How big problem is Cu contamination in crystalline silicon photovoltaics? Hele Savin Aalto University Department of Electronics and Nanoengineering Electron Physics Group Espoo, Finland (population ~ 5 million) 5.10.2019 2 5.10.2019 3

slide-1
SLIDE 1

How big problem is Cu contamination in crystalline silicon photovoltaics?

Hele Savin

Aalto University Department of Electronics and Nanoengineering Electron Physics Group Espoo, Finland

slide-2
SLIDE 2

5.10.2019 2

(population ~ 5 million)

slide-3
SLIDE 3

5.10.2019 3

slide-4
SLIDE 4

5.10.2019 4

slide-5
SLIDE 5

Helsinki School of Economics University of Art & Design Helsinki Helsinki University of Technology

1849 1871 1911

2010

Merger of three leading Finnish universities

12 000

full-time equivalent degree students A staff of about 4 000, of which nearly 400 are professors

slide-6
SLIDE 6

Micronova: Research center in Micro - and Nanotechnology

  • The centre also hosts many

companies

  • Industrial scale facilities, 2600m2
  • f cleanrooms
  • 360 personnel (19 in maintenance)
  • 60 PhD students
  • Over 150 major equipment

installed

  • 150 mm R&D Fab, currently

upgraded to 200 mm

http://www.micronova.fi/

slide-7
SLIDE 7

Micronova: Research center in Micro - and Nanotechnology

http://www.micronova.fi/

F1 Flip-chip Bonding F2 Wet Processing F3 Nanolithography F4 Plasma and Sputtering F5 Plating F6 Metrology F7 Furnace F8 Lithography F9 ALD F10 Plasma F11 Wafers F12 Chemistry F13 Analysis Lab

slide-8
SLIDE 8

Micronova: Research center in Micro - and Nanotechnology

http://www.micronova.fi/

F1 Flip-chip Bonding F2 Wet Processing F3 Nanolithography F4 Plasma and Sputtering F5 Plating F6 Metrology F7 Furnace F8 Lithography F9 ALD F10 Plasma F11 Wafers F12 Chemistry F13 Analysis Lab

slide-9
SLIDE 9

Electron Physics Group

Crystalline silicon PV activities

  • Black silicon
  • DRIE and MACE
  • Electrical simulations
  • IBC/lab and PERC/industry
  • How to explain >100% EQE
  • Black Ge
  • ALD metal oxides
  • Surface passivation, passivated contacts
  • Up-conversion materials
  • Coating of module glasses
  • Light/Carrier induced degradation
  • Cu-LID
  • Mitigation of LeTID

2.2.2016 9

slide-10
SLIDE 10

Use of “PV”-innovations in other fields

10

Cast-Mono in MEMS&NEMS

slide-11
SLIDE 11

Use of “PV”-innovations in other fields

11

Certified EQE in UV > 130% Cast-Mono in MEMS&NEMS

slide-12
SLIDE 12

Use of “PV”-innovations in other fields

12

Utilize LID in Integrated Circuits Certified EQE in UV > 130% Cast-Mono in MEMS&NEMS

slide-13
SLIDE 13

Can we take advantage of this effect somewhere else?

13

Reference Cu-contaminated

slide-14
SLIDE 14

Another example how to utilize LID

Fe Cu

Initial t @ high injection

slide-15
SLIDE 15

Another example how to utilize LID

Fe Cu

Initial t @ high injection After light soaking

slide-16
SLIDE 16

Another example how to utilize LID

Fe Cu

Initial t @ high injection After light soaking Nice Cu (and Fe) map !

ECS Trans. 11, 319 (2007)

slide-17
SLIDE 17

Measurement of low-Cu concentrations

  • The strength of degradation depends on Cu

concentration Benefits:

  • Other common impurities such as Fe can be

separated

  • Contactless, non-destructive, fast, sensitive
  • Appl. Phys. Lett. 87, 032109 (2005)
slide-18
SLIDE 18

ref (no Cu) low Cu med Cu high Cu high low

How about mc-Si?

t = 0

slide-19
SLIDE 19

ref (no Cu) low Cu med Cu high Cu high low

How about mc-Si?

t = 2 min

slide-20
SLIDE 20

ref (no Cu) low Cu med Cu high Cu high low

How about mc-Si?

t = 17 min

slide-21
SLIDE 21

ref (no Cu) low Cu med Cu high Cu high low

How about mc-Si?

t = 3 hours

slide-22
SLIDE 22

ref (no Cu) low Cu med Cu high Cu high low

How about mc-Si?

t = 8 hours

slide-23
SLIDE 23

Naturally works with PL too

Cu contaminated spot

slide-24
SLIDE 24

Using PL to measure Cu in Silicon

High lifetime Low lifetime

𝐷𝐷𝑣 ∝ 𝑂𝑢

∗ =

1 τ𝑒𝑓𝑕𝑠𝑏𝑒𝑓𝑒 − 1 τ𝑗𝑜𝑗𝑢𝑗𝑏𝑚

Cu contaminated spot

slide-25
SLIDE 25

The role of oxygen (BMD)

  • Sensitivity can be increased by adding
  • xygen precipitates
  • Detection limit ppt -level
  • Appl. Phys. Lett. 87, 032109 (2005)
slide-26
SLIDE 26

Boron and oxygen certainly helps…

26

… but you don’t need them

  • Appl. Phys. Lett. 95, 152111 (2009)

FZ silicon n-type silicon

slide-27
SLIDE 27

What about elevated temperature …?

27

Can be used for faster detection Definitely makes the kinetics faster

  • Appl. Phys. Lett. 107, 052101 (2015)
slide-28
SLIDE 28

What about higher intensity …?

28

Similarly makes the kinetics faster …. …. further work

  • ngoing on this
  • J. Electrochem. Soc. 150 (12), 2003
slide-29
SLIDE 29

Gettering during POCl3 diffusion?

  • Cu fast diffuser
  • Should be easy to getter
  • … not always true

29

AIP Advances 8, 015112 (2018)

Cu

Phosphorus-doped region

Cu Cu

slide-30
SLIDE 30

Gettering during POCl3 diffusion?

  • Cu fast diffuser
  • Should be easy to getter
  • … not always true

30

AIP Advances 8, 015112 (2018)

Cu

Phosphorus-doped region

Cu Cu

10 20 30 40 50 Position [mm]

Normal cooling after POCl3 + light soak

170 210 250 290 330 370 410

Diffusion length [m]

slide-31
SLIDE 31

Gettering during POCl3 diffusion?

  • Cu fast diffuser
  • Should be easy to getter
  • … not always true

31

AIP Advances 8, 015112 (2018)

Cu

Phosphorus-doped region

Cu Cu

10 20 30 40 50 Position [mm] 10 20 30 40 50 170 210 250 290 330 370 410

Position [mm] Diffusion length [m]

Normal cooling after POCl3 + light soak

170 210 250 290 330 370 410

Diffusion length [m]

Slow cooling after POCl3 + light soak

slide-32
SLIDE 32

How stable is it during firing?

It is not stable, during high-T firing copper diffuses back to the bulk !

32

  • Appl. Phys. Lett. 113 (2018)
slide-33
SLIDE 33

Impact of firing temperature?

If firing T is too slow → no Cu-LID Cu prefers to stay in the emitter / surfaces

33

  • Appl. Phys. Lett. 113 (2018)
slide-34
SLIDE 34

Impact of ramp rates during firing?

Slow ramp rates reduce Cu-LID Simulations verify that Cu goes to bulk during firing but has time to diffuse back to emitter

34

  • Appl. Phys. Lett. 113 (2018)
slide-35
SLIDE 35

Cu in PERC cells?

35

INITIALLY AFTER ILLUMINATION

Solar Energy Materials and Solar Cells 186, 373-377 (2018)

slide-36
SLIDE 36

Cu in PERC cells?

36

INITIALLY AFTER ILLUMINATION

Solar Energy Materials and Solar Cells 186, 373-377 (2018)

slide-37
SLIDE 37

Quantum efficiency

37

Solar Energy Materials and Solar Cells 186, 373-377 (2018)

slide-38
SLIDE 38

Physics behind Cu-LID (+modeling)

  • Cui positively charged, fast diffuser, not

recombination active

  • Cu precipitates positively charged, highly

recombination active

  • Hypothesis: Light changes the charge state of

Cu precipitates → electrostatic attraction

  • All parameters known (diffusivity, solubility,

precipitation kinetics, recombination parameters… )

  • Modeling shows pretty nice correlation with

experiments

38

  • H. Vahlman, PhD thesis 2018 and publications there
slide-39
SLIDE 39

Physics behind Cu-LID (+modeling)

  • Cui positively charged, fast diffuser, not

recombination active

  • Cu precipitates positively charged, highly

recombination active

  • Hypothesis: Light changes the charge state of

Cu precipitates → electrostatic attraction

  • All parameters known (diffusivity, solubility,

precipitation kinetics, recombination parameters… )

  • Modeling shows pretty nice correlation with

experiments

39

Still cannot see anything here in e.g. TEM / DLTS…

  • H. Vahlman, PhD thesis 2018 and publications there
slide-40
SLIDE 40

What about dark anneal…?

40

Solar Energy Materials and Solar Cells 134 (2018)

Formation of recombination active precipitates - supersaturation (fast reaction) Precipitate dissolution – diffusion to surfaces (slow reaction)

slide-41
SLIDE 41

What about dark anneal…?

41

Solar Energy Materials and Solar Cells 134 (2018)

slide-42
SLIDE 42

“Le-TID” after dark anneal

42

Solar Energy Materials and Solar Cells 134 (2018)

No LeTID after long dark anneal

slide-43
SLIDE 43

“Le-TID” after dark anneal in PERC

43

Silicon PV 2019

slide-44
SLIDE 44

What about hydrogenation…?

All the prior results have been carried out without PECVD SiNx:H, so we don’t know … yet

44

slide-45
SLIDE 45

Conclusions

  • LID can be also a positive issue
  • Measurement of Cu contamination
  • Enhancing Cu gettering in microelectronics
  • Cu can cause severe LID in solar cells – be aware of

contamination risks

  • It may be difficult to separate Cu-LID from other LID

mechanisms …

  • Looking forward to further collaborations with UNSW!

45

slide-46
SLIDE 46

2.2.2016 46

Thank you!

Funding acknowledgements:
