slide-1
SLIDE 1

Hit the Highways

September 27th Bus Tour

slide-2
SLIDE 2

A Special Thanks to our Sponsoring Partners

2

slide-3
SLIDE 3

The highway system

3

  • Statewide Quick Facts:

– 140,000 mile of public roads, 10,000 state highways – 4th largest in the nation – 837 miles of city connecting links

  • Regional Quick Facts:

– 3,349 miles of state highway in KDOT District 6

slide-4
SLIDE 4

District 6

4

19 counties Population: 151,496 Daily Vehicle Miles Traveled in 2015: 5,041,992 Total Miles Roads/Streets/Highways: 19,828

slide-5
SLIDE 5

District 6 Major Traffic Concerns

5

  • Increased Truck Traffic
  • Safety Concerns
  • Economic Development Needs

– Rural needs – Agriculture demands – Wind Industry

  • Incomplete Projects
slide-6
SLIDE 6

Modernization/Expansion Project Delays as announced 4/2016

6 US-69 Project reprogrammed back into T-WORKS

slide-7
SLIDE 7

District 6 Truck Traffic Trends

7

slide-8
SLIDE 8

156 Truck Traffic Trends over 20 years

8

65.6% 87% 67.3% 81%

slide-9
SLIDE 9

50/400 Truck Traffic Trends over 20 years

9

87% 59%

slide-10
SLIDE 10

US-50 Project Delayed

10

US-50 Project Goals: Expands 16 miles of US 50 as a four-lane expressway safety concerns truck traffic concerns

slide-11
SLIDE 11

US-50 Project Delayed

11

slide-12
SLIDE 12

US-50 Project Delayed

12

slide-13
SLIDE 13

US-50 Project Delayed

13

slide-14
SLIDE 14

US-54 Project Delayed

14

slide-15
SLIDE 15

US-54: Tucker Rd to County Road O

15

  • 4-land divided limited access expressway
  • 100 foot wide grassy median
  • Close US-54 to Tucker Rd, County Rd M, and Salley Rd and RR crossings
  • New 90 degree intersection between Salley Rd and County Rd M with

westbound to northbound turn lane and gated railroad crossing

  • Construct various access roads

*Source provided from KDOT US-54 public informational meeting

slide-16
SLIDE 16

US-54: Arkalon Plant Int. Project

16

  • 4-lane divided limited access expressway
  • 100-150 foot wide grassy median
  • Arkalon Rd intersection: reduce angle, include gated RR crossing & increase

storage between US-54 & RR tracks

  • Close US-54 access to County Rd 8
  • Couny Rd P intersection: reduce angle, include turn lanes, increase storage

between US-54 & RR tracks, and include gated RR crossing

*Source provided from KDOT US-54 public informational meeting

slide-17
SLIDE 17

US-54: Cimarron River Crossing

17

  • 4-lane divided limited access expressway
  • 125 foot wide grassy median
  • R Park Road intersection to 90 degrees
  • New bridge for westbound traffic north of existing bridge
  • Existing bridge used for eastbound traffic
  • Davies/Panhandle Road intersection: Construct various turn lanes and improve

intersections

  • Construct various access roads

*Source provided from KDOT US-54 public informational meeting

slide-18
SLIDE 18

Shoulder Needs

18

slide-19
SLIDE 19

Bridge Conditions

* Source KDOT’s Performance Measures website

19

slide-20
SLIDE 20

Bridge Conditions

  • Two Classifications

– Structurally Deficient – Functionally Obsolete

20

slide-21
SLIDE 21

Bridge Conditions

21

Source: KDOT Data submitted to FHWA

slide-22
SLIDE 22

Bridge Conditions

* Source KDOT’s Performance Measures website

22

slide-23
SLIDE 23

Bridges: Lewis & Clark

23

slide-24
SLIDE 24

Bridges: Lewis & Clark

24

slide-25
SLIDE 25

Bridges: Lewis & Clark

25

slide-26
SLIDE 26

Bridges: Lewis & Clark

26

slide-27
SLIDE 27

Bridges: Lewis & Clark

27

slide-28
SLIDE 28

Practical Improvements

28

  • A practical improvement

– A recognition that needs will always

  • utpace resources

– Gives engineers and others the flexibility to use lower-cost alternatives to the full-scale complement of improvements that have been standard. Sometimes includes Narrowing project footprint Identifying less-expensive means

slide-29
SLIDE 29

Pavement Analysis

29

What are they measuring?

  • 1. Ride
  • 2. Joint Distress or

Cracking

  • 3. Faulting or Rutting
slide-30
SLIDE 30

Pavement Analysis

30

  • Level 1-Denotes segments are smooth and exhibit few if any

surface defects. Pavement segments in this category do not require corrective action, however it may be appropriate to perform preventative maintenance to prolong this good condition.

  • Level 2-Denotes segments that appear to require at least

routine maintenance to address roughness or to correct moderate surface defects.

  • Level 3-Denotes segments that appeared to require a

rehabilitative action beyond routine maintenance at the time of the survey

slide-31
SLIDE 31

Preservation of Concrete

31

I-70 Example

slide-32
SLIDE 32

Right Action/Right Time

32

slide-33
SLIDE 33

Types of Projects & Preservation Spending Breakdown

  • Resurfacing $220m - $250m/year

– Typical project scopes include thinner overlays, chip seals and patching of existing roads. Would improve 1200 – 1500 miles/year. Includes interstate and non-interstate routes.

  • Bridge Replacements $50m - $75m/year

– Would replace deteriorated bridges. Number of bridges would vary depending on sizes.

  • Bridge Repairs $15m - $20m/year

– Typical project scope includes deck replacement/repair, structural repair, repainting of existing bridge structures. Number of bridges would vary depending on size and magnitude of repairs needed.

  • Heavy Preservation $50m - $90m/year

– Typical project scopes would include full depth pavement reconstruction/replacement or significant rehab of the existing pavement section.

33

slide-34
SLIDE 34

Where we are today

$450-$500m in sales tax receipts transferred each fiscal year – the entirety that can be transferred is being transferred More than $500m in delayed projects Month to month lettings “the agency will make decisions on a month to

month basis.” – Wichita Eagle Article 11/14/16

Inability to respond to emerging or urgent infrastructure needs

34

slide-35
SLIDE 35

Preservation Spending Pre-17 Session

35 FY 11 FY 12 FY 13 FY 14 FY 15 FY 16 FY 17 FY 18 FY 19

17 added

slide-36
SLIDE 36

How is KDOT coping? A look at Revenues & Expenditures

36 200 400 600 800 1000 1200 1400 1600 1800 FY 17 Revenues FY 17 Expenses FY 18 Revenues FY 18 Expenses FY 19 Revenues FY 19 Expenses

Total needed for existing payouts and $380m in preservation Local Support Modes Outsourced Engineering Agency Ops Debt Service Transfers Carry over from previous years ending balance Misc Fees Federal Aid Sales & Compensating Use Tax MFT

FY 18 Revenues fall below existing payouts and necessary preservation

slide-37
SLIDE 37

Do we really need to worry about dropping in preservation funds?

37

For each $1 spent during the first 40% of pavement quality will cost $4-$5 if delayed until the pavement loses 80% of it’s original quality.

http://www.dennis.polhill.info/archives/category/pavement-management

slide-38
SLIDE 38

Do we really need to worry about dropping in preservation funds?

38

Pavement Condition 2015 – Level 1 Pavement Condition 2016 – Level 3

slide-39
SLIDE 39

Population and Growth Opportunities

39

Percentage of Population changes since 2010

Source: institute for policy & social research, The University of Kansas, data from U.S. Census Bureau Population Estimates, Vintage 2016

slide-40
SLIDE 40

Transload Facility

40 Photo from Garden City Telegram, James M. Dobson

slide-41
SLIDE 41

A Special Thanks to our Sponsoring Partners

41
