SLIDE 1

Hikvision Temperature Screening and Social Distancing Solution

SLIDE 2

Solution Background

Residential Community Public Transportation Industry Park/ Office Building Other Public Places

Fast deployable screening solution to build the first health screening back line Efficient screening and social distancing for indoor crowds to avoid cross infection risks Safe and efficient staff management to help create a safer working environment Flow control and efficient screening to protect indoor public places with large amounts of random visitors

Human skin-surface temperature is an important indicator of physical health. In many scenarios, besides the traditional mercury thermometer or ear thermometer that needs to be applied manually with contact risks, high labor cost and statistics difficulties, efficient and accurate skin-surface

temperature screening for a mass amount of people, along with mask detection and further social distancing measures becomes

urgent needs to help build a safer environment.

SLIDE 3

Reduce Risk All solutions are contact-free Boost Efficiency Instant detection, real-time interactive and statistics report Reliable Result Highly accurate with traceable records What We Bring

One-stop Protection Fast Deployment Employee Management Corporate HQ Manager Site Manager Onsite Security

Solution Architecture

Efficient Crowds Screening Social Distancing

Evidence Retrieval Statistical Report Employee Status & Attendance

Flexible Product Choice for a Multitude of Scenarios Cross-device Site Management of Statistics and Evidencing Records Cross-site Central Management by remote supervision and statistics

Commercial Building, station, etc.

1 2 5

Store and public places

Remote Supervision & Statistics

Industrial Applications by Hikvision or by third party

3 4

Residential, hospital, etc.

Detected results and abnormal events Health Status Statistics and abnormal events

Office, factory, etc. Temperature screening & social distancing all in 1 unit

SLIDE 4

Employee Management - MinMoe Access Terminal for SMB Office Scenario

Access and Attendance based on Temperature Screening and Mask Detection Result

1

Business Flow (SMB Office)

Mifare Card Reader Facial Recognition Temperature screening

System Topology (SMB Office)

LAN MinMoe Access Terminal Indoor Station (optional for visitor call)

Screening distance: 0.3m - 2m Facial authentication: 0.5s

Entrance Reception

DS-K1T671TM-3XF MinMoe Access Terminal Touch-free Authentication

Instant Alarm with Audio

1 2

Door opens

• nly when ID verified, mask on

and temperature normal

Employee Access

No door permission

• n abnormal temperature or

no mask alarm

Attendance Report

3

Staff attendance report from the MinMoe access terminal See Visitor Status at Reception

Visitor Access

Initiate Video Call

1 2

Remotely grant/ refuse visitor access according to the status shown on the indoor station Initiate video call from the door station

SLIDE 5

Employee Management - MinMoe Access Terminal for Office Building Scenario

Access and Attendance based on Temperature Screening and Mask Detection Result

1

Business Flow (Office Building)

Visitor access granted

Visitor Access

Temperature screening of visitor

1 2

Visitors can enter and exit the designated office area within the designated time. Receptionist uses Handheld Thermal to measure the temperature of visitor.

Visitor registration

For visitor with normal temperature, register visitor information in Visitor registration Client (HCP) and assign access permission for visitor.

3

System Topology

HCP Server & Control Client

LAN … … … Office Building

LAN

Reception Desk

Visitor Registration Client

Command Center

LAN

Enrollment Station Handheld Terminal

Touch-free Authentication

Instant Alarm with Audio

1 2

Door opens

• nly when ID verified, mask on

and temperature normal

Employee Access

No door permission

• n abnormal temperature or

no mask alarm

Attendance Management

3

Attendance report and one-click correction for people with abnormal temperature

SLIDE 6

Employee Management - MinMoe Access Terminal for Large Corporation Scenario

Access and Attendance based on Temperature Screening and Mask Detection Result

1

Touch-free Authentication Instant Alarm with Audio

1 2

Door opens

• nly when ID verified, mask on

and temperature normal

Onsite Security

No door permission

• n abnormal temperature or

no mask alarm

Onsite Screening and Access Control by Terminal System Topology (Corporation) Business Flow (Corporation)

HCP Server

WAN … … … Branch Office A

HCP Client

LAN

… … Branch Office B

HCP Client

LAN

HQ

Site Manager

Viewing statistics

Attendance Management & Export

1 2

Attendance report and one-click correction for people with abnormal temperature Temperature and mask statistics for all or staff-only with report

Management and Attendance Report by HCP

SLIDE 7

Application Scenarios Retail Store, Shopping Mall and Other Indoor Public Places

Social Distancing Solutions

Flow control and close contact alarm for social distancing

2

Flow Control on Digital Signage

2-1

Concurrent Display of Flow Control and Media Info on Digital Signage

Or Digital Signage Box: DS-D60C-B connected to monitor Digital Signage:

DS-D60xx Series iDS-2CD7146G0-IZS DS-2CD6825G0/C-I(V)S

Flow Control Camera:

Close Contact Alarm by Dual Lens Camera

2-2

Precise contact distance detection and close

contact alarm

• Configurable alarm threshold of close contact distance

DS-2CD6825G0/C-I(V)S with special bracket

SLIDE 8

Social Distancing - Flow Control on Digital Signage

Concurrent Display of Flow Control and Advertising Media, Optional Mask and Temperature Status

2-1

• Ceiling mount only, 90° downward viewing
• 2.5m or above installation height
• Filtering target by height
• Ceiling mount or wall mount
• 2m or above installation height
• For scenes with no overlapping

Entrance C Entrance A Control Room

System Topology

Focsign Info Release System HCP Server HCP Client NVR

Entrance B

Site A Site N

…

Flow Control Highlight

WAN / Company VPN LAN

Concurrent Display with Advertising Media, Mask & Temperature Status

Optional display of mask and temperature status on the digital signage if connected with corresponding camera and/or NVR.

Notification: ‘Please wear a mask!’

Thermographic Image with Temperature Status Advertising Media

2

People Counting & Flow Control

Multi-door supported by digital signage,

I series NVR, DeepinMind NVR or HCP.

1

Flow Control

Option 1

Flow Control, Mask Detection & BI

Option 2

• 4MP HD CCTV surveillance
• Mask detection
• Retail business intelligence
• 90° ceiling mount
• 1080p

O R

SLIDE 9

Social Distancing - Close Contact Alarm by Dual Lens Camera

Close Contact Alarm for Indoor Public Places

2-2

User-configurable Alarm Threshold

Set threshold of minimum safe contact distance - contact distance less than this threshold will trigger alarm

2

Precise Contact Distance Detection

Precise distance detection between people powered by 3D binocular stereo vision and deep learning algorithm.

1

Configuration Sample: Trigger alarm if contact distance <1m

System Topology

HCP Client Existing CCTV PoE Switch HCP Server

LAN

Audio Speaker (3rd Party)

Audio triggered by I/O signal on close contact distance alarm

I series NVR Dual Lens Camera DS-2CD6825G0/C-I(V)(S) Hikvision IP Speaker (Upcoming end of May)

OR

Deployment Topology

Please use special bracket with tilted viewing angle for contact distance detection Easy one-step calibration Calibrate ground area in the video to get precise contact distance detection Instant Alarm popup with video and audio linkage ① Installation height:2.5m - 6m ② Installation angle: 25° - 60 ° ③ Coverage (referencing): about

40m² with 3m installation height

SAFE DISTANCE UNSAFE DISTANCE

Mandatory tilt bracket: DS-2272ZJ-KL

SLIDE 10

One-stop Protection - DeepinMind NVR

One-stop protection with visualized interaction & advanced features for new and reuse project

3

 Convenient legacy system upgrade to get mask detection  Intuitive display of all information

1

Visualized notification of temperature screening and social distancing

3

Reuse Project for fast deployment and high cost-effective

2

Advanced Features

ONE-STOP Protection Highlight

 Identification with temperature record and demonstration  Quick search and export of evidence by various event filters and search modes. Index Name Normal Days Absent Days Temperature Status Mask 1 Jack 10 2 Abnormal Yes 2 Allen 10 1 Normal No  Attendance report with temperature and mask status

Application Scenarios …

Airport Enterprise Industrial Park

Reuse Project

① Flow Control ② Mask Detection ③ Facial AI Application

New Project

① Temperature Screening with identification ② Flow Control ③ Mask Detection ④ Facial AI Application

New Project

① Flow Control ② Mask Detection ③ Contact Distance ④ Facial AI Application

Multi-channel flow control, mask detection and facial AI capability

Blackbody Calibrator (optional) PoE Switch HCP Client

LAN

HCP Server （Optional） DeepinMind NVR

System Topology

Thermographic Camera Existing CCTV Flow Control / Contact Distance Camera Digital Signage

SLIDE 11

One-stop Protection - DeepinMind NVR

One-stop protection with visualized interaction & advanced features for new and reuse project

3

Business Flow Quick Search & Export of Evidence

Filter by abnormal temperature or no mask event type

1

Onsite Security

2 3

Intuitive Local Monitoring

Temperature and mask status

Instant & Interactive Alarm

Abnormal temperature or no mask

Onsite Monitoring, Alarm and Quick Evidencing by Deepinmind

DeepinMind NVR Thermographic Camera Flow Control / Contact Distance Camera

Multi-Sites/Devices Management via HCP

Site Manager

1

View Statistics & Records

Temperature statistics and records; Staff-only trends with report export

2

Attendance Management

Attendance Management and batch correction for people with abnormal temperature

DeepinMind NVR Thermographic Camera Flow Control / Contact Distance Camera HCP

SLIDE 12

Thermographic Bullet Camera

Application Scenarios

Station Airport Commercial Building …

Efficient Crowds Screening Solutions

Group screening and handheld free patrol for indoor open space with crowds

4-2

4

Highly Efficient 30 People Group Screening & Mask Detection

Group Detection

DS-2TD2636B-15/P DS-2TD2636B-13/P DS-2TD2637B-10/P

Temperature Screening on Patrol

Application Scenarios

Workshop Office Classroom …

4-1

• 1m-2m safe screening distance

Handheld Mobility and Safe Screening Distance

DS-2TP21B-6AVF/W

SLIDE 13

Efficient Crowds Screening - Temperature Screening on Patrol

Handheld Mobility and Safe Screening Distance

4-1

Temperature screening distance: 1m - 2m Continuous operation: 4 - 5 hours Manual double check by mercury thermometer, ear thermometer, etc.

• Thermal resolution: 160 × 120
• Optical video resolution: 640 × 480
• 2MP/ 5MP/ 8MP snapshot

DS-2TP21B-6AVF/W

Handheld Thermographic Camera

• 3.5’’ LCD touch screen
• Bi-spectrum image fusion
• Wi-Fi hotspot and Wi-Fi connection
• Abnormal temperature alarm

Deployment Topology Product Showcase

SLIDE 14

Efficient Crowds Screening- Thermographic Bullet Camera Highly Efficient 30 People Group Screening & Mask Detection

4-2

PoE Switch Blackbody Calibrator (optional) Tripod (optional) HCP Client Thermographic Bullet Camera Existing CCTV I series NVR

Ethernet

HCP Server (Centralized Management

• f Thermographic + Existing CCTV)

Real-time monitoring & alarm Distance between camera and blackbody: 5 m (15 mm thermal lens) 3 m (13 mm or 10mm thermal lens) Installation height: 2.5 m Distance between camera and people: 2.5–9 m (15 mm thermal lens) 2.5–7 m (13 mm thermal lens) 2-7 m (10 mm thermal lens) Wall-mount Manual double check by mercury thermometer, ear thermometer, etc.

Viewing statistics Records retrieval

1 2

Temperature statistics dashboard

Site Manager

Multi-site records available at center

Site management via HCP

Thermographic Bullet Camera I series NVR HCP

Deployment Topology System Topology Business Flow

Quick search & export of evidence Local monitoring

Bi-spectrum live view

Instant alarm popup

Alarm with audio, snapshot and video Filter by tag ‘Abnormal Temperature’

1

Onsite Security

2 3

Onsite Monitoring, Alarm and Quick Evidencing by NVR

Thermographic Bullet Camera I series NVR

SLIDE 15

Thermographic Camera Metal Detector Door

Application Scenarios

College Retail Hospitality Public Transportation … Residential

Fast Deployment Solutions

Simple installation for quick visitor inspection

5

5-1 5-2

Bi-spectrum Temperature Screening & Mask Detection, simple tripod installation Route-guiding, temperature screening, mask detection and metal detection with integrated sound & light alarm

DS-2TD2617B-3/6PA DS-2TD1217B-3/6PA ISD-SMG318LT-F

SLIDE 16

Fast Deployment- Thermographic Camera

Bi-spectrum Temperature Screening & Mask Detection

5-1

Fast Deployment- Metal Detector Door

Route-guiding, Temperature Screening, Mask Detection

and Metal Detection with Integrated Sound & Light Alarm

5-2

ISD-SMG318LT-F Metal Detector Door Blackbody Calibrator (optional) Tripod (optional) PoE Switch Blackbody Calibrator (optional) Tripod & Adaptor Thermographic Camera I series NVR (optional for video evidencing) Laptop with iVMS-4200

Camera- Personnel Distance: 0.8-1.5 m (3 mm lens) 1.5-3 m (6 mm lens) 1.5 m installation height Camera- Blackbody Calibrator Distance: 1 m (3 mm lens) 2 m (6 mm lens) Manual double check Blackbody shall be placed at upper left or upper right corner within the camera view. NVR optional for video evidencing Manual double-check Measurement distance: 0.8 m - 1.5 m Detection height between 1.45 m - 1.85 m Physical dimensions of the door: 2,200 mm x 850 mm x 480 mm Camera- Blackbody Calibrator Distance: 1 m Blackbody shall be placed at upper left or upper right corner within the camera view.

Deployment Topology System Topology Deployment Topology System Components

SLIDE 17

Situation Awareness Cross-site statistical reports of temperature, mask and employee status Remote Supervision Fast and convenient records retrieval for abnormal events

What We Bring

Corporate HQ Manager Site Manager Onsite Security

Solution Architecture

Evidence Retrieval Statistical Report Employee Status & Attendance

Flexible Product Choice for a Multitude of Scenarios Cross-device Site Management of Statistics and Evidencing Records Cross-site Central Management by remote supervision and statistics

Remote Supervision & Statistics

Industrial Applications by Hikvision or by third party

Detected results and abnormal events Health Status Statistics and abnormal events One-stop Protection Fast Deployment Employee Management Efficient Crowds Screening Social Distancing

Commercial Building, station, etc.

1 2 5

Store and public places

3 4

Residential, hospital, etc. Office, factory, etc. Temperature screening & social distancing all in 1 unit

SLIDE 18

Supervision Department-Group Co.

Data Fusion For Event Prediction & Prevention

3

…

Statistics Report for branches Remote Supervision (Abnormal event notification ) HQ Employee Status report (Attendance/Health status)

1

Corporate HQ HR

Corporate HQ

Statistics Review and Remote Supervision for Better Protection

2 3

SLIDE 19

Supervision Department-Group Co.

Data Fusion For Event Prediction & Prevention

3

Corporate HQ

View Overall Statistics and Manage Records via HCP

Cross-site Event Statistics and Records Retrieval Manual Info Register for a More Complete and Manageable Record

1 2

Multi-site Flow Control Status

4

Personnel Attendance Report, Statistics of Temperature and Mask Status

3

Abnormal Normal

SLIDE 20

Product Showcase

Temperature Screening

• Thermal: 384 × 288, 15 mm/13 mm/10 mm lens
• Optical: 2688 × 1520, 6mm/4mm lens
• Up to 30 people simultaneous screening
• Abnormal temperature and mask detection

DS-2TD2636B-15/P DS-2TD2636B-13/P DS-2TD2637B-10/P

Highly Efficient Group Screening Camera

• Thermal resolution: 160 × 120, Optical resolution: 640 × 480
• Wi-Fi supported, touch-screen operation

DS-2TP21B-6AVF/W

Flexible Handheld Patrol Accessories

• Blackbody Calibrator
• Tripod and adaptor

DS-2TE127-G4A

Social Distancing

• 4MP@30fps, ceiling mount or wall mount
• Bi-directional people counting
• Indoor flow control
• Built-in facial AI

iDS-2CD7146G0-IZS

Flow Control Camera with HD Video

DS-KC001

• Temperature screening, mask detection, facial access and attendance
• Abnormal temperature and mask detection, voice reminder on alarm

DS-K1T671TM-3XF

MinMoe Temperature Screening Terminal Indoor Station

DS-KAB671-B Floor Stand (Optional)

• 7-inch touch screen
• Wifi 802.11b/g/n supported
• Thermal: 160 × 120, 3 mm / 6 mm lens
• Optical: 2688 × 1520, 4 mm / 8 mm lens
• Abnormal temperature and mask Detection, onboard

audio alarm DS-2TD2617B-3/6PA DS-2TD1217B-3/6PA

Fast Deployable Thermographic Cameras

• 2,200 mm x 850 mm x 480 mm
• Thermal:160 x 120; optical: 2688 x 1520
• Abnormal temperature and mask detection, 7-inch LCD, onboard

audio and light alarm ISD-SMG318LT-F

Metal Detector Door with Thermographic Turret Camera

• 1920 × 1200 @ 30fps,
• Ceiling mount: Bi-directional people counting and flow control
• Tilted wall-mount with special bracket: contact distance detect

DS-2CD6825G0/C-I(V)S

Flow Control / Contact Distance Camera

DS-2272ZJ-KL Tilt-mount bracket for contact distance

IP Speaker

DS-PA0103-A DS-PA0103-B

• 32G MicroSD, 8Vms speaker output
• PoE, DC12V/1A, aluminum alloy shell, 0-55

Monitor Display

• 1080P, HDMI/VGA input, plastic casing, VESA, base bracket included, 7 x 24h

DS-D5024FC DS-D5032FC-A DS-D5043UC DS-D5024FN DS-D5032QE DS-D5043QE Models with build-in speaker:

• 4K output, flexible program schedule
• Concurrent display of flow control, media info,

temperature and mask status

• Optional mask and temperature info

Digital Signage / Digital Signage Box

DS-D60C-B Digital Signage Box DS-D60xx Digital Signage

• 43’’/ 55’’ vertitcal/ horizontal 1080p display

DS-D6043FN-B(/S) DS-D6055FN-B(/S) DS-D6055UN-B

Storage, Management & Networking

• 16-ch IP video, 160 Mbps incoming bandwidth
• 16ch 1080p synchronize playback
• 4 SATA, 16/4 Alarm I/O, 1.5U case,19“
• 2 HDMI, 1 VGA

DS-7716NI-I4(B)

I-Series NVR

iDS-7716(/32)NXI-I4/(16P)/X(B)(STD)(T) iDS-9616(/32)NXI-I8/X(B)(STD)(T)

• Up to 8ch/ 16ch facial recognition;
• 32 library capacity with up to 100,000 face

pictures in total.

• Multi-channel mask detection and density control

DeepinMind NVR

• Lightweight deployment on i5, 16GB RAM
• Unified temperature, alarm and video management
• Statistical report and easy records retrieval for abnormal

events

HikCentral Professional

• L2 unmanaged, 10/100M RJ45 PoE
• 1x 10/100M RJ45 uplink port
• 802.3af/at, PoE power budget.
• 300m long distance transmission
• 6KV surge protection

DS-3E0105P-E(B) DS-3E0109P-E(C)

POE switch

SLIDE 21

Thanks

See far, go further
