How do Codecademy's The online Python Tutor interpreter 45 - - PowerPoint PPT Presentation

▶
how do codecademy s the online python tutor interpreter
SMART_READER_LITE
LIVE PREVIEW

How do Codecademy's The online Python Tutor interpreter 45 - - PowerPoint PPT Presentation

Dec 25, 2023 136 likes •775 views

How do Codecademy's The online Python Tutor interpreter 45 million users currently has 60,000 users per month learn to code? input() input() u = 42 x = float(input()) print(x * math.e / 2)

slide-1
SLIDE 1
slide-2
SLIDE 2
slide-3
SLIDE 3
  • ○
slide-4
SLIDE 4

How do Codecademy's

45 million users

learn to code? The online Python Tutor interpreter currently has 60,000 users per month

slide-5
SLIDE 5

input()

slide-6
SLIDE 6

input()

slide-7
SLIDE 7
slide-8
SLIDE 8
slide-9
SLIDE 9
slide-10
SLIDE 10

u = 42 x = float(input()) print(x * math.e / 2)

slide-11
SLIDE 11

26,2

u = 42 x = float(input()) print(x * math.e / 2)

slide-12
SLIDE 12

26,2

u = 42 x = float(input()) print(x * math.e / 2)

ValueError: could not convert string to float: '26,2'

slide-13
SLIDE 13

26,2

u = 42 x = float(input()) print(x * math.e / 2)

ValueError: could not convert string to float: '26,2'

29.2

slide-14
SLIDE 14

26,2

ValueError: could not convert string to float: '26,2'

29.2 $1.50

ValueError: could not convert string to float: '$1.50'

1.50 math.py/6

ValueError: could not convert string to float: 'math.py/6'

3.14

slide-15
SLIDE 15

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array)

slide-16
SLIDE 16

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array)

  • input_b

input_a

  • input_c

input_a

slide-17
SLIDE 17

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array)

slide-18
SLIDE 18

abcd *d%# #*%*d*%

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array)

slide-19
SLIDE 19

abcd *d%# #*%*d*%

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array) KeyError: '#'

slide-20
SLIDE 20

abcd *d%# #*%*d*%

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array) KeyError: '#'

abcd *d%# abcd

slide-21
SLIDE 21
slide-22
SLIDE 22

P

  • P : program code
  • I : token_sequence
  • M : string
  • T : string → Mutation
  • R : set of Mutations
  • N : ℕ
slide-23
SLIDE 23

Error-message template applies? Apply error message template to I Duplicate I? Apply random mutation to I Run P(I) Inputs: program P, buggy input I, error message M Return minimized I, the repaired input! M

slide-24
SLIDE 24

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array)

Current Input Error Message Action abcd *d%# #*%*d*% KeyError: '#'

slide-25
SLIDE 25

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array)

Current Input Error Message Action abcd *d%# #*%*d*% KeyError: '#' Random Mutation: Remove random token abcd *d%#

slide-26
SLIDE 26

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array)

Current Input Error Message Action abcd *d%# #*%*d*% KeyError: '#' Random Mutation: Remove random token abcd *d%# EOFError

slide-27
SLIDE 27

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array)

Current Input Error Message Action abcd *d%# #*%*d*% KeyError: '#' Random Mutation: Remove random token abcd *d%# EOFError Error Message template: Generate new token - either random or from bad input abcd *d%# abcd

slide-28
SLIDE 28

input_a = input() input_b = input() input_c = input() c_array = [] dictionary = {} for i in range(len(input_a)): dictionary[input_a[i]] = input_b[i] for j in range(len(input_c)): c_array += dictionary[input_c[j]] print(c_array)

Current Input Error Message Action abcd *d%# #*%*d*% KeyError: '#' Random Mutation: Remove random token abcd *d%# EOFError Error Message template: Generate new token - either random or from bad input abcd *d%# abcd Success!

slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32

Year Number of Input-Related Bugs 2015 1,640 2016 4,440 2017 6,949 2018 12,723 Total 25,995

slide-33
SLIDE 33
slide-34
SLIDE 34

Research Question Evaluation Metric Success Criterion RQ1: How effective is InFix? % Inputs repaired >= 80% (Ahmed et al., 2018) RQ2: How high quality are InFix's repairs? Statement coverage >= 75% (Tillmann et al., 2008) Human subjective assessment of quality >= 75% the quality of human patches (Kim et al., 2013)

slide-35
SLIDE 35
  • ○
  • ○

○

  • ○

○

slide-36
SLIDE 36

Input-Error Scenarios Probes to Solve Time (sec) Year Total Repaired % Med Avg Med Avg 2015 1,640 1,582 96.5 1 2.98 0.87 1.12 2016 4,440 4,683 94.8 2 3.23 0.88 1.16 2017 6,949 6,590 94.8 2 3.47 0.90 1.23 2018 12,723 11,947 93.9 2 3.70 0.88 1.28 Total 25,995 24,559 94.5% 2 3.50 0.88 1.23

slide-37
SLIDE 37

Input-Error Scenarios Probes to Solve Time (sec) Year Total Repaired % Med Avg Med Avg 2015 1,640 1,582 96.5 1 2.98 0.87 1.12 2016 4,440 4,683 94.8 2 3.23 0.88 1.16 2017 6,949 6,590 94.8 2 3.47 0.90 1.23 2018 12,723 11,947 93.9 2 3.70 0.88 1.28 Total 25,995 24,559 94.5% 2 3.50 0.88 1.23

slide-38
SLIDE 38

Input-Error Scenarios Probes to Solve Time (sec) Year Total Repaired % Med Avg Med Avg 2015 1,640 1,582 96.5 1 2.98 0.87 1.12 2016 4,440 4,683 94.8 2 3.23 0.88 1.16 2017 6,949 6,590 94.8 2 3.47 0.90 1.23 2018 12,723 11,947 93.9 2 3.70 0.88 1.28 Total 25,995 24,559 94.5% 2 3.50 0.88 1.23

slide-39
SLIDE 39

Input-Error Scenarios Probes to Solve Time (sec) Year Total Repaired % Med Avg Med Avg 2015 1,640 1,582 96.5 1 2.98 0.87 1.12 2016 4,440 4,683 94.8 2 3.23 0.88 1.16 2017 6,949 6,590 94.8 2 3.47 0.90 1.23 2018 12,723 11,947 93.9 2 3.70 0.88 1.28 Total 25,995 24,559 94.5% 2 3.50 0.88 1.23

slide-40
SLIDE 40

Input-Error Scenarios Probes to Solve Time (sec) Year Total Repaired %Repaired Med Avg Med Avg 2015 1,640 1,582 96.5 1 2.98 0.87 1.12 2016 4,440 4,683 94.8 2 3.23 0.88 1.16 2017 6,949 6,590 94.8 2 3.47 0.90 1.23 2018 12,723 11,947 93.9 2 3.70 0.88 1.28 Total 25,995 24,559 94.5% 2 3.50 0.88 1.23

slide-41
SLIDE 41
slide-42
SLIDE 42
  • ○
slide-43
SLIDE 43
  • ○

○

slide-44
SLIDE 44
slide-45
SLIDE 45
  • ○
  • ○
slide-46
SLIDE 46
slide-47
SLIDE 47
  • p = 0.047)
  • ○

○

  • ○

○

slide-48
SLIDE 48
slide-49
SLIDE 49

p

slide-50
SLIDE 50
slide-51
SLIDE 51
  • ○

○

  • ○

○

  • ○

○

slide-52
SLIDE 52
  • ○

○

  • ○

○

  • ○

○

slide-53
SLIDE 53

T

ValueError: invalid literal for int() with base 10: 'x' 'x' ValueError: could not convert string to float: 'x' 'x' ValueError: too many / not enough values to unpack EOFError: EOF when reading a line

slide-54
SLIDE 54

R

Insert a token Split delimited list Swap a token Remove a token Empty the input

slide-55
SLIDE 55
slide-56
SLIDE 56
  • ValueError

○ ValueError: invalid literal for int ○ ValueError: could not convert string to float ○ ValueError: not enough/too many values to unpack

slide-57
SLIDE 57
slide-58
SLIDE 58

Number of Threads 1 2 3 4 5 1 30.8% 36.4% 39.9% 42.6% 44.6% 5 64.1% 72.7% 77.3% 80.3% 82.6% 10 73.6% 81.0% 84.5% 86.7% 88.4% 20 80.5% 86.1% 88.8% 90.6% 91.7% 30 83.1% 88.2% 90.5% 92.0% 93.0% 60 86.7% 91.0% 92.7% 93.8% 94.5% 500 92.5% 94.5% 95.3% 95.8% 96.1% Maximum Number of Probes

slide-59
SLIDE 59

Number of Threads 1 2 3 4 5 1 30.8% 36.4% 39.9% 42.6% 44.6% 5 64.1% 72.7% 77.3% 80.3% 82.6% 10 73.6% 81.0% 84.5% 86.7% 88.4% 20 80.5% 86.1% 88.8% 90.6% 91.7% 30 83.1% 88.2% 90.5% 92.0% 93.0% 60 86.7% 91.0% 92.7% 93.8% 94.5% 500 92.5% 94.5% 95.3% 95.8% 96.1% Maximum Number of Probes

slide-60
SLIDE 60

Number of Threads 1 2 3 4 5 1 30.8% 36.4% 39.9% 42.6% 44.6% 5 64.1% 72.7% 77.3% 80.3% 82.6% 10 73.6% 81.0% 84.5% 86.7% 88.4% 20 80.5% 86.1% 88.8% 90.6% 91.7% 30 83.1% 88.2% 90.5% 92.0% 93.0% 60 86.7% 91.0% 92.7% 93.8% 94.5% 500 92.5% 94.5% 95.3% 95.8% 96.1% Maximum Number of Probes

slide-61
SLIDE 61
  • ○

○ ○

  • ○

○ k = 0.71 Helpfulness of InFix’s repairs depending on experience:

slide-62
SLIDE 62
