SLIDE 1
Honey, I shrunk the database!
Resilience and recoverability in Cloud Native services
JEFFREY FARBER SIDNEY SHEK
Honey, I shrunk the database! Resilience and recoverability in Cloud - - PowerPoint PPT Presentation
Honey, I shrunk the database! Resilience and recoverability in Cloud - - PowerPoint PPT Presentation
Honey, I shrunk the database! Resilience and recoverability in Cloud Native services JEFFREY FARBER SIDNEY SHEK Cloud infrastructure = reliable services right? SUPER RESILIENT CLOUD-BASED ARCHITECTURE Canary Progressive Rollouts
SLIDE 2
SLIDE 3
Cloud infrastructure = reliable services
right?
SLIDE 4
SUPER RESILIENT CLOUD-BASED ARCHITECTURE
Canary Progressive Rollouts Blue-Green Deployments 5 minute backups Distributed Multi-Region Cassandra Database
SLIDE 5
WITH LOTS OF DEPENDENCIES
Reliability Promise = 99.999% Recovery Time Objective = 1 hour Recovery Point Objective = 5 minutes
SLIDE 6
Until…
SLIDE 7
BET YOU DIDN’T SEE THIS COMING (THIS IS A TRUE STORY)
SLIDE 8
WE RESTORE…
2 hour old snapshot
SLIDE 9
WE RESTORE… … BUT WHAT ABOUT OUR DEPENDENCIES?
LOST DATA WRONG(?) DATA MAY HAVE
CORRECT DATA, BUT HOW TO SYNC?
10X
NORMAL LOAD?
SLIDE 10
💪 will happen.
Accept and plan for it.
Emergent behaviour
Our systems are complex and unpredictable.
Broad spectrum solutions
Incorporate general recovery methods to handle the unexpected.
Big statement with support
SLIDE 11
💪 will happen.
Accept and plan for it.
Emergent behaviour
Our systems are complex and unpredictable.
Broad spectrum solutions
Incorporate general recovery methods to handle the unexpected.
Big statement with support
SLIDE 12
💪 will happen.
Accept and plan for it.
Emergent behaviour
Our systems are complex and unpredictable.
Broad spectrum solutions
Incorporate general recovery methods to handle the unexpected.
Big statement with support
SLIDE 13
- 3. Local and distributed redundancy
Having fallbacks for fallbacks for fallbacks…
- 1. Event sourcing
Minimize data loss after a restore
- 2. Easily recoverable replication
Get downstream systems back in sync
PATTERNS FOR GUARDING AGAINST THE IMPOSSIBLE
SLIDE 14
- 3. Local and distributed redundancy
Having fallbacks for fallbacks for fallbacks…
- 1. Event sourcing
Minimize data loss after a restore
- 2. Easily recoverable replication
Get downstream systems back in sync
PATTERNS FOR GUARDING AGAINST THE IMPOSSIBLE
SLIDE 15
- 3. Local and distributed redundancy
Having fallbacks for fallbacks for fallbacks…
- 1. Event sourcing
Minimize data loss after a restore
- 2. Easily recoverable replication
Get downstream systems back in sync
PATTERNS FOR GUARDING AGAINST THE IMPOSSIBLE
SLIDE 16
Event sourcing
Minimize data loss after a restore
SLIDE 17
Let’s add recovery here
SLIDE 18
Event Sourcing Recover from bugs ruining data
Databases can replicate your data across regions. It also replicates your bugs.
Minimize data loss of DB restore (RPO)
Critical applications can’t afford hours of data loss.
Accuracy & Time (RTO)
We need confidence in our restored data, and we need it quickly!
Goals Generating Recovery Write Events
SLIDE 19
Event Sourcing Recover from bugs ruining data
Databases can replicate your data across regions. It also replicates your bugs.
Minimize data loss of DB restore (RPO)
Critical applications can’t afford hours of data loss.
Accuracy & Time (RTO)
We need confidence in our restored data, and we need it quickly!
Goals Generating Recovery Write Events
SLIDE 20
Event Sourcing Recover from bugs ruining data
Databases can replicate your data across regions. It also replicates your bugs.
Minimize data loss of DB restore (RPO)
Critical applications can’t afford hours of data loss.
Accuracy & Time (RTO)
We need confidence in our restored data, and we need it quickly!
Goals Generating Write Events Recovery
SLIDE 21
INSERT INTO table DELETE FROM table SELECT FROM table
Service
Event Sourcing
Goals Generating Write Events Recovery
SLIDE 22
INSERT INTO table DELETE FROM table SELECT FROM table
Event Sourcing
Goals Generating
Writes Reads
Write Events Recovery
SLIDE 23
INSERT INTO table DELETE FROM table historical command store SELECT FROM table INSERT/APPEND
Event Sourcing
Goals Generating
Writes
Write Events Recovery
SLIDE 24
INSERT INTO table DELETE FROM table historical command store SELECT FROM table INSERT/APPEND
Event Sourcing
Goals Generating
Writes Replay events to main database
Write Events Recovery
SLIDE 25
INSERT INTO table DELETE FROM table historical command store SELECT FROM table INSERT/APPEND
Event Sourcing
Goals Generating
MAKE SURE THIS IS AN INDEPENDENT STORE!
Writes
Write Events Recovery
SLIDE 26
Generating
[ { "sequence": 20, "stream": "user123", "commandType": "grant_permission", "params": { "user": "user123", "resource": "issueABC", "permission": "view" }, "timestamp": "2019-07-24 3:30 PM”, "actor": "jira_share_service" }, ]
Event Sourcing
Goals Write Events Recovery
SLIDE 27
Generating
[ { "sequence": 20, "stream": "user123", "commandType": "grant_permission", "params": { "user": "user123", "resource": "issueABC", "permission": "view" }, "timestamp": "2019-07-24 3:30 PM”, "actor": "jira_share_service" }, ]
Event Sourcing
Order all writes, so we can replay in same order Goals Write Events Recovery
1
SLIDE 28
Generating
Event Sourcing
Order all writes, so we can replay in same order Goals Write Events Recovery
Stream Sequence user123 19
STRICTLY ORDERED
SET sequence = sequence + 1 WHERE sequence = 19
"sequence": 20, sequences -> 19, 20, 21...
1
SLIDE 29
Generating
Event Sourcing
Order all writes, so we can replay in same order Goals Write Events Recovery
"sequence": 20,
MOSTLY ORDERED
sequence = {timestamp}{unique_node_id}
sequences -> 1565312340, 1565323450, ...
1
SLIDE 30
Generating
Event Sourcing
Order all writes, so we can replay in same order Goals Write Events Recovery
"sequence": 20,
MOSTLY ORDERED
sequence = {timestamp}{unique_node_id}
sequences -> 1565312340, 1565323450, ...
No SPOF (database) Only certain writes need strict ordering Clock skew window is small (< 1 sec) Don’t know previous sequence
1
SLIDE 31
timestamp2 > timestamp1
Generating
Event Sourcing
Order all writes, so we can replay in same order Goals Write Events Recovery
"sequence": 20,
MOSTLY ORDERED + CUSTOMER-DICTATED STRICT ORDERING
/create
write1 {sequence/timestamp1}
/delete
write2 ?after={timestamp1} {sequence/timestamp2}
1
SLIDE 32
Generating
[ { "sequence": 20, "stream": "user123", "commandType": "grant_permission", "params": { "user": "user123", "resource": "issueABC", "permission": "view" }, "timestamp": "2019-07-24 3:30 PM”, "actor": "jira_share_service" }, ]
Event Sourcing
Streams guarantee order Parallelize across streams Goals Write Events Recovery
2
SLIDE 33
Generating
[ { "sequence": 20, "stream": "user123", "commandType": "grant_permission", "params": { "user": "user123", "resource": "issueABC", "permission": "view" }, "timestamp": "2019-07-24 3:30 PM”, "actor": "jira_share_service" }, ]
Event Sourcing
Goals Write Events Recovery
user123
{sequence: 20, commandType: ”grant", permission: "view"} {sequence: 21, commandType: ”revoke”, permission: "view"}
Streams guarantee order Parallelize across streams
2
SLIDE 34
Generating
[ { "sequence": 20, "stream": "user123", "commandType": "grant_permission", "params": { "user": "user123", "resource": "issueABC", "permission": "view" }, "timestamp": "2019-07-24 3:30 PM”, "actor": "jira_share_service" }, ]
Event Sourcing
2
Goals Write Events Recovery
user456
{sequence: 74, commandType: ”grant", permission: “edit"} {sequence: 75, commandType: ”revoke”, permission: “edit"}
user123
{sequence: 20, commandType: ”grant", permission: "view"} {sequence: 21, commandType: ”revoke”, permission: "view"}
Streams guarantee order Parallelize across streams
SLIDE 35
Event Sourcing
Generating Goals Write Events Recovery
1
Restore snapshot
SLIDE 36
Event Sourcing
Generating Goals Write Events Recovery
1 2
Recover streams in parallel
user123 user456
21, 20 19
Restore snapshot
73 ..., 76, 75, 74
SLIDE 37
Event Sourcing
Generating Goals Write Events Recovery
1 2
Recover streams in parallel Bonus: process all stream events in-memory
user123 user456
21, 20 19
Restore snapshot
73 ..., 76, 75, 74
SLIDE 38
Event Sourcing
[ { "stream": "user123", "sequence": 20, "commandType": "grant_permission", "params": { "user": "user123", "resource": "issueABC", "permission": “view" }, ... }, Events for stream “user123” Main Datastore Stream Sequence user123 19 { "stream": "user123", "sequence": 21, "commandType": "grant_permission", "params": { "user": "user123", User Resource Permissions user123 issueABC []
Generating Goals Write Events Recovery
SLIDE 39
Event Sourcing
[ { "stream": "user123", "sequence": 20, "commandType": "grant_permission", "params": { "user": "user123", "resource": "issueABC", "permission": “view" }, ... }, Main Datastore { "stream": "user123", "sequence": 21, "commandType": "grant_permission", "params": { "user": "user123",
Generating Goals Write Events Recovery
Events for stream “user123” Stream Sequence user123 20 User Resource Permissions user123 issueABC [“view”]
SLIDE 40
Event Sourcing
"user": "user123", "resource": "issueABC", "permission": “view" }, ... }, Main Datastore { "stream": "user123", "sequence": 21, "commandType": "grant_permission", "params": { "user": "user123", "resource": "issueABC", "permission": “edit” }, ... } ]
Generating Goals Write Events Recovery
Stream Sequence user123 20 User Resource Permissions user123 issueABC [“view”]
SLIDE 41
Event Sourcing
"user": "user123", "resource": "issueABC", "permission": “view" }, ... }, Main Datastore { "stream": "user123", "sequence": 21, "commandType": "grant_permission", "params": { "user": "user123", "resource": "issueABC", "permission": “edit” }, ... } ]
Generating Recovery Goals Write Events
Stream Sequence user123 21 User Resource Permissions user123 issueABC [“view”, “edit”]
SLIDE 42
THE DATABASE JUST LOST HALF IT’S DATA!
ALERT - INCOMING PAGE!
SLIDE 43
INCIDENT RECOVERY
1
Stop new writes
(depends on architecture) write API
error
SLIDE 44
INCIDENT RECOVERY
1
2 hour old snapshot write API
error
2
Restore from backup Stop new writes
(depends on architecture)
SLIDE 45
INCIDENT RECOVERY
1
2 hour old snapshot write API
error
2
Restore from backup
3
Catchup via command store
(a) Command store queryable by time (b) Logs (c) Worst case -> check all streams
Stop new writes
(depends on architecture)
SLIDE 46
INCIDENT RECOVERY
1
2 hour old snapshot write API
error
2
Restore from backup
3 4
Go relax!
Re-enable writes (if applicable)
Catchup via command store
(a) Command store queryable by time (b) Logs (c) Worst case -> check all streams
Stop new writes
(depends on architecture)
SLIDE 47
Easily Recoverable Replication
Get downstream systems back in sync
SLIDE 48
Recover this data!
SLIDE 49
Our goals
Recover quickly
Minimise downtime of all systems
SLIDE 50
Recover correctly
Confidently serve consistent data across systems through idempotency
Our goals
Recover quickly
Minimise downtime of all systems
SLIDE 51
Recover correctly
Confidently serve consistent data across systems through idempotency
Our goals
Control the chaos
Avoid self-inflicted denial of services during recovery
Recover quickly
Minimise downtime of all systems
SLIDE 52
SENDING EVENTS TO CONSUMERS
INSERT INTO table
Write Service
search
Downstream Services
ecosystem
Events sent to event bus
SLIDE 53
Downstream Services Write Service
user123 Operation-Based
{sequence: 22, commandType: "grant", permission: "edit"} {sequence: 23, commandType: "revoke", permission: "edit"}
Can build from internal event sourcing events Requires perfect ordering. Cannot lose a single message Recovery requires replaying from sequence=0
search
SLIDE 54
{sequence: 22, permissions: [“edit"]} {sequence: 23, permissions: []}
State-Based
Downstream Services Write Service
user123 user123 Operation-Based
{sequence: 22, commandType: "grant", permission: "edit"} {sequence: 23, commandType: "revoke", permission: "edit"}
Can build from internal event sourcing events Requires perfect ordering. Cannot lose a single message Recovery requires replaying from sequence=0
Each message is independent Recovery requires single message Requires another DB query to produce state
search search
SLIDE 55
INSERT INTO table
Write Service Downstream Services
search ecosystem
Operation-Based State-Based
Query database to generate state-based event
Events sent to event bus
SLIDE 56
INSERT INTO table
Write Service Downstream Services
search ecosystem
Operation-Based State-Based
Events sent to event bus
Save outbound event Query database to generate state-based event
SLIDE 57
ERROR DETECTION AND RECOVERY
Synchronizing APIs Downstream Services
search
Stream Sequence user123 23 user456 75 Stream Sequence user123 23 user456 48
/resendLatest /latestSequence /allStreamIds
SLIDE 58
ERROR DETECTION AND RECOVERY
Synchronizing APIs Downstream Services
search
Stream Sequence user123 23 user456 75 Stream Sequence user123 23 user456 48
/resendLatest /latestSequence /allStreamIds /latestSequence?stream=user123 sequence: 23
SLIDE 59
ERROR DETECTION AND RECOVERY
Synchronizing APIs Downstream Services
search
Stream Sequence user123 23 user456 75 Stream Sequence user123 23 user456 48
/resendLatest /latestSequence /allStreamIds /latestSequence?stream=user456 sequence: 75
SLIDE 60
ERROR DETECTION AND RECOVERY
Synchronizing APIs Downstream Services
search
Stream Sequence user123 23 user456 75 Stream Sequence user123 23 user456 48
/resendLatest /latestSequence /allStreamIds /latestSequence?stream=user456 sequence: 75
SLIDE 61
ERROR DETECTION AND RECOVERY
Synchronizing APIs Downstream Services
search
Stream Sequence user123 23 user456 75 Stream Sequence user123 23 user456 48
/resendLatest /latestSequence /allStreamIds /resendLatest?stream=user456 {sequence: 75, permissions: [latest state]}
SLIDE 62
ERROR DETECTION AND RECOVERY
Synchronizing APIs Downstream Services
search
Stream Sequence user123 23 user456 75 Stream Sequence user123 23 user456 75
/resendLatest /latestSequence /allStreamIds /resendLatest?stream=user456 {sequence: 75, permissions: [latest state]}
SLIDE 63
ERROR DETECTION AND RECOVERY
Synchronizing APIs Downstream Services
search
Stream Sequence user123 23 user456 75 Stream Sequence user123 23
/resendLatest /latestSequence /allStreamIds /allStreamIds [user123, user456,..., (paginated)]
SLIDE 64
SEARCH SERVICE HAS BEEN DROPPING MESSAGES FOR 4 HOURS!
ALERT - INCOMING PAGE!
SLIDE 65
INCIDENT RECOVERY
1
Determine dropped streams
(a) Command store queryable by time (b) Logs (c) Worst case -> check all streams
SLIDE 66
INCIDENT RECOVERY
1
Determine dropped streams
(a) Command store queryable by time (b) Logs (c) Worst case -> check all streams
2
- Depending on (1), could help to improve speed
Compare via /latestSequence
SLIDE 67
INCIDENT RECOVERY
1
Determine dropped streams
(a) Command store queryable by time (b) Logs (c) Worst case -> check all streams
2
Compare via /latestSequence
- Depending on (1), could help to improve speed
3 Resend state via /resendLatest
- Messages are idempotent
- Can occur alongside new messages
SLIDE 68
Local and Distributed Redundancy
Having fallbacks for fallbacks for fallbacks…
SLIDE 69
Redundancy?
SLIDE 70
Our goals
“Always online” even during incidents
Debugging and data recovery take time.
SLIDE 71
Eliminate DB as single point of failure
Replicas don’t guard against data corruption, cluster config errors, etc.
Our goals
“Always online” even during incidents
Debugging and data recovery take time.
SLIDE 72
Eliminate DB as single point of failure
Replicas don’t guard against data corruption, cluster config errors, etc.
Our goals
Do better than region failover
Cross-region call latency is always higher than local calls
“Always online” even during incidents
Debugging and data recovery take time.
SLIDE 73
REDUNDANT DATA STORES
CONSISTENT CONSISTENT? INVALIDATIONS? MODERATE LATENCY Serve reads
App layer
Main data store e.g. Cassandra Cache e.g. Redis Event store e.g. S3 LOW LATENCY EVENTUALLY CONSISTENT HIGHER LATENCY MODERATE SCALE HIGHLY SCALABLE
- V. HIGHLY
SCALABLE
SLIDE 74
REDUNDANT DATA STORES
Serve reads
Writes
Main data store e.g. Cassandra Cache e.g. Redis Event store e.g. S3
Reads
Invalidate
SLIDE 75
Redundancy!
SLIDE 76
DISTRIBUTED RESULTS WITH VALIDATABLE TOKENS Identity Consumer 2 Consumer 1
Check X Token Request + Token Validate token Validate token
SLIDE 77
Things to consider
Signed, with the right lifetime
Fast validation algorithm, appropriate lifetime, https://bitbucket.org/ atlassian/asap
SLIDE 78
Blacklists for invalidation
Low volume, easily distributable and cacheable
Things to consider
Signed, with the right lifetime
Fast validation algorithm, appropriate lifetime, https://bitbucket.org/ atlassian/asap
SLIDE 79
Blacklists for invalidation
Low volume, easily distributable and cacheable
Things to consider
Centralise logic with sidecars
Easier maintenance, avoid bugs due to inconsistency
Signed, with the right lifetime
Fast validation algorithm, appropriate lifetime, https://bitbucket.org/ atlassian/asap
SLIDE 80
DATABASE IS OVERLOADED & FAILING ALL QUERIES
ALERT - INCOMING PAGE!
SLIDE 81
DATABASE IS OVERLOADED & FAILING QUERIES
Token
Hystrix flips to serve fallback datastore Hystrix flips to serve primary datastore
SLIDE 82
DATABASE IS OVERLOADED & FAILING QUERIES
SLIDE 83
Looking back… to look forward
SLIDE 84
💪 will happen.
Accept and plan for it.
Emergent behaviour
Our systems are complex and unpredictable.
Broad spectrum solutions
Incorporate general recovery methods to handle the unexpected.
Big statement with support
SLIDE 85
💪 will happen.
Accept and plan for it.
Emergent behaviour
Our systems are complex and unpredictable.
Broad spectrum solutions
Incorporate general recovery methods to handle the unexpected.
Big statement with support
SLIDE 86
💪 will happen.
Accept and plan for it.
Emergent behaviour
Our systems are complex and unpredictable.
Broad spectrum solutions
Incorporate general recovery methods to handle the unexpected.
Big statement with support
SLIDE 87
- 3. Local and distributed redundancy
Having fallbacks for fallbacks for fallbacks…
- 1. Event sourcing
Minimize data loss after a restore
- 2. Easily recoverable replication
Get downstream systems back in sync
PATTERNS FOR GUARDING AGAINST THE IMPOSSIBLE
SLIDE 88
- 3. Local and distributed redundancy
Having fallbacks for fallbacks for fallbacks…
- 1. Event sourcing
Minimize data loss after a restore
- 2. Easily recoverable replication
Get downstream systems back in sync
PATTERNS FOR GUARDING AGAINST THE IMPOSSIBLE
SLIDE 89
- 3. Local and distributed redundancy
Having fallbacks for fallbacks for fallbacks…
- 1. Event sourcing
Minimize data loss after a restore
- 2. Easily recoverable replication
Get downstream systems back in sync
PATTERNS FOR GUARDING AGAINST THE IMPOSSIBLE
SLIDE 90
How do you take on the impossible?
SLIDE 91
Thank you!
JEFFREY FARBER SIDNEY SHEK
SLIDE 92
Rate today ’s session
Session page on conference website O’Reilly Events App
SLIDE 93
REFERENCES TO ALL THOSE PICS
https://www.imdb.com/title/tt4834206/ https://www.imdb.com/title/tt2015381/ https://www.lynchburgvirginia.org/event/back-to-the-future-film-event/ https://www.youtube.com/watch?v=LQxe-JkSv4o https://www.quora.com/If-you-punch-yourself-and-it-hurts-are-you-strong-or-are-you-weak https://www.amazon.com/Iron-Man-3-Theatrical-Version/dp/B00FEHXCIG https://unitedlocksmith.net/wp-content/uploads/open-24-hours.jpg https://jwt.io/ https://businesstech.co.za/news/wp-content/uploads/2019/05/Blacklisted.png https://www.dmcsidecars.com/wp-content/uploads/2016/05/DSCN5400-e1468435592887.jpg https://www.starsjackets.com/product/star-lord-chris-pratt-jacket https://aws.amazon.com/architecture/icons/
