 2006;81(1):104-130.

48

April 18, 2020 C. Hsia

slide-49
SLIDE 49

Bone marrow factory - The future

49

April 18, 2020 C. Hsia

slide-50
SLIDE 50

What does it mean in patients with MDS?

April 18, 2020 C. Hsia

50

slide-51
SLIDE 51
  • Coronaviruses are a large family of viruses. Some cause illness in people and
  • thers cause illness in animals. Human coronaviruses are common and are

typically associated with mild illnesses, similar to the common cold.

  • COVID-19 is a new disease that has not been previously identified in humans.

Rarely, animal coronaviruses can infect people, and more rarely, these can then spread from person to person through close contact.

  • Human coronaviruses cause infections of the nose, throat and lungs. They are

most commonly spread from an infected person through:

  • respiratory droplets generated when you cough or sneeze
  • close, prolonged personal contact, such as touching or shaking hands
  • touching something with the virus on it, then touching your mouth, nose or eyes before

washing your hands

  • Current evidence suggests person-to-person spread is efficient when there is

close contact.

April 18, 2020 C. Hsia

51

https://www.canada.ca/en/public-health/services/diseases/2019-novel-coronavirus- infection/symptoms.html?topic=ex-col-faq#a

slide-52
SLIDE 52
  • A pneumonia of unknown cause detected in Wuhan, China was first

reported to the WHO Country Office in China on 31 December 2019.

  • WHO is working 24/7 to analyse data, provide advice, coordinate with

partners, help countries prepare, increase supplies and manage expert networks.

  • The outbreak was declared a Public Health Emergency of International

Concern on 30 January 2020.

  • The international community has asked for US$675 million to help

protect states with weaker health systems as part of its Strategic Preparedness and Response Plan.

  • On 11 February 2020, WHO announced a name for the new coronavirus

disease: COVID-19.

April 18, 2020 C. Hsia

52

https://www.who.int/emergencies/diseases/novel-coronavirus-2019/events-as-they-happen

slide-53
SLIDE 53
  • COVID-19: Disease name
  • COrona Virus Infectious Disease-19
  • SARS-COV-2: Virus itself
  • Causative agent of COVID-19
  • HCoV-19 –Human Coronavirus-19 (old name)
  • SARS-COV: Severe Acute Respiratory Syndrome -COronaVirus
  • Causative agent of SARS (outbreak 2002 –2003)

April 18, 2020 C. Hsia

53

Lu et al.Genomic characterizationand epidemiology of 2019 novel coronavirus: implications for virus origins and receptor Binding. Lancet 2020

slide-54
SLIDE 54

April 18, 2020 C. Hsia

54

https://www.who.int/emergencies/diseases/novel-coronavirus-2019/events-as-they-happen

slide-55
SLIDE 55

April 18, 2020 C. Hsia

55

https://www.who.int/emergencies/diseases/novel-coronavirus-2019/events-as-they-happen

slide-56
SLIDE 56

April 18, 2020 C. Hsia

56

https://www.wired.com/story/whats-social-distancing-flattening-curve-covid-19-questions/

slide-57
SLIDE 57

April 18, 2020 C. Hsia

57

https://www.visualcapitalist.com/infection-trajectory-flattening-the-covid19-curve/

slide-58
SLIDE 58
  • In an effort to prevent the spread of COVID-19 within communities and

across the country, all Canadians are advised to:

  • stay at home unless you have to go to work
  • talk to your employer about working at home if possible
  • avoid all non-essential trips in your community
  • do not gather in groups
  • limit contact with people at higher risk, such as older adults and those in poor

health

  • go outside to exercise but stay close to home
  • if you leave your home, always keep a distance of at least 2 arms lengths

(approximately 2 metres) from others

  • household contacts (people you live with) do not need to distance from each
  • ther unless they are sick or have travelled in the last 14 days

April 18, 2020 C. Hsia

58

https://www.canada.ca/en/public-health/services/diseases/2019-novel-coronavirus- infection/symptoms.html?topic=ex-col-faq#a

slide-59
SLIDE 59

April 18, 2020 C. Hsia

59

https://www.canada.ca/en/public-health/services/diseases/2019-novel-coronavirus- infection/symptoms.html?topic=ex-col-faq#a

slide-60
SLIDE 60
  • Hygiene: Proper hygiene can help reduce the risk of infection or

spreading infection to others:

  • wash your hands often with soap and water for at least 20 seconds, especially

after using the washroom and when preparing food

  • use alcohol-based hand sanitizer if soap and water are not available
  • when coughing or sneezing:
  • cough or sneeze into a tissue or the bend of your arm, not your hand
  • dispose of any tissues you have used as soon as possible in a lined waste

basket and wash your hands afterwards

  • avoid touching your eyes, nose, or mouth with unwashed hands

April 18, 2020 C. Hsia

60

https://www.canada.ca/en/public-health/services/diseases/2019-novel-coronavirus- infection/symptoms.html?topic=ex-col-faq#a

slide-61
SLIDE 61

April 18, 2020 C. Hsia

61

https://www.canada.ca/en/public-health/services/diseases/2019-novel-coronavirus- infection/symptoms.html?topic=ex-col-faq#a

slide-62
SLIDE 62

April 18, 2020 C. Hsia

62

The American Society of Hematology (ASH) https://www.hematology.org/covid-19/covid-19-and-myelodysplastic-syndromes

slide-63
SLIDE 63

April 18, 2020 C. Hsia

63

The American Society of Hematology (ASH) https://www.hematology.org/covid-19/covid-19-and-myelodysplastic-syndromes

slide-64
SLIDE 64

April 18, 2020 C. Hsia

64

The American Society of Hematology (ASH) https://www.hematology.org/covid-19/covid-19-and-myelodysplastic-syndromes

slide-65
SLIDE 65

April 18, 2020 C. Hsia

65

The American Society of Hematology (ASH) https://www.hematology.org/covid-19/covid-19-and-myelodysplastic-syndromes

slide-66
SLIDE 66

Consider enrolling in a registry

April 18, 2020 C. Hsia

66

slide-67
SLIDE 67

April 18, 2020 C. Hsia

67

https://www.hematology.org/covid-19/covid-19-and-myelodysplastic-syndromes

slide-68
SLIDE 68

April 18, 2020 C. Hsia

68

https://blood.ca/en/convalescentplasma

slide-69
SLIDE 69

LET’S TAKE YOUR QUESTIONS..

  • Do you have any questions about this talk?
  • Do you have questions about your own blood tests and results?

69

April 18, 2020 C. Hsia

slide-70
SLIDE 70

REFERENCES

ASH Education Book 2005 – 2019

World Health Organization Classification of Tumours. Pathology & Genetics: Tumours of Haematopoietic and Lymphoid Tissues. Edited by Elaine S. Jaffe, Nacy Lee Harris, Harald Stein, James W. Vardiman. IARC Press Lyon 2001 and updated WHO 2008 and 2016.

Bennett JM, Catovsky D, Daniel MT, et al. Proposals for the classification of the myelodysplastic syndromes. British Journal of

  • Haematology. 1982; 51:189-199.

Harris NL, Jaffe ES, Diebold J, et al. World Health Organization Classification of Neoplastic Diseases of the hematopoietic and lymphoid tissues: report of the clinical advisory committee meeting – Airlie House, Virginia, November 1997. J Clin Oncol. 1999;17:3835-3849.

Greenberg P, Cox C, LeBeau MM, et al. International Scoring System for evaluating prognosis in myelodysplastic syndromes.

  • Blood. 1997;89:2079-2088.

Steensma DP and Bennett JM. The Myelodysplastic Syndromes: Diagnosis and Treatment. Mayo Clin Proc. 2006;81(1):104- 130.

Komrokji RS and Bennett JM. Evolving classifications of the myelodysplastic syndromes. Current Opinion in Hematology. 2007;14:98-105.

Malcovati L. Prognostic Factors and Life Expectancy in Myelodysplastic Syndromes Classified According to WHO Criteria: A Basis for Clinical Decision Making. J Clin Oncol 2005;23:7594-7603.

Tefferi A, Vardiman JW. Myelodysplastic syndromes. N Engl J Med. 2009 Nov 5;361(19):1872-85. PMID: 19890130

70

April 18, 2020 C. Hsia

slide-71
SLIDE 71

71

April 18, 2020 C. Hsia
