High-level Introduction to MTG Ground Segment Workshop on NWC Applications using MTG-IRS Fausto Roveda MTG Data Processing System Facility Manager EUM/MTG/VWG/13/715994 Slide: 1 25 July 2013 Summary of the Presentation Ground Segment

slide-1
SLIDE 1

EUM/MTG/VWG/13/715994 25 July 2013

High-level Introduction to MTG Ground Segment

Workshop on NWC Applications using MTG-IRS Fausto Roveda MTG Data Processing System Facility Manager

Slide: 1

slide-2
SLIDE 2

EUM/MTG/VWG/13/715994 25 July 2013

Summary of the Presentation

  • Ground Segment Overview
  • Payload Data Processing Systems
  • Multi-Mission Elements
  • Ground Segment T

echnical Challenges

  • Availability and Timeliness;
  • Data rates and Volumes;
  • Estimated Computational Needs;
  • Status of Facility Procurements

Slide: 2

slide-3
SLIDE 3

EUM/MTG/VWG/13/715994 25 July 2013

The MTG System

Slide: 3

Launch and LEOP Service Space Segment Ground Segment

slide-4
SLIDE 4

EUM/MTG/VWG/13/715994 25 July 2013

MTG Ground Segment Context

Slide: 4

EUMETSAT Headquarter Dissemination Ground Stations Mission Operation Data Processing Archive and Retrieval SAF Network

MTG GS Major Components:

  • Ground Stations Facilities (TTCF,

MDAF)

  • Mission Operation Facility (MOF)
  • Data Processing Facilities (IDPF,

L2PF)

  • Multi-Mission Elements (MMEs)

Note: “Facility” = hardware + software

slide-5
SLIDE 5

EUM/MTG/VWG/13/715994 25 July 2013

MTG Payload Data Processing Systems

Slide: 5 On-Line Environments Off-line Environments (Analysis & Reporting, Developoment)

Raw Data

Instrument Data Processing Facility (Level-1) Level-2 Processing Facility Data Centre Data Dissemination Off-line Buffer Reprocessing (L1 and L2)

slide-6
SLIDE 6

EUM/MTG/VWG/13/715994 25 July 2013

On-Line Environments

Slide: 6

On-Line Environments

Raw Data

Instrument Data Processing Facility (Level-1) Level-2 Processing Facility OPE VAL IV&V OPE VAL IV&V

slide-7
SLIDE 7

EUM/MTG/VWG/13/715994 25 July 2013

Instrument Data Processing Facility (IDPF)

The IDPF receives raw instrument data and performs:

  • Science data extraction and chunking (for parallel processing);
  • Radiometric and spectral calibration;
  • Geometric rectification to a reference grid (FCI only);
  • Image Navigation and Registration;
  • Aggregation of chunks and formatting into output file.
  • It provides also capabilities for Algorithm Development,

Fast Scientific Validation and Reprocessing (at least 5 times faster than near-real-time processing).

Slide: 7

slide-8
SLIDE 8

EUM/MTG/VWG/13/715994 25 July 2013

Level 2 Processing Facility (L2PF)

  • The L2PF generates meteorological products from the Level-1 data

produced by the IDPF .

  • Flexibility and simplicity to include new products are key features of

EUMETSAT level 2 processing

  • Contract(s) will foresee the capability to add in additional products,

potentially developed in house by EUMETSAT (including products developed by Satellite Application Facilities)

  • Flexibility is also considered for the evolutions of existing products

during the development of the L2 Facility

  • It provides also capabilities for Algorithm Development,

Fast Scientific Validation and Reprocessing.

Slide: 8

slide-9
SLIDE 9

EUM/MTG/VWG/13/715994 25 July 2013

Multi Mission Elements (MMEs)

What are the Multi-Mission Elements ?

  • Elements currently used in several Operational Programmes or evolution of them, and can be re-used for future

programmes, in particular for the MTG Ground Segment.

  • These are identified as Multi-Mission Elements (MME)

The main reasons for considering re-use are:

  • Reduced development risks and costs
  • Reduce long-term maintenance costs
  • Consistency towards end users
  • Easier, homogeneous operations
slide-10
SLIDE 10

EUM/MTG/VWG/13/715994 25 July 2013

The MMEs provide the following functions for MTG

Slide: 10

§

Data Archive (MME DAC)

  • long term archival and retrieval of MTG mission data
  • user support and helpdesk services, including service registration

§

Dissemination (MME DIS)

  • dissemination of data to end users via EUMETCast, RMDCN/GTS and Internet
  • presentation of data via Internet (rolling archive, image generation)
  • ingestion of data from external parties into the GS
  • master and session keys for TC authentication and payload data encryption

§

Monitoring (MME MON)

  • analysis and reporting (including science and long term trend analysis)
  • centralised monitoring capabilities for the whole MTG ground segment
  • end-to-end production, service status, hardware, remote spacecraft telemetry

§

Infrastructure (MME INF)

  • network connectivity to/from the MMEs and inter-building
  • internet, RMDCN/GTS lines and network security
  • time reference, voice loop and data protection services
slide-11
SLIDE 11

EUM/MTG/VWG/13/715994 25 July 2013

Ground Segment Technical Challenges

Slide: 11

slide-12
SLIDE 12

EUM/MTG/VWG/13/715994 25 July 2013

MTG Operational Availability

Major contributing components of the Ground Segment Operational Availability are: Completeness; Accuracy; Timeliness

Note:

  • As opposed to Space Segment, any Ground Segment outage, planned or unplanned,

contributes negatively to the operational availability;

  • Any systematic loss of quality introduced due to data formatting or compression in
  • rder to comply with the agreed format specifications does not contribute to
  • perational availability of the ground segment.

Slide: 12

datasets received and that meet the quality thresholds datasets scheduled to have been sent or made available

*For a given period and removing the part corresponding to the scheduled outages and the external outages

slide-13
SLIDE 13

EUM/MTG/VWG/13/715994 25 July 2013

MTG Timeliness

It excludes:

  • delay introduced by transmission lines and networks outside EUMETSAT control

(e.g. Internet, GTS).

  • the processing time outside EUMETSAT control (e.g. SAF processing time).

Slide: 13

Time difference The foreseen end of acquisition of the last contributing data

*from a sample, a dwell, a swath, a granule

The end of reception

  • f the corresponding

data by the users

*before decryption and decompression

slide-14
SLIDE 14

EUM/MTG/VWG/13/715994 25 July 2013

GS Architectural Design Allocation of Key Parameters

Examples:

L1 processing chain timeliness Availability apportionment

Satellite MDA L1 Proc L2 Proc Dissemination End User System End-to-End [SRD] : 98% System Level Segment Level Space : 99% (incl S-G Link & L1 algorithm) Ground : 99% (excludes L1 algorithm) GS Facility Level Dissemination L2 L1 ( - alg) MDA 99.5% 99.8% 99.8% 99.97%

L1 Processing

EUMETCast/HR Dissemination Internet Download

T4 T2 T0

Ground End-to-End (GSRD)

MDA Station (incl. WAN)

IDPF MME Diss. MME Diss.

T3 T1

MDA (& WAN)

slide-15
SLIDE 15

EUM/MTG/VWG/13/715994 25 July 2013

EUMETCast Availability and Timeliness

Slide: 15 Disseminated datasets GS oper. availabili ty Accounting Unit Timeliness via EUMETCast Level 1 Datasets Full Disc Scanning Service (FCI-FDSS) 99% Repeat Cycle 450 sec. Rapid Scanning Service (FCI-RSS) 99% Repeat Cycle 280 sec IR Sounder dataset 99% Repeat Cycle 1600 sec UVN sounding dataset 99% Repeat Cycle 2720 sec (6320 sec for day 2 Level 2 products) DCP messages and DCP bulletins Alert messages 99% Message 115 sec DCP Bulletins 99% 10 min group 295 sec FCI Level 2 Products >=Daily products 99% Product 60 min >=3-hourly products 99% Product 60 min >=Hourly products 99% Product 30 min < hourly 99% Product 20 min IRS Level 2 Products > 3 hourly 99% Product 120 min >= hourly & =< 3 hourly 99% Product 90 min < hourly 99% Product 60 min LI Level 2 Products Lightning Flash dataset 99% Flash 25 sec Retransmission

  • f

SAF Products

slide-16
SLIDE 16

EUM/MTG/VWG/13/715994 25 July 2013

Availability and Timeliness - others

Slide: 16

RMDCN disseminated datasets GS oper. availabilit y Accounting Unit Timeliness

Level 1 datasets 99% Repeat Cycle 60 min Level 2 datasets 99% Product 60 min DCP bulletins 99% Message 60 min Service Messages 99% Message 60 min

Archived data GS oper. Availabilit y Accounting Unit Retrieval ready after

Level 0 data 99.99% Product N/A Level 1 datasets 99.95% Product 24 hours Level 2 datasets 99.95% Product 24 hours

GS oper. Availabilit y Accounting Unit Timeliness

Internet disseminated datasets 99% As per datasets 60 min after NRT disseminatio n

slide-17
SLIDE 17

EUM/MTG/VWG/13/715994 25 July 2013

MTG GS – Constraint & Main Design Drivers

Mission Data Processing Throughput

  • Real-Time processing:

1 x NRT

  • Fast Scientific Validation: 5 x NRT
  • Re-Processing 30 x NRT

Comparison

  • MSG science data downlink

~3 Mbps

  • MTG science data downlink

~600 Mbps (2 MTG-I+1 MTG-S) Payload Data Encryption

  • Decryption unit must operate at speed around 170 Mbps

(approximate IRS data rate)

slide-18
SLIDE 18

EUM/MTG/VWG/13/715994 25 July 2013

Data-Rates for Downlink and Dissemination in Comparison with MSG and MTP

Slide: 18 Nominal = 2 MTG-I + 1 MTG-S * Data-rates are estimated based on current satellite design and dissemination assumptions

slide-19
SLIDE 19

EUM/MTG/VWG/13/715994 25 July 2013

Number of CPU Cores per Instruments Level-1 and Comparison with Level-2

Slide: 19 * Numbers are estimated based on current assumptions and results of the Phase B Study. SpecFp_rate2006 = 160

slide-20
SLIDE 20

EUM/MTG/VWG/13/715994 25 July 2013

Number of CPU Cores per In-orbit Configuration Level-1 only

Slide: 20 Nominal = 2 MTG-I + 1 MTG-S * Numbers are estimated based on current assumptions and results of the Phase B Study. SpecFp_rate2006 = 160

slide-21
SLIDE 21

EUM/MTG/VWG/13/715994 25 July 2013

Daily Circulating Data Volume per Instrument (Level-1 only)

Slide: 21 * Numbers are estimated based on current assumptions and include all on-line environments

slide-22
SLIDE 22

EUM/MTG/VWG/13/715994 25 July 2013

Status of Facility Procurements

Slide: 22

slide-23
SLIDE 23

EUM/MTG/VWG/13/715994 25 July 2013

Status of Ground Segment Facility Procurements

Slide: 23

Instrument Data Processing Facility (IDPF) support for MTG-I (FCI + LI) + framework Final stage of direct negotiation with Space Segment Prime Contractor. Kick-off foreseen in October 2013 Instrument Data Processing Facility (IDPF) support for MTG-S (IRS + UVN) Specifications are being prepared. Procurement will be initiated in later stage. Level-2 Processing Facility (L2PF) Likely to be split between Imager (FCI+LI) and Sounder (IRS). Procurement will be initiated in later stage. Mission Operation Facility (MOF) Contractor has been selected. Kick-off foreseen in the coming months after contract signature. Ground Stations Facilities (MDAF & TTCF) Offers from Industry are currently under evaluations. Multi-Mission Elements (MMEs) Specifications are ready. Preliminary Design Review is planned for September

  • 2014. This is likely to be a EUMETSAT internal activity
slide-24
SLIDE 24

EUM/MTG/VWG/13/715994 25 July 2013

Thank you for your attention

Slide: 24 High-level Introduction to MTG Ground Segment

Workshop on NWC Applications using MTG-IRS Fausto Roveda MTG Data Processing System Facility Manager fausto.roveda@eumetsat.int
