HEILMAN DINING CENTER Addition Presented by: Trey McDonald, LEED AP Charles Tilley, AIA, REFP, LEED AP Sustainability Coordinator BCWH Architects, Associate University of Richmond ctilley@bcwh.com tmcdonald@richmond.edu Campus Sustainability

slide-1
SLIDE 1

HEILMAN DINING CENTER

Addition

slide-2
SLIDE 2

Presented by: Charles Tilley, AIA, REFP, LEEDAP BCWH Architects, Associate ctilley@bcwh.com Trey McDonald, LEEDAP Sustainability Coordinator University of Richmond tmcdonald@richmond.edu

slide-3
SLIDE 3

Campus Sustainability Overview Heilman Dining Center Addition

LEED Features

slide-4
SLIDE 4
  • Signed ACUPCC and Talloires Declaration
  • Climate Action Plan - draft completion
  • Environmental Awareness Week: 10/26 – 10/30
  • Dorm energy conservation competition
  • Waste audits
  • Recycling
  • Diverted 35.6% of waste in 2008-09
  • Hired first recycling intern this semester
  • RecycleMania participant
  • Began “Green Bikes” program in Fall
  • LEED
  • Weinstein Hall - 2nd LEED building in VA
  • PCC - All new construction must meet LEED Silver
  • 2 certified, 7 pending
  • Integral part of UR’s commitment Signed the Presidents Climate

Commitment and the Talloires Declaration

UR’s COMMITMENT TO SUSTAINABILITY

slide-5
SLIDE 5

UR SUSTAINABILITY MAP

slide-6
SLIDE 6

HEILMAN DINING CENTER ADDITION

slide-7
SLIDE 7
slide-8
SLIDE 8
slide-9
SLIDE 9
slide-10
SLIDE 10

NORTH VIEW

slide-11
SLIDE 11

EXISTING MAIN LEVEL PLAN

SERVERY KITCHEN DINING LOBBY RETAIL

slide-12
SLIDE 12

MAIN LEVEL PLAN

slide-13
SLIDE 13

Offices Offices Post Office Roof Area

NEW MEZZANINE LEVEL PLAN

slide-14
SLIDE 14

BEFORE

slide-15
SLIDE 15

BEFORE

slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32

LEED SITE BORDER

slide-33
SLIDE 33

LEED BUILDING

slide-34
SLIDE 34
  • Smoke free environment
  • Recycling
  • Paper, aluminum, etc
  • Used cooking oil
  • E & S Plan
  • Fundamental Commissioning
  • Minimum Energy Performance
  • Refrigerant Management
  • Minimum IAQ

LEED – Prerequisites

slide-35
SLIDE 35
slide-36
SLIDE 36
  • Lake serves as BMP
  • preserved open space
  • community connectivity
  • parking capacity

LEED – Sustainable Sites

slide-37
SLIDE 37
  • Community Connectivity

LEED – Sustainable Sites

slide-38
SLIDE 38
  • Preferred parking
  • High Occupancy - Vanpool
  • Low Emissions

LEED – Sustainable Sites

slide-39
SLIDE 39

LEED – Water Efficiency

  • No irrigation
  • All native or adaptive species
  • Non-invasive
slide-40
SLIDE 40

LEED – Water Efficiency

  • water conserving fixtures – aerators, dual flush and

waterless fixtures

slide-41
SLIDE 41

LEED – Water Efficiency

  • Process water for equipment
  • ice makers air cooled – not water cooled
slide-42
SLIDE 42

LEED – Water Efficiency

  • Process water for equipment
  • Combi-steamer intelligent technology
  • Includes software to alert staff for cleaning
  • savings of 15% over traditional units
slide-43
SLIDE 43

LEED – Water Efficiency

  • Process water for equipment
  • Dishwashing – water saving
  • Steam operated booster heat
slide-44
SLIDE 44

LEED – Water Efficiency

  • Process water for equipment
  • Pulper system – reduces waste and recycles water
slide-45
SLIDE 45

LEED – Energy and Atmosphere

  • Fundamental Commissioning
  • All new and replacement equipment contains CFC free

refrigerant

  • Energy efficient cooking equipment
  • Low voltage lighting and compact fluorescent lighting
slide-46
SLIDE 46

LEED – Energy and Atmosphere

  • Refrigeration
  • For food service – accounts for 5% of energy costs
  • CFC Free refrigerants
  • Electronic / remote controls and off site monitoring
  • 4” thick insulated walls meet 2009 energy standards
slide-47
SLIDE 47

LEED – Energy and Atmosphere

  • Cooking Hood Operations
  • Hoods located against walls – shielding
  • Every hood has this system
  • Sensors control roof top fans by

monitoring heat and smoke vapor

  • Fully automatic – fans run 25%

speed to start

  • Payback estimated at 2 – 3 years
slide-48
SLIDE 48

LEED – Materials and Resources

  • 79% of ALL project waste diverted
  • 800 Tons generated
  • 638 Tons diverted
  • 42% of all materials used were from

Regional Sources

  • Lyptus Veneer Plywood
  • Refurbished or donated existing

cooking equipment

slide-49
SLIDE 49

LEED – Innovation in Design

  • Environmental Studies & LEED Education
  • Part of the “The Built Environment and Creating a Sustainable World” course
  • LEED Informational Poster
  • Campus “Green” Tour
  • Integrated Pest Management
  • Exemplary Performance – Maximize Open Space
  • More than doubled the open space requirement
  • Protected land adjacent to HDC along the Lake
  • Exemplary Performance – Regional Materials
  • 42% of building materials were harvested & manufactured within 500 miles
  • Steel, CMU, Brick, Concrete, Ceiling Tiles
slide-50
SLIDE 50
  • Informational and

Educational Poster

  • Highlights
  • General Benefits of

green building

  • LEED overview
  • Specific building

features

  • To be part of a

campus ‘green’ tour

LEED – Education

slide-51
SLIDE 51

UR SUSTAINABILITY MAP

slide-52
SLIDE 52

Sustainable Dining Services Initiatives

LOCALLY GROWN AND PRODUCED FOOD

  • Locally Grown Food (within 150 miles)
  • Locally Processed Food (within 150 miles)

ORGANIC AND SUSTAINABLY PRODUCED FOOD

  • Antibiotics and Hormone Free Dairy Products
  • Organically Grown Products

DISHWARE AND ECO-FRIENDLY INCENTIVES

  • Reusable and Disposable Dishware
  • Trayless Program
  • Lug-a-Mug Program

FOOD COMPOSTING AND WASTE DIVERSION

  • Utilize pulper to minimize waste
  • Excess food donated to food bank
  • Monthly waste audits
  • Recycling oil and protein products for biodiesel

http://dining.richmond.edu.

slide-53
SLIDE 53

LOCALLY GROWN AND PRODUCED FOOD

  • Locally Grown Food (within 150 miles)
  • Locally Processed Food (within 150 miles)

ORGANIC AND SUSTAINABLY PRODUCED FOOD

  • Antibiotics and Hormone Free Dairy Products
  • Organically Grown Products

DISHWARE AND ECO-FRIENDLY INCENTIVES

  • Reusable and Disposable Dishware
  • Trayless Program
  • Lug-a-Mug Program

FOOD COMPOSTING AND WASTE DIVERSION

  • Utilize pulper to minimize waste
  • Excess food donated to food bank
  • Monthly waste audits
  • Recycling oil and protein products for biodiesel

http://dining.richmond.edu.

Sustainable Dining Services Initiatives

slide-54
SLIDE 54

LOCALLY GROWN AND PRODUCED FOOD

  • Locally Grown Food (within 150 miles)
  • Locally Processed Food (within 150 miles)

ORGANIC AND SUSTAINABLY PRODUCED FOOD

  • Antibiotics and Hormone Free Dairy Products
  • Organically Grown Products

DISHWARE AND ECO-FRIENDLY INCENTIVES

  • Reusable and Disposable Dishware
  • Trayless Program
  • Lug-a-Mug Program

FOOD COMPOSTING AND WASTE DIVERSION

  • Utilize pulper to minimize waste
  • Excess food donated to food bank
  • Monthly waste audits
  • Recycling oil and protein products for biodiesel

http://dining.richmond.edu.

Sustainable Dining Services Initiatives

slide-55
SLIDE 55

LOCALLY GROWN AND PRODUCED FOOD

  • Locally Grown Food (within 150 miles)
  • Locally Processed Food (within 150 miles)

ORGANIC AND SUSTAINABLY PRODUCED FOOD

  • Antibiotics and Hormone Free Dairy Products
  • Organically Grown Products

DISHWARE AND ECO-FRIENDLY INCENTIVES

  • Reusable and Disposable Dishware
  • Trayless Program
  • Lug-a-Mug Program

FOOD COMPOSTING AND WASTE DIVERSION

  • Utilize pulper to minimize waste
  • Excess food donated to food bank
  • Monthly waste audits
  • Recycling oil and protein products for biodiesel

http://dining.richmond.edu.

Sustainable Dining Services Initiatives

slide-56
SLIDE 56

Many more resources available now for energy efficient kitchen equipment and water conservation

Innovation Credits Change overtime

Process – develop a consistent process for projects over time

Lessons Learned

slide-57
SLIDE 57

LEED – Kitchen Equipment Resources

  • Consortium for Energy Efficiency
  • Food Service Technology Center
  • Energy Star
slide-58
SLIDE 58
  • 2009 LEED for Retail NC – Prescriptive Path

LEED – Kitchen Equipment Resources

Base Line Model

  • Efficiency
  • Water usage
  • Listing Agencies
slide-59
SLIDE 59

LEED – Sustainable Kitchen Equipment

  • New List for energy modeling including kitchen equipment

LEED Goals for Prescriptive Path

  • Minimum efficiency
  • Water usage
  • Listing Agencies
slide-60
SLIDE 60

LEED – Sustainable Kitchen Equipment

  • New List for energy modeling including kitchen equipment

Energy Star

  • Current Energy Star

acceptance

slide-61
SLIDE 61

Questions ????

slide-62
SLIDE 62

Thank You

Charles Tilley, AIA, REFP, LEEDAP BCWH Architects, Associate ctilley@bcwh.com Trey McDonald, LEEDAP Sustainability Coordinator University of Richmond tmcdonald@richmond.edu
