SynBio Is Expensive iGEM is great. Brings synthetic biology to the masses. But its really expensive. Enzymes, Digestions, Ligations Equipment - Thermocycler, Incubator, Centrifuge Minipreps, Gels,etc Want to help other teams as well! We

slide-1
SLIDE 1
slide-2
SLIDE 2

SynBio Is Expensive

iGEM is great. Brings synthetic biology to the masses. But it’s really expensive. Enzymes, Digestions, Ligations Equipment - Thermocycler, Incubator, Centrifuge Minipreps, Gels,etc Want to help other teams as well! We decided to look at DIY approaches to synthetic biology to make iGEM accessible.

slide-3
SLIDE 3

DIY Cost Comparison

Protocol # Price Transformations 4 $8.25 Plating 4 $0.71 Overnights 4 $0.15 Digests 4 $0.80 Ligations 1 $6.40 Minipreps 4 $1.74 Gels 2 $2.70

slide-4
SLIDE 4

Safety

Emerging new field of biotechnology - a new hope, a new worry… Our Project:

  • Creating the tools
  • Bottleneck to control access

to dangerous DNA

www.sechintower.com

slide-5
SLIDE 5

The Plan

Recycling Methods:

  • Minicolumns
  • Gels

DIY Methods:

  • Minicolumns
  • Enzyme Purification

○ RTX & ELP ○ Gel Purification

  • Enzymes

○ EcoRI, M.EcoRI

blogs.nature.com

slide-6
SLIDE 6

DIY Cost Comparison

Protocol # Price Transformations 4 $8.25 Plating 4 $0.71 Overnights 4 $0.15 Digests 4 $0.80 Ligations 1 $6.40 Minipreps 4 $1.74 Gels 2 $2.70

slide-7
SLIDE 7

DIY - Homemade Minipreps

  • DIY Buffers
  • Minicolumn Recycling
slide-8
SLIDE 8

DIY Buffers

  • Homemade Buffer Efficiency

❖ Increased overall efficiency from ~50% to ~60%

Yield Efficiency QIAprep Spin Miniprep Kit 219.6 ng/uL

  • Re-suspension Buffer Only

189.1 ng/uL 86% Lysis Buffer Only 221.5 ng/uL 101 % Neutralization Buffer Only 102.8 ng/uL 47% Binding Wash Only 240.2 ng/uL 109 % Column Wash Only 239.5 ng/uL 109%

Klenchin (2010).

slide-9
SLIDE 9

Minicolumn Recycling

Yield New Minicolumn 175.8 ng/uL Recycled Minicolumn 178.7 ng/uL

100% Efficiency 0% Carryover

Nagadenahalli B. Siddappa. et.al. (2007).

slide-10
SLIDE 10

DIY Minicolumns & Gel Recycling

slide-11
SLIDE 11

DIY Enzymes

Protocol # Price Transformations 4 $8.25 Plating 4 $0.71 Overnights 4 $0.15 Digests 4 $0.80 Ligations 1 $6.40 Minipreps 4 $1.74 Gels 2 $2.70

slide-12
SLIDE 12

ELP (Elastin Like Protein)

  • Oligomeric repeats of Val-Pro-Gly-Xaa-Gly
  • Fused at ends of proteins and precipitates at elevated

temperatures and increased concentrations of NaCl.

Meyer (1999)

slide-13
SLIDE 13

RTX (Repeats in Toxin)

  • Polypeptide repeats
  • Undergoes conformational change upon binding to

Calcium which causes them to precipitate.

  • We submitted an RTX to the registry in freighburg

format. BBa_K1188002

Shur (2013)

slide-14
SLIDE 14

RTX Characterization

  • Fused RTX to GFP
  • Grew in culture
  • Lysed cells
  • Treated lysed cells

with various CaCl

  • Results show 10mM

concentrations of Ca are effective in precipitating tag when attached to GFP

0 mM 0.1mM 1 mM 10 mM 100 mM Cell Lys

slide-15
SLIDE 15

RTX

slide-16
SLIDE 16

Gel Purification with Color Tags

  • Agarose Gel
  • AmilCP and RFP
  • Quick
  • Easy to do
  • High purity
  • Decent yields
  • Utilizes only common lab

materials

slide-17
SLIDE 17

Characterization

slide-18
SLIDE 18

Results of Separation

20% Yield 34% Yield

slide-19
SLIDE 19

The Plan

ChlorR E X P

J23100 B0034

EcoRI S AmpR E X P

J23100 B0034

M. EcoRI S

slide-20
SLIDE 20

Making the Plasmids

  • Origin of sequence:

REBASE

▫ Codon optimized

  • Process

▫ Gibson Assembly ▫ PCR ▫ Digestion/ Ligation

slide-21
SLIDE 21

Unfortunately...

AmpR E X S P

J23100

B0034

ChlorR E X S P

J23100

B0034

M. EcoRI

X P S EcoRI X P S

slide-22
SLIDE 22

Summary

Protocol # Price Transformations 4 $8.25 Plating 4 $0.71 Overnights 4 $0.15 Digests 4 $0.80 Ligations 1 $6.40 Minipreps 4 $1.74 Gels 2 $2.70

slide-23
SLIDE 23

Outreach

High School Curriculum

  • HS science labs can range thousands per year
  • Key curriculum involves gel electrophoresis,

restriction digestion, ect.

  • Future iGEMers in peril!

How can DIY bio help?

slide-24
SLIDE 24

Outreach (cont.)

The iGEM Experience:Creating DIY, safe, low-cost biology for the mass through kits.

Transformation (Chemical) DNA Chemically Competent Cells Antibiotics Digestion Enzymes: E, P, X (DIY) 10x NEBuffer 2.1 DNA Gel Electrophoresis DNA Loading Dye DNA Ladder Agarose powder (Recycle) Sybr Safe

slide-25
SLIDE 25

Concluding Notes

Excerpt from “Biopunk, DIY Scientists Hack the Software of Life”:

"We reject the popular perception that science is only done in million-dollar University, government, or corporate labs; we assert that the right of freedom

  • f inquiry, to do research and pursue

understanding under one's own direction, is as fundamental a right as that of free speech or freedom of religion."

slide-26
SLIDE 26

Thanks to Our Sponsors!!

slide-27
SLIDE 27

Questions?
