Our pillar– High technology at competitive price!

Monitor ltd. is one of the leading companies in Russia in the field of medical equipment production. It was founded on February 14, 1992 Address: 344068, Russia, Rostov-on-Don, str. Krasnokursantskaya, 104A. Tel/Fax +7 (863) 243-61-11, 231-04-01, 243-63-77 e-mail: mon@monitor-ltd.ru www.monitor-ltd.ru Our activities: Developing and manufacturing of the diagnostic medical equipment:

• diagnostic patient monitors, central monitoring stations;
• ECG machines, stress-test systems and graphic spirometers.

Our activities: Developing and manufacturing of the diagnostic medical equipment. Our activity is the production of diagnostic patient monitors, 1/3 and 3/4/6/12 channel ECG machines and graphic spirometers. There are many thousands medical devices produced by our company in use all over the world: on the whole territory of Russia, in Europe, Asia and Latin America. All our products are tested in the leading hospitals; scientific, research and medical institutes of Russia. Our company has an a certificate of quality management system in accordance with ISO 13485:2003 for the following scope: Design, development, manufacture, maintenance, sales and distribution of patient monitoring equipment, ECG equipment and spiromerets.

Our main contracts for the last years:

• We have supplied 3408 pcs. monitors MITAR 01-"R-D" and 6120 pcs. ECG

Machines on the program of modernization of health of Russian Federation.

• We have supplied 3164 pcs. 1/3 channel ECG machines EC3T- “R-D” and

about 600 pcs. monitor MITAR 01-"R-D" for ambulances under national project of Russian government “Health”.

• In 2000-2009 years we have supplied about 2000 pcs. ECG machines For

Military Ministry of Russia.

• In 2006-2012 the regular supplies of ECG Machines and patient monitors
• n government projects in Uzbekistan, Turkey, Indonesia and others.
• In 2009 we have equipped cardiovascular and prenatal medical centers

and supplied our health evaluation complexes for the national wellness program.

• Export is about 20%

Our Office Director general (CEO)

• Dr. Youri B. POPOV

Sales department

MISSION OF COMPANY To carry out development, production, realization and introduction in practice the competitive methods and technologies for diagnostics and monitoring of person’s health level, allowing to provide the most effective treatment and health preservation as it is possible for lager number of people around the world.

Company has Europeans certificates:

Quality Policy

The company has determined as a basic activity in quality policy the permanent growth of quality effectiveness, medical equipment quality by using the achievements of science and technologies meeting the requirements of the European Instruction Directive 93/42 EES and medical low of Russian Federation .

The major purposes in the field of quality:

• Improvement the company’s economic position by upgrading the quality of products and arising

volumes of sales;

• Optimization of pricing and expansion the Russian and foreign markets;
• Improvement the product’s quality by using quality system ISO13485;
• Expansion to the markets of the counties requested CE mark availability;
• Improvement the products quality to the level of Europe producers;
• Satisfaction the requirements of all kind of consumers : from the doctor of private medicine to the

leading medical centers of the country.

• Systematic carrying out the new developments for the purpose of product range expansion.

Our partner – company Covidien is part of the local fabric of the communities which

• perating around the world. Company success is made possible through the dedication
• f 41,000 employees, nearly two-thirds of whom work in 53 manufacturing facilities

located in 16 countries. Every day, over 5,000 Covidien sales representatives meet the needs of customers in more than 65 countries. In all, Company derives over 45% of its sales from outside the United States. Over the years, Covidien have pioneered a number of medical advances, including contrast media delivery, pulse oximetry, electrosurgery, surgical stapling, laparoscopic instrumentation and embolization devices. This extensive product line, spanning medical devices, pharmaceuticals and medical supplies, enables to serve healthcare needs in hospitals, long-term care and alternate care facilities, doctors’ offices, pharmacies and in the home. Our company use the following production of Covidien:

• BIS modules for measurement the anesthesia level

Our partner – company Masimo Sweden AB (Phasein) develops, markets and manufactures ultra-compact mainstream and sidestream multigas analyzers, which can be integrated into patient monitors, anesthesia delivery systems and ventilators. Masimo Sweden AB’s products shall be available as stand-alone “plug-in and measure” analyzers and as easy to integrate build-in modules. Masimo Sweden AB ’s products shall be designed using the latest advances in component and microprocessor technology for optimal convenience, mobility and ease of integration. PHASEIN’s vision is to become the partner of choice for those requiring a mobile and flexible solution for measuring respiratory gases in any clinical application. Our company use the following production of Masimo Sweden AB :

• Mainstream and sidestream gas analyzers

Our partner – company Vitalograph Ltd. was founded in 1963, building on a successful business in respiratory diagnostic and therapeutic products started in 1951. Vitalograph achieved its early success by taking spirometry from a complex laboratory test to a simple effective screening procedure - with the key benefit of providing early detection, and therefore more effective treatment. Vitalograph designs, manufactures and markets respiratory diagnostic and therapeutic products and is recognised world wide for excellent lung function testing equipment and related services. Vitalograph is represented in 113 countries through Authorised Distributors who are trained to provide a high standard of product sales and support, with ready back up when needed from the UK. Our company use the following production of Vitalograph Ltd:

• The flow sensor for digital spirometer SMP21/01-”R-D”

Our partner – company TreyMed was incorporated in 1996 with the mission to design and manufacture intelligent and affordable respiratory monitoring sensors and

• devices. TreyMed has designed its own proprietary, patented sensor systems which

are available as OEM components, and offer complete monitors which utilize these

• sensors. TreyMed manufactures sensors for two basic areas of respiratory care: gas

analysis and airway flow/pressure. From these basic measurements, many parameters related to a patient's cardiovascular and respiratory health can be calculated. TreyMed has grown to become a leading supplier of respiratory care products around the world. Company successfully competes for OEM business by providing excellent quality products at lower cost with faster technical support and service. Our company use the following production of TreyMed :

• CO2 sensors

Our partner – company Shenzhen Med-link Electronics Tech Co.,Ltd works in the field

• f professional development, production and marketing of medical equipment,

accessories and supplies. Products widely used in monitoring, oximetry, ECG, Holter ECG, EEG, a B-ultrasonic fetal supervisor equipment, complete product specifications, and compatible with the majority

• f

imported and domestic models. Products based on the latest international standard production with non-toxic, durable, comfortable and interference characteristics, and has made well-known professional certification of CE, SFDA certification. Long, the company focus on the introduction of professionals and training, has formed a research and development, management, manufacturing of high-quality and professional team that will enable us to meet or exceed customer requirements. Best- selling products in the CE, FDA, the SFDA market within the region, agents around the world nearly 60 countries. Our company use the following production of Med-link Electronics Tech Co.,Ltd:

• SPO2 and Temperature Sensors, extension cables, disposable BP cuffs

Our partner – company B Braun supplies the global healthcare market with products for anesthesia, intensive medicine, cardiology, extra corporeal blood treatment and surgery, as well as services for hospitals, general practitioners and the homecare sector. Through dialogue with those who are using B. Braun's products on a daily basis, the company is continually gaining new knowledge which it incorporates into product

• development. In this way, the company contributes with innovative products and

services towards optimizing working procedures in hospitals and medical practices all

• ver the world and improving safety – for patients, doctors and nursing staff.

With approximately 44,000 employees in more than 50 countries, B. Braun achieved a turnover in 2011 of 4.6 billion Euros. Our company use the following production of B Braun :

• thermodilution catheters;
• thermosensors;
• devices for invasive monitoring;
• devices for infusion flows.

Our partner – company BD is a medical technology company that serves healthcare institutions, life science researchers, clinical laboratories, industry and the general

• public. BD manufactures and sells a broad range of medical supplies, devices,

laboratory equipment and diagnostic products. BD is headquartered in the United States and has offices in more than 50 countries worldwide. BD Medical is among the world's leading suppliers of medical devices and a leading innovator in injection- and infusion-based drug delivery since 1906, when the Company built the first-ever facility in the U.S. to manufacture needles and syringes. The BD Medical segment is focused on providing innovative solutions to reduce the spread of infection, enhance diabetes treatment and advance drug delivery. Our company use the following production of B Braun :

• thermodilution catheters;
• thermosensors;
• kits for cardiac output measuring.

Our partner – Fujitsu is the leading Japanese information and communication technology (ICT) company offering a full range of technology products, solutions and

• services. Over 170,000 Fujitsu people support customers in more than 100 countries.

Fujitsu uses experience and the power of ICT to shape the future of society with the

• customers. Fujitsu Limited (TSE:6702) reported consolidated revenues of 4.5 trillion yen

(US$54 billion) for the fiscal year ended March 31, 2012. Fujitsu uses field Innovation to find new approaches and the inspiration to improve

• urselves, while delivering added value to the customers, provides global

environmental solutions in all business areas and works together to accelerate global business expansion. Our company use the following production of Fujitsu:

• thermoprinters for ECG machines.

It is equipped with the 3-4- 6-12 ECG channels colored TFT display with LED backlight

ECG Machine EC12T-01-”R-D” with colored display

• ECG Machine provides

patient’s ECG measurement in the system of twelve common used leads, Cabrera and Frank leads, Nebh 3 leads,

Main features:

• TFT display allows watching 3 ,4, 6 or 12

ECG leads simultaneously and print them in the same scale on thermal printer;

• Possibility of remote receiving and

conducting ECG analyze using GSM module and the Internet.

• “ECG Analysis” Mode;
• Full syndromal diagnostics (271 reports);
• Possibility to print 12 ECG leads and ECG

protocol on external laser printer;

• Trials mode - observation period up to 3

hours, printing interval from 1 to 90 min;

• Possibility to record ECG in manual mode

with any electrodes number;

• “Hot” keys for the quick access to

important functions;

• Alphanumeric keyboard;
• Set up of parameters for every user (10

define user profiles).

One of the main features of EC12T is the availability of “HOT” keys for quick access to important functions and easy-to-use knob

There is a possibility from the MAIN MENU to set up all important characteristics

There is a possibility of automatic ECG cable quality control

You can print ECG leads on thermal printer in the same scale as they are reflecting on LCD display Simultaneous recording

• f 3 ECG leads on Z-fold

thermal paper

You can print ECG leads on thermal printer in the same scale as they are reflecting on LCD display Simultaneous recording

• f 3 ECG leads

+1 rhythm lead on roll thermal paper

You can print ECG leads on thermal printer in the same scale as they are reflecting on LCD display Simultaneous recording

• f 6 ECG leads
• n Z-fold thermal

paper

You can print ECG leads on thermal printer in the same scale as they are reflecting on LCD display Simultaneous recording

• f 6 ECG leads
• n roll thermal paper

There is an automatic rhythm printing on arrhythmia One lead rhythm printing with sweep speed 5 mm/sec.

There is an automatic rhythm printing on arrhythmia Three leads rhythm printing with sweep speed 10 mm/sec.

In EC12T there is a possibility to connect external memory (Flash card), external keyboard and laser printer for simultaneous printing of 12 leads on A4 paper format via USB-А port. Internal flash memory allows to use EC12T in bed wards without ECG printing and then via internal flash memory transfer the data to PC for the analysis and

• archiving. It allows to use several ECG machines with one PC.

Wireless data transfer via bluetooth serial adapter to PC.

Demountable maintainable ECG cable for ECG machine EC12T-01-”R-D”

ECG printout to the external laser printer with simultaneous printing of 12 ECG leads on the A4 format paper

Examination report printout to the external laser printer on the A4 format paper

Calculating and printing of rhythmogram, histogram and scattergram.

ECG Machine EC12T-01-”R-D” with 63 mm TFT display

• ECG Machine provides patient’s

ECG measurement in the system of twelve common used leads, Cabrera and Frank leads, Nebh 3 leads;

• LCD display allows to watch any of

12 ECG leads;

• ECG Analysis Mode;
• RR gram mode;
• Possibility to work as a part of

stress-test system;

• Internal memory with possibility of

ECG fragments printing.

• Possibility to work with different

groups of patients (adult, children).

Features of ECG Machine EC12T-01 – “R-D”

• Simultaneous printing of 3, 4, 6 ECG

leads along and 12 ECG leads across the paper;

• Possibility to set up half amplification for

chest leads;

• Registration of average ECG complex

with peak marks;

• Paper speed 10, 25 and 50 mm/sec;
• Trials mode - observation period up to 3

hours, printing interval from 1 to 90 min;

• RR gram printing up to 10 hours;
• Automatic start if arrhythmia emerge;
• Printing the reports about electrical axis
• f heart position, ST segment deviation,

amplitude-time characteristics of QRS complexes;

• Automatic ECG characteristic

measurement on every ECG lead;

• Weight not more than 2 kg.

ECG Machine EC12T-01-“R-D” with software it is unique combination of technical features of ordinary and computer ECG Machines

Software provides the following functions:

• Registration into PC memory and reflecting
• n PC screen standard ECG signals;
• Forming and managing the archives of ECG

signals;

• Forming the averaged P-QRS-T complexes;
• Measurement of amplitude-to-time

characteristics of ECG intervals and peaks;

• Calculation of standard ECG characteristics;
• Sindromal interpretation of ECG pathologic

changes with preliminary diagnosis;

• Possibility to edit the medical report.

USAGE:

• Electrocardio

diagnosis;

• Intensive care units;
• Ambulance;
• Private physicians

ECG Machine EC3T-01-”R-D”

EC3T is designed to register and measure heart bioelectric potentials for electrocardiographic examinations. EC3T is designed to be used in functional diagnostics offices (ECG offices) of out-patient clinics, hospitals, coronary care units and critical care units of hospitals, as well as in emergency cars and other medical establishments.

Features of ECG Machine EC12T-01 – “R-D”

• Simultaneous printing of 1, 2, 3 ECG

leads;

• Possibility to set up half amplification for

chest leads;

• Registration of average ECG complex

with peak marks;

• LCD display allows to watch ECG curve;
• Paper speed 10, 25 and 50 mm/sec;
• Trials mode - observation period up to 3

hours, printing interval from 1 to 90 min;

• RR gram printing up to 10 hours;
• Automatic start if arrhythmia emerge;
• Printing the reports about electrical axis
• f heart position, ST segment deviation,

amplitude-time characteristics of QRS complexes;

• Automatic ECG characteristic

measurement on every ECG lead;

• Weight not more than 2 kg.

Interactive system of ECG data transfer via e-mail:

• Scientific and technical progress in the field of computer

technology and the Internet allows to refuse from system of ECG transfer by a phone in favor of Internet use;

• Introduction of similar system not only at the all-Russian and

regional level, but also at the level of the rural medical assistant's and obstetric centers will allow to provide ECG recording and receiving by e-mail the qualified medical conclusions;

• There is no need of patients and specialists to go to the

district center to record ECG;

• Compatible for each point of system and affordable software

will allow to make ECG analysis in any point of a system;

• You can choose any of ECG machines produced by Monitor

LTD;

• Possibility to use laptop or PC;
• Choose dimensions, the prices and possibilities!

Possibility to use ECG machine EC12T in the stress-test system

Trademeal Valiant (Lode) Bicycle ergometer Corival

Window of ECG stress test (Report)

Window of Monitor ECG stress test .

System of vacuum electrodes to use during stress tests Applicard 2.0.

ECG Machines produced by Monitor LTD are used in ambulances

Digital spirometer SMP/21-01-”R-D” 36 parameters of pulmonary ventilation on expiration and inspiration and making a spirometry results report.

• Test of VC and forced expiration
• “Maximal flow-volume loop” test
• Test of minute tidal volume
• Test of maximal voluntary

ventilation

• Post medication test

Digital spirometer SMP/21-01-”R-D”

Purpose of use:

State of lungs diagnosis; State of lungs monitoring; Population's health evaluation while carrying out the mass examination.

Digital spirometer SMP/21-01-”R-D” provides the following functions:

• Measuring of 4 VC parameters, 19 FVC parameters, 26 “flow-volume loop” parameters, 7 MTV parameters and 3 MVV

parameters;

• Predicted values calculation for lung volumes and peak expiratory flow characteristics for adult and children on

Klement/Shiryaeva, ITS, ECCS, KNUDSO N standards;

• Evaluation of parameters on Russian and ATS methods;
• Dispaying measurement results on colored TFT display;
• Printing a spirometry results report on built in thermoprinter;
• Printing a spirometry results report via USB port on external laser printer;
• Post medication test;
• Work from built in battery;
• Keeping patient data in memory;
• Possibility to use the device both in stationary and in ambulatory conditions.
• Easy knob to operate the device

Test of Maximal voluntary ventilation (MVV)

Test “flow-volume loop”

Test of VC and forced expiration

In spirometer SMP21/01-”R-D” Vitalograph airflow sensor is used

Monitor MITAR 01-”R-D”

with colored display 10,4” 16 kinds of models depending on measurement characteristics

Three in one: Stationary, portable, mobile USAGE: Intensive care units of hospitals and ambulances

Monitor MITAR 01-”R-D” with colored display 12,1

• ECG and HR
• Respiration
• SpO2 and Photoplethysmogram
• NIBP and up to 4 channels of IBP
• 2 channels of Temperature
• СО2 and Capnogram
• Cardiac Output
• Multigas
• BIS

16 kinds of models depending on measurement characteristics

Monitor MITAR 01-”R-D” in the anesthesiology and resuscitation department

Three in one:

Stationary

( 10,4 or 12,1” display)

Portable

(ergonomic hand grip and battery power supply)

Mobile

(automobile constant power supply, easy fits on a standard hospital bed-rail)

Number of graphic channels from 2 to 9

Touch screen or easy knob to operate

• ECG 3 leads;
• ECG 7,8 or 12 leads (option)
• HR by impedance,

capnographic or thermistor methods;

Combining of possibility to use up to 10 standard forms with possibility of their individual setup (number of simultaneous reflecting channels from 1 to 9, trends, alarm limits and modules configuration)

Possibility of reflecting vital functions near the short trends and possibility to freeze all curves or 2/3 of the display

Possibility of reflecting graphic or tabular trends in any graphic zone Possibility of bed-to-bed preview Possibility of wired and wireless (WiFi) connection of monitors and the central monitoring station

Oxycardiorespirogramm

• Simultaneous reflecting
• f 12 ECG leads with 10

electrode cable;

• Possibility of synthesis of

12 ECG leads with 5 electrode cable;

• Oxycardiorespirogramm

MULTI -GAS monitoring using IRMA probe (PHASEIN) Et CO2 и Ins CO2, Et O2 и Ins O2, V2O, HAL, ISO, SEV, DES, ENF

Touch screen or easy to operate knob

Ergonomic hand grip

Possibility of printing any vital function (up to 3 channels), digital data and trends on built in thermo printer with print width 57 mm,

Big digits mode

• During working with IRMA

CO2 probe in that mode the concentration of monitoring gases is reflecting on the display

• Full recording of

monitoring information on SD card

Possibility to replicate the information on VGA display

Accessories and cables Possibility of measuring NIBP in manual and automatic modes and automatic switch on of NIBP measurement if PWTT range is exceeded

MENU «PATIENT»

• Possibility to data
• utput to central

monitoring station;

• Possibility to switch
• ff unusable modules
• Drugs calculators,

haemodynamics,

• xygenation,

ventilation and renal function

SpO2 accessories used in monitor MITAR-01-”R-D”:

• Pediatric silicone soft

sensor;

• Pediatric and adult finger

clip sensor;

• Adult silicone soft sensor;
• Disposable neonatal

silicone soft sensor

Temperature accessories used in monitor MITAR- 01-”R-D”:

• Adult reusable Skin-Surface

Temp Probe;

• Children reusable Skin-Surface

Temp Probe;

• Adult reusable

Esophageal/Rectal Temp Probe;

• Children reusable

Esophageal/Rectal Temp Probe.

Monitor MITAR-01-”R-D” delivery set may contain 3,5, 6 or 10 leads ECG cables 6 leads ECG cables 10 leads ECG cables

There is a possibility to use BIS technology in monitor Mitar-01-”R-D”. BIS technology can help clarify the distinction between brain and spinal cord responses, enabling clinicians to manage anesthetic goals of hypnosis, analgesia and immobility. · Because BIS technology measures electrical activity in the brain, it provides a direct correlation with depth of consciousness (hypnosis). · BIS technology enables you to assess consciousness and sedation independent of cardiovascular reactivity. How BIS Technology Works: · Raw EEG data are obtained through a sensor placed on the patient’s forehead. · The BIS™ system processes the EEG information and calculates a number between 0 and 100 that provides a direct measure of the patient’s level of consciousness. · A BIS™ monitoring value of 100 indicates the patient is fully awake. · A BIS monitoring value of 0 indicates the absence

• f brain activity.

• Possibility to use monitor

MITAR-01-”R-D” in ambulances;

• In automobile constant power

supply 12V.
